Bellini BMW625TKX User manual

1
60cm Built In
Microwave Oven
Installation and User manual
Content
Important Safety instructions-------------------- 2
Product description--------------------------------- 5
Installation-------------------------------------------- 6
Start using your oven------------------------------- 7
Maintenance and cleaning------------------------ 19
Warranty----------------------------------------------- 20
BMW625TKX
BMW625TKX-F
BMW625IGX
BMW625IGX-F
20130729 issue5
For warranty service call 1300 373 199(Australia)
or 0508 123108(New Zealand) to connect you to
the nearest authorised service centre

2
Important Safety Instructions
This manual explains the proper installation and use of your oven, please read it carefully before
using even if you are familiar with the product. The manual should be kept in a safe place for future
reference.
Warnings
If the supply cord is damaged, the cord must be
replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a
hazard.
If the door or door seals are damaged, the oven
must not be operated until it has been repaired by
an authorised person.
Do not place any object between the oven front
face and the door or allow soil or cleaner residue
to accumulate on sealing surfaces.
If the apparatus is not maintained in a good state
of cleanliness, its surface could be degraded and
affect the lifespan of the apparatus and lead to a
dangerous situation.
Liquids and other foods must not be heated in
sealed containers since they are liable to explode.
It is hazardous for anyone other than a authorised
person to carry out any service or repair operation
that involves the removal of a cover which gives
protection against exposure to microwave energy.
Do not run the unit without any food inside.
Only use utensils suitable for use in microwave
ovens.
When heating food in plastic or paper containers,
keep an eye on the oven due to the possibility of
ignition.
If smoke is observed, switch off or unplug the
appliance and keep the door closed in order to
stifle any flames.
Do not overcook food.
Do not use the oven cavity for storage purposes.
Do not store items, such as bread, cookies, etc.
inside the oven.
Remove wire twist-ties and metal handles from
paper or plastic containers/bags before placing
them in the oven.
Install or locate this oven only in accordance with
the installation instructions provided.
Eggs in the shell and whole hard-boiled eggs
should not be heated in microwave ovens since
they may explode, even after microwave heating
has ended.
Use this appliance only for its intended uses as
described in manual. Do not use corrosive
chemicals or vapors in this appliance. This oven is
especially designed to heat. It is not designed for
industrial or laboratory use.
Do not store or use this appliance outdoors.
Do not use this oven near water, in a wet
basement or near a swimming pool.
The temperature of accessible surfaces may be
high when the appliance is operating. The
surfaces are liable to get hot during use. Keep
cord away from heated surface, and do not cover
any events on the oven.
Do not let cord hang over edge of table or counter.
The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature
checked before consumption, in order to avoid
burns.
Microwave heating of beverages can result in
delayed eruptive boiling; therefore care must be
taken when handling the container.
The appliances are not intended to be operated by
means of an external timer or separate
remote-control system.
During use the appliance becomes hot. Care
should be taken to avoid touching heating
elements inside the oven.
Always use gloves when handling hot items inside
the oven.
Always turn the grill off immediately after use as fat
left behind may catch fire.
Do not leave the appliance unattended when
cooking. Oils and fats may catch fire due to
overheating or boiling over.
Do not attempt to operate this oven with the door
open since this can result in harmful exposure to
microwave energy. It is important not to break or

