Bellini BMWM28 User manual

OPERATION INSTRUCTIONS
Built-In Black Microwave
Model No. BMWM28
V2 March 2022
GSM Retail Australia Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0800 764 912 NZ
www.belliniappliances.com.au Model: BMWM28 Fineline: 295810 Built-In Black Microwave

Thank you.
Thank you for choosing Bellini Appliances.
Bellini prides itself on ‘affordable living’ making sure there is not
compromise in your favourite room.... The Kitchen.
All Bellini appliances carry a 3 year In Home warranty, be sure to
retain your installation and user manual and receipt.
For all warranty and technical queries please phone:
1300 373 199
GSM Retail Australia Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0800 764 912 NZ
www.belliniappliances.com.au Model: BMWM28 Fineline: 295810 Built-In Black Microwave

Contents
Safety instructions ............................................... 2-4
Product description ............................................ 5-8
Start using your appliance ................................. 9
Maintenance ...................................................... 10-11
Warranty ..............................................................12-13
GSM Retail Australia Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0800 764 912 NZ
www.belliniappliances.com.au Model: BMWM28 Fineline: 295810 Built-In Black Microwave

Safety Instructions
This manual explains the proper installation and use of your appliance, please read it
carefully before using even if you are familiar with the product. The manual should be
kept in a safe place for future reference. In case of failure, only the authorised Technical
Service may repair this hob. Otherwise the guarantee will be null and void.
All Bellini Appliances are for domestic use only.
2
1. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
2. Children should be supervised to ensure that
they do not play with the appliance.
3. If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.( For appliance with type Y attachment)
4. WARNING: Ensure that the appliance is switched
off before replacing the lamp to avoid the
possibility of electric shock.
5. WARNING: It is hazardous for anyone other than
a competent person to carry out any service or
repair operation that involves the removal of a
cover which gives protection against exposure
to microwave energy.
6. WARNING: Liquids and other foods must not be
heated in sealed containers since they are
liable to explode.
7. When heating food in plastic or paper
containers, keep an eye on the oven due to the
possibility of ignition.
8. Only use utensils that are suitable for use in
microwave ovens.
9. If smoke is emitted, switch off or unplug the
appliance and keep the door closed in order to
stifle any flames.
10. Microwave heating of beverages can result
in delayed eruptive boiling, therefore care must
be taken when handling the container.
11. The contents of feeding bottles and baby
food jars shall be stirred or shaken and the
temperature checked before consumption, in
order to avoid burns.
12. Eggs in their shell and whole hard-boiled
eggs should not be heated in microwave ovens
since they may explode, even after microwave
heating has ended.
13. The oven should be cleaned regularly and any
food deposits removed.
14. Failure to maintain the oven in a clean condition
could lead to deterioration of the surface that could
adversely affect the life of the appliance and
possibly result in a hazardous situation.
15. Only use the temperature probe recommended
for this oven.(for ovens provided with a facility to
use a temperature-sensing probe.)
16. The microwave oven must be operated with the
decorative door open. (for ovens with a decorative
door.)
17. This appliance is intended to be used in
household and similar applications such as:
- staff kitchen areas in shops, offices and other
working environments;
- by clients in hotels, motels and other residential
type environments;
- farm houses;
- bed and breakfast type environments.
18. The microwave oven is intended for heating
food and beverages. Drying of food or clothing and
heating of warming pads, slippers, sponges, damp
cloth and similar may lead to risk of injury, ignition
or fire.
19. Metallic containers for food and beverages are
not allowed during microwave cooking.
20. The appliance shall not be cleaned with a
steam cleaner.
21. The appliance must not be installed behind a
decorative door in order to avoid overheating. (This
is not applicable for appliances with decorative
door.)
22. The microwave oven is intended to be used
built-in.
23. Care should be taken not to displace the
turntable when removing containers from the
appliance. (For fixed appliances and built-in
appliances being used equal or higher than 900mm
above the floor and having detachable turntables.
But this is not applicable for appliances with
horizontal bottom hinged door.)

