BDI CODE 7379 User manual

1
Product Registration
Registering your new BDI product allows us to send you important
product updates, service information and helpful hints related to your
BDI products. Register today, and you will be entered to win free a
BINK table from BDI: www.bdiusa.com/register
Placement and Maintenance
Your Code Console is designed for indoor use on level floors.
Clean painted surfaces and steel parts with a damp cloth.
Code is engineered for easy assembly. Carefully follow this procedure
to prevent any damage. Do not use power tools for assembly of this
product.
Step 1
Unpack and identify the parts listed below. The assembly workspace
should be a non-marring surface such as carpet. For missing hardware
pieces, contact BDI Customer Service at:
[email protected].
For all other concerns, please contact your BDI retailer.
bdiusa.com
customerservic[email protected]om
Designed by Matthew Weatherly.
These distinctive product configurations are protected by US and international patents, trade dress, and/or
copyright laws. Code & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2018, BDI
Patent: www.bdiusa.com/ip
Made in China. 05.29.2019 V2
Tool Required:
Phillips Screwdriver
C1 Cabinet x 1
C5 Back Panel x 2
C4 Side Shelf x 2
C3 Center Shelf x 1
A1 Base Rails x 2
A2 End Plates x 2
A3 Leg x 2
T1 Hex Wrench x 1
H1 1/4-20 x 10 mm Flat
head Screw x 8
H4 #6 x 12 mm
Wood Screw x 8
H3 1/4-20 x 87 mm
Screw x 6
H5 Door Pull x 4
H2 1/4-20 x 12mm
Screw x 8
C2 Ventilated Drop-in
Panel x 4
CODE™7379
CONSOLE

bdiusa.com
customerservic[email protected]om
CODE 7379
MEDIA CONSOLE
2
Step 2 - Assemble the base
Position both base rails A1 on a padded floor with the threaded holes on the ends facing up. Orient the 2 end
plates A2 as shown with countersunk holes on the outside. Attach both end plates A2 to the base rails A1
with flathead screws H1 going through the countersunk holes. Tighten screws with hex wrench T1.
Step 3 - Attach the legs
Attach the legs A3 to the base frame using screws H2 and hex wrench T1.
T1
H1 x 8
A1
A1
Countersunk holes
face up.
Arrow faces up.
A2
A2
H1
H1
A3
A3
H2
H2
H2 x 8
A2

bdiusa.com
customerservic[email protected]om
CODE 7379
MEDIA CONSOLE
3
Step 4 - Attach the base
With help from another person, carefully position the cabinet on its back. Attach the base using screws H3
and hex wrench T1 going through the holes on the base rails and into the threaded holes on the bottom of
the cabinet.
2 Person Ta sk
H3 x 6T1
H3
H3
H3
H3
H3
H3

bdiusa.com
customerservic[email protected]om
CODE 7379
MEDIA CONSOLE
4
Step 5 - Stand Up / Attach Door Pulls / Adjust shelves
With help from another person, carefully position the cabinet onto its base. Open the doors and attach the
4 door pulls H5 using 8 wood screws H4 and a Phillips screwdriver. The shelves in your Code Media
Console are adjustable. Shelf pins may be unscrewed and moved up or down. Place the 4 ventillated drop-in
panels inplace as shown.
Step 6 - Level your unit
Levelers are integrated into each leg assembly and are accessed at the bottom of each cabinet leg. If your floor
is uneven, you may extend one or more levelers to attain a level, stable cabinet placement. Turning the leveler
clockwise will extend the leveler; turning it counter-clockwise will retract it.
2 Person Ta sk
H4 Phillips
Screwdriver
Ventilated Drop-in
Panels
C2
Shelf Pins
Levelers
H5

bdiusa.com
customerservic[email protected]om
CODE 7379
MEDIA CONSOLE
5
Step 7 - Install both back panels C5 to the backside of the cabinet by inserting the top edge in the upper slot
then tipping the bottom edge forward and into the lower slot. The back panels C5 can also slide horizontally
towards the center of the cabinet to easily plug in media components.
Step 8 - Your Code Console is equipped with a TV safety strap. Find the strap bundle inside the cabinet and
push it through the mouse hole so that it hangs out the back. Follow the instructions on the hang tag to attach
the loose ends of the strap to your TV.
TV Saftely Strap
2
1
C5
C5

bdiusa.com
customerservic[email protected]om
CODE 7379
MEDIA CONSOLE
6
Step 8 - Adjust Door Hinges (if needed)
The doors on your cabinet should be evenly spaced and the doors should open and close freely without rubbing
against the door frame. If the cabinet’s doors appear out of alignment, this condition can be corrected with minor
adjustment to the European hinges on each door. Because these hinges are adjustable, adjusting one hinge
element can sometimes cause the need for adjustments to other elements. But with a few adjustments, you can
modify the orientation of the cabinet doors to make sure that they hang perfectly within your cabinet.
Example:
Tightening Screw 1
on top hinge will move the
top of the door in the
direction shown
Example:
Adjusting Screw 2
on both hinges (same direction)
will move the door up or down
Use the Phillips Screwdriver T1 supplied to adjust the door hinges:
• By adjusting Screw 1, the door will move LEFT or RIGHT within the
frame. Make minor adjustments at both top and bottom hinges for
best results.
• By adjusting Screw 2, the door will move UP or DOWN. For best
results, adjust Screw 2 on both the top and bottom hinges.
• By adjusting Screw 3 the entire door will move IN or OUT, opening
or closing the gap between the door frame and cabinet. (This screw
rarely needs adjustment.)
123
