BCP SKY5506 User manual

SKY6743 + SKY6744 + SKY6745 + SKY6746 + SKY6747
SKY5506 + SKY5507 + SKY5508 + SKY5509 + SKY5510 + SKY5511
Ver. 4
INSTRUCTION
MANUAL
12V Ride-On with Remote

As shoppers, we’re always trying
to find the perfect balance between
quality & value. At BCP, we believe
we’ve achieved that. Our diverse
catalog of everyday essentials is
tailored especially to our customers
& guaranteed to hit that sweet
spot of high quality & low price.
Always.

bestchoiceproducts.com
Charge for 12 hrs
before initial use.
After initial charge,
follow the normal
recommended
charging time.

4 |
Please retain these instructions for future reference.
SAFETY
This vehicle must be assembled by an adult who has read and understood the instructions in this manual.
Keep the packaging and bags away from children and dispose of all packaging before use. Always use
common sense and safe practices when operating this vehicle. This product contains or emits chemicals
known in the state of California to cause cancer or birth defects or other reproductive harm.
NOTE: For best performance, only use this vehicle on flat and hard surfaces.
AGE RANGE: 3 to 8 years old
WEIGHT CAPACITY: 61 lbs.
The following safety hazards may result in serious injury or death:
• This product contains small parts. Keep children away during assembly. Make sure to remove all packaging
material and parts from underneath the vehicle body.
• Never open the battery. Batteries contain lead and lead compounds (acids) that are toxic and corrosive,
and known to the state of California to cause cancer and reproductive harm.
• Limbs, hair, and clothing can get caught in moving parts. Always wear shoes, keep limbs away from
moving parts, and do not wear loose clothing while operating this vehicle.
• This vehicle does not have brakes or braking capability. Do not leave a child unattended during operation.
Do not use this in a location that may require braking capability, as this could result in loss of control,
which may cause serious injury or death.
• Use of this vehicle near streets, motor vehicles, steps, bodies of water, sloped surfaces, hills, wet areas,
flammable vapors, in alleys, at night, or in the dark could result in an unexpected accident.
• Use of this vehicle in unsafe conditions such as snow, rain, loose dirt, mud, sand, or gravel may result in
an unexpected accident such as tipping over, and could damage the electrical system or battery.
• Do not operate this vehicle in an unsafe manner. Examples include but are not limited to:
- Pulling the vehicle with another vehicle or similar device
- Allowing more than one rider
- Pushing the user
- Traveling at an unsafe speed
BATTERY WARNINGS
The following safety hazards may result in serious injury or death:
• Use of a battery or charger other than the supplied rechargeable battery and charger may cause a fire
or explosion. Only use the supplied battery and charger.
• Use of the rechargeable battery and charger for any other product may result in overheating, fire,
or explosion. Never use the supplied rechargeable battery and charger with another product.
• Explosive gases are created during charging. Charge the battery in a well-ventilated area. Do not charge
the battery near heat or flammable materials.
• Contact between the positive and negative terminals may result in fire or explosion. Avoid direct contact
between the terminals. Picking up the battery by the wires or charger can cause damage to the battery
and may result in a fire. Always pick up the battery by its case or handles.
• Liquids on the battery may cause fire or electric shock. Always keep all liquids away from the battery and
keep the battery dry. Contact or exposure to battery leakage (lead acid) may cause serious injury.
If contact or exposure occurs immediately call your physician. If the chemical is on the skin or in the eyes,
flush with cool water for 15 minutes. If the chemical was swallowed, immediately give the person water
or milk. Do not give water or milk if the patient is vomiting or has a decreased level of alertness. Do not
induce vomiting.
• Battery posts, terminals, and related accessories contain lead and lead compounds (acid) – chemicals
known to the State of California to cause cancer, reproductive harm, and are toxic and corrosive.
Never open the battery.
• Tampering or modifying the electric circuit system may cause a shock, fire or explosion and permanently
damage the system. Exposed wiring and circuitry in the charger may cause electric shock. Always keep
the charger housing closed.

|5
SPECIFICATIONS
Weight
Weight Capacity
Age Range
Max Speed
Charging Time
Run Time
Battery Type
Electric Motor
Charger
Material
32 lbs.
61 lbs.
3 – 8 years old
2.8 mph.
8 – 12 hours
Initial Charge Time 12 hours
1 - 2 hours
12V 4.5AH
12V
Output: DC 12V
PP Plastic, Metal
• Never leave a child unattended.
• Always sit in the seat when using this vehicle.
• Keep your hands, hair, and clothes away from moving parts.
• Children under 3 years of age cannot use the vehicle.
• Only drive on level ground.
• Do not drive the vehicle into loose dirt, mud, sand, fine gravel, or on wet surfaces.
To reduce the risk of injury, adult supervision is required. Never use on roadways, near motor vehicles, on
or near steep inclines or steps, swimming pools or other bodies of water; always wear shoes, and never
allow more than one rider.
WARNING

