Beale Street Audio PESV-6B User manual

Beale Street Audio
PESV-6B, PESV-6W, PESV-8B and PESV-8W
Pendant Enclosures
Installation Guide

2
Introduction
The Beale Street Audio Pendant Speaker Enclosures allow integrators
to easily install Beale Street Audio speakers into projects that do not
have a standard drop or drywall ceiling, for unprecedented sound quality,
consistency, and efficiency in both residential and commercial installations.
The Pendant Speaker Enclosures provide a solution for the award winning
and patented Beale Street Audio speakers with Sonic Vortex technology to
be used for pendants or surface mount solutions. Compatible with most
4-inch, 6.5-inch, and 8-inch Beale Street Audio in-ceiling speaker and
subwoofer models.
The innovative Pendant Speaker Enclosures are available in two different
sizes with either a white or black paintable enclosure, as well as paintable
grill, to allow for custom color-matching in any installation space. IP65
rated, the Pendant Speaker Enclosures are water, weather, and UV
resistant, offering further flexibility by making them ideal for either indoor
or outdoor projects.
What’s Inside?
• 6.5” Pendant Speaker Enclosure- White
• Mounting Hardware
• Product Manual
PESV-6W
• 6.5” Pendant Speaker Enclosure- Black
• Mounting Hardware
• Black magnetic grill
• Product Manual
PESV-6B
• 8” Pendant Speaker Enclosure- White
• Mounting Hardware
• Product Manual
PESV-8W
• 8” Pendant Speaker Enclosure- Black
• Mounting Hardware
• Black magnetic grill
• Product Manual
PESV-8B

3
Features
6.5” Pendant Speaker Enclosure - White
PESV-6W
• Compatible with most 4”and 6.5” Beale Street Audio speakers with Sonic Vortex technology
• Supports 8 ohm and 70V speakers and subwoofers
• Perfect for open-ceiling and exposed environments
• Water, weather and UV resistant for indoor and outdoor installations
• IP65 Rated
• Custom color-match in any space with included white paintable enclosure; white paintable grill
provided with speaker (sold separately)
• Includes additional pendant mounting options and hardware
6.5” Pendant Speaker Enclosure - Black
PESV-6B
• Compatible with most 4”and 6.5” Beale Street Audio speakers with Sonic Vortex technology
• Supports 8 ohm and 70V speakers and subwoofers
• Perfect for open-ceiling and exposed environments
• Water, weather and UV resistant for indoor and outdoor installations
• IP65 Rated
• Custom color-match in any space with included black paintable enclosure and grill
• Includes additional pendant mounting options and hardware
8” Pendant Speaker Enclosure - White
PESV-8W
• Compatible with most 8” Beale Street Audio speakers with Sonic Vortex technology
• Supports 8 ohm and 70V speakers and subwoofers
• Perfect for open-ceiling and exposed environments
• Water, weather and UV resistant for indoor and outdoor installations
• IP65 Rated
• Custom color-match in any space with included white paintable enclosure; white paintable grill
provided with speaker (sold separately)
• Includes additional pendant mounting options and hardware
8” Pendant Speaker Enclosure - Black
PESV-8B
• Compatible with most 8” Beale Street Audio speakers with Sonic Vortex technology
• Supports 8 ohm and 70V speakers and subwoofers
• Perfect for open-ceiling and exposed environments
• Water, weather and UV resistant for indoor and outdoor installations
• IP65 Rated
• Custom color-match in any space with included black paintable enclosure and grill
• Includes additional pendant mounting options and hardware

4
Installation
Speaker wire must be run from the equipment or volume control location to
each potential speaker location. Choose a location for each speaker that is
free of obstructions or anything else that might not allow for the depth of
the speaker or create interference or noise.
Sonic Vortex
Speaker
PESV Hanging
Pendant
Speaker Wires

