Beko WCY81233W User manual

Document Number= 2302061040_EN/13-02-16.(10:15)
Washing Machine
User’s Manual
WCY81233W
EN

This product was manufactured using the latest technology in environmentally friendly conditions.

3/ EN Washing Machine / User’s Manual
1 Important instructions for safety and environment
This section contains safety instructions that will help protect from risk of personal injury
or property damage. Failure to follow these instructions shall void any warranty.
1.1 General safety
•Thisproductcanbeusedbychildrenatandabove8yearsoldandbypersonswhose
physical, sensory or mental capabilities were not fully developed or who lack expe-
rience and knowledge provided that they are supervised or trained on the safe usage
of the product and the risks it brings out. Children must not play with the product.
Cleaning and maintenance works should not be performed by children unless they
are supervised by someone. Children of less than 3 years should be kept away unless
continuously supervised.
•Neverplacetheproductonacarpet-coveredfloor.Otherwise,lackofairflowbeneath
the machine will cause electrical parts to overheat. This will cause problems with your
product.
•Iftheproducthasafailure,itshouldnotbeoperatedunlessitisrepairedbythe
Authorized Service Agent. There is the risk of electric shock!
•Thisproductisdesignedtoresumeoperatingintheeventofpoweringonaftera
powerinterruption.Ifyouwishtocanceltheprogramme,see"Cancellingthepro-
gramme"section.
•Connecttheproducttoagroundedoutletprotectedbya16Afuse.Donotneglectto
havethegroundinginstallationmadebyaqualifiedelectrician.Ourcompanyshallnot
be liable for any damages that will arise when the product is used without grounding
in accordance with the local regulations.
•Thewatersupplyanddraininghosesmustbesecurelyfastenedandremainundama-
ged.Otherwise,thereistheriskofwaterleakage.
•Neveropentheloadingdoororremovethefilterwhilethereisstillwaterinthedrum.
Otherwise,riskoffloodingandinjuryfromhotwaterwilloccur.
•Donotforceopenthelockedloadingdoor.Theloadingdoorwillbereadytoopenjust
afewminutesafterthewashingcyclecomestoanend.Incaseofforcingtheloading
door to open, the door and the lock mechanism may get damaged.
•Unplugtheproductwhennotinuse.
•Neverwashtheproductbyspreadingorpouringwaterontoit!Thereistheriskof
electric shock!
•Nevertouchtheplugwithwethands!Neverunplugbypullingonthecable,always
pull out by grabbing the plug.
•Usedetergents,softenersandsupplementssuitableforautomaticwashingmachines
only.
•Followtheinstructionsonthetextiletagsandonthedetergentpackage.
•Theproductmustbeunpluggedduringinstallation,maintenance,cleaningandrepai-
ring procedures.
•AlwayshavetherepairingprocedurescarriedoutbytheAuthorizedServiceAgent.
Manufacturer shall not be held liable for damages that may arise from procedures ca-
rried out by unauthorized persons.

4/ EN Washing Machine / User’s Manual
•Ifthepowercableisdamaged,itmustbereplacedbythemanufacturer,aftersales
service or a similarly qualified person (preferably an electrician) or someone designa-
ted by the importer in order to avoid possible risks.
•Placetheproductonarigid,flatandlevelsurface.
•Donotplaceitonalong-pilerugorsimilarsurfaces.
•Donotplacetheproductonahighplatformorneartheedgeonacascadedsurface.
•Donotplacetheproductonthepowercable.
•Neverusespongeorscrubmaterials.Thesewilldamagethepainted,chromeplated
and plastic surfaces.
1.2 Intended use
•Thisproducthasbeendesignedfordomesticuse.Itisnotsuitableforcommercial
use and it must not be used out of its intended use.
•Theproductmustonlybeusedforwashingandrinsingoflaundrythataremarked
accordingly.
•Themanufacturerwaivesanyresponsibilityarisenfromincorrectusageortransporta-
tion.
1.3 Children's safety
•Packagingmaterialsaredangeroustochildren.Keeppackagingmaterialsinasafe
place away from reach of the children.
