Bartec Pegasus 7100 User manual

PEGASUS
User Manual
PEGASUS 71xx Series
English

User manual
PEGASUS Type 71xx series
PEGASUS 7100 Type G7-C011-*Q*1/0000
PEGASUS 7110ex Type 17-C111-*Q*1/0000
PEGASUS 7120ex Type B7-C211-*Q*1/0000
Document no. 11-C111-7D0001
Version: 05.09.2011
Reservation: Technical data subject to change without notice. Changes, errors and
misprints may not be used as a basis for any claim for damages.
English
Contents
Page
1 - 47
Appendix
Declaration of Conformity
Service address:
GmbH
Max-Eyth-Straße 16
Phone: [phone]
[email protected]
97980 Bad Mergentheim
Fax: [phone]
www.bartec.de
Germany

Safety Instructions
PEGASUS 71xx series
Technical data subject to change without notice.
09-2011
Notes on this manual
The user manual is a constituent part of the product and must be kept in the direct vicinity
of the device and accessible at all times to installation, operating and maintenance
personnel.
It contains important notes, safety instructions and test certificates which are necessary
for perfect functioning when the devices are being operated and handled. It is written for
technically qualified personnel.
Familiarity with and the technically perfect implementation of the safety instructions and
warnings described in this manual are preconditions for safe installation and
commissioning. The safety notes and warnings given in this documentation are given in a
general way and only qualified personnel will have the necessary specialized know-how
to interpret and implement them correctly in specific cases.
Qualifications of the personnel working with the devices
The user manual is written for all people who carry out assembly, installation,
commissioning and service work on the product, whereby the directives and standards
must be observed.
For Europe: 99/92/EC, EN 60079-17, EN 60079-19 for the gas
area EN 61241-17 and EN 61241-19 for the dust area
For North America: NEC 500.
For other countries or regions: National directives and standards must
be observed.
Changes to the document
BARTEC reserves the right to alter the contents of this document without notice. No
guarantee is given for the correctness of the information. In case of doubt the German
safety instructions shall apply because it is not possible to rule out errors in translation or
in printing. In the event of a legal dispute, the “General Terms and Conditions” of the
BARTEC group shall apply in addition.
The respective up-to-date versions of data sheets, manuals, certificates, EC Declaration
of Conformity may be downloaded from the “Ex Visualization and Communication
Systems” product page at www.bartec-group.com or ordered directly from BARTEC
GmbH.
Languages
Note
The original user manual were written in German. All other available languages are
translations of the original operating instructions.
The operating instructions are available in various languages. They are enclosed with the
product in the languages German, English, French, Italian, Spanish, Czech, Swedish and
Dutch.
If you require any other languages, please ask BARTEC or request them when placing
the order.
Read carefully
before putting the
devices into
operation.

PEGASUS 71xx series
Safety Instructions
Technical data subject to change without notice.
09-2011
Handing the Product
The documents are currently available in German and English.
The product described in this manual has been tested and left the factory in perfect
condition as regards meeting safety requirements.
To maintain this condition and ensure that this product operates perfectly and safely, it
may be used only in the manner described by the manufacturer. Appropriate
transportation, suitable storage and careful operation are also essential for the perfect
and safe operation of this product.
Safety Instructions
Safety instructions and warnings are specially highlighted in this manual and marked by
symbols.
The safety instructions and warnings are assigned to the individual work steps. Careful
handling and consistent observation of the instructions will prevent accidents, personal
injuries and damage to property.
The adherence to all directions and safety instructions in this manual is a precondition for
safe working and the correct handling of the device.
The graphic representations in these instructions serve to show the information being
described and are not necessarily true to scale and they may deviate slightly from the
actual construction of the device.
Marking
Particularly important points in these instructions are marked with a symbol:
Danger!
Non-observance leads to death or serious physical injury.
The necessary safety measures must be taken.
Caution!
Warning of damage to property and financial and penal disadvantages
(e.g. loss of guarantee rights, liability etc.).
Attention!
Important instructions and information on preventing disadvantageous behavior.
Note
Important instructions and information on effective, economical
and environmentally compatible handling.
Read carefully
before putting
the devices into
operation.

