AIR TRAFFIC CONTROL RADAR BEACON SYSTEM / MODE SELECT
(ATCRBS / MODES) AIRBORNE EQUIPMENT
Transponder Level 2es
BXP6401-1-(XX) Class 1
BXP6401-2-(XX) Class 2
INSTALLATION AND OPERATION
Manual DV 69801.03 PN 0584.053-071
Issue 3 September 2011
Becker Flugfunkwerk GmbH · Baden-Airpark B 108 · 77836 Rheinmünster · Germany
Telephone [phone] / 305-0 · Fax [phone] / 305-217
http://www.becker-avionics.de · e-mail: [email protected] or [email protected]
Issue 3
September 2011 34-50-08

© Copyright by Becker Flugfunkwerk GmbH 77836 Rheinmünster / Germany
All rights reserved. Subject to technical changes.
34-50-08 Issue 3
September 2011

RECORD OF REVISIONS
REV.
NO. ISSUE DATE INSERTED REV. NO. ISSUE DATE INSERTED
DATE BY DATE BY
1
2
3
February 2007
April 2007
September 2011
02/07
04/08
09/11
Becker
Becker
Becker
ROR Page 1
34-50-08 September 2011
INSTALLATION AND OPERATION BXP 6401-X-(XX)

BLANK
INSTALLATION AND OPERATION BXP 6401-X-(XX)
ROR Page 2
34-50-08 September 2011

LIST OF EFFECTIVE PAGES
SUBJECT PAGE DATE SUBJECT PAGE DATE
Title Page TP-1 Sept. 2011 Operation 3-1 Sept. 2011
TP-2 3-2 Sept. 2011
3-3 Sept. 2011
Record of Revisions ROR-1 Sept. 2011 3-4 Sept. 2011
ROR-2 Sept. 2011 3-5 Sept. 2011
3-6 Sept. 2011
3-7 Sept. 2011
List of Effective Pages LEP-1 Sept. 2011 3-8 Sept. 2011
LEP-2 Sept. 2011 3-9 Sept. 2011
3-10 Sept. 2011
Introduction Intro-1 Sept. 2011
Intro-2 Sept. 2011
Intro-3 Sept. 2011
Intro-4 Sept. 2011
Table of Contents I-I Sept. 2011
I-II Sept. 2011
General Description 1-1 Sept. 2011
1-2 Sept. 2011
1-3 Sept. 2011
1-4 Sept. 2011
1-5 Sept. 2011
1-6 Sept. 2011
1-7 Sept. 2011
1-8 Sept. 2011
Table of Contents II-I Sept. 2011
II-II Sept. 2011
Installation 2-1 Sept. 2011
2-2 Sept. 2011
2-3 Sept. 2011
2-4 Sept. 2011
2-5 Sept. 2011
2-6 Sept. 2011
2-7 Sept. 2011
2-8 Sept. 2011
2-9 Sept. 2011
2-10 Sept. 2011
2-11 Sept. 2011
2-12 Sept. 2011
2-13 Sept. 2011
2-14 Sept. 2011
2-15 Sept. 2011
2-16 Sept. 2011
Table of Contents III-I Sept. 2011
III-II Sept. 2011
LEP Page 1
34-50-08 September 2011
INSTALLATION AND OPERATION BXP6401-X-(XX)

BLANK
INSTALLATION AND OPERATION BXP6401-X-(XX)
LEP Page 2
34-50-08 September 2011

INTRODUCTION
1. General
The single block Mode S transponder BXP6401-X-(XX) is described in this manual
“Installation and Operation”.
2. Manufacturer
The Mode S transponder was developed and is manufactured by :
Becker Flugfunkwerk GmbH
Baden-Airpark B 108
77836 Rheinmünster / Germany
Telephone: [phone] / 305-0
Telefax: +49 (0) 7229 / 305-217
http://www.becker-avionics.de
e-mail: [e-mail] or [e-mail]
CERTIFIED QUALITY SYSTEM
The Becker quality management system is certified according to :
DIN EN ISO 9001:2008
and EN9100:2003/AS9100B Certificate Registration No. 12 210 20985 TMS
LICENSES AND APPROVALS
DE.21G.0075 Approval as manufacturer to EASA PART 21
DE.145.0166 Approval as maintenance organization to
EASA PART 145
3. Safety information
nThe installation of the Mode S transponder into an aircraft may be carried
out only by an authorized installation company. The country regulations
always have to be observed.
nDo not connect the unit to AC sources.
nMake sure that the unit is connected to a DC source £33 V DC.
nIf no load is connected to pin 6 of P9, the unit should be protected from the
aircraft power supply by a dedicated 3 A circuit breaker.
nIf an external load is connected to pin 6 of P9, the circuit breaker should
be a 5A type.
nDo not connect the unit with reversed polarity to the DC source.
nDo not switch on the unit before the aircraft engines are started. Switch off
the unit before the engines are shut down.
INTRO Page 1
34-50-08 September 2011
INSTALLATION AND OPERATION BXP6401-X-(XX)