Safety Instructions
GSM Retail Australia Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust
www.belliniappliances.com.au Model: BPI1200 Fineline Aus Portable Induction Cooker
GSM Retail Australia Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust
www.belliniappliances.com.au Model: BPI1200 Fineline Aus Portable Induction Cooker
3
DANGER
Electric Shock Hazard Touching some of the
internal components can cause serious personal
injury or death. Do not disassemble this
appliance.
WARNING
Electric Shock Hazard Improper use of the
grounding can result in electric shock. Do not
plug into an outlet until appliance is properly
installed and grounded.
This appliance must be grounded. In the event of
an electrical short circuit, grounding reduces the
risk of electric shock by providing an escape wire
for the electric current.
This appliance is equipped with a cord having a
grounding wire with
a grounding plug. The
plug must be plugged into an outlet that is
properly installed and grounded.
Consult a qualified electrician or serviceman if the
grounding instructions are not completely
understood or if doubt exists as to whether the
appliance is properly grounded.
If it is necessary to use an extension cord, use only
a 3-wire extension cord.
1. A short power-supply cord is provided to
reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. If a long cord set or extension cord is used:
1. The marked electrical rating of the cord set
or extension cord should be at least as great
as the electrical rating of the appliance.
2. The extension cord must be a grounding-
type 3-wire cord.
3. The long cord should be arranged so that it
will not drape over the counter top or tabletop
where it can be pulled on
by children or tripped over unintentionally.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since this can result in harmful
exposure to microwave energy. It is important not to break or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner residue
to accumulate on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the oven must not be operated until it has been
repaired by a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of cleanliness, its surface could be
degraded and affect the lifespan of the apparatus and lead to a dangerous situation.
Specifications
Model:
Rated Voltage:
Rated Input Power(Microwave):
240V~ 50Hz
1450W
AM928BV1-S0EFF0

4
CLEANING
Be sure to unplug the applia nce from the power supply.
1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighboring parts must be cleaned carefully with
a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven
door glass since they can scratch the surface, which may result in shattering of the
glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the food cooked can
touch: Place half a lemon in a bowl, add 300ml (1/2 pint) water and heat on 100%
microwave power for 10 minutes. Wipe the oven clean using a soft, dry cloth.
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for anyone other
than a competent person to
carry out any service or repair
operation that involves the
removal of a cover which gives
protection against exposure to
microwave energy.
See the instructions on "Materials you can use in microwave oven or to be
avoided in microwave oven." There may be certain non-metallic utensils
that are not safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of co water (250ml)
along with the utensil in question.
2. Cook on maximum power for 1 minute
3. Carefully feel the utensil. If the empty utensil warm, do not use it for
microwave cooking.
4. Do not exceed 1 minute cooking time.

5
Materials you can use in microwave oven
Utensils Remarks
Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch
(5mm) above the turntable. Incorrect usage may cause the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped
dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant
and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or
chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make slits to allow steam to
escape.
Use for short–term cooking/warming only. Do not leave oven unattended while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision for a short-term
cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be labeled "Microwave
Safe". Some plastic containers soften, as the food inside gets hot. "Boiling bags" and tightly
closed plastic bags should be slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain moisture. Do not
allow plastic wrap to touch food.
ThermometersMicrowave-safe only (meat and candy thermometers).
Wax paperUse as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed to high
temperature.
Wood will dry out when used in the microwave oven and may split or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.

Installation
6
TURNTABLE INSTALLATION
Cleaning the cooking compartment and putting the turntable in place. For new
installations, make sure all packaging and shipping tape has been removed from the
turntable shaft. Before using the appliance to prepare food for the first time, you will need
to put the turntable in place correctly. You must clean the cooking compartment and
accessories.
1. .Never use the appliance without the turntable. Make sure that it properly engaged. The
turntable can turn clockwise or anti-clockwise.
2. Never place the glass tray upside down. The glass tray shou never be restricted.
3. Both glass tray and turntable ring assembly must always be us during cooking.
4. All food and containers of food are always placed on the glass tr for cooking.
5. Never restrict the movement of the turntabl
6. If glass tray or turntable ring assembly cracks or breaks, conta your nearest authorized
service center.
How to put the turntable in place: 1.. Place
the turntable ri assembly ③ into the recess in
the cooking compartment.
2.
. Place the glass tra ① on the turntable ring
assembly ③. Fit the raised, curved lines in
the center of the glass tray bottom between
the three spokes of the shaft. Make sure that
the glass tray ① engages in the turntable
shaft ② in the centre of the cooking
compartment floor. The rollers on the ③
should fit inside the turntable bottom ridge.
3
2
1

