Belkin F8T051 User manual

Bluetooth™
GPS Receiver
Use your mobile device
as a wireless navigation
system
User Manual
F8T051
En
Fr
De
Nl
Es
It
F8T051_man.qxd 2/9/04 9:19 AM Page 1

Bluetooth™
GPS Receiver
Use your mobile device
as a wireless navigation
system
User Manual
F8T051
En
F8T051_man.qxd 2/9/04 9:20 AM Page 2

TABLE OF CONTENTS
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Selecting and loading maps tou your handheld device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Using the software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
by Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
by Intersection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
by Points of Interest. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
from Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
from Favourites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
from Recents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Safety Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Speed Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Fog Driving Assistance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Destination Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Detour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Stopover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Route Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Display Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Creating and Editing the Favourites List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Recording a Track . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Playing Back a Track . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Panning and Zooming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Volume Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Copyright and Trademark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
1
F8T051_man.qxd 2/9/04 9:20 AM Page 4

2
SELECTING AND LOADING MAPSINSTALLATION
3
Selecting and loading maps to your handheld device
1. Connect your handheld device to your PC
2. Start the map loader program on your PC. Click Start, Programs, Belkin, Navigation System, Map
Loader
3. Click on the areas of the map that you want to transfer to your handheld device
4. Select where you want to copy the maps to by clicking on the “Location” box at the bottom of the map
loader screen. Choose either “Pocket PC Storage Card” or “Pocket PC Main Memory.”
5. Check the memory status to confirm that your handheld device has sufficient memory
6. Click OK to begin transfer
Maps can also be transferred to your storage card thru a USB card reader or a PC card (PCMCIA) adapter.
Belkin Navigation System is designed to run on handheld devices running the Microsoft Pocket PC
operating system. Since the map of the entire United States is very large and will not fit on most
handheld devices, you must use the companion map loading software on your desktop PC (or laptop) to
select the portion of the map that you need and transfer it to your handheld device. When you travel to a
different area of the country and need a different map, the map loader will let you change the maps on
your handheld device.
(!) Advisory - Make sure your handheld device's ActiveSync software is installed before you install the
Belkin Navigation System.
(!) Advisory - Make sure your handheld device is connected to your desktop (or laptop) and is turned on
before installing Belkin Navigation System.
Please close all programs except Microsoft's ActiveSync program. Insert the Belkin Navigation System CD-
ROM into your CD-ROM drive. If the setup program does not automatically start, click Start, Run, then
type “D:\setup.exe” where D: is the drive letter of your CD-ROM, and press Enter. Follow the directions in
the ensuing dialog boxes.
F8T051_man.qxd 2/9/04 9:20 AM Page 2

Selecting and loading maps via USB card reader or PC card adapter
1. Make sure the USB card reader or PC card adapter is plugged in and the storage card is inserted.
2. Start the map loader program on your PC. Click Start, Programs, Belkin, Navigation System, Map Loader.
3. Click on the areas of the map that you want to transfer to your handheld device
4. Select where you want to copy the maps to by clicking on the “Location” box at the bottom of the map
loader screen. The storage card should appear as a drive letter, e.g. “E:.”
5. Check the memory status to confirm that your storage card has sufficient memory
6. Click OK to begin transfer
SELECTING AND LOADING MAPS
4
USING THE SOFTWARE
5
To Enter a Destination by Address
1. Tap Menu, Destinations, Address.
2. Tap Change to select the city in which to search.
3. Tap Street First to enter the street name first or City First to entry the city name first.
If you've selected Street First
4. Enter street name and tap OK.
(!) Advisory - DO NOT ENTER STREET TYPE. For Main Street just enter Main.
5. Enter house number and tap OK.
6. From the match list, select the desired address.
7. Tap Nav to navigate to this location or;
8. Tap Fav to add this location to your Favourites list or;
9. Tap Map to set this location as your starting point and see the location on the map.
F8T051_man.qxd 2/9/04 9:20 AM Page 4