3
tamper with the safety interlocks.
Do not place any object between the oven front
face and the door or allow soil or cleaner residue
to accumulate on sealing surfaces.
Do not use the appliance in the event of a
technical fault. Any faults must be fixed by an
appropriately qualified and authorised person.
In the event of any incident caused by a technical
fault, disconnect the power and report the fault to
the service centre to be repaired.
The rules and provisions contained in this
instruction manual should be strictly observed.
Do not allow anybody who is not familiar with the
contents of this instruction manual to operate the
appliance.
Child Safety
This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they’ve been
given supervision or instruction concerning use of
the appliance by a person responsible for their
safety.
Children should be supervised to ensure that they
do not play with the appliance.
During use this appliance becomes hot. Care
should be taken to avoid touching hot surfaces,
e.g. oven door, heating elements.
Accessible parts will also become hot when in use.
To avoid burns and scalds children should be kept
away.
Installation, Cleaning & Servicing
The appliance must be installed only by an
authorised person in compliance with the
instructions provided. Incorrect installation may
cause harm to persons, animals or may damage
property.
Before using the appliance, ensure that all
packing materials are removed from the
appliance.
In order to avoid any potential hazard, the
enclosed installation instructions must be
followed.
Ensure that all specified vents, openings and air
spaces are not blocked.
The panels adjacent to the oven must be made of
heat-resistant material.
The oven should be cleaned regularly and any
food deposits should be removed. Failure to
maintain the oven in a clean condition could lead
to deterioration of the surface that could adversely
affect the life of the appliance and possibly result
in a hazardous situation. Steam cleaner is not to
be used.
Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they
can scratch the surface, which may result in
shattering of the glass.
The rear surface of appliance shall be placed
against a wall.
Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of
electric shock.
To reduce the risk of fire, do not place or install this
unit in areas where the ventilation or circulation
ducts may become blocked. Make sure there are
at least 45mm of space between the back of your
oven and the wall. Keep some distance on each
side of your oven that you can use that distance
flowing installing instructions.
The unit's power cord must be connected to a
properly grounded and protected, 230-240V
electrical outlet.Always use ground fault protection
where required by the electrical code. Do not let
cord hang over edge of table or counter.
When transporting or storing the unit, keep it in a
dry location, free from dust, excessive vibration or
other factors, which may damage the unit.
Do not operate oven with a damaged cord, plug or
if the oven has malfunctioned or has been dropped
or damaged in any manner. Return oven to
authorised service facility for repair.
Only authorised personnel should carry out
servicing. (Certificate of Compliance to be
retained)
Always ensure the appliance is switched off before
cleaning or replacing parts.
Do not use steam cleaners, as this may cause
moisture build-up.
Always clean the appliance immediately after any
food spills.
THIS APPLIANCE MUST BE EARTHED.

4
To maintain safe operation, it is recommended
that the product be inspected every five years by
an authorised service person.
Microwave Oven
During use the appliance becomes hot. Care
should be taken to avoid touching the hot surfaces
inside the oven.
To avoid an accident, ensure that oven shelves
and fittings are always inserted into the appliance
in accordance with the instructions.
Do not use the door as a shelf.
Do not push down when the oven door is open.
Grill
Do not cover the grill insert with foil, as fat built up
may catch on fire.
Always keep the grill dish clean as any build up
may catch on fire.
Do not leave the grill on unattended.
To avoid fire, ensure that grill trays and fittings are
always inserted into the appliance in accordance
with the instructions.
Do not place thick portions of food under the grill.
Foods may curl, catch and ignite.
Accessible parts may become hot when grill is in
use. Children should be kept away.
Environmental Hints
This product must not be disposed together with
domestic waste. This product has to be disposed at an
authorised place for recycling of electrical and
electronic appliances.
By collecting and recycling waste, you help save
natural resources, and make sure the product is
disposed in an environmental friendly and healthy way.

5
Product Description
Accessory Name Picture
( for reference only, physical unit maybe different)
Quantity
User Manual 1
Installation Manual 1
1:1 installation template 1
Screw A 2 (For BMW625IGX(-F))
Adjust Screw B 1
Bracket 1 (For BMW625IGX(-F))
Already installed Trim Kit 1
1 (For BMW625TKX(-F))
Grill Rack
1 (For BMW625IGX(-F))
Turntable RingAssembly See above item C 1
Glass Tray See above item D(Diameter=315mm) 1
Technical Specifications
model product dimensions
(h x w x d) mm
Appro
x. net
weight
Oven
capacity electrical connection Rated input power
Rated out
power
(Microwave)
BMW625TKX
BMW625TKX-F
388 x 595 x
470 20.9 Kg 25 L 230-240V/50Hz 1400 – 1450W(Microwave)
1000 – 1100W(Grill)
2300 – 2400W(Convection) 850 – 900W
BMW625IGX
BMW625IGX-F 388 x 594 x 410 19.7 Kg 25 L 230-240V/50Hz 1450W(Microwave) 1000 – 1100W(Grill) 900W
A. Control Panel
B. Turntable Shaft
C. Turntable Ring Assembly
D. Glass Tray
E. Observation Window
F. Door
G. Safety Interlock System

6
Installation
WARNING!
Please follow the points below when installing the appliance
Use An Authorized Person
As stated in the local municipal building codes
and other relevant statutory regulations:
Wiring connections must be in accordance with
AS/NZS 3000 Wiring Rules and any particular
conditions of the local authority.
Refer to data plate for rating information. The
data plate is positioned at the side of cavity.
A functional switch should be provided near the
appliance in an accessible position. Refer to
AS/NZS 3000 clause 4.7.1.
Wiring should be protected against mechanical
failure. Refer toAS/NZS 3000 clause 1.5.
A means of disconnection with a contact
separation of at least 3mm must be supplied in
the fixed wiring.
Disconnect the power plug of the appliance from
the power point when conducting maintenance
or repairs to the unit

