Belling FW914 Whi User manual

Belling FW914 Whi
Washing Machine User Manual

2
Contents
Product support
Troubleshooting 36
Help and assistance 37
Declaration of conformance to product
standards 38
Disposal 39
7
Safety information
Safety information 6
Getting to know your
washing machine
Ready? Let’s begin 10
Accessories 12
Installing your washing
machine
Installation requirements 14
Unpacking 14
Connections (electrical, water, gas) 15
Functions
Functions 18
Using your washing machine
First use of washing machine 24
Standard and advanced functions/use 25
Care and Maintenance
Cleaning 30
Maintenance actions 30
Technical specifications 32
1
2
3
4
5
6

Safety information
Important - Please read these instructions fully before
installing or operating
3
If the supply cord is damaged,it
must be replaced by the
manufacturer,its service agent or
similarly qualified persons in order
to avoid a hazard.
The new hose-sets supplied with
the appliance are to be used and
that old hose-sets should not be
reused.
This washing machine is for indoor
use only.
The openings must not be
obstructed by a carpet.
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical,sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safeway and understand the
hazards involved.
Cleaning and maintenance shall
not be made by children without
supervision.
This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of
• the appliance by a person
responsible for their safety.
Pull out its plug from the power
socket before cleaning or
maintenance.
Make sure that all pockets are emptied
before putting them into this machine,
Shape and rigid items, such as icons,
nails,screws or stones etc. may cause
serious damage.
Please check whether the water inside
the drum has been drained before
opening its door.Please do not open
the door if there is any water visible.
Pls keep the door closed when not
in use to prevent pets and children
climbing into the machine, always
Glass door may be very hot during
the operation.Keep children and pets
far away from the machine during
the operation.
Ensure that the installed power vltage
frequency match those of washing
machine.
Do not use any socket with rated
current less than that of washing
machine.Never pull out power plug
with wet hands.
To ensure your safety the plug must
be inserted into an earthed three-pole
socket. Check carefully and make
sure that your socket is correctly
earthed.
•
•
•
•
•
•
•
•
•
•
•
•
•
1
check the machine before every
operation.

Children of less than 3 years should
be kept away unless continously
supervised.
Do not let kids play with the
machine.
Packing materials may be
dangerous to the children . Please
keep all packing materials (plastic
bags,foams etc) far away from the
children.
Washing machine should not be
installed in bathrooms, wet rooms
or rooms with explosive or caustic
gases.
4
Safety information
Important - Please read these instructions fully before
installing or operating
Make sure that the water and
electrical devices are connected by
a qualified technician in accordance
with the
and
local safety regulations.
Before operating this machine please
all packaging and transport bolts must
be removed, otherwise serious
damage may occur.
Before washing any clothes, please
run your first washing process empty
with detergent under the
program
The washing machine with single
inlet valve only can be connected
to the cold water supply. The
washing machine with double inlet
valves can be connected to the hot
water and cold water supply.
Flammable and explosive or toxic
solvents are forbidden.Gasoline and
alcohol etc.Shall not be used as
detergents.Please only select the
detergents suitable for machine
washing, especially for drum.
It is forbidden to wash carpets.
Be careful of burning when washing
machine drains hot washing water.
Never refill the water by hand during
washing.
After the program is completed,
Please wait for two minutes to open
the door.
If the appliance is not to be used for
a prolonged period of time please
unplug the appliance and isolate the.
Do not climb up and sit on top cover
of the machine. Do not lean against
against machine door.
Please do not close the door with
excessive forces.If it is found difficult
to close the door,please check if the
excessive clothes are put in or
distributed well.
The household washing machine
isn't intended to be built-in.
Cautions during moving/Re-positing
1.Transport bolts shall be reinstalled
to the machine by a specialized
person.
2.Any excess water should be drained
out of the machine.
3. Handle the machine carefully, the
Never hold each protruded part on
the machine while lifting. Machine
door can not be used as the handle
during the conveyance.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
manufacturer's instructions
Your washing machine is only
for home use and is only
designed for the textiles suitable
for machine washing.
• Your washing machine is only
for home use and is only
designed for the textiles suitable
•
water supply.
machine door cannot be used as
lifting handle.
the Machine
“Cottons 90℃”.