Contents
PEGASUS 71xx series
Technical data subject to change without notice.
09-2011
1Product Description................................................................................................................1
1.1 Definition ........................................................................................................................1
1.2 Use for the Intended Purpose ........................................................................................2
2Technical Data PEGASUS 71xx series ..................................................................................3
2.1 Specification PEGASUS 7100, type G7-C011-*Q*1/0000..............................................3
2.1.1 Marking ............................................................................................................3
2.1.2 Technical data..................................................................................................3
2.2 Specification PEGASUS 7110ex, type 17-C111-*Q*1/0000............................................4
2.2.1 Ex protection marking ......................................................................................4
2.2.2 Technical data..................................................................................................4
2.3 Specification PEGASUS 7120ex, type B7-C211-*Q*1/0000............................................5
2.3.1 Ex protection marking ......................................................................................5
2.3.2 Technical data..................................................................................................5
2.4 Product Marking.............................................................................................................6
3Safety and Security.................................................................................................................7
3.1 Notes of Handling...........................................................................................................7
3.2 Accessories Safety.........................................................................................................8
3.3 Battery Safety.................................................................................................................8
3.4 Exposure to RF energy ..................................................................................................9
3.5 Driving............................................................................................................................9
3.6 Electronic devices ..........................................................................................................9
3.7 Vehicle electronic equipment .........................................................................................9
3.8 Medical electronic equipment.........................................................................................9
3.9 Aircraft..........................................................................................................................10
3.10 Blasting areas ..............................................................................................................10
3.11 Potentially explosive atmospheres...............................................................................10
3.12 Safety Standards..........................................................................................................10
3.13 RF Exposures ..............................................................................................................10
3.14 Statement of the UL .....................................................................................................11
4Commissioning .....................................................................................................................12
4.1 Scope of delivery..........................................................................................................12
4.2 Functional Parts of the device......................................................................................13
4.3 Fastening and Changing the Belt Clip..........................................................................15
4.4 Inserting and Changing the Battery..............................................................................16
4.5 Charging the Battery ....................................................................................................17
4.5.1 Stand-by time.................................................................................................18
4.5.2 Talk time.........................................................................................................18
4.5.3 Charging time.................................................................................................18
4.6 Inserting the Micro SD-card..........................................................................................19
5Operation ...............................................................................................................................20
5.1 Getting started..............................................................................................................20
5.1.1 PIN number....................................................................................................20
5.1.2 Navigation Principle .......................................................................................21
5.1.3 General Settings ............................................................................................21
5.1.4 Ringtone.........................................................................................................21
5.1.5 Ringvolume ....................................................................................................22

