Biokan ROASTER User manual

MANUAL
CHARCOAL CHURRASCO
GRILL
By BIOKAN Inc.

1
PLEASE READ ALL THE INSTRUCTIONS IN THIS
MANUAL THOROUGHLY BEFORE INSTALLING AND
OPERATING THE GRILL.
RETAIN IT FOR FUTURE REFERENCE.

2
IMPORTANT
The present manual will help you use the product safely.
• Read all instructions before installing and using the equipment.
• Save these instructions.
• Keep the manual within reach for future reference.
• The pictures, technical drawings and general information in this manual might have been
modified since its first edition.
When this rotisserie is not properly installed, a fire may result. To reduce risk of fire, follow the
installation instructions.
Please read this manual carefully before you install the Churrasco Grill.
Failure to follow instructions may result in property damage, body injury or death.
Since 1988
KOZANI, GREECE

3
WELCOME TO BIOKAN Inc.
Our company, BIOKAN Inc. was founded in 1988 and is headquartered in Kozani, Greece.
Since then, we have been manufacturing stainless steel constructions for restaurants and
other food service establishments.
Over the past few years, we have specialized in manufacturing commercial kitcen exhaust
hoods, charcoal ovens and rotisseries with great success. What led us to this success is the
know-how and our experienced staff as well as our avant-garde machinery. We boast one of
the most technologically advanced production lines of stainless-steel constructions in Greece.
As a result, we manufacture high quality products, which combine modern design with
functionality, to the most competitive prices.
We manufacture and offer to our clients a large product line of stainless-steel commercial
kitchen equipment, such as exhaust hoods, charcoal ovens, wood/gas pizza ovens, charcoal
rotisseries and grills. We also offer consulting services, regarding the exhaust hood
installation and the space disposal of the professional equipment in commercial kitchens.
BIOKAN Inc. believes in continuous improvement. Our engineers are constantly developing
and redesigning products so that they can respond to our customers’ needs. BIOKAN strives
to construct products that are more efficient, easier to install and maintain, and products that
meet the highest standards.
Our Vision is to continue being a customer centric business which has determined our
development, commercial expansion, and strategy since our foundation and to keep providing
our clients with high quality products and services to fair prices.
As a result, we have established long-term and fruitful business relations with the
companies we have cooperated for the past few years. We always offer to our clients the best
pre-sales and after - sales support.

4
CONTENTS
1. BEFORE USING THE CHURRASCO GRILL
1.1. Before Using the Churrasco Grill ……………………………………………………………….5
2. CHURRASCO GRILL MODELS
2.1 Churrasco Grill Models ……………………………..…………………,,………………………..7
2.2 Technical Information …………………………………………………………………………....8
2.4 Drawings …………………………………………………………………………………………..9
3. COMPONENTS
3.1 Components ………………………………………………………………………………..……10
3.4 Accessories ………………………………………………………………………………………12
4. INSTALLATION INSTRUCTIONS
4.1 Warnings …………………………………………………………………………………………13
4.2 Assembly …………………………………………………………………………………………14
5. CLEANING AND MAINTENANCE
5.1 Cleaning …………………………………………………………………………………….……15
5.2 Maintenance ……………………………………………………………….……..…………..….16
6. WARRANTY
6.1 Warranty ………………………………………………………………………………………….17
7. CONTACT DETAILS
7.1 Contact Details …………………………………………………………………………………..18

5
1.1 BEFORE USING THE CHURRASCO GRILL
Place the Churrasco grill on a hard level, non-combustible, stable surface
(concrete, ground, etc.), which can support the weight of the grill. Never place the
grill on wooden or other combustible surfaces.
The Churrasco grill is hot when in use. To avoid burns wear protective gloves or
oven mitts.
DO NOT touch any surface of the Churrasco grill, as the surfaces are at high
temperature.
DO NOT attempt to move the Churrasco grill when it is in use. Do NOT clean
the grill while it is still hot.
Place the Churrasco grill on a surface which is NOT accessible to children and
pets. Close supervision is necessary when the grill is in use.
Never leave burning charcoal/wood or ashes in the Churrasco grill unattended.
Before the grill can be left unattended, the remaining charcoal and the ashes
must be removed. Do NOT pour ashes into flammable or thermo deformable
buckets made from materials like plastic, rubber, wood or similar.
Store the unit in a safe and dry place. Rain or adverse weather conditions may
damage the Churrasco grill.
Do NOT put off the fire by throwing water in the grill.
Do NOT throw the charcoal into the Churrasco grill but place them gently.