This Appliance Must Be Properly Earthed
Do not lift the appliance by the door handles.
Prepare the cupboard opening to match your
appliance measurements. (See diagrams).
Slide appliance in to cabinet cavity, ensuring
supply cable is not obstructed (kinked, jammed
or twisted).
Where the appliance is built into a cabinet, the
cabinet material must be capable of withstanding
70°C. Installation into low temperature tolerant
cabinetry (E.g. vinyl coated) may result in
deterioration of the low temperature coating by
discoloring or bubbling.
If the appliance is to be installed adjacent to vinyl
wrapped surfaces, use an installation kit
available from the vinyl-wrap supplier.
GSM cannot accept responsibility for damage
caused by installation into low temperature
tolerant cabinets.
After installation, test and ensure the appliance
operates correctly before handing it over to the
customer.
CAUTION!
Where the appliance is connected via power supply
cable to a power point, the installed power point must
remain accessible after appliance installation
Adedicated power circuit is recommended for the unit
but not required. Additional electrical appliances on
the same circuit may exceed the current (amperage)
rating for that circuit. If after the installation of your
unit the circuit breaker trips or the fuse fails on a
repeated basis, then a dedicated circuit will likely be
required.
WARNING!
To avoid any potential hazard, you must
follow our instructions when you install
your appliance. Failure to install the
appliance correctly could invalidate any
warranty or liability claims and lead to
prosecution.
Cut-out dimensions
Install the unit according to installation manual in the
packaging.
model Dimension A(mm)
BMW625TKX,
BMW625TKX-F 550 minimum
BMW625IGX
BMW625IGX-F 500 minimum

7
Start Using Your Microwave Oven
WARNING!
DO NOT RUN THE UNIT WITHOUT ANY FOOD INSIDE.
Material to be avoided use in microwave oven
Utensils Why
Aluminium tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal
handle May cause arcing. Transfer food into microwave-safe dish.
Metal or metal trimmed
utensils Metal shields the food from microwave energy. Metal trim may cause arcing.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside when exposed to high
temperature.
Wood Wood will dry out when used in the microwave oven and may split or crack.
Material could be used in microwave oven
Utensils Suggestion
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of meat
or poultry to prevent overcooking. Arcing can occur if foil is too close to oven
walls. The foil should be at least 1 inch (2.5cm) away from oven walls.
Browning dish Follow manufacturer’s instructions. The bottom of browning dish must be at
least 3/16 inch (5mm) above the turntable.
Dinnerware Microwave-safe only. Do not use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most glass jars are
not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim. Do
not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer’s instructions. Do not close with metal tie. Make slits to
allow steam to escape.
Paper plates and cups Short–term using only. Do not leave oven unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for a
short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Labeled "Microwave Safe" only. Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be slit,
pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain moisture. Do
not allow plastic wrap to touch food.

8
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Operation Instruction for BMW625TKX
This microwave oven uses modern electronic control to adjust cooking parameters to meet your needs better for
cooking.
O’ Clock Setting
When the microwave oven is electrified, the LED will display "0:00", buzzer will ring once.
1. Press " Clock/Pre-set " to choose 12-hour or 24-hour
2. Turn " ” to adjust the hour figures, the input time should be within 0--23(24-hour) or 1--12(12-hour).
3. Press “Clock/Pre-set ", the minute figures will flash.
4. Turn " " to adjust the minute figures, the input time should be within 0--59.
5. Press “Clock/Pre-set " to finish clock setting. ":" will flash.
NOTE:
Microwave indicator Convection indicator
Grill indicator Defrost indicator
Childlock Auto menu
Convection temperature unit indicator, ON if
centigrade is chosen
Weight unit (On when choose defrost by weight)
Convection temperature indicator
Door open push button