Getting to know your washing machine
You’ll be up and running in no time
5
Ready? Let’s begin...
Please read these instructions carefully. They contain
important information which will help you get the best
from your and ensure safe and washing machine
correct installation and operation.
If you require any further assistance, our technical
experts are happy to help. For full details, refer to
the product support section at the end of these
instructions.
2

Component
1.Detergent Drawer 7.Transport bolt x 4
5 6
7
7 7
7
8
6
4.Control Panel
5.Power lead
3.Filter 6.Drain hose
1
2
3
4
5
6
2.Door
Getting to know your washing machine
You’ll be up and running in no time
8.Water inlet

Accessories
This machine includes below accessories,please install
these parts by yourself before operating.
• plastic hole plug x 4
• Inlet hose
Tools
You may use this tools to help install above parts
•
•
glove
spanner
7
Getting to know your washing machine
You’ll be up and running in no time
Model capacity Spin Speed Energy class
Belling FW914 Whi 9kg 1400rpm A+++

Installing your washing machine
Bringing it all together
Installation requirements
Levelling feet
In addition to the instructions mentioned here,
special regulations of the relevant water and
companies may apply. If in doubt, have the
washing machine connected by a qualified
technician.
The washing machine is heavy - caution when
lifting it.
Do not lift by projecting components (e.g.
washing machine door).
Warning: Frozen hoses may tear/burst. Do not
install washing machine in outdoor areas or
where there is a risk of frost.Please operate
washing machine above 0℃.
Lay hoses and cables in such a way that there is
of tripping over them.no risk
An additional space (approximately 120mm) is
required at the rear of the washing machine.
This is to allow
hose and drain hose connections.
enough space for the water
Unpacking
Unpacking your washing machine
Caution:2 people are required to unpack the
washing machine,it is recommended that gloves
are worn.
Carefully remove all packing materials including
the foam base, dispose of correctly.
Note:When opened,water droplets may be visible
in the drum etc. this is normal as each appliance
is tested before delivery.
Removing the transport bolts
Important:The bolts are designed to
support the internal components during transit
these MUST be removed before use.
2:Remove the bolts by pulling them.( 3)
transport
Fig
1:For your machine to work efficiently with
minimum vibration it should be settled on flat,
nonslippery,firm ground.
2:You can adjust the balance of your machine by
changing the positioning of its feet.
3:First,loosen the plastic adjustment nut.(Fig 5)
4:Adjust by rotating the feet upwards or
downwards.(Fig 6)
5:After the desired position has been reached,
tighten the plastic adjustment nut again by rotating
it upwards.
Note:Never put cartons,wooden blocks or similar
materials under the machine to balance
irregularities in the level of the ground.
Fig1 Fig2
•
•
•
•
•
Fig3 Fig4
Fig5 Fig6
1:Loosen the screws by rotating counterclockwise
with a suiltable wrench,(Fig 1 2)
3:When the transport bolts have been removed,
insert the plastic transport screw taps found in
the accessories bag into the holes.(Fig 4)
3
8