6
Installation and connection
1.This appliance is only intended for domestic use.
2.This oven is intended for built-in use only. It is not intended for counter-top use or for use
inside a cupboard.
3.. Please observe the special stallation instructions.
4.The appliance can be installed in a 60cm wide wall-mounted cupboard.
5.The appliance is fitted with a plug and must only be connected to a properly installed
earthed socket.
6.The mains voltage must correspond to the voltage specified on the rating plate.
7.The socket must be installed and connecting cable must only be replaced by a
qualified electrician. If the plug is no longer to accessible following installation, an all-
pole disconnecting device must be present on the installation side with a contact gap
of at least 3mm.
8.Adapters, multi-way strips and extension leads must not be used. Overloading can
result in a risk of fire.
The accessible surface may be hot during
operation.

7
Installing the appliance
•The oven is fitted with a plug and must only be connected to a proper installed earthed
socket. The socket must only be installed and the connecting cable must only be replaced
by a qualified electrician, and in accordance with appropriate regulations. If the plug is no
longer accessible following installation, an all-pole isolating switch must be present on the
installation side with a contact gap of at least 3mm. The fitted cabinet must not have a
back wall behind the appliance.
A gap must be maintained between the wall and the base of the
unit above. Specific gap size
could be referenced by the diagrams.
Minimum installation height: 85cm
Do not cover ventilation slots and suctions holes.
Note:
Do not trap or bend the power cable
Screw
Mounting Plate

8

9
B.Pre p are the caib inet
Holes " "a"
PN:261800316968
3.. Remove the bottom cabinet template and fix the mounting plateith screw.
2.. Make the marks on the bottom plane of cabinet according to marks"a"
the template
put the template on the bottom plane of cabinet.
1.. Read the instruction on the BOTTOM CABINET TEMPLATE
Screw
Mounting Plate

9
C.Install the oven
4. . Install the oven to the cabin
-Make sure the back of the oven is locked by mounting plate
-Do not trap or kink the power cord
Mounting
Plate
5.. Open the door, fix the oven to the cabinet th Screw , at the installa tion hole.
Screw Installation
Hole

9
Control Panel

9
1)) Press Micro
.
" once, the screen display "P100 .
2)) Turn
2) Turn " " to adjust the hour the input time should be within 0--23.
", the minute figures will flash.
3)) Press
Start/+30S ec./Confirm
" to confi P80".
4)
) Turn4) Turn " " to adjust the cooking time until the ove s "20:00".
Operation Instructions
1.. Clock Setting
When the microwave oven is electrified, the LED will display "0:00", buzzer will ring once.
1)) Press "Kitchen Timer/Clock" twice to select clock function, the hour figures will flash.
4)) Turn4) Turn " " to adjust the minute the input time should be within 0--59.
5)) Press "Kitchen Timer/Clock"
" to finish clock setting. ":" will flash, and the time will light.
5) Press " Start/+30S
ec./Confirm" to start cooking .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0--- 0---1
1---5 1---
5---10 5---
10--- 10-- ute
30---95 30---
2)
) Press "
Mic ro
.
" once again " once again or turn" e
power.
Note: 1)
", 2)
2) During the process of clock setting, if you do
the oven will go back to the previous status automatically.
"
2.. icrowave Cookin g
Press "
Micr o .
" the LED will display "P100 ".Press "
Micr o." repeatedly or
turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Star Then press"
t/+30Sec./Confirm
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
Start/+30S
"
ec./Confirm" again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
The clock will not work if it is not set when powered.
3) Press "Kitchen Timer/Clock"
Kitchen Timer/Clock