PEGASUS 71xx series
Contents
Technical data subject to change without notice.
09-2011
5.1.6 Vibration.........................................................................................................22
5.1.7 Geofence........................................................................................................22
5.1.8 Tracking .........................................................................................................22
5.1.9 Man-Down......................................................................................................23
5.1.10 Lighting (keypad)............................................................................................24
5.1.11 Language .......................................................................................................24
5.1.12 Save PIN (SIM card) ......................................................................................24
5.1.13 Setting Time Zone..........................................................................................24
5.1.14 Setting Time & Date.......................................................................................25
5.1.15 Device Info .....................................................................................................25
5.1.16 Key lock..........................................................................................................25
5.2 Phone settings .............................................................................................................26
5.2.1 Making a call ..................................................................................................26
5.2.2 Starting dialing from the start screen..............................................................26
5.2.3 Starting dialing from the "Select" menu..........................................................26
5.2.4 Dialing a number from "Phonebook" menu ....................................................27
5.2.5 Dialing a number from "SIM card" menu........................................................27
5.2.6 Call log ...........................................................................................................28
5.2.7 Own number...................................................................................................28
5.3 SMS (Short Message Service) Settings.......................................................................28
5.3.1 SMS Options..................................................................................................28
5.3.2 New message ................................................................................................28
5.3.3 Inbox ..............................................................................................................29
5.3.4 Outbox............................................................................................................30
5.3.5 Drafts..............................................................................................................30
5.4 Emergency Call Button ................................................................................................31
5.4.1 Operation .......................................................................................................31
5.5 Bluetooth......................................................................................................................32
5.5.1 General Points ...............................................................................................32
5.5.2 Activating the Bluetooth .................................................................................32
5.5.3 Pairing with a Device......................................................................................33
6Phonebook Software Installation.........................................................................................34
6.1 Requirements...............................................................................................................34
6.2 Installation....................................................................................................................34
6.3Connection to PEGASUS.............................................................................................36
6.4 Start Software ..............................................................................................................36
6.5 Menu Settings ..............................................................................................................37
6.6 Phonebook Menu.........................................................................................................39
6.7 Alarm Functions Menu .................................................................................................40
6.8 Provider Menu..............................................................................................................43
7Troubleshooting, Fault Elimination .....................................................................................44
8Order Numbers, Accessories...............................................................................................45
9Maintenance, Inspection, Repair..........................................................................................46
10 Disposal .................................................................................................................................47
11 Dispatch and Packaging Instructions .................................................................................47
Appendix Declaration of Conformity

PEGASUS 71xx series
Product Description
Technical data subject to change without notice.
09-2011
1/47
1Product Description
1.1 Definition
PEGASUS is the mobile phone/online tracking system for industry. It is perfect for
utilization in extreme conditions in the chemicals and pharmaceuticals industries and also
in the oil and gas industry.
PEGASUS 71xx series is available in different models and is the optimal mobile phone
for every region and every field of application:
PEGASUS 7100 Grey line (industrial version)
PEGASUS 7110ex Blue line (ATEX Zone 1 and 22, IECEx Zone 1;
UL Class I Division 1)
PEGASUS 7120ex Green line (ATEX Zone 2 and 22, IECEx Zone 2;
UL Class I Division 2)
Figure 1: PEGASUS 71xx series
Each model is available in four different versions:
PEGASUS 71xx-0 type *7-C*11-0Q01/0000
PEGASUS 71xx-1 type *7-C*11-0Q11/0000 with man-down
PEGASUS 71xx-2 type *7-C*11-1Q01/0000 with online tracking
PEGASUS 71xx-3 type *7-C*11-1Q11/0000 with online tracking/with man-down
User-friendly keyboard
The keyboard is generously dimensioned and offers enough space for steady operation,
even with gloves. To prevent operating errors, all keys give tactile feedback in the form of
a click.
Quad Band GSM Module
Thanks to the quad band GSM module (850/900/1800/1900 MHz), the mobile phone can
be used on almost all continents.

Product Description
PEGASUS 71xx series
2/47
Technical data subject to change without notice.
09-2011
Hands-free function
The integrated loudspeaker allows convenient hands-free operation and emits a vibration
alarm at the same time as the ring tone.
Professional Online Tracking System
GPS receivers and special software make PEGASUS an efficient online tracking system.
The "history" function provides a map showing movement along a route. This opens up
new possibilities for transporters of hazardous goods and other logistical tasks. You can
choose to store and evaluate the PEGASUS data on your own server or use the server
BARTEC has set up especially for it. Location inside buildings is possible only to a limited
degree.
Note
A licence agreement is required in order to use the BARTEC server.
Access is gained with the on-line tracking software.
Man-down function
PEGASUS is the perfect mobile phone for protecting individuals in extreme areas. The
fitted sensor (motion detection) reacts to the absence of movement and triggers an
emergency call after a defined period of time. A text message also transmits the last
registered GPS position data providing a GPS signal is available.
1.2 Use for the Intended Purpose
The PEGASUS 71xx series conforms to the latest technical developments and
recognised safety regulations. Nevertheless, its use can still cause danger to life and limb
of the user or damage the device and other property.
The PEGASUS 71xx series is available in three versions:
PEGASUS 7100 Type G7-C011-*Q*1/0000
was developed for use in non Ex areas.
PEGASUS 7110ex Type 17-C111-*Q*1/0000
was developed specially for use in hazardous areas in
ATEX Zone 1 and 22, IECEx Zone 1; UL Class I Division 1.
PEGASUS 7120ex Type B7-C211-*Q*1/0000
was developed specially for use in hazardous areas in
ATEX Zone 2 and 22; IECEx Zone 2; UL Class I Division 2.
The manufacturer will not be liable for any ensuing damage. The risk shall be borne by
the user alone. Use for the intended purpose requires also the observation of the
operating instructions. Only people who are familiar with the PEGASUS 71xx series and
instructed about the risks it poses may use it or do any maintenance work on it.