•Electricalproductsaredangerousforthechildren.Keepchildrenawayfromthepro-
ductwhenitisinuse.Donotletthemtotamperwiththeproduct.Usechildlockto
prevent children from intervening with the product.
•Donotforgettoclosetheloadingdoorwhenleavingtheroomwheretheproductis
located.
•Storealldetergentsandadditivesinasafeplaceawayfromthereachofthechildren
by closing the cover of the detergent container or sealing the detergent package.
While washing the laundry at high temperatures, the loading door glass
becomes hot. Therefore, keep especially the children away from the
loading door of the machine while the washing operation is in progress.
1.4 Package information
•Packagingmaterialsoftheproductaremanufacturedfromrecyclablematerialsinac-
cordance with our National Environment Regulations. Do not dispose of the packaging
materials together with the domestic or other wastes. Take them to the packaging
material collection points designated by the local authorities.
1.5 Disposing of the waste product
•Thisproducthasbeenmanufacturedwithhighqualitypartsandmaterialswhichcan
be reused and are suitable for recycling. Therefore, do not dispose the product with
normal domestic waste at the end of its service life. Take it to a collection point for the
recyclingofelectricalandelectronicequipment.Pleaseconsultyourlocalauthorities
to learn the nearest collection point. Help protect the environment and natural resour-
ces by recycling used products. For children's safety, cut the power cable and break
the locking mechanism of the loading door so that it will be non-functional before dis-
posing of the product.

5/ EN Washing Machine / User’s Manual
1.6 Compliance with WEEE Directive
ThisproductcomplieswithEUWEEEDirective(2012/19/EU).Thisproduct
bears a classification symbol for waste electrical and electronic equipment
(WEEE).
This product has been manufactured with high quality parts and materials
which can be reused and are suitable for recycling. Do not dispose of the
waste product with normal domestic and other wastes at the end of its servi-
ce life. Take it to the collection center for the recycling of electrical and elec-
tronicequipment.Pleaseconsultyourlocalauthoritiestolearnaboutthese
collection centers.
Compliance with RoHS Directive:
TheproductyouhavepurchasedcomplieswithEURoHSDirective(2011/65/EU).It
does not contain harmful and prohibited materials specified in the Directive.
2 Installation
Refer to the nearest Authorised Service Agent for installation
of the product. To make the product ready for use, review
the information in the user manual and make sure that the
electricity, tap water supply and water drainage systems are
appropriatebeforecallingtheAuthorizedServiceAgent.If
they are not, call a qualified technician and plumber to have
any necessary arrangements carried out.
CPreparationofthelocationandelectrical,tapwaterand
waste water installations at the place of installation is
under customer's responsibility.
Make sure that the water inlet and discharge hoses
as well as the power cable are not folded, pinched or
crushed while pushing the product into its place after
installation or cleaning procedures.
BWARNING: Installationandelectricalconnections
of the product must be carried out by the Authorized
Service Agent. Manufacturer shall not be held liable for
damages that may arise from procedures carried out by
unauthorized persons.
AWARNING:Priortoinstallation,visuallycheckif
theproducthasanydefectsonit.Ifso,donothaveit
installed. Damaged products cause risks for your safety.
2.1 Appropriate installation location
• Placethemachineonarigidfloor.Donotplaceitona
long pile rug or similar surfaces.
• Totalweightofthewashingmachineandthedryer-with
full load- when they are placed on top of each other
reachestoapprox.180kilograms.Placetheproduct
on a solid and flat floor that has sufficient load carrying
capacity!
• Donotplacetheproductonthepowercable.
• Donotinstalltheproductatplaceswheretemperature
may fall below 0ºC.
• Placetheproductatleast1cmawayfromtheedgesof
other furniture.
2.2 Removing packaging reinforcement
Tilt the machine backwards to remove the packaging
reinforcement. Remove the packaging reinforcement by
pulling the ribbon.
2.3 Removing the transportation locks
AWARNING: Do not remove the transportation locks
before taking out the packaging reinforcement.
WARNING: Remove the transportation safety bolts
beforeoperatingthewashingmachine!Otherwise,the
product will be damaged.

