Beta Aivin GT112 User manual

ATTENTION
To avoid to damage amplifier or other equipments, please turn off the level of all equipments before
connection and power off the equipments as well.
Power on the equipments ordinal.
This amplifier equips with protected circuit, which will startup for few seconds after the amplifier powers on.
This amplifier will be MANUAL modestate as it powers on.
PANEL DESCRIPTIONS
o
3
510
4
2
8
9
7
6
112 13 14
11
15
1. Input jack 1/4"(6.35mm): Use this jack to connect electric guitar
2. Set/Manual button: Use this button to store the setting in Channel 1 to 5.
More details of usage please see User setting
3. Channel 1to 5: Use these channels to stored user setting
4. Amp Models: Use this control to select 4 models of ( each model has two tone): Clean, Tweed, Fuzz, Metal.
5. Gain: Use this control to adjust the level of gain
6. Level: Use this control to adjust the output level
7. EQ: Use these 3 controls to adjust Bass Mid and Treble frequency level, ( 12dB)
IMPORTANT SAFETY INSTRUCTIONS
GUITAR AMPLIFIER
GT112
CAUTION
To reduce the risk of fire or electric shock. Do not expose this apparatus to rain or moisture. To reduce the
risk of electric shock. Do not remove cover. Refer servicing to qualified service personnel for repair this
apparatus.
Voltage: AC 220V~50Hz
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle is intended to alert you to the presence of
important operating and servicing instructions.
The lighting flash & arrowhead symbol, within an equilateral triangle, is intended to alert you to the
presence of danger.
1. Connect the amplifier ONLYto a properly grounded AC outlet of the proper voltage for your amp.
2. Avoid the thread to be under kick or heavily hustled.
3. Do not block any ventilation openings on this amplifier.
4. Do not operate near any heat source.
5. Do not expose this amplifier to rain or moisture.
6. Disconnect the power cord if the amplifier is not in use for longer period.
7. To reduce the risk of electric shock, DO NOT remove the cover.
Please read before using this product and strictly follow the owner's manual
Please keep this manual for future reference.

8. Modulation: Use this control to select modulation effects: chorus flanger phase wah-wah
9. TAP: Use this control to set the rate of effect
10. DELAY: Use this control to adjust the feedback and output level of delay.
11. TAP: Use this control to adjust the time of delay
12. REVERB: Use this control to adjust the output level of reverb.
13. MASTER: Use this control to adjust the master volume.
14. HEADPHONE (1/4"): Use this jack to connect headphone for silent practice.
15. POWER: Use this switch to turn the amplifier on/off.
REAR PANEL
16. LINE OUT (1/4") : Use this jack to connect external amplifier
mixer or others equipments.
17. FOOTSWITCH: Use this jack to connect FS-D2 for selecting channels
from1 to 5
1. To adjust the controls and create a new sound.
2. Hold the button SET/MANUAL, and press one of the button
(channel indication) 1 to 5 to store the sound created.
3. Repeat the operation to create and store 5 sounds in
channels.
HOW TO MAKE THE SETTING
Preset settings are stored in 5 channels of this amplifier at first
time you power on it.
For restore the preset settings just Hold the SET/MANUAL button
before you power on the amplifier.
The channels will be restored as preset settings.
RESTORE THE PRESET SETTINGS
17 16
F
OOT SWITCH
FS-D2
Input sensitive/Impedance------------------------- -20dBu/1M (@1KHz)
Output(RMS)---------------------------------------------60W/4 Ohm
Speaker---------------------------------------------------12 (30cm)x1
Connection(1/4 )---------------------------------------Input
--------------------------------------------------------------Headphone
--------------------------------------------------------------Line out
Amp Models-----------------------------------------------Clean Tweed Fuzz Metal
User storage channel-----------------------------------1-5
EQ(3 Band EQ)-------------------------------------------Bass Middle Treble
Modulation------------------------------------------------Chorus Flanger Phase Wah-wah
Delay-------------------------------------------------------Delay
Reverb-----------------------------------------------------Reverb
Power/Supply---------------------------------------------220V~50Hz
Net weight-------------------------------------------------14Kg
Packing Size----------------------------------------------587x305x490mm
Accessories-----------------------------------------------FS-D2 Foot switch((5M cable RJ45)
SPECIFICATION
Latest DSP electric guitar amplifier built-in original designed A.D. module
Advanced Amp models and professional DSP effect
Beta Aivincontinually develops newproducts, as wellas improves existingones.
For this reason,the specifications andinformation in thismanual are subjectto change withoutnotice.
www.beta-aivin.com
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
AC 220V 50Hz
~
FUSE T1.0A
FOOT SWITCH LINE OUT
GUITAR AMPLIFIER
OUTPUT(RMS): 60W/4 Ohm
SERIAL NO:
GT112