9
¾If the clock is not set, it would not function when powered.
¾During the process of clock setting, if you press “Stop/Clear ", the oven will go back to previous status
automatically.
Microwave Cooking
1. Press the "Microwave” once, the LED will display "P100".
2. Press “Microwave” for times or turn " “to select the microwave power from 100% to 10%. "P100",
"P80", "P50", "P30", "P10" will display in order. For example if you want cook in 50% power than press
“Microwave” 3 times until P50 displayed. (See below table 1 for reference only)
3. Press "Start/+30Sec./Confirm” to confirm.
4. Turn " " to adjust the cooking time. (The time setting should be 0:05- 95:00.When turn the knob,
increasing of each turning is not even, see below table 2 for reference only)
5. Press “Start/+30Sec./Confirm “to start cooking.
NOTE:
Table 1 Table 2
Display Microwave
Power Grill Power (1000W)
P100 100%
P80 80%
P50 50%
P30 30%
P10 10%
G 0% 100%
Grill Cooking
1. Press the "Grill” once, "G-1" display.
2. Turn " " to adjust the cooking time. (The time setting should be 0:05- 95:00.)
3. Press “Start/+30Sec./Confirm “to start cooking.
NOTE:
When half of the grill time up, buzzer sound twice to remind you turn the food over. In order to have a better
effect of grilling food, turn it over, close the door, and press “Start/+30Sec./Confirm" to continue cooking.
Microwave + Grill Cooking
1. Press the "Micro. +Grill” once, “G-2" display.
2. Press “Micro. +Grill” for times or turn " “to select “G-3”, “G-4”, “G-2” in sequential.
3. Press “Start/+30Sec./Confirm “to confirm the setting.
4. Turn " " to adjust the cooking time(The time setting should be 0:05 – 95:00)
5. Press “Start/+30Sec./Confirm “to start cooking.
Microwave + Convection Cooking
1. Press the “Micro.+Conv. " key once, and "G-1" display.
Setting duration
range Time increasing by each turn
0 -1 min 5 seconds
1 – 5 min 10 seconds
5 – 10 min 30 seconds
10 – 30 min 1 minute
30 – 90 min 5 minutes

10
2. Press “Micro. +Conv” for times or turn " " to select “C-1”, “C-2”, “C-3” or “C-4” in order.
3. Press “Start/+30Sec./Confirm “to confirm the setting.
4. Turn " " to adjust the cooking time(The time setting should be 0:05 – 95:00)
5. Press “Start/+30Sec./Confirm “to start cooking.
NOTE: Combination instructions
Display Microwave Power
(900W) Grill Power (1000W) Convection Power (2500W)
G-2 28% 72%
G-3 38% 62%
G-4 48% 52%
C-1 28% 72%
C-2 38% 62%
C-3 48% 52%
C-4 28% 72% 72%
Convection Cooking(With preheating function)
The convection cooking can allow you to cook the food as a traditional oven. Microwave is not used. It is
recommended that you should preheat the oven to the appropriate temperature before placing the food in.
1. Press the "Convection” once, "140" will flash.
2. Keep pressing “Convection” or turn " " to select the convection function.
*** The temperature can be chosen from 140 degrees to 230 degrees.
3. Press the “Start/+30Sec./Confirm “to confirm the temperature.
4. Press the “Start/+30Sec./Confirm “to start preheating. When the preheating temperature reaches, the
buzzer will sound twice to remind you to put the food into the oven. And the preheated temperature is
displayed and flash.
5. Put the food into the oven and close the door. Turn " " to adjust the cooking duration. (The
maximum duration is 95 minutes.)
6. Press the “Start/+30Sec./Confirm “to start cooking.
NOTE:
¾Cooking duration can not be input until the preheating temperature reach. When the temperature
reach, open the door and input the cooking time.
¾If no time input operation in 5 minutes, the oven will stop preheating. The buzzer sound five times and
turn back to stand-by.
Convection Cooking( Without pre-heating function)
1. Press the “Convection” once, "140" will flash.
2. Keep pressing “Convection” or turn " " to select the convection function.
*** The temperature can be chosen from 140 degrees to 230 degrees.
3. Press the " Start/+30Sec./Confirm" to confirm the temperature