6/ EN Washing Machine / User’s Manual
1. Loosen all the bolts with a suitable spanner until they
rotate freely (C).
2. Remove transportation safety bolts by turning them gently.
3.AttachtheplasticcoverssuppliedintheUserManualbag
into the holes on the rear panel. (P)
C
Keepthetransportationsafetyboltsinasafeplaceto
reuse when the washing machine needs to be moved
again in the future.
Never move the product without the transportation safety
bolts properly fixed in place!
2.4 Connecting water supply
CThe water supply pressure required to run the product is
between1to10bars(0.1–1MPa).Itisnecessaryto
have 10 – 80 liters of water flowing from the fully open
tap in one minute to have your machine run smoothly.
Attach a pressure reducing valve if water pressure is
higher.
AWARNING: Models with a single water inlet should not
beconnectedtothehotwatertap.Insuchacasethe
laundry will get damaged or the product will switch to
protection mode and will not operate.
WARNING: Do not use old or used water inlet hoses
onthenewproduct.Itmaycausestainsonyourlaundry.
1. Tighten all hose nuts by hand. Never use a tool when
tightening the nuts.
2.Openthetapscompletelyaftermakingthehose
connection to check for water leaks at the connection
points.Ifanyleaksoccur,turnoffthetapandremovethe
nut. Retighten the nut carefully after checking the seal. To
prevent water leakages and damages caused by them,
keep the taps closed when the machine is not in use.
2.5 Connecting to the drain
• Theendofthedrainhosemustbedirectlyconnectedto
the wastewater drain or to the washbasin.
AWARNING: Your house will be flooded if the hose
comes out of its housing during water discharge.
Moreover, there is risk of scalding due to high washing
temperatures! To prevent such situations and to ensure
smooth water intake and discharge of the machine, fix
the end of the discharge hose tightly so that it cannot
come out.
• Thehoseshouldbeattachedtoaheightofatleast40
cm, and 100 cm at most.
• Incasethehoseiselevatedafterlayingitonthefloor
level or close to the ground (less than 40 cm above the
ground), water discharge becomes more difficult and the
laundry may come out excessively wet. Therefore, follow
the heights described in the figure.
• Topreventflowingofdirtywaterbackintothemachine
and to allow for easy discharge, do not immerse the hose
end into the dirty water or do not drive it in the drain more
than15cm.Ifitistoolong,cutitshort.
• Theendofthehoseshouldnotbebent,itshouldnotbe
stepped on and the hose must not be pinched between
the drain and the machine.

7/ EN Washing Machine / User’s Manual
• Ifthelengthofthehoseistooshort,useitbyadding
an original extension hose. Length of the hose may
not be longer than 3.2 m. To avoid water leak failures,
the connection between the extension hose and the
drain hose of the product must be fitted well with an
appropriate clamp as not to come off and leak.
2.6 Adjusting the feet
AWARNING: Inordertoensurethattheproduct
operates more silently and vibration-free, it must stand
level and balanced on its feet. Balance the machine
byadjustingthefeet.Otherwise,theproductmay
move from its place and cause crushing and vibration
problems.
1. Loosen the lock nuts on the feet by hand.
2. Adjust the feet until the product stands level and
balanced.
3. Tighten all lock nuts again by hand.
AWARNING: Do not use any tools to loosen the lock
nuts.Otherwise,theywillgetdamaged.
2.7 Electrical connection
Connect the product to a grounded outlet protected by a 16
Afuse.Ourcompanyshallnotbeliableforanydamages
that will arise when the product is used without grounding in
accordance with the local regulations.
• Connectionmustcomplywithnationalregulations.
• Powercableplugmustbewithineasyreachafter
installation.
• Ifthecurrentvalueofthefuseorbreakerinthehouseis
less than 16 Amps, have a qualified electrician install a
16 Amp fuse.
• Thevoltagespecifiedinthe"Technicalspecifications"
section must be equal to your mains voltage.
• Donotmakeconnectionsviaextensioncablesormulti-
plugs.
BWARNING: Damaged power cables must be
replaced by the Authorized Service Agents.
