QNAP REXP-1200U-RP Instructions for use

QNAP RAID Expansion Enclosure
Hardware User Manual
© 2014. QNAP Systems, Inc. All Rights Reserved.
Проконсультироваться икупить данное оборудование вы можете вкомпании «АНД-Системс»
адрес: 125480, г.Москва, ул.Туристская, д.33/1; site: https://andpro.ru тел: [phone] email: [email protected]
При обращении используйте промокод AND-PDF иполучите скидку.

2
Thank you for choosing QNAP products! This user manual provides descriptions of the
hardware of the QNAP RAID expansion enclosure and relevant guidelines of certain
functions. Please read this manual carefully and strictly adhere to its instructions.
This user manual is applicable to the following RAID expansion enclosure(s):
REXP-1200U-RP, REXP-1600U-RP, REXP-1000 Pro
Note:
The product you purchased may not support certain functions dedicated to specific
models.
All features, functionality, and other product specifications are subject to change
without prior notice or obligation.
Information presented is subject to change without notice.
No part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, mechanical, electronic, photocopying,
recording, or otherwise, without prior written permission of QNAP Systems, Inc.
QNAP and the QNAP logo are registered trademarks of QNAP Systems, Inc. Other
products and company names mentioned herein may be the trademarks of their
respective companies.
Проконсультироваться икупить данное оборудование вы можете вкомпании «АНД-Системс»
адрес: 125480, г.Москва, ул.Туристская, д.33/1; site: https://andpro.ru тел: [phone] email: [email protected]
При обращении используйте промокод AND-PDF иполучите скидку.

3
DISCLAIMER
In no event shall the liability of QNAP Systems, Inc. (QNAP) exceed the price paid for the
product from direct, indirect, special, incidental, or consequential software, or its
documentation. QNAP makes no warranty or representation, expressed, implied, or
statutory, with respect to its products or the contents or use of this documentation and all
accompanying software, and specifically disclaims its quality, performance, merchantability,
or fitness for any particular purpose. QNAP reserves the right to revise or update its
products, software, or documentation without obligation to notify any individual or entity.
Note:
Back up your system periodically to avoid any potential data loss. QNAP disclaims any
responsibility of all sorts of data loss or recovery.
Should you return any components of the RAID expansion enclosure package for
refund or maintenance, make sure they are carefully packed for shipping. Any form of
damages due to improper packaging will not be compensated.
Проконсультироваться икупить данное оборудование вы можете вкомпании «АНД-Системс»
адрес: 125480, г.Москва, ул.Туристская, д.33/1; site: https://andpro.ru тел: [phone] email: [email protected]
При обращении используйте промокод AND-PDF иполучите скидку.

4
Regulatory Notice
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/television technician for help.
The changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Shielded interface cables, if any, must be used in order to comply with the emission limits.
CE NOTICE
Class B only.
Проконсультироваться икупить данное оборудование вы можете вкомпании «АНД-Системс»
адрес: 125480, г.Москва, ул.Туристская, д.33/1; site: https://andpro.ru тел: [phone] email: [email protected]
При обращении используйте промокод AND-PDF иполучите скидку.

5
Symbols in this document
Warning
This icon indicates the instructions must be strictly followed. Failure to
do so could result in injury to human body or death.
Caution
This icon indicates the action may lead to disk clearance or loss OR
failure to follow the instructions could result in data damage, disk
damage, or product damage.
Проконсультироваться икупить данное оборудование вы можете вкомпании «АНД-Системс»
адрес: 125480, г.Москва, ул.Туристская, д.33/1; site: https://andpro.ru тел: [phone] email: [email protected]
При обращении используйте промокод AND-PDF иполучите скидку.

6
Contents
CONTENTS..........................................................................................................................................................6
SAFETY WARNINGS..........................................................................................................................................7
BEFORE YOU START........................................................................................................................................9
1. PACKAGE CONTENTS..............................................................................................................................9
1.1. REXP-1200U-RPAND REXP-1600U-RP...............................................................................................9
1.2. REXP-1000 PRO ...................................................................................................................................10
2. HARDWARE SPECIFICATION..............................................................................................................11
2.1. REXP-1200U-RPAND REXP-1600U-RP............................................................................................. 11
2.2. REXP-1000PRO....................................................................................................................................13
3. RAID EXPANSION ENCLOSURE HARDWARE ILLUSTRATION ..................................................15
3.1. FRONT VIEW ..........................................................................................................................................15
3.2. REAR VIEW ............................................................................................................................................18
3.3. REXP-1000 PRO FRONT VIEW...............................................................................................................19
3.4. REXP-1000 PRO REAR VIEW ................................................................................................................21
4. CABLE THE SYSTEM..............................................................................................................................22
4.1. CABLING INSTRUCTIONS .......................................................................................................................22
4.2. MINI SAS CABLE REMOVAL..................................................................................................................24
5. REMOVE AN AIR DUCT (APPLIED TO REXP-1600U-RP)...............................................................25
6. INSTALL/REMOVE A FAN MODULE...................................................................................................26
6.1. INSTALL A FAN MODULE (APPLIED TO REXP-1600U-RPAND REXP-1200U-RP)................................26
6.2. REMOVE A FAN MODULE (APPLIED TO REXP-1600U-RPAND REXP-1200U-RP) ...............................26
7. INSTALL POWER SUPPLY UNIT (APPLIED TO REXP-1600U-RPAN D REXP-1200U-RP)........27
TECHNICAL SUPPORT...................................................................................................................................29
Проконсультироваться икупить данное оборудование вы можете вкомпании «АНД-Системс»
адрес: 125480, г.Москва, ул.Туристская, д.33/1; site: https://andpro.ru тел: [phone] email: [email protected]
При обращении используйте промокод AND-PDF иполучите скидку.