11
4. Turn " " to adjust the cooking duration. (The maximum duration is 95 minutes.)
5. Press the “Start/+30Sec./Confirm “to start cooking.
Multi-Stage Cooking
¾2 stages can be maximally set. The buzzer will ring once after each stage and the next stage will begin.
¾Auto menu and preheating cannot be set as one of the multi-stage.
¾Defrosting must be put as the first stage.
Example: if you want to defrost the food for 5 minutes, then to cook with 80% microwave power for 7 minutes.
Do as following:
1. Press "W.T./Time Defrost " twice, the LED will display "dEF2";
2. Turn " " to adjust the defrost time as 5 minutes;
3. Press” Microwave" once
4. Press " Microwave " for times or turn " " till "P80" display;
5. Press " Start/+30Sec./Confirm " to confirm;
6. Turn " " to adjust the cooking duration as 7 minutes;
7. Press “Start/+30Sec./Confirm “to start multi-stage cooking.
Pre-set Function
Combined O’clock and multi-stage cooking, you can set up a preferred cooking program starts from defined time
point. To do that, you must set up O’clock as per foresaid instruction firstly.
Example: if you want to cook with 80% microwavepowerfor 7minutes but start from 15:30, do as below
Make sure your O’clock set as per current time.
1. Do as per “Multi-stage” example but final step do not press " Start/+30Sec./Confirm ", instead, press"
Clock/Pre-set ", current time displays and the hour figures flash.
2. Turn " " to adjust desired hour figures, the input time should be within 0--23(24-hour) or
1--12(12-hour).
3. Press " Clock/Pre-set ", the minute figures will flash, Turn " " to adjust desired minute figures
4. Press “Start/+30Sec./Confirm " to finish setting. ":" will light, buzzer will ring twice when the time arrives
15:30, then cooking will start automatically.
NOTE: Defrost function should not be set in the pre-set function
Auto Menu
1. In stand by state, press "AUTO MENU" key once, and "A1" display.
2. Press” AUTO MENU” for times or turn " " to choose “A2”, “A3”…”A10”, “A1”
3. Press “Start/+30Sec./Confirm “to confirm the menu you need.
4. Turn " " to choose the weight of menu, and “g” indicator will light
5. Press “Start/+30Sec./Confirm “to start cooking.
NOTE:

12
When you chooseA8 cake, please do not put the cake into the oven at the beginning until buzzer sounds
twice to remind you it is time to do it because the oven needs to be preheated to 180 degree firstly. After
putting the cake in the oven and door closed, press “Start/+30Sec./Confirm “again to start the program.
Auto menu table for reference only
Menu Weight(gram) Display Power
150 150
250 250
350 350
450 450
A1
Reheat
600 600
100%
About 230g 1
About 460g 2
A2
Potato About 690g 3 100%
150 150
300 300
450 450
A3
Pork 600 600
100%
150 150
350 350
A4
Vegetable 500 500 100%
150 150
250 250
350 350
450 450
A5
Fish
650 650
80%
50(With 45ml water) 50
100(With 800ml water) 100
A6
Pasta 150(With 1200ml water) 150 80%
200 200
400 400
A7
Soup 600 600 100%
A8 Cake 475 475 Must preheat
200 200
300 300
A9
Pizza 400 400 C-4
500 500
750 750
1000 1000
A10
Chicken 1200 1200
C-4
Defrost by W.T.
1. Press "W.T./Time Defrost" once, LED will display "dEF1",.
2. Turn " " to select the weight of food, "g" will lights. The weight should be 100-2000g.

13
3. Press “Start/+30Sec./Confirm “to start defrosting" " and " " indicators will flash, "g" indicator
will go out.
Defrost by Time
1. Press " W.T./Time Defrost " twice, LED will display "dEF2"
2. Turn " " to set the cooking duration. The maximum duration is 95 minutes.
3. Press “Start/+30Sec./Confirm “to start defrosting. " " and " " indicators will flash.
TIPS:
If the food weight less than 200g, please place the food at the edge of the glass turntable but not the
center to be defrosted.
Speedy Cooking
1. In stand by state, press “Start/+30Sec./Confirm “to cook with 100% power level for 30 seconds. Each
press on the same key can increase 30 seconds. The maximum cooking time is 95 minutes.
2. During microwave, grill, convection and combination states, press “Start/+30Sec./Confirm “to cook with
100% power level for 30 seconds. Each press on the same key can increase 30 seconds.
NOTE:
this function cannot work under defrost, auto menu and multi-stage cooking.
Speedy Microwave Cooking
In stand by state, turn " " left to choose cooking time directly then press " Start/+30Sec./Confirm” key
to cook with 100% microwave power. This program can be set as one of multi-stage.
Inquiring Function
You are able to check power level or settings during programs running.
¾In cooking state, press “Microwave”, “Grill”, “Micro./Conv.”, or “Convection”, the current power will be
displayed for 2-3 seconds.
¾During cooking state, press “Clock/Pre-set” to check the current time. It will be displayed for 2-3
seconds.
Child Lock
In waiting state, press “Stop/Clear” for 3 seconds, there will be a long "beep" denoting entering into the
children-lock state and " " indicator will light. LED will display current time or 0:00.
Press " Stop/Clear " for 3 seconds again to quit from Lock status, a long "beep" denoting that the lock is
released, and " " indicator will disappear.
Specification
1. The buzzer will sound once when turning the knob at the beginning.
2. " Start/+30Sec./Confirm " must be pressed to continue cooking if the door is opened during cooking;
3. If “Start/+30Sec./Confirm " is not pressed in 5 minutes after the cooking program set, the setting will be
cancelled and O’clock time will be displayed.
4. The buzzer sounds once by efficient press, inefficient press will be no response.
5. The buzzer will sound five times to remind you when cooking finished.