5
1. At each speaker location, route the speaker cable hanging from the
ceiling through the top cover and dress the cables to the wire rope.
2. Unscrew the watertight grommet on the top of the can and slide the
speaker cables through the hole in the back cover. Screw on the cap to
make this a watertight connection
3. Strip the cable ends approximately 1/8” to 3/16”
4. Connect the wires from the amplifier or previous speaker to the supplied
terminal block
5. If mounting to the wall/ceiling with the mounting bracket, use the
appropriate hardware and securely attach to the wall or ceiling
6. If being used with our 70/100V speakers make sure to adjust the tap
settings on the back of the speaker prior to installing
Hanging
Ceiling
P
ole
Hook
F
astener
Hanging Cable
P
endant Speaker
The offset loop can be used for
additional support. Please
check your local safety codes.
NOTE: Make sure the speaker is properly secured to the building’s structure. Please use
the proper screws, bolts, or anchors as failure to do so may cause the speaker to become
unsecured and cause potential damages and injuries.

6
Description PESV-6B/PESV-6W PESV-8B/PESV-8W
Dimensions 10.5” x 8.25” (267mm x 210mm) 12.3” x 11.0” (314mm x 280mm)
Weight 3.45 lbs (1.56kg) 6.0 lbs (2.72kg)
Material ABS Plastic
Compatible Beale Street Audio
Speaker Models
IC6-B, IC6-MB, IC6-BB
ICA6-B, ICA6-MB, ICA6-BB
IC6DVC-B, ICW6-MB, TU401
P4-MB, P4-BB
TIC651, BS650, ICS6-MB
IC8-B,IC8-MB,IC8-BB,TIC801,ICS8-MB
Specifications

7
Limited Warranty
With the exceptions noted in the next paragraph, Vanco warrants to the original purchaser
that the equipment it manufactures or sells will be free from defects in materials and
workmanship for a period of two years from the date of purchase. Should this product, in
Vanco’s opinion, prove defective within this warranty period, Vanco, at its option, will repair
or replace this product without charge. Any defective parts replaced become the property
of Vanco. This warranty does not apply to those products which have been damaged due to
accident, unauthorized alterations, improper repair, modifications, inadequate maintenance
and care, or use in any manner for which the product was not originally intended.
Items integrated into Vanco products that are made by other manufacturers, notably
computer hard drives and liquid crystal display panels, are limited to the term of the
warranty offered by the respective manufacturers. Such specific warranties are available
upon request to Vanco. A surge protector, power conditioner unit, or an uninterruptible
power supply must be installed in the electrical circuit to protect against power surges.
If repairs are needed during the warranty period, the purchaser will be required to provide
a sales receipt/sales invoice or other acceptable proof of purchase to the seller of this
equipment. The seller will then contact Vanco regarding warranty repair or replacement.
TECHNICAL SUPPORT
In case of problems, please contact Vanco Technical Support by dialing 1-800-626-6445.
You can also email technical support issues to [email protected]. When calling,
please have the Model Number, Serial Number (affixed to the bottom of the unit) and
Invoice available for reference during the call. Please read this Instruction Manual prior to
calling or installing this unit, since it will familiarize you with the capabilities of this product
and its proper installation. All active electronic products are 100% inspected and tested
to insure highest product quality and trouble-free installation and operation. The testing
process utilizes the types of high-definition sources and displays typically installed for
entertainment and home theatre applications. For additional information please visit www.
vanco1.com.
LIABILITY STATEMENT
Every effort has been made to ensure that this product is free of defects. The manufacturer
of this product cannot be held liable for the use of this hardware or any direct or indirect
consequential damages arising from its use. It is the responsibility of the user and installer
of the hardware to check that it is suitable for their requirements and that it is installed
correctly. All rights are reserved. No parts of this manual may be reproduced or transmitted
by any form or means electronic or mechanical, including photocopying, recording or by
any information storage or retrieval system without the written consent of the publisher.
Manufacturer reserves the right to revise any of its hardware and software following its
policy to modify and/or improve its products where necessary or desirable. This statement
does not affect the legal rights of the user in any way.