Connections Electrical
Water inlet hose connections
Important:This washing machine MUST only be
connected to a cold water supply.
1:Connect the water inlet hose,the angled
connection attaches to the water inlet on the
back of the washing machine.(Fig 7)
2:The straight connection attaches to the water
supply valve.(Fig 8)
3:Ensure all seals are in place before connecting.
Important:Only tighten the hose connection nut
by hand - do not overtighten.
Drain hose connections
Important:The height of the top of the curve in
the drain hose MUST be between 60 - 100cm
from the floor.(Fig 9)
Drain hose can be fitted to the drainer or
a wash basin.
Max.100cm
Min.60cm
Fig7
Fig8
Fig9
Any electrical work that is required to
install this appliance MUST be carried
out by a qualified electrician.
Warning:THIS APPLIANCE MUST BE
EARTHED
Before making any electrical connections,
ensure that:
Electrical safety is only guaranteed when the
earth system of your house is in accordance
with the related local regulations.
•
• Do not bend, stretch or pull the supply cable
to avoid electric shock.
• Ensure the power socket is suiable for the
maximum power of the machine (fuses in the
power circuit must be 13 amp).
• The supply voltage should be the same as that
indicated in the technical specifications and
the applicance rating plate.
• The appliance should be earthed and in
complicance with the applicable law.
• When installed,the power socket must be
within easy reach.
• If the socket outlets in your home are not
suitable for the plug supplied with this unit
check with a qualified electrician for
replacement.
• To avoid the risk of overloading your plug
socket, the use of adapters, multiple connectors
• The applicance must be connected to a
220-240 volt 50Hz AC supply by means of
a three pin socket, suitably earthed and
protected by a 13 amp fuse.
• Should the fuse need to be replaced , a 13
amp fuse approved to BS 1362/A must be
used.
• The plug contains a removable fuse cover
that must be refitted when the fuse is replaced.
if the fuse cover is lost or damaged, the plug
must not be used until a replacement cover
has been fitted or the plug is replaced.
• A damaged plug should be cut off as close to
the plug body as possible , the fuse should be
removed and the plug disposed of safely.
Installing your washing machine
Bringing it all together
or extension cables are not recommended.
9

Plug replacement (UK lreland only)&
Should you need to replace the plug;the wires
in the power cable are coloured in the following
way:
Blue - Neutral ’ N’
Brown - Live ’ L’
Green Yellow - Earth ’E’ &
As the colour of the wires in the power cable
may not correspond with the coloured markings
identifying the terminals in your plug,and
proceed as follows(Fig10):
The green yellow wire must be connected to
the terminal in the plug that is marked with the
letter E or by the earth symbol.
&
The blue wire must be connected to the terminal
that is marked with the letter N.
The brown wire must be connected to the terminal
that is marked with the letter L.
If power supply cord is damaged , it must replaced
by the manufacturer or its service agent or a
similar qualified person in order to avoid a hazard.
Fig10
Installing your washing machine
Bringing it all together
10

Simple everyday use
11
Introduction of control panel
4
Programme
For the convenience of users to washing
clothes with the different programme.
Start/Pause
Press the button to start or pause the wash cycle
On/Off
Press once to turn the washing machine on, press again to turn the washing machine off.
Notes: 1.The Control panel line chart is for reference only,Please refer to real product as standard.
2.The Control panel could be changed without written notice. Please visit the website of Washing Machine or call up the service line for
consultation. 3.When the lights of Speed (400,800,1200,1400,1600) are off means the speed is 0.
Function setting
Press the button repeatedly to set the delaying time
Temp.,speed and so on.
Speed
1400: 400-800-1200-1400 1600:400-800-1200-1400-1600
400 800 1200 1400
Display
Plus Wash
Extra Rinse
Prewash
Delay
My Wash
RinseWash
Less Iron
Intensive Wash
Spin
Time Saver
Child Lock
Stain
Door Lock

