Benchmark 1282-701 User manual

5 Year Limited Warranty

•Please note (where the ¼” NPT connecter is not already installed on the tool) your tool may be
shipped with a black plastic cap installed in the air inlet.
Pry the cap out prior to installing the ¼” NPT connector.
•
•
•
NOTE these instructions pertain to the tool only. Please refer to your
compressors operator’s manual and follow the manufactures instructions.

-

Oxygen
nydrogen
Combustible
explosive
SYMBOL MEANING

:

SYMBOLS
Read operator s manual: To reduce the risk of injury,
user must read and understand operator s manual
before using this product.
Eye protection: Always wear safety goggles, safety
glasses with side shields, or a full face shield when
operating this product.
•Avoid direct contact with accessory and work surface during and after work as they
become heated and sharp. Wear safety gloves to protect hands.
•Operators must be physically able to handle the bulk, weight, and power of tool. Do not
force the tool.
•Repetitive work motions and exposure to vibration can be harmful to hands and arms. If
numbness, tingling, pain or whitening of the skin occurs, stop using the tool.
•Stay clear of the hammer while in operation. Flying objects can cause severe injury.
•Avoid “free-running”. This occurs when the tool is not in proper contact with the work,
either sliding off or breaking through thin concrete or rock.
•Never use the hammer steel as a hand struck tool. They are designed for air hammers
only.
•Select the correct shank and retainer for the tool being used.
•Never use dull accessories as they require excessive work
pressure and can break.
•Always maintain a balanced body position and secure footing.
•Be aware of hidden hazards that may exist where you are
working, such as electric wires etc.
•This tool is not intended for use in an explosive atmosphere.
Risk to hearing Always wear ear prptection
when using this tool ,failure to do so may result
in hearing loss.

5
2
1
4
3

Be sure to use a proper air compressor with air-powered tools. The
compressor should be able to supply a minimal air delivery of 4 CFM @ 90
PSI to ensure the compressor can run continuously with the tool.
4-5 Gallons
Light-duty and
Intermittent use
Light-duty and
Intermittent use
Light-duty and
Intermittent use
6-11 Gallons
Light-duty and
Intermittent use
Medium-duty and
Intermittent use
Medium-duty
and Intermittent
use
15+ Gallons
Medium-duty and
Intermittent use
Heavy-duty and
Continuous use
Heavy-duty
and
Continuous
use

10
2 5 7
3 3 8
1 9
6
4

It is recommended that a filter-regulator-lubricator is used and located as close to the tool as
possible.
If a filter-regulator-lubricator is not installed, place up to 6 drops of compressor oil into the NPT
inlet plug before each use.
If a filter-regulator-lubricator is installed, keep the air filter clean. A dirty filter will reduce the air
pressure to the tool, which will cause reduction in power, efficiency, and general performance.
For optimal performance, install a quick coupler in the hose, if applicable.
Verify that all of the connections in the air supply system are sealed in order to prevent air from
leaking.
Read and follow all the safety
instructions at the beginning of this manual. Inspect the air- powered tool prior to each use in
order to:
-Ensure that the proper power source is being used.
-Verify that the tool is in proper working order.
-Verify that the air pressure level (s) are properly set on the air compressor. Do not use the tool if
it is not in proper working order.
Do not use oxygen, CO2 (carbon dioxide) or any other combustible, or bottled gas to power this
tool.
Do not use this tool in the presence of any flammable liquids or gases.
Keep hands and other parts of the body away from the firing head during use. Do not point the
tool towards the operator or other people.

1.
2.
3.
4.
If it is necessary to store the tool for an extended period of time, apply a generous
amount of lubrication before storing.
The tool should be allowed to run for approximately 30 seconds after lubricating, in
order to ensure that the lubrication is uniformly distributed throughout the tool.

-
-
-
- ce.

•Inspect the trigger, the spring, and the safety mechanism for free movement on a regular
basis in order to ensure that the safety system is fully functional.
•Verify that no part is loose or missing and that no part is stuck or jammed.
•
Disconnect the toolfromthe airsupply, clean, andstoreit ina safe, dry,andchildproof
location,whentoolisnotinuse.
•When temperatures are below freezing, keep tools as warm as possible using any safe,
convenient method.
•Check the air supply for correct size and type of hose connectors. To avoid loss of power or
erratic action, ensure that there is no additional drain on the air line and no moisture or
restriction in the air pipe.
⚠

Key#
Part #
PartName
Qty

5 Year Limited Warranty
©
M
MC
Made in China