Transportation of the product
1.Unplugtheproductbeforetransportingit.
2. Remove water drain and water supply connections.
3. Drain all water that has remained in the product.
4.Installtransportationsafetyboltsinthereverseorderof
removal procedure;
CNever move the product without the transportation
safety bolts properly fixed in place!
AWARNING: Packagingmaterialsaredangerousto
children.Keeppackagingmaterialsinasafeplace
away from reach of the children.
3 Preparation
3.1 Sorting the laundry
• Sortlaundryaccordingtotypeoffabric,colour,and
degree of soiling and allowable water temperature.
• Alwaysobeytheinstructionsgivenonthegarmenttags.
3.2 Preparing laundry for washing
• Laundryitemswithmetalattachmentssuchas,
underwired bras, belt buckles or metal buttons will
damage the machine. Remove the metal pieces or wash
the clothes by putting them in a laundry bag or pillow
case.
•Takeoutallsubstancesinthepocketssuchascoins,
pens and paper clips, and turn pockets inside out and
brush. Such objects may damage the product or cause
noise problem.
• Putsmallsizeclothessuchasinfant'ssocksandnylon
stockings in a laundry bag or pillow case.
• Placecurtainsinwithoutcompressingthem.Remove
curtain attachment items.
• Fastenzippers,sewloosebuttonsandmendripsand
tears.
• Wash“machinewashable”or“handwashable”labeled
products only with an appropriate programme.
• Donotwashcoloursandwhitestogether.New,dark
coloured cottons release a lot of dye. Wash them
separately.
• Toughstainsmustbetreatedproperlybeforewashing.If
unsure, check with a dry cleaner.
• Useonlydyes/colourchangersandlimescaleremovers
suitable for machine wash. Always follow the instructions
on the package.
• Washtrousersanddelicatelaundryturnedinsideout.
• KeeplaundryitemsmadeofAngorawoolinthefreezer
for a few hours before washing. This will reduce pilling.
• Laundrythataresubjectedtomaterialssuchasflour,
lime dust, milk powder, etc. intensely must be shaken off
before placing into the machine. Such dusts and powders
on the laundry may build up on the inner parts of the
machine in time and can cause damage.
3.3 Things to be done for energy saving
Following information will help you use the product in an
ecological and energy-efficient manner.
• Operatetheproductinthehighestcapacityallowedby
the programme you have selected, but do not overload;
see,"Programmeandconsumptiontable".
• Alwaysfollowtheinstructionsonthedetergent
packaging.
• Washslightlysoiledlaundryatlowtemperatures.
• Usefasterprogrammesforsmallquantitiesoflightly
soiled laundry.
• Donotuseprewashandhightemperaturesforlaundry
that is not heavily soiled or stained.
• Ifyouplantodryyourlaundryinadryer,selectthe
highest spin speed recommended during washing
process.
• Donotusedetergentinexcessoftheamount
recommended on the detergent package.

8/ EN Washing Machine / User’s Manual
Detergent Drawer
The detergent drawer is composed of three compartments:
– (1) for prewash
– (2) for main wash
– (3) for softener
– (*) in addition, there is siphon piece in the softener
compartment.
1
3
2
Detergent, softener and other cleaning agents
• Adddetergentandsoftenerbeforestartingthewashing
programme.
• Neverleavethedetergentdraweropenwhilethewashing
programme is running!
• Whenusingaprogrammewithoutprewash,donot
put any detergent into the prewash compartment
(compartmentnr."1").
• Inaprogrammewithprewash,donotputliquiddetergent
intotheprewashcompartment(compartmentnr."1").
• Donotselectaprogrammewithprewashifyouareusing
adetergentbagordispensingball.Placethedetergent
bag or the dispensing ball directly among the laundry in
the machine.
• Ifyouareusingliquiddetergent,donotforgettoplace
the liquid detergent cup into the main wash compartment
(compartmentnr."2").
Choosing the detergent type
The type of detergent to be used depends on the type and
colour of the fabric.
• Usedifferentdetergentsforcolouredandwhitelaundry.