7
USING THE SOFTWARE
6
USING THE SOFTWARE
If you've selected City First
4. Enter city name and tap OK.
5. Enter street name and tap OK.
(!) Advisory - DO NOT ENTER STREET TYPE. For Main Street just enter Main.
6. Enter house number and tap OK.
7. From the match list, select the desired address.
8. Tap Nav to navigate to this location or;
9. Tap Fav to add this location to your Favourites list or;
10. Tap Map to set this location as your starting point and see the location on the map.
(i) Information - If a large number of records are found by the Street First method, the program will
automatically revert to City First method.
To Enter a Destination by Intersection
1. Tap Menu, Destinations, Intersection.
2. Tap Change to select the state in which to search.
3. Tap either Street First to enter the street name first or City First to enter the city name first.
If you've selected Street First
4. Enter street name and tap OK.
(!) Advisory - DO NOT ENTER STREET TYPE. For Main Street just enter Main.
5. Enter the name of the cross street and tap OK.
(!) Advisory - DO NOT ENTER STREET TYPE. For Main Street just enter Main.
6. From the match list, select the desired intersection.
7. Tap Nav to navigate to this location or;
8. Tap Fav to add this location to your Favourites list or;
9. Tap Map to set this location as your starting point and see the location on the map.
F8T051_man.qxd 2/9/04 9:20 AM Page 6

USING THE SOFTWARE
To Enter a Destination by Points of Interest
1. Tap Menu, Destinations, Points of Interest.
2. Tap one of the categories for Points of Interest.
3. Select Alphabetical or By Distance within 10 miles or Alphabetical under List All.
If you've selected Alphabetical
4. Enter the name of the destination.
5. Select a matching POI location from the list.
6. Tap OK to accept the location. The location details will be shown.
7. Tap Nav to navigate to this location or;
8. Tap Fav to add this location to your Favourites list or;
9. Tap Map to set this location as your starting point and see the location on the map.
If you've selected By Distance
4. Select a POI
5. Tap Nav to navigate to this location or;
6. Tap Fav to add this location to your Favourites list or;
7. Tap Map to set this location as your starting point and see the location on the map.
USING THE SOFTWARE
If you've selected Street First
4. Enter city name and tap OK.
5. Enter the name of the city and tap OK.
6. Enter street name and tap OK.
(!) Advisory - DO NOT ENTER STREET TYPE. For Main Street just enter Main.
7. Enter the name of the cross street and tap OK.
(!) Advisory - DO NOT ENTER STREET TYPE. For Main Street just enter Main.
8. From the match list, select the desired intersection.
9. Tap Nav to navigate to this location or;
10. Tap Fav to add this location to your Favourites list or;
11. Tap Map to set this location as your starting point and see the location on the map.
(i) Information - If a large number of records are found by the Street First method, the program will
automatically revert to City First method.
9
8
F8T051_man.qxd 2/9/04 9:20 AM Page 8

USING THE SOFTWARE
To Enter a Destination from Recents
1. Tap Menu, Destinations, Recents.
2. Select the destination.
3. Tap Nav to navigate to this location or;
4. Tap Map to set this location as your starting point and see the location on the map or;
5. Tap Edit to create a label such as HOME for this destination or change the label if one already exists
or;
6. Tap Del to delete this location from your Recent list.
USING THE SOFTWARE
To Enter a Destination from Contacts
(!) Advisory - This feature obtains the list of names from the Outlook's Contacts list. You must first
create or have already created one using the Contacts application. In order for Belkin Navigation
System to find a match for the address, the contact's information must be accurate. In some cases, a
match to an abbreviated word may not be found.
1. Tap Menu, Destinations, Contacts.
2. Select a name from the list.
3. Tap Home, Office, or Other to set it as the destination.
To Enter a Destination from Favourites
1. Tap Menu, Destinations, Favourites.
2. Select a destination from the list if you have already created one.
3. Tap Nav to navigate to this location or;
4. Tap Map to set this location as your starting point and see the location on the map or;
5. Tap Edit to create a label such as HOME for this destination or change the label if one already
exists or;
6. Tap Del to delete this location from your Favourites list.
11
10
F8T051_man.qxd 2/9/04 9:20 AM Page 10