61 LBS
CAPACITY
LBS
APPROXIMATELY
45 MIN.
ASSEMBLY
2 PERSON
ASSEMBLY
TOOLS REQUIRED
PARTS
PLASTIC
WRENCH
(2, PROVIDED)
1 PC
REAR AXLE
4 PCS 4 PCS
WHEEL
1 PC
WINDSHIELD
D
1 PC
FRONT AXLE
AB
F
E
1 PC
STEERING WHEEL
CAP
C
PHILLIPS
SCREWDRIVER
2 AAA BATTERIES
(FOR REMOTE)
+AAA -
HARDWARE
1
2 PC
SPRING M4 x 12mm
SCREW
2
4 PCS
6 |

J
2 PCS
1 PC
BACK FRAME
MREMOTE CONTROL
K
1 PC
BACK BAR L
2 PCS
FRAME LIGHT
N
1 PC
12 VOLT CHARGER
PARTS
1 PC
BACKREST
G
1 SET
SIDE MIRRORS (L/R) IH
1 PC
SEAT
|7

2
PRODUCT ASSEMBLY
1
Remove the nuts/washers from the part A rear axle. Slide the rear axle through the gearboxes.
Make sure rear axle is positioned evenly on each side.
Flip vehicle over and lay it on a level surface. Remove all parts and packaging from the vehicle
body. Lift the rear gearbox frame.
Remove two screws from the mounts, insert the gearbox frame into the mounts, then replace
the screws to attach the frame. Insert the gearboxes into their designated slots.
8 |
[2]
A

4
PRODUCT ASSEMBLY
3
Remove two nuts from the bottom of the part D front axle. Remove the nut on the steering column.
Insert the front axle and two part 1 springs into the front frame. Insert the steering column
into the designated hole on the front axle. Replace the nuts on the front axle/steering
column to secure it in place.
Slide a part B wheel onto the rear axle and secure it by replacing a nut/washer. Snap on a
part C cap. Repeat on the other side.
NOTE: Use two plastic wrenches (one on each side) and rotate in opposite directions
to tighten nuts.
B
Cx2 x2
|9
G
1
D
x2

6
PRODUCT ASSEMBLY
5
Flip the car onto its wheels. Join the connector from the part E steering wheel to the
connector from the steering mount.
Remove the nut and bolt from the steering wheel, slide it on the steering mount, and then
replace the nut and bolt to secure it.
Remove the nuts/washers from the part D front axle. Slide a part B wheel onto the front axle
and secure it by replacing a nut/washer. Snap on a part C cap. Repeat on the other side.
E
B
C
D
x2 x2
10 |

8
PRODUCT ASSEMBLY
7
Within the seat, insert the connector from the battery into the designated terminal
on the circuit board.
NOTE: Make sure the connector is oriented correctly to fit into the terminal.
Snap on the part F windshield and part G side mirror set.
|11
G
F

10
PRODUCT ASSEMBLY
9
Attach the part I backrest with two part 2 screws.
Attach the part H seat with two part 2 screws.
2
I
2
x2
H
x2
12 |

PRODUCT ASSEMBLY
11 Slide two part L frame lights onto the part K back bar. Slide the back bar into two part J back
frames.
Insert the back frame assembly into the rear of the car.
J
K
L
CHARGING INSTRUCTIONS AND WARNINGS
• Charging port is located below the seat. Insert one end of the charger into the charging port and
plug the other end into a wall outlet.
• Charge the battery 12 hours before initial use.
• On average, you will need to charge the battery between 8 and 12 hours. Do not charge the battery
for more than 20 hours. Failure to charge the battery as directed could cause permanent damage
to the battery and void the warranty.
• Damage to the battery may occur if it is allowed to drain completely. Do not allow the battery to
drain completely.
• Check the battery and charger (supply cord, connector) for wear and damage before charging.
Do not charge the battery if damage has occurred.
• Only an adult who has read and understood the safety warnings should handle, charge and
recharge the battery.
x2
x2
|13

CARING FOR YOUR RIDE-ON
• Park the vehicle indoors or cover it with a tarp to protect it from wet weather.
• Do not leave the vehicle in the sun for long periods of time or fading may occur. Store in shade or
cover with tarp.
• Do not wash the vehicle with a hose.
• Do not wash the vehicle with soap.
• Charge battery at least once a month to prolong the life of the battery.
DASHBOARD DIAGRAM
•Push down on the pedal to drive forward/reverse. Release the pedal to slow down and stop.
DASHBOARD
GOAHEAD
REVERSE
LIGHTS
POWER
IGNITION
SOUNDS FORWARD
REVERSE
HORN
MEDIA PLAYER
CHARGING PORT
HIGH/LOW
SPEED SWITCH
UNDER SEAT
High Speed/Low Speed:
Adjusts the speed of the
vehicle. Also aects the
reverse speed of the
vehicle.
HIGH SPEED
LOW SPEED
14 |