14
Operation Instruction for BMW625IGX
O’ Clock Setting
When the microwave oven is electrified, the LED will display "0:00", buzzer will ring once.
1. Press “Clock/Kitchen Timer" once to select O’clock setting, the hour digit will flash.
2. Turn " ” to adjust the hour figures, the input time should be within 0--23.
3. Press “Clock/Kitchen Timer ", the minute figures will flash.
4. Turn " " to adjust the minute figures, the input time should be within 0--59.
5. Press “Clock/Kitchen Timer " to finish clock setting. ":" will flash.
NOTE:
¾If the clock is not set, it would not function when powered.
¾During the setting, if you press “Stop/Clear ", the oven will go back to previous status automatically.
Microwave indicator Grill indicator
Defrost by time Defrost by weight
Microwave power O’clock
Timer indicator Auto menu
Child lock
Weight unit (On when choose defrost by weight)
Door open push button

15
Microwave Cooking
1. Press the "Microwave/Grill/Combi." once, "P100" will display.
2. Press “Microwave/Grill/Combi” for times or turn " “to select the microwave power from 100% to
10%. "P100", "P80", "P50", "P30", "P10" will display in sequence. For example if you want cook in 50%
power than press “Microwave” 3 times until P50 displayed.(See below table 1 for reference only) Press
" Start/+30Sec./Confirm " to confirm choice.
3. Turn " " to adjust the cooking duration. (The range should be 0:05- 95:00, when turn the knob,
increasing of each turning is not even, see below table 2 for reference only)
4. Press “Start/+30Sec./Confirm “to start cooking.
NOTE:
Table 1 Table 2
Display Microwave Power Grill Power
(1000W)
P100 100%
P80 80%
P50 50%
P30 30%
P10 10%
G 0% 100%
C-1 55% 45%
C-2 36% 64%
Grill or Combi Cooking
1. Press the "Microwave/Grill/Combi" key once, "P100" will display.
2. Press “Microwave/Grill/Combi” for times or turn " " to choose power you want. “G”, “C-1” and
“C-2” will display in sequence. Press “Start/+30Sec./Confirm “to confirm.
3. Turn " " to adjust the cooking time. (The time setting should be 0:05- 95:00)
4. Press “Start/+30Sec./Confirm “again to start cooking.
Example:
If you want to use 55% microwave power and 45% grill power(C-1) to cook for 10 minutes, do as below
1. Press “Microwave/Grill/Combi" once, LED display "P100".
2. Press “Microwave/Grill/Combi” once again or turn " " to choose combi. 1 mode.
3. Press “Start/+30Sec./Confirm" to confirm, and the screen displays "C-1".
4. Turn " " to adjust the cooking time until the oven displays "10:00".
5. Press " Start/+30Sec./Confirm " to start cooking .
NOTE:
When half of the grill time up, buzzer sound twice to remind you turn the food over. In order to have a better
effect of grilling food, turn it over, close the door, and press “Start/+30Sec./Confirm" to continue cooking.
Setting duration
range Time increasing by each turn
0 -1 min 5 seconds
1 – 5 min 10 seconds
5 – 10 min 30 seconds
10 – 30 min 1 minute
30 – 90 min 5 minutes