Simple everyday use
Introduction of control panel
12
Delicate
You can select this procedure to wash your
delicate clothes. Its washing movement is
gentler and spin speed is less compared
with the procedure “Synthetic”. It is
recommended for the articles to be
washed softly.
Wool
You can select this procedure to wash the
wool textiles labeled with “Machine Wash”.
Please select the proper washing
temperature according to the label on the
articles to be washed. Furthermore, the
proper detergent shall be selected for wool
textiles.
Colours
You can choose the program washing
brightly coloured clothing, it can protect the
bright colour better .
Spin Only
Separate spin only procedure. Soap water
or rinse water shall be drained out before
spinning.
Quick
This procedure is suitable for washing few
and not very dirty clothes quickly.
Turning the machine on
Plug in your machine. Place the laundry in the
machine and add detergent and softener. Press
the "on/off" button.
program selection
The main washing procedures depend on the types
of the clothes to be washed as follows:
Main program
Depending on the type of textile, the following main
programs are avaiblable: Each of these main
programs comprise of a complete washing process,
including washing, rinsing and, if required, spin
cycles.
Synthetic
You can select this procedure to wash
the quite delicate clothes. The
procedure is shorter compared with
that for cottons and the washing
movement is quite gentle.It is
recommended to wash synthetic articles,
for example: shirts, coats, blending. As for
curtains and laced textiles, the procedure
“Synthetic ” shall be selected. While
washing the knitting textiles, detergent
quantity shall be reduced due to its loose
string construction and easily forming
bubbles.
•
•
•
•
•
•
•
Rinse&Spin
Separate Rinse&Spin Procedure.
Drain Only
Separate Drain only Procedure.
•
Mix
•
Cotton
Cotton ECO
This is the most energy efficient
programme to clean all kinds of soiled
cotton laundry.
•
•
Baby Care
You can select this procedure to wash
your baby’s clothes, it can make the
baby's wear cleaner and make the
rinse performance better to protect
the baby skin.
•
Suitable for textiles made of cotton or
linen, for example coats, bed sheets,
towels, etc.
This program is suitable for daily wash.
Cotton / Synthetic / Jeans / Kids textiles
can all be mixed and washed together with
like colours. Do not use this programme for
wool and delicate clothes such as silks.
First, switch the program knob to select
suitable program according to the types
of textiles.
Second, select a proper temperature
by following the care instructions on
the clothes.
Last, select the proper spin speed.
Generally, the higher temperature
will consume more energy; the higher
spin speed will cause more noise.
PLEASE NOTE: to protect the clothes, the delicate
lower spin speed shall be selected.

Simple everyday use
13
Introduction of control panel
•
Prewash
The indicator of prewash will light up on the
display.
The Prewash function can get an extra wash
before main wash.
Time Saver
The function can decrease the washing time.
Extra Rinse
The laundry will undergo extra rinse once after
you select it.
Delay
Delay function can be set with this button, the
delaying time is 0-24 H.
Set the Delay function:
1. Select a programme;
2.Press the Delay button to choose the time;
3.Press Start/Pause to commence the delay
operation.
Cancel the Delay function: Press the Delay
button until the display will be 0H.It should be
pressed before starting the program. If the
program already started, should press the
On/Off button.
Notes: If there is any break in the power supply
while the machine is operating, a special
memory stores the selected programme and
when the power is restarted, press the
Start/Pause button the left time is continues.
Auxiliary function
These functions can be used based on
main program, you can press these
functions after you chose the main
program.
Note: you can't use these functions after
the main program started.
•
Sports Wear
You can select this procedure to wash the
activewear.
Jeans
This program is specially designed for washing
jeans.
Hand Wash
As for few light dirty clothes, the default
temperature of washing is cold.
My Wash
Press Spin 3sec. for my cycle to memory the
procedure. The default my cycle is cotton.
•
•
•
•
•
•
Stain
•
This function can be adjusted depending on the
amount of stains on the clothes to be washed,
this will adjust the wash cycle accordingly.
There are 3 levels that can be selected,
“Light", "Normal" and "Heavy".
•
Plus Wash
This function can be used to add any items that have
been missed from the wash load once the wash
cycle has started.
To operate this function please follow the
steps below:
Child Lock
To avoid that the washing procedure cannot operate
normally due to the mis operation by kids during the
washing procedure, you can select this function, In
this case, the other buttons except On/Off button
can not work, at this state ,the machine power off
when press the key on/off. The machine remembers
the program child lock and the program during
powered off when press the key on/off again.
Press Extra Rinse and Pre Wash together 3 seconds
during the running procedure, the buzzer will beep ,
Start/Pause button as well as the rotary switch are
locked. Press the two buttons for 3 seconds together
and buzzer will beep to release to locking. But cut
off the power supply , the kid’s protection is also
release to locking. The kid’s protection will not be
cancelled after all procedures are completed.
Suppression of the acoustic signals
This is an additional buzzer function on your
appliance. After deactivating the buzzer function,
the buzzer will be closed. After starting the machine,
press the “Temp.&Spin” button for 3 seconds and
you will hear a beep, then the buzzer will be closed.
To restart the buzzer function, press the
“Temp.&Spin”button again for 3 seconds. The setting
will be kept until the next reset.
Warning: After deactivating the buzzer function, the
sounds will not be activated any more.
- Bubble Removal Function
Bubble Check Function: Redundant bubbles will
occur when there is excessive detergent, which will
affect wash and rinse effects. The procedure will
check automatically and one bubble removal
procedure will be added automatically to remove
bubbles when excessive bubbles are checked.
•
•
1.Press and hold the “Start/Pause” button
for 3 seconds.
2.Wait for the drum to stop rotating and the door
lock to be released.
3.Open the door and add the garments that
have been missed.
4.Close the door and repress the
“Start/Pause” button.

