BENQ Corporation
Wireless LAN USBAdapter
AWL-300
User Manual
Version 1.0
April 2002

BENQ Corporation
i
Notice I
Copyright Statement
This manual cannot be reproduced in any form or by any means or
used to make any derivative such as translation, transformation, or
adaptation without the prior written permission of BenQ Corporation.
BenQ Corporation reserves the right to change this manual and the
specifications to improve products without prior notice. So you can get
the most recent software and user documentation for all BenQ
Wireless LAN products on our web site.
http://www.BenQ.com
Trademarks
Copyright ©2002 BenQ Corporation. All rights reserved.
Contents subject to change without prior notice. BenQ is a registered
trademark of BenQ Corporation. All other trademarks belong to their
respective proprietors.

BENQ Corporation
ii
Notice II
FCC Warning
The AWL-300 compiles with Part 15 of the FCC rules.
Operation is subject to the following two conditions.
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Note:
The AWL-300 has been tested and found to comply with the limits
for a Class B digital device and a low power transmitter, pursuant to
Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a residential environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.

BENQ Corporation
iii
Table of Contents
Contents........................................................................................ iii
Chapter 1. Introduction
Chapter 2. Installation................................................................... 1
2.1 Driver Installation (Win98/WinME/Win2000)......................... 3
2.2 Driver Installation (WinXP)......................................................... 6
2.3 Application Installation .................................................................. 9
2.4 Application & USB Driver Installation ......................................12
Chapter 3. Uninstallation............................................................ 18
Chapter 4. Configuration & Monitor Utility.............................. 21
4.1 Monitor ..........................................................................................21
4.2 Statistics..........................................................................................23
4.3 Site Survey .....................................................................................24
4.4 Encryption......................................................................................25
4.5 Advanced........................................................................................26
4.6Version ............................................................................................27

BENQ Corporation
1
Chapter 1. Introduction
Thank you for purchasing a BenQ AWL300 Wireless LAN USB Adapter. The
AWL300 Wireless LAN USB Adapter lets you connect to your network and the
Internet without needing to be tethered to a fixed location by a physical cable, while
still getting the same data transfer rates as with traditional Ethernet. You can use it
with any desktop or notebook PC with a USB port. In addition to allowing you to
enjoy the wonders of wireless networking, the AWL100 provides two operating
modes—ad-hoc mode (peer-to-peer) and infrastructure mode (station-to-AP)—to
meet to your varying needs at different purposes.

BENQ Corporation
2
1-1Product Kit
Before installation, make sure that you have the following items:
u
u AWL300 Wireless LAN USB Adapter
u
u USB cable
u
u Software CD containing user manual and utility
u
u Quick Start Guide
u
u Warranty card
1-2 System Requirements
Before using your AWL100, please check that you have the following required items:
u
u PC/Notebook with USB port and CD-ROM drive
u
u Microsoft Windows 98SE/ME/2000/XP operating system
1-3 Mechanical Description
Top panel of theAccess Point
The following table provides an overview of each LED activity:
Activity Description
PWR
LINK Steady Green When connecting to PC

BENQ Corporation
3
2. Installation
There’re three ways to install your AWL300:
Driver Only: Read chapter 2.1 –2.3
Application Only: Read chapter 2.3
Driver & Application: Read chapter 2.4
2.1 Driver Installation (Win98/WinME/Win2000)
Insert AWL300 USB Adapter into your PC, and then Windows will show the dialog –
“Add New HardwareWizard”.
Select “Specify the location of the driver” and press Next button.

BENQ Corporation
4
Select ‘Specify a location’ and browse the BENQ Wireless LAN CD to find
AWL300. For example, if your CD-ROM has a drive D, the location is
D:\AWL300\Win982k.
Windows has found BENQ AWL300 Wireless LAN USB Adapter. Press Next button.

BENQ Corporation
5
Please wait while coping files.
Press Finish.
PressYes and restart your computer.

BENQ Corporation
6
2.2 Driver Installation (WinXP)
Insert AWL300 USB Adapter into your PC, and then Windows will show the dialog –
‘Found New Hardware Wizard’.
Select ‘Specify the location of the driver’ and press Next button.

BENQ Corporation
7
Select ‘Specify a location’ and browse the BENQ Wireless LAN CD to find
AWL300. For example, if your CD-ROM is drive D, the location is
D:\AWL300\WinXP.
Press Continue Anyway

BENQ Corporation
8
Please wait while coping files.
Press Finish.

BENQ Corporation
9
2.3Application Installation
Execute Setup.exe in the AWL300 directory in BENQ Wireless LAN CD. For
example, if your CD-ROM has a drive D, please execute D:\AWL300\Setup.exe.
Press Next button

BENQ Corporation
10
Select ‘Application & USB Drivers’ to install both of them if you don’t have USB
Drivers installed yet.Or, select the ‘Application Only’ icon to install AWL300
applications.
Press Browse,if you want to change destination location of applications, and then
press Next button.
The folder name will be AWL300. Press Next button if you don’t want to change it.

BENQ Corporation
11
Press Next button.
Press Finish and restart your computer.

BENQ Corporation
12
2.4Application & USB Driver Installation
Execute Setup.exe in the AWL300 directory in BENQ Wireless LAN CD. For
example, if your CD-ROM has a drive D, please execute D:\AWL300\Setup.exe.
Press Next button

BENQ Corporation
13
Select ‘Application & USB Drivers’ to install both of them if you don’t have USB
Drivers installed yet.
Press Next button

BENQ Corporation
14
Press Next button
Press Next button

BENQ Corporation
15
Select the operating mode and then press Next button
Specify ESSID and then press Next button

BENQ Corporation
16
Press Next button
Press Finish and restart your computer.