9
1) P Weight/T ress "
ime Defrost
1)1)) PressPress " .
2)) Turn2) Turn " " to select the weight of food from 100 .
3) Start/+30S
Press "
ec./Confirm
3)3)
) PressPress " .
1Start/+30S
) In waiting state, Press " ec./Confirm
1)
1) In waiting state, Press " r
.uick Star t
In waiting state, Press "
and 30 seconds directly.
Notes: (1) In microwave cooking Grill cooking combination or multi stage state, each
press of Start/+30Sec./Confirm " " can increase 30 seconds of cooking time.
(2) Quick start can be one of the multi stage
2)
) In waiting state, turn " " left to set the cook with 1 % microwave power,
" to start cooking. and 90 minutes.and then press"
4.
5.. frost By Weight
Start/+30S
ec./Confirm
6.. frost By Time
1) Weight/Time Defrost ) Press " " twice, and the oven will display "dEF .
2)
) Turn2) Turn " " to select the defr The MAX time is 95 minutes.
3. Kitchen Timer
(1)1) Pres
(2) Turn "
(3)3) Pres
(1 K ) P itchen
Timer/Clock
" once, LED will display 00:00.
urn " " to enter the correct r.(The maximum cooking time is 95 minutes.)
(3 Star ) Press " t/+30Sec./Con
firm" to confirm setting.
Note: There is not any program during the kitchen timer.
3)) Press " Start/+30S
ec./Confirm
3) Press " " to star d
it will not be changed.

9
7) Start/+30Sec./Confirm ) Press " " to start cooking, and buzzer will sound once for e
first section, defrosting time counts down; buzzer will sound once again entering
the second cooking. when cooking finish, buzzer sounds five times.
1) Weight/T
Press "
ime Defrost
1)1)) PressPress " .
2)
) Turn2) Turn " " to select the defrost time till "5:0 y.
3)) Press Mi
cr o.
" once, the screen d .
5)
) Press Start/+30S
ec./Confirm
" to conf P80".
6)
) Turn6) Turn " " to adjust the cooking time till the ove s "7:00".
4)
) Pres
" Mic ro
.
" once " %
microwave power.
8.. nquiring Function
(1)(1) In states of microw cooking, press " Micr
o.
",
for 3 sec onds. After 3 seconds, the oven will turn back
to the former state;
(2)
2) In cooking state, pres( K 2) I itchen Tim
er/Clock " to inquire the time and the time will
display for 3 seconds.
9.Lock-out Function for Children
Lock: In waiting state, press "Lock: Stop/Clear In waiting state, press " " for 3 se p
denoting entering the children-lock state and the current time will diplay if the time
has been set, otherwise, the LED will display "0:00".
Stop
Lock quitting: In locked state, press " " for 3 seconds, there will be a lon
/Clearg
"beep" denoting that the lock is released.
7.. ulti-section cooking
(1)At most 2 sections can be set for cooking. In multi-section cooking, if one section is defrosting,
then defrosting shall be placed in the first section.(2)kitchenr timer and auto menu can not
seconds each time except weight defrost.
Example: If you want to defrost food for 5 minutes and then cook with 80% microwave
power for 7 minutes, operate it as the following:
t
h
e current power will
d
i
splay
as one of the multi stage.(3)Press"
St art/+30Sec./Confirm " to increase the cook time by 30

9
1)
Turn " " clockwise till "A-6" display.
4) Start/+30Sec./Con ) Press " " to start cooki
firm.
Example: If you want to use "Auto Menu" to cook fish for 350g.
2)) Press2 Start/+30S ) Press "
ec./Confirm
2) Press " .
1) Turn " " right to choose the menu, and "A-1" to "A-8" will display, which
means pizza,meat, fish,beverage and popcorn.
2) Start/+30S Press "
ec./Confirm
2)2)) Press Press " .
3) Turn "urn " " to choose the default weight as the menu .
3) Turn "Turn " " to select the weight of fish till "350" y.
4) Start/+30S Press "
ec./Confirm
4) Press " .
10. Auto Menu
vegetable,pasta, potato,
4)) Press
Auto Menu
MenuWeight Display
A-3
A-5
Vegetable
A-6
Fish
Beverage
A-7
A-4
Pasta
A-8
Popcorn
200 g
400 g
250 g
300 g
400 g
200 g
1cup(about 120ml)
2cups(about 240ml)
3cups(about 360ml)
50g(with 450 cold water)
100g(with 800 cold water)
50g
A-1
Pizza
200
400
250
200
300
400
200
1
2
3
50
100
50
A-2
Meat 350 g
450 g
350
450
200 g
Potato 400 g
600 g
400
600
250 g
350 g
450 g
250
350
450
100g 100
85g 85