PEGASUS 71xx series
Technical Data
Technical data subject to change without notice.
09-2011
3/47
2Technical Data PEGASUS 71xx series
2.1 Specification PEGASUS 7100, type G7-C011-*Q*1/0000
2.1.1 Marking
Marking
R&TTE certificate
0681
Normen:
- EMV
- Radio
EN 60950-1:2006+A11:2009+A1:2010
EN 301 489 V1.3.1:2005
EN 301 489 V1.8.1:2005
EN 301 511 V9.0.2:2003
EN 300 440-2 V1.4.1:2011
FCC Part 15/Class B
2.1.2 Technical data
Display
OLED color display
Networks
Quad Band GSM 850/900/1800/1900 MHz
Dimensions (Height x Width x Depth)
155 mm x 59 mm x 27 mm
Weight
Approx. 240 g
Rating
IP 65
Ambient temperature
-20 °C to +60 °C
Storage and transport temperature
-20 °C to +60 °C
Charging temperature
0 °C to +50 °C
Air humidity
5 % up to 95 % (non-condensing)
GSM module
Telit GE864
Power supply
Lithium polymer battery 3,7 V/2650 mAh
Interfaces
Mini USB, Bluetooth
Audio system
Microphone and speaker integrated
Antennas
Integrated in the device
(GPS, GSM and Bluetooth)
Bluetooth
2.0 EDR
Audio Headset profile
SPP (serial protocol)
Figure 2: PEGASUS 7100

Technical Data
PEGASUS 71xx series
4/47
Technical data subject to change without notice.
09-2011
2.2 Specification PEGASUS 7110ex, type 17-C111-*Q*1/0000
2.2.1 Ex protection marking
ATEX marking for Zone 1
II 2G Ex ib IIC T4 0044
DEMKO 10 ATEX 0911055X
IECEx marking for Zone 1
Ex ib IIC T4 Gb
IECEx UL 10.0003X
Standards:
EN 60079-0:2009 IEC 60079-0:2007 Ed5
EN 60079-11:2007 IEC 60079-11:2006 Ed5
ATEX marking for Zone 22
II 3D Ex ic IIIC T130°C Dc X
Standards:
IEC 60079-0:2007 Ed5
IEC 60079-11:2011 Ed6
UL marking
Class I Division 1, Groups A-D, T4
E 321557
Standards:
UL 913 Ed7
R&TTE certificate
0681
Standards:
- EMC
- Radio
EN 60950-1:2006+A11:2009+A1:2010
EN 301 489 V1.3.1:2005
EN 301 489 V1.8.1:2005
EN 301 511 V9.0.2:2003
EN 300 440-2 V1.4.1:2011
FCC Part 15/Class B
Directives
94/9/EG 2004/108 EG 1999/5/EG
2.2.2 Technical data
Display
OLED color display
Networks
Quad Band GSM 850/900/1800/1900 MHz
Dimensions (Height x Width x
Depth)
155 mm x 59 mm x 27 mm
Weight
Approx. 240 g
Rating
IP 65
Ambient temperature
-20 °C to +60 °C
Storage and transport temperature
-20 °C to +60 °C
Charging temperature
0 °C to +50 °C
Air humidity
5 % up to 95 % (non-condensing)
GSM module
Telit GE864
Power supply
Lithium polymer battery 3,7 V/2650 mAh
Interfaces
Mini USB, Bluetooth
Audio system
Microphone and speaker integrated
Antennas
Integrated in the device
(GPS, GSM and Bluetooth)
Bluetooth
2.0 EDR
Audio Headset profile
SPP (serial protocol)
Figure 3: PEGASUS 7110ex