nDo not operate the unit under ambient temperatures below -20 °C and abo-
ve +70 °C.
nVoltages > 42 V are possible within the transponder.
nThe programming of the address module AM6400-1 with the ICAO 24-bit
address of the aircraft must be carried out by an authorized installation
company or the manfacturer.
4. Layout of manual
The manual is divided into three chapters:
- GENERAL DESCRIPTION
- INSTALLATION
- OPERATION
5. Revisions of the manual
All changes to the manual are recorded consecutively on the pre-page “Record of
Revisions”.
6. List of abbreviations
AA Aicraft Address (24-bit ICAO)
ADLP Avionics Data Link Processor
ADS-B Automatic Dependent Surveillance-Broadcast
AI Aircraft Identifier
ALT Altitude or transponder ALT mode
ATC Air Traffic Control
BIT Built-In Test
CBIT Continuous Built-In Test
CCS Company Call Sign
CS Call Sign
DV Manual identification number
EASA European Aviation Safety Agency
ELS Elementary Surveillance
EHS Enhanced Surveillance
es e = Extended squitter and s = SI capability
FAA Federal Aviation Administration
FL Flight Level
FMS Flight Management System
FN Flight Number
GICB Ground Initiated Comm-B
GND Ground
ICAO International Civil Aviation Organization
IBIT Initiated Built-In Test
ID Identifier
IDT Ident (Identification)
IFR Instrument Flight Rules
INTRO Page 2
34-50-08 September 2011
INSTALLATION AND OPERATION BXP6401-X-(XX)

MTL Minimum Triggering Level
ON Transponder ON mode (without altitude transmission)
NSCM Nato Supply Code of Manufacturers
PBIT Power-on Built-In Test
PN Part Number
R Reply
RX Receiver
SBY Standby mode
SEL Selection
SI Surveillance Identifier
SPI Special Position Identification Pulse
STO Store
SUPP Supply voltage DC
TCAS Traffic Collision and Alert Avoidance System (US)
TIS Traffic Information Service
TN Tail Number
TX Transmitter
VFR Visual Flight Rules
XPDR Transponder
INTRO Page 3
34-50-08 September 2011
INSTALLATION AND OPERATION BXP6401-X-(XX)

BLANK
INSTALLATION AND OPERATION BXP6401-X-(XX)
INTRO Page 4
34-50-08 September 2011

TABLE OF CONTENTS
GENERAL DESCRIPTION Page
1. Application 1-1
2. General description 1-1
3. Technical data 1-2
4. Software 1-7
5. System approvals 1-7
6. Equipment 1-7
7. Accessories 1-7
INSTALLATION AND OPERATION BXP 6401-X-(XX)
Page I-I
34-50-08 September 2011

BLANK
INSTALLATION AND OPERATION BXP 6401-X-(XX)
Page I-II
34-50-08 September 2011