Note : Water and power consumption and programme duration may differ from the table shown,
subject to changes in water pressure, water hardness and temperature, ambient temperature, type
and amount of laundry, selection of auxiliary functions, and fluctuations in the supply voltage.
- Half load for 9.0Kg machine:4.5Kg.
● Means must ○ Means optional Means not necessary
Simple everyday use
Program Selection Guide - 9
kg washing machine(Belling FW914 Whi)
14
1) Test wash cycle in compliance with directive : Set Cotton ECO with temperature
of 60C
- This cycle is designed for cotton loads with a normal soil level and is the most efficient in
terms of both electricity and water consumption; it should be used for garments which can be
washed at 60C. The actual washing temperature may be differ from the indicated value.
2) Test wash cycle in compliance with directive 2010/30/EU : Set Cotton ECO with temperature
of 40C
- This cycle is designed for cotton loads with a normal soil level and is the most efficient in
terms of both electricity and water consumption; it should be used for garments which can be
washed at 40C. The actual washing temperature may be differ from the indicated value.
2010/30/EU
o
o
o
o
Load(kg) Detergent Box
Procedure
Description
Default Speed
(RPM)
Default Time (H)
Delay
Default Temp.
(℃)
Softener
Case
1400
9.0kg
1400
Cotton
40 800
Jeans
60 800
Baby Care
30 800
Hand Wash
Cold 800
Mix
40 800
Synthetic
40 800
Drain Only
Spin Only
×1200
Rinse&Spin
1200
Cotton ECO
60 1400
Colors
Cold 1200
Quick15'
Cold 800
Wool
40 800
Delicate
30 800
Rapid45'
Intensive
wash
40 800
Less iron
Prewash
2:40
1:45
1:20
1:00
1:13
1:40
0:01
0:12
0:20
3:41
1:10
0:15
1:07
0:50
0:45
Extra rinse
9.0
9.0
9.0
9.0
2.0
9.0
4.5
9.0
9.0
9.0
4.5
2.0
2.0
2.5
2.0
Time saver

Using your washing machine
Getting the most from your appliance
15
Read
to help you sort your washing into
different loads.
the washing label on each garment
Sort the laundry by colour, type of fabric
and by how soiled it is. This will help you
choose the correct programme and
temperature for each wash.
Do not exceed the maximum load! See
the programme selection table for the
maximum
require. load for the programme you
Treat stains before washing.
Some items should be put into a cleaning
net before going into the washing
machine. i.e. bras with metal wires, tights
and lace clothing to prevent damage.
•Check that pockets do not contain any
objects which may damage your clothes
and the washing machine.
Tie up any loose strings on laundry, close
zippers and reverse clothing with zips
inside out.
To prevent any large, heavy objects (e.g.,
buckles, large buttons, etc.) from hitting
the glass door, turn your clothing inside
out, or remove the heavy objects. These
could damage your laundry or the
washing machine.
Remove any surplus hair, animal fur, sand,
and other materials with a brush before
washing.
If clothes have raised fabric turn them
inside out.
Clothes that are not colour fast should be
washed separately.
Insert your clothes into the washing
machine.
Close the washing machine door. Ensure
that you do not trap any items of clothing
between the loading door and the rubber
seal.
Organising Laundry Preparing Laundry
•
Iron
Do not iron
Dry clean
Do not dry clean
Warm iron.medium
(max 150℃)
Cool iron(max 110 ℃ )
A
F
Dry clean normal cycle
with any solvent
Dry clean normal cycle
petroleum solvent only Dry flat
Tumble dry normal Drip dry
Hang to dry
/Line dry
Tumble dry. Low heat
(max 110℃)
Tumble dry. Medium
(max 150℃ )
C
C
Bleach
Do not bleach
Hand wash
Do not wash
40
Warm wash
(max 40℃ )
Chlorine bleach
may be used
Normal wash
Gentle wash
Chlorine bleach
not be used
Do not tumble dry
Iron with cloth
Steam Iron
Dry after wash
Line Dry in shade
Warmly dry clean
No WringLine Dry No machine wash
•
•
•
•
•
•
•
•
•
•
•
•
5
Delicate
Cotton
Synthetic
Wool
9.0kg
9.0kg
4.5kg
2.0kg
2.5kg
Fiber Type Maximum Loading C ityapac