• Washyourdelicateclothesonlywithspecialdetergents
(liquid detergent, wool shampoo, etc.) used solely for
delicate clothes.
• Whenwashingdarkcolouredclothesandquilts,itis
recommended to use liquid detergent.
• Washwoolenswithspecialdetergentmadespecifically
for woolens.
Awarning: Useonlydetergentsmanufacturedspecifically
for washing machines.
warning: DonotusePowderedSoap.
3.4 Initial use
Before starting to use the product, make sure that all
preparations are made in accordance with the instructions in
sections“Importantsafetyinstructions”and“Installation”.
To prepare the product for washing laundry, perform first
operationinDrumCleaningprogramme.Ifyourproduct
is not equipped with Drum Cleaning programme, perform
theInitialUseprocedureinaccordancewiththemethods
describedunder“5.2Cleaningtheloadingdoorandthe
drum”sectionoftheusermanual.
CUseananti-limescalesuitableforthewashingmachines.
Some water might have remained in the product due to
thequalitycontrolprocessesintheproduction.Itisnot
harmful for the product.
3.5 Correct load capacity
The maximum load capacity depends on the type of laundry,
the degree of soiling and the washing programme desired.
The machine automatically adjusts the amount of water
according to the weight of the loaded laundry.
Awarning: Followtheinformationinthe“Programme
andconsumptiontable”.Whenoverloaded,machine's
washing performance will drop. Moreover, noise and
vibration problems may occur.
3.6 Loading the laundry
1.Opentheloadingdoor.
2.Placelaundryitemslooselyintothemachine.
3.Pushtheloadingdoortocloseuntilyouhearalocking
sound. Ensure that no items are caught in the door.
CThe loading door is locked while a programme is running.
The door can only be opened a while after the programme
comes to an end.
Awarning: Incaseofmisplacingthelaundry,noiseand
vibration problems may occur in the machine.
3.7 Using detergent and softener
CWhen using detergent, softener, starch, fabric dye, bleach
or limescale remover read the manufacturer's instructions
on the package carefully and follow the suggested dosage
values.Usemeasuringcupifavailable.

9/ EN Washing Machine / User’s Manual
Adjusting detergent amount
The amount of washing detergent to be used depends
on the amount of laundry, the degree of soiling and water
hardness.
• Donotuseamountsexceedingthedosagequantities
recommended on the detergent package to avoid
problems of excessive foam, poor rinsing, financial
savings and finally, environmental protection.
• Uselesserdetergentforsmallamountsorlightlysoiled
clothes.
Using softeners
Pourthesoftenerintothesoftenercompartmentofthe
detergent drawer.
•Donotexceedthe(>max<)levelmarkinginthesoftener
compartment.
•Ifthesoftenerhaslostitsfluidity,diluteitwithwater
before putting it in the detergent drawer.
Using liquid detergents
If the product contains a liquid detergent cup:
• Makesurethatyouhaveplacedtheliquiddetergentcup
incompartmentnr."2".
•Iftheliquiddetergenthaslostitsfluidity,diluteitwith
water before putting in the detergent cup.
If the product does not contain a liquid detergent
cup:
• Donotuseliquiddetergentfortheprewashina
programme with prewash.
• Liquiddetergentstainsyourclotheswhenusedwith
DelayedStartfunction.IfyouaregoingtousetheDelayed
Start function, do not use liquid detergent.
Using gel and tablet detergent
Apply the following instructions when using tablet, gel and
similar detergents.
• Ifthegeldetergentthicknessisfluidalandyourmachine
does not contain a special liquid detergent cup, put the
gel detergent into the main wash detergent compartment
duringfirstwaterintake.Ifyourmachinecontainsaliquid
detergent cup, fill the detergent into this cup before
starting the programme.
• Ifthegeldetergentthicknessisnotfluidalorintheshape
of capsule liquid tablet, put it directly into the drum before
washing.
• Puttabletdetergentsintothemainwashcompartment
(compartmentnr.“2”)ordirectlyintothedrumbefore
washing.
CTablet detergents may leave residues in the detergent
compartment.Ifyouencountersuchacase,placethe
tablet detergent between the laundry, close to the lower
part of the drum in future washings.