16
Quick Start
You are able to only set cooking duration and use “Quick start” to cook food in 100% power by simple operation.
¾If in stand by mode, press “Start/+30Sec./Confirm “or turn " " left to start cooking with 100% power,
then press “Start/+30Sec./Confirm “to start cooking.
TIPS:
If you are in microwave cooking or time defrosts function already and want to increase cooking duration, press
“Start/+30Sec./Confirm “to add cooking time, each additional pressing can increase 30 seconds up to 95 min.
Auto Menu
1. Turn " " right, "A-1" to “A-8” will display in sequence.
2. Stop turning at wanted menu and press "Start/+30Sec./Confirm" to confirm.
3. Turn " " to choose the weight of menu, and “g” indicator will light.(See below table for reference)
4. Press "Start/+30Sec./Confirm" to start cooking.
Auto menu table for reference only
Menu Weight(gram) Display Menu Weight(gram) Display
200 200
400 400 50g(with 450ml water) 50
A1
Reheat 600 600
A5
Pasta 100g(with 800ml water) 100
200 200 200 200
300 300 400 400
A2
Vegetable 400 400
A6
Potato 600 600
250 250
350 350 200 200
A3
Fish 450 450
A7
Pizza 400 400
250 250
350 350 200ml 200
A4
Pork 450 450
A8
Soup 400ml 400
Defrost by W.T.
1. Press "Weight./Time Defrost" once, LED will display "dEF1",.
2. Turn " " to select the weight of food, "g" will lights. The weight should be 100-2000g.
3. Press "Start/+30Sec./Confirm"to start defrosting," " and " " indicators will flash and "g"
indicator will go out.
Defrost by Time
1. Press " Weight./Time Defrost " twice, LED will display "dEF2"
2. Turn " " to set the cooking duration. The maximum duration is 95 minutes.
3. Press “Start/+30Sec./Confirm" key to start defrosting. " " and " " indicators will flash .
NOTE: The defrost power is fixed at P30 in this function.

17
Multi-Stage Cooking
¾2 stages can be maximally set. The buzzer will ring once after each stage and the next stage will begin.
¾Auto menu and preheating cannot be set as one of the multi-stage.
¾Defrosting must be put as the first stage.
Example: if you want to defrost the food for 5 minutes, then to cook with 80% microwave power for 7 minutes.
Do as following:
1. Press "Weight/Time Defrost " twice, the screen will display "dEF2";
2. Turn " " to adjust the defrost time as 5 minutes;
3. Press” Microwave/Grill/Combi." Once, LED display P100
4. Press " Microwave/Grill/Combi." for times or turn " " till "P80" display;
5. Press "Start/+30Sec./Confirm" to confirm;
6. Turn " " to adjust the cooking duration as 7 minutes;
7. Press "Start/+30Sec./Confirm" to start multi-stage cooking.
Kitchen Timer
You are able to use this function as minute minder to give reminder when set duration time up.
1. Press” Clock/Kitchen Timer” twice, LED display 00:00
2. Turn " " to set a desired duration(Maximum duration is 95 minutes)
3. Press “Start/+30Sec./Confirm" to confirm setting.
4. When set duration time up, clock indication will go out and buzzer ring 5 times.
NOTE: this function is differ from 24 hours O’Clock system but a minute minder only.
Child Lock
In waiting state, press "Stop/Clear" for 3 seconds, there will be a long "beep" denoting entering into the
children-lock state and " " indicator will light. LED will display current time or 0:00.
Press " Stop/Clear " for 3 seconds again to quit from Lock status, a long "beep" denoting that the lock is
released, and " " indicator will disappear.
Inquiring Function
You are able to check power level or settings during programs running.
¾In cooking state, press "Microwave/Grill/Combi", the current power will be displayed for 3 seconds.
¾During cooking state, press "Clock/Pre-set" to check the current time. It will be displayed for 3 seconds.

18
Trouble Shooting
Trouble Possible causes To do
Microwave oven
interfering with TV
Radio and TV reception may be interfered when
microwave oven running. It is similar with interfere
of small appliances and normal. It is normal
Dim oven light In lower power microwave cooking, oven light may
become dim. It is normal
Steam accumulating
on door, hot air out of
vent
In cooking, steam may come out from food and
most will go out from vent but some of them may
accumulate on cool place like door. It is normal
Power cord not plug in tighten Unplug, then plug again after 10s, make sure
connection is secure.
Fuse blowing or circuit breaker works Call service center
Can not start
Trouble with power supply Check to ensure proper
power supplied
Door not closed well. Close door wellOven does not heat
food up Magnetron out of work Call service center
Glass turntable noisy
when microwave oven
running Dirty roller Clean dirty part.