GENERAL DESCRIPTION
1. Application
The single block Mode S transponder BXP6401-X-(XX) is the airborne component of the
Air Traffic Control (ATC) Mode S Secondary Surveillance Radar system with added
ADS-B Transmitting Subsystem functionality. It acts as a part of the surveillance system
in two ways:
las a Mode S Transponder which provides responses to ground station interroga-
tions and allows air traffic control to locate, identify and track aircraft
las an ADS-B Broadcast-Only System which spontaneously broadcasts aircraft in-
formation
2. General description
A. The BXP6401-X-(XX) transponder is designed as a single block unit and is in-
tended for installation in the instrument panel of aircraft. The dimensions cor-
respond to the standard instrument size with a 58 mm (2¼ inch) diameter.
B. All control elements are located on the front panel of the unit. The two 25-pin
unit connectors for connection to the aircraft interwiring, the 5-pin subminiatu-
re connector for the Address Module AM6400-1-(XX) and the TNC antenna
socket are located at the rear side of the unit.
C. Serial interfaces RS-422 are available at the unit connectors.
D. The Mode S transponder provides the following features:
(1) In the selective mode (Mode S), the Ground Control can interrogate the
transponder individually using an ICAO-24-bit address, which is unique
to the particular aircraft.
(2) Support of the SI code (Surveillance Identifier)
(3) Register capability for elementary surveillance (ELS) and enhanced sur-
veillance (EHS)
(4) Extended squitters transmission
(5) Data link capability
(6) GPS receiver connection capability
(7) ADS-B Broadcast-Only System Class B0 i.e. broadcasts following data:
- Airborne Position Message
- Surface Position Message
- Airborne Velocity Message
- Extended Squitter Aircraft Status Message
NOTE:
Actual generation of each ADS-B message type and data within each
message depends on availability of navigation data and GPS engine ca-
pabilities.
Page 1-1
34-50-08 September 2011
INSTALLATION AND OPERATION BXP6401-X-(XX)

E. Inherent features:
(1) Mode A - in this mode, the 4096 character code set on the control head
is sent as a reply to interrogation from a ground station.
(2) Mode C - in this mode, the encoded altitude is sent in addition to the
mode A reply. The altitude information must be delivered from an exter-
nal device (e.g. Becker Blind Encoder BE6400).
(3) A special identifier pulse (SPI) can be activated by pressing the IDT
button in Mode A/C and Mode S.
(4) Selftests (BITs). An Initiated Built-In Test (IBIT), a Continuous Built-
In Test (CBIT) and a Power-on Built-In Test (PBIT) are integrated in
the transponder.
3. Technical data
A. General data
Supply voltage 10.0 V to 33.0 V DC
Typical consumption 50 mode S replies/sec. + Squitter
0.37 A at 14 V (illumination off)
0.22 A at 28 V (illumination off)
0.43 A at 14 V (illumination max.)
0.25 A at 28 V (illumination max.)
in standby mode:
0.22 A at 14 V (illumination off)
0.14 A at 28 V (illumination off)
0.28 A at 14 V (illumination max.)
0.16 A at 28 V (illumination max.)
Panel illumination control input
Illumination control current max. 1 mA at 28 V
Illumination color (display and buttons) white
Serial interfaces RS-422
Data link capability 255 GICB registers
DME suppression:
- input voltage < 2 V (no suppression)
> 8 V (suppression)
- output voltage < 0.5 V (not active)
> 18 V (active)
External Ident input:
“0” (active) £3.5 V
“1” (passive) ³4.0 V
source (shorted to GND) £10 mA
Page 1-2
34-50-08 September 2011
INSTALLATION AND OPERATION BXP6401-X-(XX)

Ground detection input:
“ground” £0.5 V
“airborne” ³2 V
source (shorted to GND) £10 mA
Power-up time 2 s (including internal self-test PBIT)
Internal fuse protection F 5 A
External fuse protection T 3 A (circuit breaker) *
* NOTE:
5 A circuit breaker if an external load is connected to pin 6 at P9.
Operating temperature range -20 °C to +55 °C
(short-time +70 °C)
Storage temperature range -55 °C to +85 °C
Operating altitude 50000 ft. max. (class 1)
15000 ft. max. (class 2)
Mode S Class 1 or 2, Level 2es
- extended squitter capability
- surveillance identifier (SI code)
Conformity RTCA DO-181C,
FAA TSO-C112, class 2A or 2B,
EUROCAE ED-73B, Level 2es,
EASA ETSO-2C112a, class 1or 2
Environmental conditions in accordance with EUROCAE/
(see also paragraph D) RTCA ED-14D/DO-160D
Mechanical dimensions :
- Front panel 61.3 x 61.3 mm (H x W)
(2.413 x 2.413 inch)
- Instrument size diameter 58 mm (2¼ inch)
- Case depth
without antenna socket 192 mm (7.599 inch)
with antenna socket 206 mm (8.110 inch)
with address module 239 mm (9.409 inch)
Weight approx. 0.8 kg (1.764 lb)
B. Receiver data
Operating modes Mode A/C/S,
depending on interrogation
Receive frequency 1030 MHz ±0.1 MHz (mode A/C)
1030 MHz ±0.01 MHz (mode S)
Page 1-3
34-50-08 September 2011
INSTALLATION AND OPERATION BXP6401-X-(XX)