PLAY/PAUSE/SEEK
FORWARD/VOLUME+
BACK/VOLUME
MUSIC MODE
MEDIA PLAYER
BLUETOOTH
• Back/Volume-: Short press to play the previous song/radio station, long press to decrease volume
• Play/Pause/Seek: Play/pause music, seek radio stations
• Forward/Volume+: Short press to play the next song/radio station, long press to increase volume
• Mode: Press to toggle between music and FM radio
1. Place your desired audio device near the media player and power the car on.
2. Press Mode on the media player and wait until you hear “Bluetooth device is ready to pair.”
3. On your desire audio device, locate the Bluetooth setting and select the device named “Best Choice
Products Ride On.”
4. When the device says “Your Bluetooth device is connected successfully,” select the desired song.
|15
REMOTE CONTROL
•Remote control operation will OVERIDE manual operation; the pedal will not work when operating
the remote control.
•After a period of non-operation, the remote will go into power-saving mode.
Linking the remote control:
1. Turn the vehicle o.
2. Install 2 AAA batteries into the remote control and the indicator lights will flash.
3. Turn the vehicle on. The indicator lights will turn solid indicating a successful link.
4. If the indicator lights continue to flash (indicating an unsuccessful link), remove and reinsert
batteries and repeat steps 1 to 3.
FORWARD
PARK / STOP
SPEED SELECT
INDICATOR LIGHTS
REVERSE TURN LEFT
TURN RIGHT

TROUBLESHOOTING
REASON
Low battery
Electrical protection
Switch not in the correct position
Battery connectors disconnected
Low battery
Overloaded vehicle
Uneven or sloped road
Loose connection to motor
Battery connectors disconnected
Charger not connected
to socket or outlet
Battery does not have a full charge
Normal
PROBLEM
Battery is warm and
makes a slight noise
while charging
Slow speed
Vehicle is silent
Vehicles shakes
while driving
Battery does not last
Battery does not recharge
Vehicle does not move
SOLUTION
Fully charge the battery
Stop use for several minutes and restart
Completely press in switches
Plug in battery connectors
Fully charge the battery
Reduce the weight on the vehicle
Drive on flat pavement
Ensure the motor is properly
connected to the battery
Plug in battery connectors
Completely plug in the charger
Fully charge the battery
Normal
Diculty shifting between
forward/reverse Only shift when the vehicle is at a stop
Properly connect the steering
wheel connector
Attempting to shift while
vehicle in motion
Steering wheel is not
properly connected
16 |
WARNINGS REGARDING BATTERIES
•Do not mix alkaline, standard (carbon zinc) and rechargeable (nickel hydride) batteries.
•Do not mix old and new batteries.
•Non-rechargeable batteries should not be charged.
•Rechargeable batteries should be charged under adult supervision only.
•Exhausted batteries should be removed.
•The supply terminals should not be short-circuited.
•Do not put batteries next to or in a heat source (fire, electronic heating device, etc.).
•Do not hit batteries against hard objects.
•Do not submerge batteries in water.
•Batteries should be inserted with the correct polarity.
CALIFORNIA PROPOSITION 65
WARNING: Battery posts, terminals, and related accessories can expose you to chemicals including
lead and lead compounds, which are known to the State of California to cause cancer and birth defects or
other reproductive harm, and are toxic and corrosive. Wash hands after handling. For more information go
to www.P65Warnings.ca.gov

|17
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)
This product may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Any changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Responsible party (contact for FCC matters only):
Quality Control Dept.
15101 Red Hill Ave.
Tustin, CA 92780
FCC COMPLIANCE STATEMENT

Check out more great products:
bestchoiceproducts.com

Earn points while you shop. Join today!
bestchoiceproducts.com
Give your friends 15% o their first order! For each
successful referral you’ll receive 100 points.

All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long
as the item is returned in its original product packaging and all accessories from its original shipment are
included. All returned items will receive a full refund back to the original payment method. All returned
items will not be charged a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best
Choice Products Customer Service Representative when the return request is submitted. Items received
without an RA may not be accepted or may increase your return processing time. Once an item has been
received by Best Choice Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If
the reason for return is a result of an error by Best Choice Products then Best Choice Products will provide
a pre-paid shipping label via email. Boxes for return shipping will not be provided by Best Choice Products,
and is the customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items
returned are not considered undamaged until they are received by Best Choice Products and verified as
such. All damages to items are the customer’s responsibility until the item has been received by and
acknowledge by Best Choice Products as undamaged.
PRODUCT WARRANTY INFORMATION
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, or neglect of this product.
HELP CENTER
Product Assembly
Product InquiryChat Support Returns & Refunds
Orders FAQ
WARNING
Question about your product? We're here to help. Visit us at:
help.bestchoiceproducts.com
CHAT
US!