PEGASUS 71xx series
Technical Data
Technical data subject to change without notice.
09-2011
5/47
2.3 Specification PEGASUS 7120ex, type B7-C211-*Q*1/0000
2.3.1 Ex protection marking
ATEX marking for Zone 2
II 3G Ex ic IIC T4
DEMKO 10 ATEX 147282X
IECEx marking for Zone 2
Ex ic IIC T4 Gc
IECEx UL 10.0004X
Standards:
EN 60079-0:2009 IEC 60079-0:2007 Ed5
EN 60079-11:2007 IEC 60079-11:2006 Ed5
ATEX marking for Zone 22
II 3D Ex ic IIIC T130°C Dc X
Standards:
IEC 60079-0:2007 Ed5
IEC 60079-11:2011 Ed6
UL marking
Class I Divison 2, Groups A-D, T4
E 321557
Standards:
UL 913 Ed7
R&TTE certificate
0681
Standards:
- EMC
- Radio
EN 60950-1:2006+A11:2009+A1:2010
EN 301 489 V1.3.1:2005
EN 301 489 V1.8.1:2005
EN 301 511 V9.0.2:2003
EN 300 440-2 V1.4.1:2011
FCC Part 15/Class B
Richtlinien
94/9/EG 2004/108 EG 1999/5/EG
2.3.2 Technical data
Display
OLED color display
Networks
Quad Band GSM 850/900/1800/1900 MHz
Dimensions (Height x Width x Depth)
155 mm x 59 mm x 27 mm
Weight
Approx. 240 g
Rating
IP 65
Ambient temperature
-20 °C to +60 °C
Storage and transport temperature
-20 °C to +60 °C
Charging temperature
0 °C to +50 °C
Air humidity
5 % up to 95 % (non-condensing)
GSM module
Telit GE864
Power supply
Lithium polymer battery 3,7 V/2650 mAh
Interfaces
Mini USB, Bluetooth
Audio system
Microphone and speaker integrated
Antennas
Integrated in the device
(GPS, GSM and Bluetooth)
Bluetooth
2.0 EDR
Audio Headset profile
SPP (serial protocol)
Figure 4: PEGASUS 7210ex

Technical Data
PEGASUS 71xx series
6/47
Technical data subject to change without notice.
09-2011
2.4 Product Marking
g
Ex Logo
Only printed on the
displayed Ex versions
of the PEGASUS 71xx
series.
PEGASUS 7110ex
PEGASUS 7120ex
Differentiation of colors
PEGASUS 7100
with grey display
border
PEGASUS 7110ex
with blue display
border
PEGASUS 7120ex
with green display
border
Type label
e. g.

PEGASUS 71xx series
Safety and Security
Technical data subject to change without notice.
09-2011
7/47
3Safety and Security
Note
This chapter contains important information on the safe and reliable use of the
PEGASUS 71xx series device. Please read this chapter carefully before use!
3.1 Notes of Handling
The device is factory-sealed. Do not open it!
The device may be opened in the factory only!
Exception: Battery cover and interface cup for Micro SD card, SIM card,
Hard shutdown and Mini USB interface.
Danger!
Protect the device from impact effects! Do not expose the equipment to corrosive/
aggressive liquids, vapors or mist! Take the equipment out of the hazardous area
immediately if it malfunctions or if the enclosure is damaged and bring it into the safe
area to put it out of operation!
Caution!
-Do not open, charge and change the devices and do not exchange any data in the
hazardous area!
-The device must be protected from shock effects.
-The user may not make any alterations to the device. Do not exchange or replace
components and do not retrofit any components on internal plug connectors or slots.
If components other than those specified are used, the protection against
explosions can no longer be assured.
Exception: SIM card, Micro SD card and battery cover (see chapter 4).
-Remove the display protection of the PEGASUS before use in hazardous location.
-Take the device out of the hazardous areas before wiping it with a dry cloth or
cleaning it!
-Avoid the influence of heat that is higher or lower than the specified temperature
range.
-General statutory regulations or directives on safety at work, accident prevention
regulations and environmental protection legislation must be complied with, e.g.
Ordinance on industrial health and safety (BetrSichV) or the national ordinances.