Sensitivity (MTL) - 74 dBm ±3 dB (for 90 % reply rate
in mode A/C and 99 % in mode S)
Selectivity ±15 MHz > 40 dB
±25 MHz > 60 dB
Dynamic range ³60 dB
Bandwidth ±3 MHz < 3 dB
Modulation (Mode A/C) PAM (Pulse Amplitude Modulation)
Modulation (Mode S) DPSK (Differential Phase Shift
Keying)
Side Lobe Suppression 3-pulse method (Mode A/C)
P5 (Mode S)
Nominal impedance 50 W
C. Transmitter data
Transmit frequency 1090 MHz ±1 MHz
Transmit modulation 12MOM1D PAM (Pulse Amplitude
Modulation)
Transmitter type Solid state
Transmit power (class 1) ³125 W (+ 21 dBW) at antenna end
terminal and ³250 W at unit output
Transmit power (class 2) ³70 W (+ 18.5 dBW) at antenna end
terminal and ³140 W at unit output
Reply rate capability (mode A/C) at least 1200 mode A/C replies
per second for a 15 pulse coded
reply, can be limited to 500...1200
Reply rate capability (mode S) at least 50 mode S replies in
one-second interval (thereof at
least 16 long formats)
Mode S squitter rate (approx.) Acquisition squitter 4/sec.
Extended squitter 1/sec.
Reply code (mode A) ICAO coding system with 4096
pulse reply possibilities (octal
code)
Altitude code (mode C) ICAO coding system 100 ft. steps
from -1000 to 62700 ft.
Altitude code (mode S) 25 ft. or 100 ft. steps
(depending on source)
INSTALLATION AND OPERATION BXP6401-X-(XX)
Page 1-4
34-50-08 September 2011

Transmit pulse shape pulse width 0.45ms±0.1ms (mode A/C)
pulse width 0.5ms±0.05ms (mode S)
rise time 0.05 to 0.1ms
fall time 0.05 to 0.2ms
Nominal output impedance 50 W
D. Environmental conditions in accordance
with EUROCAE/RTCA ED-14D/DO-160D
Input voltage range 10.0 to 33.0 V DC
Low operating temperature -20 °C
High operating temperature +55 °C
High short-time operating temperature +70 °C
Storage temperature range -55 °C to +85 °C
In-flight loss of cooling Cat. Z, no auxiliary cooling required
Altitude 50,000 ft. max. (class 1)
15,000 ft. max. (class 2)
Humidity Cat. A / +50° C; 95%, 48 h
Vibration resistance Cat. S, test curve M
Cat, U, test curve G
Operational shocks 6 g in any direction
Crash safety 20 g shocks
20 g acceleration
Magnetic effect Category Z
Environmental categories:
Env.Cat. [D1Z]BAB[(SM)(UG)]XXXXXXZBABA[WW]B[A3E3X]XXA
INSTALLATION AND OPERATION BXP6401-X-(XX)
Page 1-5
34-50-08 September 2011

