Best Automobile security system User manual
1/ 8
®
®
Operating Instructions
Foreword
Thank you for choosing The BEST® automobile security system. This system is developed and
manufactured by Auto Secure USA, Inc., using the world's most advanced high-performance
fingerprint dedicated DSP processing chip. A low-power CPU combined with Microchip Technology
Inc., Sweden Fingerprint Cards, AB FPC-1011 planar fingerprint recognition sensor with fingerprint
entry, image processing, template storage, fingerprint matching search and voice prompt intelligent
function module. Recognition speed superior to similar products, unique low-volt consumption
design (standby current <10mA), negligible power consumption controlling various automotive
systems. With the BEST® fingerprint management systems convenience and security, keeping your
vehicle safe will be easier and more convenient.
Table of Contents
Foreword 1
Product Overview 2
Main functions 2
The system installation instructions 2
Operating procedure 3
Initialization steps 4
Production standard 5
The performance parameters 5
Component list 5
Product warranty 6-8
Precautions
1. Installed in accordance with the original vehicle anti-theft system, no changes to the original
vehicle circuit occur, having no effect on any of the original vehicle’s security performance.
2. To achieve the optimal use of all the features of this product, before installing this system, all
systems of the original vehicle must be intact.
3. When installing this system, please read the instructions carefully and install strictly in accordance
with the module installation wiring diagram.
2/ 8
Product Overview
MICROCHIP®, the latest encryption technology, is also one of the world's most advanced vehicle
control systems, preventing theft through fingerprint security.
Main Function
1. Live Fingerprint Identification
Uses live fingerprint recognition technology to encrypt the original vehicles’anti-theft system,
eliminating the original vehicle alarm control technology. This circumvents alarm failure due to
mechanical or human error. A registered fingerprint must be entered to start the vehicle.
2. Starting the vehicle securely
When you insert the vehicles’ key into the ignition and rotate to the "ON" position (Push the Start
button on cars so equipped) and place the correct fingerprint on the sensor, the system will disarm
the alarm and start the vehicle. (After installation, the system must be set up in anti-theft mode to
have this feature)
3. Easy to use setting with multi-mode startup operation
Use the left and right buttons to store & remove fingerprints fast, to switch between fingerprint
startup mode, password security mode and valet mode.
4.Large capacity fingerprint storage
Up to 30 fingerprints can be set and stored in the system.
5. Voice prompts
Voice prompts will guide and inform you through setup and enrollment.
6. Emergency Start
If the vehicle dies due to mechanical failure, simply twist the key back to the OFF position and
restart in six seconds without fingerprint authentication. (Valet Mode)
7.Low voltage alarm
The system has a low voltage detection function, notifying you when the vehicle battery drops below
9 volts.
8. Start time learning function
System will remember how much cranking time is needed after you first start the car.
System installation instructions
This system needs to be installed by trained professionals. Do not insert the key into the vehicle
ignition switch. During the installation process, all the circuit wiring should be carefully connected
and well insulated, the module should be installed in a concealed place, avoiding high temperature,
water.
3/ 8
Operating Procedure
Yes
YES NO
NO
YES
Insert the key into the vehicle
ignition or push Start button on
vehicles so equipped
ignition switch
Turn key to the "ON"
Activate fingerprint
Enter the correct fingerprint
Operation
successful!
Vehicle
started
Entry error, please re-enter
After 5 entry
errors times,
alarm sounds
4/ 8
Press and hold right button until the
broadcast voice prompts for
fingerprint input (system will prompt
first user to register print initially,
subsequent users can then be
entered by authorizing from
registered print)
Initialization steps:
Entering the menu
Note:
In the fingerprint registration, one fingerprint must be entered twice. These two will be stored as different
templates, in order to improve the system's fault tolerance. In the two entry process, if the deviation of the
entries is too large, the system will refuse to register the user. If the entry positions are identical, the system
will reject the entry and require you to start over. This prevents fraudulent inputs. We recommend the thumb,
index or middle finger. A thumbs’lines are clearer, index finger and middle finger are more flexible and
convenient to use. In addition, the best lines to register the fingerprint are clear, with obvious feature points
and no damage.
First step
Turn key to off position
or remove from the
ignition
Entering into menu
Press the right button, follow
prompts or wait 3 seconds to
enter the next menu
automatically
Fingerprint registration.
Press left button to register
new fingerprints. Press right
button to delete fingerprints
(Warning: All fingerprints will
be deleted, please think
twice). If nothing is entered,
system will enter into mode
selection in 3 seconds
automatically
Mode selection
Press right button to enter into
mode selection, press left button
to confirm, press right button to
choose mode.
In car maintenance mode, no
fingerprint is needed to start the
car. IN secure mode, a
registered fingerprint is required,
Exit menu by pressing right
button.
5/ 8
Production standards
This system complies with the Q / SZ 5-2005 standard
Performance parameters
(1) Module rated working voltage: DC 10V ~~ 15V
(2) Module rated operating current (standby state) <10mA
(3) Module rated operating current (start state): 0.4A
(4) Module control relay biggest shock capacity > 40A
(5) Maximum working power: <5W
(6) Normal working temperature: -40 ° C to 85 ° C
(7) Case Material: ABS flame retardant material
(8) Interface standard: industry-standard interface
Component list
Live fingerprint controller accessories list:
Module 1 pc
Fingerprint entry 1pc
DB9 cable line 1set
Six-pin cable 1set
Manual 1pc
Certificate 1pc
Installation diagram 1pc
Product warranty card 1pc
United States Patent No.6,927,668
6/ 8
Product warranty terms and conditions
From the date of purchase Auto Secure USA will offer a minimum of a 3 year warranty (See details
under Warranty), due to any problem arising from the quality of the product.