19
Maintenance and Cleaning
WARNING!
Before cleaning your oven, or performing maintenance, disconnect it from the
power supply.
Do not use steam cleaners.
Do not line the oven bottom with aluminium foil, as the consequent accumulation of
heat could compromise the cooking and even damage the enamel.
To protect against the risk of electrical shock, do not immerse the unit, cord or plug
in water or other liquid or sprinkle water to clean the appliance!
Do not clean the appliance when it is still hot! The inside and external surface of
the oven should preferably be cleaned with a damp cloth when it has cooled down.
Wash all accessories in hot sudsy water or in a dishwasher, wipe dry with a paper
or cloth towel.
If you use your oven for an extended period of time, condensation may form. Dry it
using a soft cloth.
Stainless steel
All grades of stainless steel can stain, discolour or become greasy. You must clean these areas regularly by
following the procedures below, if you want your appliance to look its best, perform well and have a long life.
Care must be taken when wiping exposed stainless steel edges, they can be sharp!
The front frame around the oven can be cleaned with stainless steel cleaners if it becomes soiled or
discoloured.
The stainless steel should only be cleaned with warm water and a mild detergent as normal cleaning.
DO NOT use abrasive cleaners or harsh solvents.
NOTE: Make sure you follow the polish or brushing lines in the stainless steel
Glass
Glass surfaces on doors and control panels are best cleaned immediately after soiling.
A damp cloth may help remove baked on food deposits.
Oven cleaners can be used to remove stubborn marks and stains.
The glass door on this appliance is made from a tough, durable material that withstands heating and cooling
without breaking.
However, it must be remembered that it is GLASS, it may break. Treat it accordingly!
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door since they can scratch
the surface, which may result in shattering of the glass.
Oven
Always keep your appliance clean. Ensure fats and oils do not accumulate around elements, burners or fans.
Always keep the oven dish, baking trays and grill dish inserts clean, as any fat deposits may catch fire.
Always wrap your meats in foil or an oven roasting bag to minimise cleaning. Any polyunsaturated fats can
leave a varnish-like residue which is very difficult to remove.
Grill
Always keep the grill dish and grill insert clean, as any fat deposits may catch fire.

20
WARRANTY
1.1 In this warranty:
1.1.1 Australian Consumer Law means the law as set out in Schedule 2 of the Competition and
Consumer Act 2010;
1.1.2 Company means GSM Sales Pty Ltd ABN 53 007 682 475 of 142-144 Fullarton Road, Rose
Park SA 5067. Telephone [phone]. Email [email protected];
1.1.3 Consumer means a “consumer” as that term is defined in Section 3 of the Australian Consumer
Law as the original purchaser of a Bellini product;
1.1.4 Consumer Guarantees means the guarantees under the Australian Consumer Law;
1.1.5 You means the Consumer.
1.2 Nothing in this warranty affects any person’s rights under the Australian Consumer Law. The benefits to
any Consumer under this warranty are in addition to the rights and remedies available under any
Consumer Guarantees.
1.3 Subject to the other clauses of this warranty, the Company warrants to the Consumer that the Bellini
product will be free of manufacturing defects and will perform to the Company’s specifications.
1.4 The benefit of this warranty extends only to the Consumer as original purchaser of a Bellini product which
is installed in a residential property.
1.5 This warranty commences on the date of purchase of the Bellini product by the Consumer and continues
for the benefit only of the Consumer until the expiry of two (2) year (Warranty Period).
1.6 If within the Warranty Period a manufacturing defect is discovered in the Bellini product or it fails to perform
to the Company’s specifications as a result of some defect in materials, components or workmanship
(Defect) then the Company will, at its option, repair the Bellini product or supply a replacement Bellini
product free of charge. A replacement Bellini product may differ from the original product purchased by the
Consumer.
1.7 This warranty will not apply to any Bellini product:
1.7.1 Installed by any person other than a qualified tradesperson; or
1.7.2 Subjected to misuse, neglect, negligence or accidental damage; or
1.7.3 Operated in any way contrary to any operating or maintenance instructions; or
1.7.4 Improperly handled, installed or maintained; or
1.7.5 Altered or modified prior to or after installation; or
1.7.6 Damaged directly or indirectly by power surges, electrical storm damage or connection to incorrect
power supply
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY THE
CONSUMER MUST CALL 1300 373 199 (AUSTRALIA) OR 0508 123 108
(NEW ZEALAND) TO CONNECT TO THE NEAREST AUTHORISED CENTRE
TheAustralianConsumerLawrequirestheinclusionofthefollowingstatement
withthiswarranty:
Our goods come with guaranteed that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a major failure.