Safety features
To Set the Speed Alert
Speed Alert notifies you with an audible sound when you have exceeded the target speed. Target speed
can be set to a fixed speed or automatically to the speed class of the roadway.
! Warning - Auto Speed Alert (using the roadway speed class) should only be used for information and
should not be used as an indicator for legal speed limits or safe driving speeds. Drivers should abide by
the law and use best judgment for safe driving at all times.
1. Tap Menu, Speed Alert to open the Speed Alert screen.
2. Check the Enable Auto Speed Alert box.
3. Tap OK to accept the changes or Cancel to reject.
- or -
1. Check the Enable Fixed Speed Alert box.
2. Enter the target speed using the numeric keypad on the screen.
3. Tap OK to accept the changes or Cancel to reject.
USING THE SOFTWARE USING THE SOFTWARE
13
To Enable Fog Driving Assistance
Belkin Navigation System provides a Safety Feature to notify you when an intersection is approaching.
This safety measure helps you to become more aware of incoming traffic and traffic signals, which is
especially needed during foggy conditions. When approaching a 4-way intersection, you will hear a
special "dong" tone.
1. Tap on the command Tools, Safety Features.
2. Tap Fog Driving to toggle on and off.
Destination options
To Set a Detour
Belkin Navigation System offers the ability to detour around a section of street that you are currently
driving on. The Detour feature will only be present if a destination has been entered.
1. Tap Menu, Destinations. Your current destination will be shown.
2. Tap Detour and you will be presented with three distance options to avoid on your current street.
3. Tap one of the distance buttons to create a Detour route.
To Cancel Detour and Revert Back to the Original Route
1. Tap Menu, Destinations. Your current destination will be shown.
2. Tap Detour, Reset.
12
F8T051_man.qxd 2/9/04 9:20 AM Page 12

USING THE SOFTWAREUSING THE SOFTWARE
To Add a Stopover
Stopover is a feature that allows you to set an intermediate destination after you've selected a final
destination. For example, if you are traveling from Paris to Amsterdam, where Amsterdam is your final
destination, you can enter a Stopover for a rest break along the way. The Stopover feature will only be
present if a destination has been entered.
1. Tap Menu, Destinations. Your current destination will be shown.
2. Tap Stopover then enter a new destination.
3. Belkin Navigation System will route you to the Stopover destination.
4. Once you have reached your Stopover, Belkin Navigation System will ask
you if you want to proceed to your original destination.
To Cancel Your Stopover Destination and Revert Back to Your Original Destination
1. Tap Menu, Destinations. Your current destination will be shown.
2. Tap Clear Dest.
3. Tap Yes when prompted to continue to original destination.
To Set the Route Options
1. Tap Menu, Route Opts to open the Route Options screen.
2. Select the desired options
3. Tap OK to accept or Cancel to reject changes
Method: Selects the method of routing. The quickest route, shortest route, route that favors major roads,
or route that favors local roads.
Toll Roads: Selects whether toll roads should be included or excluded in the route calculation.
Carpools: Selects whether carpool lanes (High Occupancy Vehicle lanes) should be included or excluded in
the route calculation.
To Set the Display Options
1. Tap Menu, Display Opts to open the Display Options screen.
2. Select the desired option(s).
3. Tap OK to accept or Cancel to reject change(s)
Map Orientation: Orients the Map screen so that the driving direction is pointing up or North is pointing up.
Colour Scheme: Sets colour scheme to Day or Night mode. Auto setting changes from Day to Night mode
automatically at approximately sunrise and sunset.
Guidance Screen: Sets the Guidance screen to automatically switch when getting closer to a turn
maneuver, or have it appear only when manually selected.
1514
F8T051_man.qxd 2/9/04 9:20 AM Page 14