Usethetabletorgeldetergentwithoutselectingthe
prewash function.
Using starch
• Addliquidstarch,powderstarchorthefabricdyeintothe
softener compartment.
• Donotusesoftenerandstarchtogetherinawashing
cycle.
• Wipetheinsideofthemachinewithadampandclean
cloth after using starch.
Using bleaches
• Selectaprogrammewithprewashandaddthebleaching
agent at the beginning of the prewash. Do not put
detergent in the prewash compartment. As an alternative
application, select a programme with extra rinse and add
the bleaching agent while the machine is taking water
from the detergent compartment during first rinsing step.
• Donotusebleachingagentanddetergentbymixing
them.
• Usejustalittleamount(approx.50ml)ofbleachingagent
and rinse the clothes very well as it causes skin irritation.
Do not pour the bleaching agent onto the clothes and do
not use it for coloured clothes.
• Whenusingoxygenbasedbleaches,selectaprogramme
that washes at a lower temperature.
• Oxygenbasedbleachescanbeusedtogetherwith
detergents; however, if its thickness is not the same
with the detergent, put the detergent first into the
compartmentnr.“2”inthedetergentdrawerandwait
until the detergent flows while the machine is taking
in water. Add the bleaching agent from the same
compartment while the machine is still taking in water.
Using limescale remover
•Whenrequired,uselimescaleremoversmanufactured
specifically for washing machines only.

10 / EN Washing Machine / User’s Manual
3.8 Tips for efficient washing
Clothes
Light colours and whites
(Recommended temperature range based
on soiling level: 40-90 °C)
Soiling Level
Heavily Soiled
(difficult stains
such as grass,
coffee, fruits and
blood.)
Itmaybenecessarytopre-treatthestains
orperformprewash.Powderandliquid
detergents recommended for whites can be
used at dosages recommended for heavily
soiledclothes.Itisrecommendedtouse
powder detergents to clean clay and soil
stains and the stains that are sensitive to
bleaches.
Normally Soiled
(For example,
stains caused by
body on collars
and cuffs)
Powderandliquiddetergentsrecommended
for whites can be used at dosages
recommended for normally soiled clothes.
Lightly Soiled
(No visible stains
exist.)
Powderandliquiddetergentsrecommended
for whites can be used at dosages
recommended for lightly soiled clothes.
Colours
(Recommended temperature range based
on soiling level: cold -40 °C)
Soiling Level
Heavily Soiled
Powderandliquiddetergentsrecommended
for colours can be used at dosages
recommendedforheavilysoiledclothes.Itis
recommended to use powder detergents to
clean clay and soil stains and the stains that
aresensitivetobleaches.Usedetergents
without bleach.
Normally Soiled
Powderandliquiddetergentsrecommended
for colours can be used at dosages
recommended for normally soiled clothes.
Usedetergentswithoutbleach.
Lightly Soiled
Powderandliquiddetergentsrecommended
for colours can be used at dosages
recommendedforlightlysoiledclothes.Use
detergents without bleach.
Clothes
Dark colours
(Recommended temperature range based
on soiling level: cold -40 °C)
Soiling Level
Heavily Soiled
Liquid detergents suitable for colours
and dark colours can be used at dosages
recommended for heavily soiled clothes.
Normally Soiled
Liquid detergents suitable for colours
and dark colours can be used at dosages
recommended for normally soiled clothes.
Lightly Soiled
Liquid detergents suitable for colours
and dark colours can be used at dosages
recommended for lightly soiled clothes.
Delicates/Woollens/Silks
(Recommended temperature range based
on soiling level: cold -30 °C)
Soiling Level
Heavily Soiled
Preferliquiddetergentsproducedfor
delicate clothes. Woollen and silk clothes
must be washed with special woollen
detergents.
Normally Soiled
Preferliquiddetergentsproducedfor
delicate clothes. Woollen and silk clothes
must be washed with special woollen
detergents.
Lightly Soiled
Preferliquiddetergentsproducedfor
delicate clothes. Woollen and silk clothes
must be washed with special woollen
detergents.
