INSTRUCTION MANUAL
Thank you for purchasing our BP-HD-923 Automatic
Hand Dryer.
Please read this instruction manual carefully and
keep for future reference.
IF YOU HAVE ANY QUESTIONS REGARDING THE INSTALLATION
OR OPERATION OF THIS HAND DRYER OR IF YOU NEED A COPY
OF THE INSTALLATION INSTRUCTIONS PLEASE CALL OUR
TECHNICAL SERVICE LINE AT 1800 121 6254
bringing India to the world...
AUTOMATIC
Technical Parameters
Frequency : 50Hz
Time Delay : 5 Sec
Voltage : 220V
Power : 1800W
Current : 8.2A Acting Distance : >140mm
Material : ABS Weight : 2.3Kg
Dimension : 250x238x230mm
IMPORTANT INFORMATION
Please read the information contained in these instructions
careful l y. It p r ov i d es im p o rtan t a dvic e regarding t he safe
installation, use and maintenance of the unit. These instructions
should be kept in a safe place and passed on to the new owner
should the unit be resold.
The manufacturer will accept no liability or damage resulting from
failure to observe the following :
4Ensure packing materials are disposed of properly.
4Any damage to the hand-dryer on delivery should be reported to
the supplier before the unit is connected.
4To ensure the safe operation of the hand-dryer, it should only be
installed and connected by a trained electrician in accordance
with the instructions contained in this booklet.
4The hand-dryer should only be used for the purpose for which it
is intended.
4Repairs to the hand-dryer should only be carried out by a trained
specialist.
USAGE
The hand-dryer is intended to be affixed to a vertical wall in
industrial and commercial areas and to be used exclusively
for drying hands. The electrician should determine the suitability
of area to fit.
Cautions:
This machine should be installed on the wall which is firm
and doesn’t shake.
Don’t install it on the wall with flammable decorative mat-
erials to avoid causing fire or accident of body
Don’t block the air vent.

FIG. 1
FIG. 2
AUTOMATIC HAND DRYER
OPERATING INSTRUCTIONS
FOR THE USER
In order to d r y you r h a nds mos t e f f i c i ently, p l ease us e t h e
following procedure:
• Shake off excess water over the wash basin
• Place hands underneath the unit at a distance of 4" - 7"
• Rub your hands together as if you were washing them
Your hands will be dry within 25 - 35 seconds.
The BHARAT PHOTON BP-HD-923 hand dryers are equipped
with an infrared sensor switch. This sensor will activate the
unit when hands are placed underneath it. Approximately 7
sec o nd s af t er t he h an d s h ave b ee n rem o v e d, t he u ni t wi l l
automatically shut off.
AUTOMATIC
INSTALLATION DIAGRAM