Warning: Any tampering with the module voids any and all warranties.
24-hour Towing Benefit
As a member of our Roadside Assistance Program, you will be covered for a tow of up to 15 miles
and/or other covered service that does not exceed the benefit limit of $100.00. Your membership
continues for a period of 12 to 36 months depending on your agreement, from the date of purchase
and registration. This is not a vehicle liability insurance contract. This is not a vehicle physical
damage insurance contract. Service obtained from any source other than a properly licensed and
insured roadside assistance provider is not covered and is not reimbursable. 24-Hour Roadside
Assistance: You will be given an 800 number for your 24-hour emergency roadside benefits.
IMPORTANT: Please be with your vehicle when the service provider arrives, as they cannot service
an unattended vehicle. Towing- Provided for up to 15 miles at no charge to member. Additional
mileage is the responsibility of the member and will be negotiated prior to sending out service
(extrication is included - 1 truck 1/2 hour).
Theft Guaranty
The theft protection system guarantees to pay the warranty holder the guaranteed benefit set forth
below in accordance with the terms and conditions listed: The Covered vehicle is
Stolen and not recovered within 60 days or stolen and deemed a total Loss by the holder's
Insurance company
DEFINITIONS
For the purpose of this Warranty the following terms shall mean:
Customer means the purchaser of the Vehicle, as listed in the application section of this Warranty. A
Customer also means an individual who has purchased the vehicle from the original Customer and
has formally transferred the Warranty.
Vehicle means the four-wheeled private passenger vehicle, van, pickup or light truck not to exceed
3/4 ton capacity, as listed in the application section of this Warranty which has had the Auto Security
System installed.
Total Loss means Total Loss Theft for any Reason: A vehicle theft is deemed to be a "total loss theft
for any reason" in the event the Customer's primary insurance company or an appraiser authorized by
the claims administrator has declared the vehicle a total loss as a direct result of theft.
Date of Loss means the date on which the theft of the Vehicle occurred. If such date is
indeterminable, the Date of Loss will be either the date established by the primary insurance
company or the date the theft was reported to the Police, whichever is the earlier.
7/ 8
Actual Cash Value means either the Customer's primary insurance company's total gross settlement
figure, prior to application of deductible, or the "Retail" value of the Vehicle with appropriate
adjustments for mileage and/or optional equipment as determined by the then current, region specific
N.A.D.A. Official Used Car Guide, whichever is the greater.
TERMS AND CONDITIONS
A. The Warranty period is 36 months and commences on the date of Vehicle purchase as shown in
the application section of this Warranty. If Warranty term is not designated, term will be the length
of the Customer's original Loan Lease Agreement not exceeding 36 months’. The original Customer
may transfer this Warranty at time of Vehicle resale, subject to a $30.00 transfer fee being paid to
"Administrator" within 15 days of the vehicle resale date. Copies of the new registered vehicle title
application and bill of sale must be included with the transfer request.
C. Since the Auto Security System is permanently installed on the Vehicle, this Warranty is
non-cancelable and non-refundable.
EXCLUSIONS
This Warranty does not apply to:
A. Total loss or damage resulting from war, whether or not declared, invasion, civil war, insurrection,
rebellion or revolution, nuclear reaction, nuclear radiation or radioactive contamination. Total loss
also excludes any act of God, Natural Disaster or Terrorist Act.
B. Total loss or damage resulting directly or indirectly from forgery or any suspicion of dishonest,
fraudulent or criminal act, or due to conversion, embezzlement or secretion by any person in lawful
possession of the Vehicle.
C. Total loss or damage resulting from theft by family members of the Customer or any person who
had access to the key of the Vehicle.
CLAIM REQUIREMENTS
IN THE EVENT OF A CLAIM, the Customer must provide within 90 days of the Date of Loss,
"Administrator" with all of the following Documentation before any Warranty payment can be
processed. Failure to provide this documentation within the 90 day period will void this
Warranty.
A. Copy of Police Report with narrative
B. Copy of Customer's Warranty.
C. Buyer's orders and finance agreement for original vehicle and or replacement vehicle.
D. Copy of Customer's Primary Insurance Company Settlement Check and Proof of Loss,
substantiating the Date of Loss, specific Cause of loss and Gross Settlement Figure.
In the event the Customer does not have physical damage theft insurance as of the Date of Loss, the
Customer must notify administrator in writing immediately upon the loss being discovered. A loss
adjuster will be instructed to investigate the circumstances of the theft and if it is determined when
the loss is covered, will calculate Actual Cash Value of the Vehicle at Date of Loss. All such loss
adjusting fees will be the sole responsibility of the Customer and will be deducted from any claim
payment. In the event the loss is determined not to be covered, the Customer must reimburse
"Administrator" for the loss adjusting fees.
CONTACT: www.Automgt.com PERFORMANCE AUTOMOTIVE MANAGEMENT
8/ 8
WARRANTY:
Auto Secure, Inc. will cover all parts including replacement of complete system for a minimum
period of 3 years (New Vehicle purchase - Auto Secure USA will match Manufacturer’s Bumper to
Bumper coverage) from date of installation (Purchase) against any manufacturer defect .Excludes:
Acts of God, Acts of terrorism, water damage, fire damage, mechanical interference. Must supply
proof of purchase and proof of installation from certified Auto Secure USA Installer
Auto Secure USA
515 N. Flagler
Suite P-300
West Palm Beach, FL 33401
888-596-8883