Safety and Security
PEGASUS 71xx series
8/47
Technical data subject to change without notice.
09-2011
3.2 Accessories Safety
Danger!
Only accessories approved by BARTEC may be used for charging and data
communication.
17-C1Z0-0010 Lithium polymer battery 3,7 V / 2650 mAh
for 17-C111-…. and B7-C211-….
G7-C0Z0-0002 Lithium polymer battery 3,7 V / 2650 mAh
for G7-C011-….
17-C1Z0-0002 Charging cable
17-C1Z0-0003 USB data cable
17-C1Z0-0004 Leather holster
17-C1Z0-0005 Desktop charger
17-C1Z0-0006 Car mount with battery charger
17-C1Z0-0007 Micro SD card with 1 GB
17-C1Z0-0008 Micro SD card with 2 GB
The use of imitation accessories or accessories from other manufacturers will render the
type of ignition protection ineffective and there will be a risk of fire or explosion.
3.3 Battery Safety
Danger!
-The battery may be charged and replaced only in areas known to be non-
hazardous and only by qualified personnel, who are authorised and have been
trained to assemble electrical components in hazardous (potentially explosive)
areas.
-For charging and communication, use only the BARTEC equipment specified in
the chapter 8.
-For operation, use only original batteries of the type 17-C1Z0-0010
and G7-C0Z0-0002 with 3.7 V/2650 mAh.
-The lithium-polymer battery assembly is not protected against mechanical
stress when outside the enclosure. Servicing and replacement of the battery
assembly must be done by a trained technician.
-Incorrect handling can cause the battery to become hot, burst or ignite and
cause serious injuries!
-The battery used in this device may present a risk of fire or explosion when
heated above 100 °C (212 °F) or incinerated.
-Do not disassemble the battery or throw it into a fire.
-Defective batteries must be disposed of immediately and in compliance with
the applicable regulations.
-Keep away from children!

PEGASUS 71xx series
Safety and Security
Technical data subject to change without notice.
09-2011
9/47
3.4 Exposure to RF energy
There has been some public concern about possible health effects of using a GSM
modem. Although research on health effects from RF energy has focused for many
years on the current RF technology, scientists have begun research on newer radio
technologies, such as GSM. After reviewing existing research and testing compliance
with all applicable safety standards, it has been concluded that the product is fit for use.
If you are concerned about exposure to RF energy, there are things you can do to
minimize exposure. Obviously, limiting the duration of your calls will reduce your
exposure to RF energy. In addition, you can reduce RF exposure by operating your
cellular modem efficiently by following the guidelines below.
3.5 Driving
Check the laws and regulations on the use of cellular devices in the area where you
drive. Always obey them. Also, when using your PEGASUS 71xx series while driving,
please pay full attention to driving, pull off the road and park before making or answering
a call if driving conditions so require. When applications are prepared for mobile use,
they should comply with road-safety rules under applicable laws!
3.6 Electronic devices
Most electronic equipment, for example in hospitals and motor vehicles is shielded from
RF energy. However, RF energy may have adverse affects on the functioning of
insufficiently shielded or defective electronic devices.
3.7 Vehicle electronic equipment
Check with your vehicle manufacturer’s representative to determine if all on-board
electronic equipment is adequately shielded from RF energy.
3.8 Medical electronic equipment
Consult the manufacturer of any personal medical devices (such as pacemakers,
hearing aids, etc.) to determine if they are adequately shielded from external RF energy.
Turn your PEGASUS 71xx series device OFF in health care facilities when any
regulations posted in the area instruct you to do so. Hospitals or health care facilities
may be using RF monitoring equipment