Wash Setting
Standard Washing
1. Pull the door handle and put the laundry in
the drum. (Refer to Preparation to sort your
laundry before it goes into the drum.) Make
sure no washing gets caught in the door.
2. Close the door and press the On/Off button.
4. Select the temperature if desired.
5. Add detergent into the detergent drawer.
The quantity of detergent will depend on the
amount of laundry, the degree of soiling and
the water hardness. Use the amount of
detergent suggested on the packaging.
6. Press the Start/Pause button to start the washing.
7. The washing machine will sound when the
programme is complete.
Before First Use
If the door is locked and you switched the
washing machine off and then on - or if
there’s a power cut - it will stay locked for
1 minute.
16
Add detergent into the appropriate dispenser.
Apply softener before you start washing.
Apply detergent and softener according to
the washing amount, the soiling level, the
water hardness in your area and the
manufacturer’s instructions of these products.
II
I
Main wash
detergent
Softener
Pre-wash
detergent
Detergent
Detergent
Softener
Dilute viscous fabric softener and fabric conditioner
with water. Prevent blockage of the overflow.
Maximum level is 40ml.
Adding Detergent and Softener
Do not use the washing machine when the
detergent drawer is removed. It may cause a
water leak or it may not work normally.
If you forget to add detergent, you can drain
the washing machine by running a drain only
programme. Then you can add detergent and
start the programme again.
Detergent only reaches the drum when water
flushes through the detergent drawer.
To prevent powder detergent staying in the
drawer, dry the inside of the drawer with a
cloth.Make sure the powder isn’t lumpy when
you add it into the drawer.
If the rinse cycle isn’t removing all the
detergent from your wash, use less detergent .
Softener should not exceed the MAX level in
the compartment.
Wash out unused softener with a splash of
water or a damp cloth after the programme
has finished.
•
•
•
•
•
•
•
•
•
Turn the Programme selection dial to select
your wash programme.
3.
Using your washing machine
Getting the most from your appliance
Prior to the first use of the appliance,
it is recommended to run a wash
programme without clothes. A small
amount of washing detergent should
be used.
•

17
Using your washing machine
Getting the most from your appliance
1.Changing the selection after the program
started?
If you need to change a setting after the wash has
started, press on/off, then on/off again, Re-select
the program, spin speed and optional functions,
and then press the Start / Pause button. (Ensure
the Child Lock is off, otherwise the original
program will continue.)
Removing Washing (Once programme is
fnished)
Door remains locked for 1 minute after
wash stopped.
Open the washing machine door and remove
your washing.
Remove any foreign objects to avoid risk of
rusting.
Leave the door and detergent drawer open so
that residual water can evaporate.
•
•
•
2.Door lock
The icon lock will light up automatically once
the program start. The door lock icon will fade
out as soon as the program end and the door
will be allowed to open automatically.
3.End of program
the end of
program and the display will indicate “end” icon.
It will sound for 5 seconds after

Using your washing machine
Getting the most from your appliance
18
Quick start
1.The washing machine will sound several times for 5 seconds.
2. close the water tap ;It is recommend to and pull out the power plug.
After washing :
3. Close the door
7. Press the 【start/pause】
2. Measure out the detergent
1. Open the door and
Load the laundry
4. Plug the power supply
6. Select the desired programme
5. Press the On/Off

