Bass Slammer FMUST05D12U User manual

Enclosure Volume: 1.2 Cubic Foot
READ ALL DIRECTIONS CAREFULLY BEFORE BEGINNING
MOUNTING LOCATION: The enclosure mounts in the trunk of the Mustang Coupe and Convertible on the rear passengers’
side.
TOOLS FOR INSTALLATION:
Powered Screwdriver #2 Phillips Head Bit
6” Bit Holder Extension Wire Cutters
INSTALLATION: Follow the steps below
1. Place enclosure in passengers’ side of cargo area.
2. Make note of the terminal location and then move enclosure aside to route wires to that location.
3. Connect speaker wires from amplifier to enclosure, positive to red terminal and negative to black terminal.
4. Fold the corner of the floor mat back under itself, as shown below.
5. Place enclosure into corner of trunk with its front edge over the folded section of floor mat. Make sure the enclosure is
pressed firmly against the side walls of the trunk liner and tail light.
FMUST05D12U

6. With supplied hardware, secure the enclosure to the floor.
As always, before screwing or drilling check to make sure you will not damage any wires, hoses or cause dam-
age to the vehicle.
7. Place gasket provided around woofer hole cutout. Connect black wire to the negative side of woofer and red to the posi-
tive side. Using screws provided install woofer into enclosure, making sure not to overtighten screw to avoid stripping.
8. Using the supplied screws, attach the included speaker grill to prevent damage from cargo.
FACTORY SPEAKER WIRE COLORS
Once the rear seat is pulled out, you will see the two main wire harnesss wrapped in black tape. Speaker wires are located
on the respective sides and are twisted together in these harnesses. Wire colors for the left rear speakers are: Tan/Yellow
(positive) and Grey/Light Blue (negative). Right rear speaker wire colors are: Orange/Red (positive) and Brown/Pink
(negative). Tap into wires with the supplied RCA High Level input wires and route into the trunk, behind trunk liner and to
pre-amp of enclosure.
Although every effort has been made to assure proper wiring color, Mitek is not responsible for any changes made by the
vehicle manufacturer which sometime occur. If wiring colors do not match then physical verification is required. These in-
structions are guidelines only and in no way are intended to replace a professional installation. As always before screwing
and drilling check to make sure you will not damage wires, hoses or cause damage to the vehicle.
MAXIMUM ENCLOSURE MOUNTING SPECIFICATIONS
13“
3/4“
3“
11 1/16“
4 7/16“
8 11/16“
10 13/16“
One Mitek Plaza Winslow, IL 61089 BassSlammer.com 1-800-225-5689
21A8248

Mitek Mobile Limited Warranty
Our Guarantee
Mitek Mobile products (including MTX, Streetwires, Coustic and Magnum) purchased in the USA after
1/1/2013 from an authorized Mitek retailer are guaranteed to be free from material defects in products
and workmanship for five (5) years to the original end user purchaser, subject to the terms and conditions
below.
Length of Limited Warranty and Remedy
The warranty period begins the day the product is purchased by the end user, and is limited to the original
retail purchaser of the product.
Free Replacement Period (2 Years)
Products found to be defective in materials or workmanship during the first 2 years will be, at Mitek's
option, repaired or replaced by Mitek at no charge. When a product is replaced during first 2 years, the
warranty does not renew, it continues on from the original date of purchase.
Proration Period (Years 3-5)
The prorated purchase price of any product which becomes defective after the first two years and prior to
the end of the warranty period may be credited toward the purchase of a new Mitek product. The amount
of the proration shall be determined by dividing the purchase price by the number of months of the
warranty period (60), and then multiplying the result by the number of months remaining in the warranty
period. Any partial months will be rounded to the nearest whole month. For example, a product purchased
37 months ago for $100 would be calculated by dividing $100 by 60 months = $1.66/month, multiplied by
23 (the months remaining in the warranty period) for a prorated warranty amount of $38.33.
You are responsible for all costs for removal, reinstallation and proper packaging, shipping, insurance or
other freight charges incurred in the shipment of the product or part to Mitek. Mitek will ship the repaired
or replaced Mitek product or replacement parts to you at no charge. Mitek reserves the right to utilize
reconditioned, refurbished, repaired or remanufactured products or parts in the warranty repair or
replacement process. Such products and parts will be comparable in function and performance to an
original product or part and warranted for the remainder of the original warranty period.
What Is Not Covered
This warranty does not cover the product if it has been subject to neglect, abuse, misuse, incorrect
connection, or if it has been subject to unauthorized repair or alterations of any nature, or if the serial
number has been altered or removed, and the warranty does not extend to cosmetics or finish. This
warranty only applies to products installed and used in the USA.
What You Must Do to Obtain Warranty Service
You must contact Mitek Warranty via our website at MTX.com, or via email at
[e-mail], or by calling 800-556-2888. If you did not purchase the product directly from
Mitek, a proof of purchase must be provided in order to receive warranty consideration. You will be issued
a Return Authorization (RA) number which must be written on the outside of the package before returning
the product to Mitek.

No Other Warranties
THE LIMITED WARRANTIES DESCRIBED ABOVE ARE EXCLUSIVE AND IN LIEU OF ANY OTHER
WARRANTIES, EXPRESS OR IMPLIED. MITEK DISCLAIMS AND EXCLUDES ALL OTHER EXPRESS
WARRANTIES, AND DISCLAIMS AND EXCLUDES ALL WARRANTIES IMPLIED BY LAW, INCLUDING
WITHOUT LIMITATION THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. TO THE EXTENT THAT APPLICABLE LAW PROHIBITS THE EXCLUSION OF IMPLIED
WARRANTIES, THE DURATION OF ANY APPLICABLE IMPLIED WARRANTY IS LIMITED TO THE
PERIOD SPECIFIED FOR THE EXPRESS WARRANTY. Some states do not allow limitations on how
long an implied warranty lasts, so the above limitation may not apply to you. Any oral or written
description of any Mitek product is for the sole purpose of identifying it and shall not be construed as an
express warranty.
Limitation of Liability
MITEK'S OBLIGATION TO PROVIDE A CREDIT, OR REPAIR OR REPLACE AT MITEK'S OPTION,
SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY AND
MITEK'S SOLE AND EXCLUSIVE OBLIGATION. MITEK SHALL NOT BE LIABLE FOR INCIDENTAL,
INDIRECT, CONSEQUENTIAL OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH
THE MITEK PRODUCT, ITS USE OR PERFORMANCE. Incidental damages include, but are not limited
to, such damages as loss of time and loss of use. Consequential damages include, but are not limited to,
the cost of repairing or replacing other property which was damaged if the Mitek product does not work
properly.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state. This limited warranty supersedes all prior warranties
and is not transferable from the original consumer purchaser.
Any assistance Mitek provides to or procures for you outside the terms, limitations or exclusions of this
limited warranty will not constitute a waiver of such terms, limitations or exclusions, nor will such
assistance extend or revive the warranty. Mitek will not reimburse you for any expenses incurred by you
in repairing or replacing any defective product, except for those incurred with Mitek's prior written
permission.