Safety and Security
PEGASUS 71xx series
10/47
Technical data subject to change without notice.
09-2011
3.9 Aircraft
Turn your PEGASUS 71xx series OFF before boarding any aircraft. Use it on the ground
only with crew permission. Do not use it in the air. To prevent possible interference with
aircraft systems, Federal Aviation Administration (FAA) regulations require you to have
permission from a crewmember to use your modem while the plane is on the ground. To
prevent interference with cellular systems, local RF regulations prohibit the use of your
modem whilst airborne.
3.10 Blasting areas
To avoid interfering with blasting operations, turn your device OFF when in a “blasting
area” or in areas posted: “turn off two-way radio”. Construction crews often use remote
control RF devices to set off explosives.
3.11 Potentially explosive atmospheres
Turn your PEGASUS 7000 series device OFF when in any area with a potentially
explosive atmosphere.
PEGASUS 7100 is intended for use in industrial environment
PEGASUS 7110ex is intended for use in hazardous locations
(ATEX Zone 1 and 22; IECEx Zone 1; Class I Division 1)
PEGASUS 7120ex is intended for use in hazardous locations
(ATEX Zone 2 and 22; IECEx Zone 2; Class I Division 2)
3.12 Safety Standards
Your GSM/GPRS/GPS device complies with all applicable RF safety standards.
PEGASUS 71xx series meets the safety standards for RF receivers and the standards
and recommendations for the protection of public exposure to RF electromagnetic
energy established by government bodies and professional organizations, such as
directives of the European Community, Directorate General V in matters of radio
frequency electromagnetic energy.
3.13 RF Exposures
This device contains 850/900/1800/1900 MHz GSM/GPRS functions that are operational
in these frequencies respectively. The PEGASUS 71xx series device contains 1800 MHz
GSM functions that are not operational (must not be used) in U.S. Territories.

PEGASUS 71xx series
Safety and Security
Technical data subject to change without notice.
09-2011
11/47
Filing is only applicable for 850MHz GSM/1900 MHz PCS operations, whereby only
these frequencies (850 MHz GSM/1900 MHz PCS) may be used in U.S. Territories.
Statement according to FCC part 15.19:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
this device may not cause harmful interference, and
this device must accept any interference received, including interference that may
cause undesired operation.
Statement according to FCC part 15.21:
Modifications not expressly approved by this company could void the user's authority to
operate the equipment.
Statement according to FCC part 15.105:
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the distance between the equipment and receiver.
Plug the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
3.14 Statement of the UL
The statement “Underwriters Laboratories Inc. (UL) has not tested the performance or
reliability of the Global Positioning System (GPS) hardware, GPS operating software or
other GPS-related aspects of this product. UL has only tested for the explosion, fire,
shock and casualty hazards required by the applicable hazardous locations standards.
UL certification does not cover the performance or reliability of the GPS hardware, GPS
operating software or other GPS-related aspects of this product. UL MAKES NO
REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER
REGARDING THE PERFORMANCE OR RELIABILITY OF ANY GPS RELATED
FUNCTIONS OF THIS PRODUCT.”

Commissioning
PEGASUS 71xx series
12/47
Technical data subject to change without notice.
09-2011
4Commissioning
4.1 Scope of delivery
Before commissioning the devices, check that all components and documents are there:
PEGASUS 71xx Mobile Phone
Lithium Polymer Battery
Charger cable with four different adapters
Adapters for Europe, Great Britain, the USA and Australia.
USB-data cable
Torx nut driver
CD-ROM
(User manual, phonebook software, USB driver)
Safety instructions