9
PN:P0000003213055
According to Waste of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected and treated. If at
any time in future you need to dispose of this product please do NOT
dispose of this product with household waste. Please send this product to
WEEE collecting points where available.
Microwave oven interfering TV
reception
Radio and TV reception may be interfered when
microwave oven operating. It is similar to the interference
of small electrical appliances, like mixer, vacuum
cleaner, and electric fan.
It is normal.
Dim oven light
Oven cannot
be started.
(1)1) Power cord is
plugged in tightly.
Unplug. Then plug again after 10
seconds.
Replace fuse or reset circuit
breaker (repaired by professional
personnel of our company)
Test outlet with other electrical
appliances.
Close door well.
(3)3) Trouble with o et.
(4)4) Door is not clo
well.
(2)2) Fuse blowing
circuit breaker
works.
Oven does not heat.
In low power microwave cooking, oven light may
become dim. It is normal.
In cooking, steam may come out of food. Most will get out
from vents. But some may accumulate on cool place like
oven door. It is normal.
Steam accumulating on
door, hot air out of vents
Oven started accidentally
with no food in.
It is forbidden to run the unit without any food inside. It is very
dangerous.
Normal
Trouble Possible Cause Remedy
Trouble shooting

WARRANTY
1.1 In this warranty:
1.1.1 Australian Consumer Law means the law as set out in Schedule 2 of the Competition and
Consumer Act 2010;
1.1.2 Company means GSM Retail Australia Pty Ltd ABN 53 007 682 475 of 142-144 Fullarton Road, Rose Park
SA 5067. Telephone [phone]. Email [e-mail];
1.1.3 Consumer means a “consumer” as that term is defined in Section 3 of the Australian Consumer
Law as the original purchaser of a Bellini product;
1.1.4 Consumer Guarantees means the guarantees under the Australian Consumer Law;
1.1.5 You means the Consumer.
1.2 Nothing in this warranty affects any person’s rights under the Australian Consumer Law. The benefits to
any Consumer under this warranty are in addition to the rights and remedies available under any
Consumer Guarantees.
1.3 Subject to the other clauses of this warranty, the Company warrants to the Consumer that the Bellini
product will be free of manufacturing defects and will perform to the Company’s specifications.
1.4 The benefit of this warranty extends only to the Consumer as original purchaser of a Bellini product which is
installed in a domestic household area.
*The in Home warranty does not apply to Commercial and or industrial usage. *Please See 1.7.7 for
additional information
1.5 This warranty commences on the date of purchase of the Bellini product by the Consumer and continues
for the benefit only of the Consumer until the expiry of three (3) year (Warranty Period).
1.6 If within the Warranty Period a manufacturing defect is discovered in the Bellini product or it fails to perform
to the Company’s specifications as a result of some defect in materials, components or workmanship
(Defect) then the Company will, at its option, repair the Bellini product or supply a replacement Bellini
product free of charge. A replacement Bellini product may differ from the original product purchased by
the Consumer.
1.7 This warranty will not apply to any Bellini product:
1.7.1 Installed by any person other than a qualified tradesperson; or
1.7.2 Subjected to misuse, neglect, negligence or accidental damage; or
1.7.3 Operated in any way contrary to any operating or maintenance instructions; or
1.7.4 Improperly handled, installed or maintained; or
1.7.5 Altered or modified prior to or after installation; or
1.7.6 Damaged directly or indirectly by power surges, electrical storm damage or connection to
incorrect power supply
1.7.7 Industrial and or Commercial usage is inclusive of staff areas in office/ shop environments, hotel/
motel or other similar accommodation or rental type properties including Bed and Breakfast
establishments.
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY THE CONSUMER MUST CALL 1300 373 199
(AUSTRALIA) OR [phone] (NEW ZEALAND) TO CONNECT TO THE NEAREST AUTHORISED CENTRE
The Australian consumer law requires the following statement with this product
Our goods come with guaranteed that cannot be excluded underthe Australian Consumer Law. You are entitled to a replacement or
refundfora major failure and for compensation forany otherreasonably foreseeableloss ordamage.
Youarealsoentitledtohavethegoodsrepairedorreplacedifthegoodsfailtobeofacceptablequalityandthefailure does not
amount to a major failure.
GSM Retail Australia Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust
www.belliniappliances.com.au Model: BMWM28 Fineline: 295810 Built-In Black Microwave