7
Safety Warnings
1. The RAID expansion enclosure can operate normally in the temperature of 0ºC–40ºC
and relative humidity of 5%–95%. Please make sure the environment is
well-ventilated.
2. The power cord and devices connected to the RAID expansion enclosure must provide
correct supply voltage (100-240V AC, 50-60Hz).
3. Do not place the RAID expansion enclosure in direct sunlight or near chemicals. Make
sure the temperature and humidity of the environment are within normal levels.
4. Unplug the power cord and all connected cables before cleaning. Wipe the RAID
expansion enclosure with a dry towel. Do not use chemical or aerosol to clean the RAID
expansion enclosure.
5. Do not place any objects on the RAID expansion enclosure to ensure normal
operation and to avoid overheating.
6. Use the flat head screws in the product package to lock the hard disks in the RAID
expansion enclosure when installing hard disks for proper operation.
7. Do not place the RAID expansion enclosure near any liquid.
8. Do not place the RAID expansion enclosure on any uneven surface to avoid falling off
and damage.
9. Make sure the voltage is correct in the location where the RAID expansion enclosure is
installed. Contact the distributor or the local power supply company for more
information.
10. Do not place any object on the power cord.
11. Do not attempt to repair the RAID expansion enclosure. Improper disassembly of the
product may expose the users to electric shock or other risks. For any enquiries,
please contact the distributor.
12. The RAID expansion enclosure should only be installed in the server room and
maintained by authorized server managers or IT administrators. The server room
should be locked by key or keycard access and only certified staff allowed access.
Проконсультироваться икупить данное оборудование вы можете вкомпании «АНД-Системс»
адрес: 125480, г.Москва, ул.Туристская, д.33/1; site: https://andpro.ru тел: [phone] email: [email protected]
При обращении используйте промокод AND-PDF иполучите скидку.

8
Warning:
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
Do NOT touch the fan inside the RAID expansion enclosure to avoid serious injuries.
The RAID expansion enclosure is heavy and should be installed into a rack by at least
two people. To avoid personal injury and/or damage to the equipment, do not attempt
to lift and install the enclosure into a rack without a mechanical lift and/or help from
other people.
Проконсультироваться икупить данное оборудование вы можете вкомпании «АНД-Системс»
адрес: 125480, г.Москва, ул.Туристская, д.33/1; site: https://andpro.ru тел: [phone] email: [email protected]
При обращении используйте промокод AND-PDF иполучите скидку.

9
Before You Start
1. The RAID expansion enclosures can ONLY be used with the QNAP Turbo NAS.
2. Install the hard drives in sequential order following the tray number.
3. The RAID expansion enclosures are applicable to the TS-x79 and TS-ECx80 Turbo NAS
series.
4. Always turn on the RAID expansion enclosures before turning on the attached NAS.
5. Always shut down the NAS before turning off the RAID expansion enclosures.
1. Package Contents
1.1. REXP-1200U-RP and REXP-1600U-RP
The product package contains the following items.
Item
Quantity
REXP-1200U-RP or
REXP-1600U-RP
or
1
Power cord
2
Screw pack
1
Quick Installation Guide
1
0.5m Mini SAS cable
1
Hardware Installation CD
1
Rail kit (optional purchase)
1
Проконсультироваться икупить данное оборудование вы можете вкомпании «АНД-Системс»
адрес: 125480, г.Москва, ул.Туристская, д.33/1; site: https://andpro.ru тел: [phone] email: [email protected]
При обращении используйте промокод AND-PDF иполучите скидку.

10
Storage expansion card
(optional purchase)
1
1.2. REXP-1000 Pro
The product package contains the following items.
Item
Quantity
REXP-1000 Pro
1
Power cord
1
Screw pack
1
Quick Installation Guide
1
0.5m Mini SAS cable
1
Hardware Installation CD
1
Storage expansion card
(optional purchase)
1