E. Environmental qualification
EUROCAE/RTCA ED-14D/DO-160D
Condition Section Cat. Description
Temperature and Altitude 4.0 D1 Equipment tested to Category D1
Low Ground Survival Temperature 4.5.1 D1 -55 °C
Low Operating Temperature 4.5.1 D1 BXP6401-X-(XX): -20 °C,
High Ground Survival Temp 4.5.2 D1 +85 °C
High Short-Time Operating Temp. 4.5.2 D1 +70 °C
High Operating Temp. 4.5.2 D1 +55 °C
In-flight Loss of Cooling 4.5.4 Z No forced cooling required – No test
required
Altitude 4.6.1 D1
A1
BXP6401-1-(XX): 50,000 ft (class 1)
BXP6401-2-(XX): 15,000 ft (class 2)
Decompression 4.6.2 Not applicable
Overpressure 4.6.3 Not applicable
Temperature Variation 5.0 B Equipment tested to Category B
Humidity 6.0 A Equipment tested to Category A
Shock and Crash Safety 7.0 B Equipment tested to Category B
Vibration 8.0 S
U
Cat. S, vibration test curve M
Cat. U, vibration test curve G
Explosion Proofness 9.0 X No test required, Equipment identified
as Category X
Waterproofness 10.0 X No test required, Equipment identified
as Category X
Fluids Susceptibility 11.0 X No test required, Equipment identified
as Category X
Sand and Dust 12.0 X No test required, Equipment identified
as Category X
Fungus Resistance 13.0 X No test required, Equipment identified
as Category X
Salt Spray 14.0 X No test required, Equipment identified
as Category X
Magnetic Effect 15.0 Z Equipment is Class Z
Power Input 16.0 B Equipment tested to Category B
Voltage Spike 17.0 A Equipment tested to Category A
Audio Freq. Conducted Suscepti-
bility
18.0 B Equipment tested to Category B
Induced Signal Susceptibility 19.0 A Equipment tested to Category A
Radio Frequency Susceptibility 20.0 WW Equipment tested to Category WW
Spurious RF Emission 21.0 B Equipment tested to Category B
Lightning Induced Transients Sus-
ceptibility
22.0 A3E3X Equipment tested to Category A3E3X
Lightning Direct Effects 23.0 X No test required, Equipment identified
as Category X
Icing 24.0 X No test required, Equipment identified
as Category X
Electrostatic Discharge 25.0 A Equipment tested to Category A
Page 1-6
34-50-08 September 2011
INSTALLATION AND OPERATION BXP6401-X-(XX)

4. Software
lThe transponder BPX6401-X-(XX) is controlled by a microcontroller in the control
head and the core unit. The software criticality is determined to be Level C in
accordance with EUROCAE/RTCA document ED12B/DO-178B.
5. System approvals
EASA.21O.322 ETSO-2C112a
FAA TSO-C112
6. Equipment
Destination Description Article-No.:
BXP6401-1-(01) Transponder,
Level 2, class 1
Article-No. 0588.687-915
BXP6401-2-(01) Transponder,
Level 2, class 2
Article-No. 0588.709-915
AM6400-1-(01) Address Module Article-No. 0572.942-915
BE6400-01-(01) Blind Encoder Article-No. 0592.137-915
7. Accessories
AMP6400-1 Address Module programmer Article-No. 0584.843-954
kit (software and cable),
parallel interface
AMP6400-2 Address Module programmer Article-No. 0604.054-954
kit (software, adapter and cable),
USB interface
CK4401-C Standard connector kit Article-No. 0552.798-954
1 D-Sub plug, 25-pin
(crimp version)
CK4401-S Standard connector kit Article-No. 0552.801-954
1 D-Sub plug, 25-pin
(soldering version)
CK6400-C Extended connector kit Article-No. 0586.064-954
1 D-Sub plug, 25-pin
1 D-Sub jack, 25-pin
(crimp version)
CK6400-S Extended connector kit Article-No. 0586.072-954
1 D-Sub plug, 25-pin
1 D-Sub jack, 25-pin
(soldering version)
TNC coaxial connector for RG-58C/U Article-No. 0551.694-277
(crimp version)
TNC coaxial connector for RG-223/U Article-No. 0551.732-277
(crimp version)
Page 1-7
34-50-08 September 2011
INSTALLATION AND OPERATION BXP6401-X-(XX)

TNC coaxial connector for RG-58C/U Article-No. 0552.781-277
and RG-223/U (soldering version)
or spare connector Article-No. 0725.900-277
1A032 Transponder antenna Article-No. 0707.007-952
Coaxial connectors for antenna 1A032:
BNC antenna connector for RG-58C/U (crimp) Article-No. 0551.708-277
BNC antenna connector for RG-223/U (crimp) Article-No. 0551.740-277
BNC antenna connector for RG-58C/U
and RG-223/U (soldering) Article-No. 0552.771-277
Manuals:
Installation and Operation BXP6401-X-(XX) Article-No. 0584.053-071
Maintenance and Repair BXP6401-X-(XX) Article-No. 0584.061-071
Data Transfer Interface Protocol Article-No. 0590.258-071
BXP640X-XX-(XX)
Installation and Operation BE6400-01-(XX) Article-No. 0594.547-071
INSTALLATION AND OPERATION BXP6401-X-(XX)
Page 1-8
34-50-08 September 2011