Care and maintenance
Looking after your appliance
19
Before your maintenance starts, please do
pull out the power plug or disconnect power
and close the tap.
- Do not use solvents clean to avoid that the
washing machine, it will damage, and toxic
gases are generated or exploded.
- Do not use the detergents containing PCMX
to clean the washing machine.
Cleaning and Maintenance of Washing
Machine Cabinet
- Proper maintenance on the washing machine
can extend its working life. The surface can
be cleaned with diluted nonabrasive neutral
detergents when necessary. If there is any
water overflow, use the wet cloth to wipe it
off immediately.
- No sharp items are allowed to strike the
cabinet.
Notes: Do not use formic acid and its diluted
solvents or equivalent .
Clean Internal Drum
- The rusts left inside the drum by the metal
articles shall be removed immediately with
chlorine-free detergents.
- Never use steel wool.
Defrost a Frozen Washing Machine
When the temperature drops below zero and
your washing machine gets frozen, you may:
1.Disconnect the power supply for the washing
machine.
2.Wash the tap with warm water to loosen inlet
pipe.
3.Take down inlet pipe and immerse it in warm
water.
4.Pour warm water into washing drum and wait
for 10 minutes.
5.Reconnect inlet pipe to the tap and check
whether inlet and outlet are working normally.
Notes: when the washing machine is reused,
make sure the ambient temperature is above 0 C
Anti-freeze
If your washing machine is located in the room
where it can get frozen easily, please drain the
remaining water inside drain pipe and inlet pipe
thoroughly.
Clean detergent drawer and
grooves
1.Press down the arrow
location on softener cover
inside the drawer.
2.Lift the clip up and take out
softener cover and wash all
grooves with water.
3.Restore the softener cover
and push the drawer into
position.
Clean inlet filter
Inlet filter shall must be
cleaned if there is not any or
insufficient water in when
the tap is opened.
Clean the tap filter:
1.Close the tap.
2.Select any procedure except
“Wash” or “Drain” procedure.
3.Press the button “Start/Pause”
and keep the procedure
running for about 40 seconds.
4.Remove the inlet pipe from
the tap.
5.Use water to wash the filter.
6.Reconnect the inlet pipe.
Washing the filter in washing
machine:
1.Screw off the inlet pipe from
the backside of the machine.
2.Pull out the filter with long
nose pliers and reinstall it back
after being washed.
3.Reconnect the inlet pipe.
4.Open the tap and make sure
there is no water leakage.
5.Close the tap.
Fig 11
Fig 13
Remove the remaining water
in inlet pipe:
1.Close the tap.
2.Screw off the inlet pipe from
tap and put its end into the
container.
3.Start up any procedure
except single Wash or Drain
procedure. Water will be
drained out of inlet pipe if any
for about 40 seconds.
4.Reconnect the inlet pipe to tap.
Remove the remaining water in
drain pump(Fig11).
o
Fig 12
Fig 14
Fig 15
6

Pull out the power plug to avoid electrical shock
before washing.
After using the washing machine, remove all
the clothes and close the door tightly.
Remove foreign matters
Drain Pump Filter:
Drain pump filter can filter the yarns and small
foreign matters from the washings.
Clean the filter periodically to ensure the normal
operation of washing machine.
According to the soil level within the cycles and
the frequency of the cycles, you have to inspect
and clean the filter regularly.
The pump should be inspected if the machine
does not empty and/or spin;The machine makes
an unusual noise during draining due to objects
such as safety pins, coins etc. blocking the pump.
When the appliance is in use and depending
on the programme selected there can be hot
water
in the pump. Never remove the filter
during a wash cycle, always wait until the
appliance has finished the cycle, and is empty.
When replacing the filter, ensure it Is securely
retight end so.
Warning!
2.Turn the filter
down as shown with
the figure and take
out sundries matters
.(Fig19)
1.After the power is
disconnected, use
hand to open the
filter cover(Fig18).
3.Reinstall each part
back after sundries
matters are removed
.(Fig20)
20
Care and maintenance
Looking after your appliance
Clean the pump filter :
Fig 18
Fig 19
Fig 20
Notes: Generally, the tap filter is washed first
and then the filter in washing machine will be
washed.
(Fig16,17)
If only the filter in washing machine is washed,
then the steps 1~3 in cleaning the tap filter
shall be repeated .
Fig 16 Fig 17