6
1.1 BEFORE USING THE CHURRASCO GRILL
DO NOT store lighter fluid and other flammable liquids or materials under the
grill. Put any flammable material at least 30 cm away from the sides or the top of
the grill.
DO NOT use gasoline, kerosene or alcohol to fire up the charcoal. Using any of
these or similar products could cause an explosion and possibly lead to severe
injury.
DO NOT install this appliance in any area where it may be affected by any
adverse conditions such as steam, grease, dripping water, high temperatures, or
any other adverse conditions.
Respect the frequency and guidelines of maintenance and cleaning
recommended by BIOKAN Inc. in this manual.
When this equipment is not properly installed, a fire may result. To reduce risk of
fire, follow the installation instructions.
BIOKAN Inc. will not be responsible of any damages caused to people, parts or
installations due to improper use or maintenance of the Churrasco Grill.
The legislation of the country and town, where the equipment is going to be
installed, must be checked since norms and regulations may ask for further
safety measures than the ones exposed in this manual.

7
2.1 CHURRASCO GRILL MODELS
COUNTER- TOP
K6S 850x610x350 mm
(6 skewers)
K9S 1100x610x350 mm
(9 skewers)
WITH CABINET
K6SF 850x610x970 mm
(6 skewers)
K9SF 1100x610x970 mm
(9 skewers)

8
2.2 CHURRASCO GRILL TECHNICAL INFORMATION
TECHNICAL INFORMATION K9S/K9SF
Roasting area
830x460 mm (9 skewers 8x8x500 mm)
Fire up time
20 min average
Charcoal daily consumption *
Charcoal 11 –13 kg
Broiling temperature
200 ºC to 250 ºC
Exhaust rate
2.800 m3/h
Net weight K9S
90 kg
Net weight K9SF
130 kg
TECHNICAL INFORMATION K6S/K6SF
Roasting area
575x460 mm (6 skewers 8x8x500 mm)
Fire up time
20 min average
Charcoal daily consumption *
Charcoal 8 –10 kg
Broiling temperature
200 ºC to 250 ºC
Exhaust rate
2.500 m3/h
Net weight
82 kg
Net weight
108 kg
INSTALLATION
Clearance with non-flammable equipment
100 mm
Clearance with flammable equipment
300 mm
INCLUDED ACCESSORIES OPTIONAL ACCESSORIES
2 Stainless steel rod grill racks Extra stainless steel rod grill racks
Set of skewers Extra skewers
Firebricks
Grill scraper
Poker
Charcoal Starter
* The quantity of the charcoal consumption depends on the cooking duration and the quality of
the charcoal used.

9
2.3 DRAWINGS
DIMENSIONS:

10
3.1 COMPONENTS
Skewers Waiting Positions
Motorized
Spinning system
Fire brick Fire pit
coating
Grill rack
holder Switcher
Cabinet
Opening doors
Wheels

11
3.1 COMPONENTS
DESCRIPTION CODE
Set of Skewers
SKEW
Grill grate
GRCH1
GRCH2
5 Waiting positions
CHWP
Fire bricks
FBRK
Cabinet
CHUC
Wheel
CGA12
Motor 220V/25Watt
CHMTR

12
3.2 ACCESSORIES
DESCRIPTION CODE
Charcoal Starter
CHST
Grill scraper
GSC
Ash Shovel
CSH
Poker
POK

13
4.1 WARNINGS
Before firing-up the Churrasco grill for the first time, remember to remove all the
plastics that are covering the exterior of the grill.
This product may have been dispatched in more than one packages. Check that
all items and accessories have been received as ordered. Keep all
instructions/manuals.
Do NOT use flammable liquids to fire-up the charcoal. Only use charcoal as fuel
for the grill.
DO NOT place any obstructions that may block the access for the maintenance
or the service of the grill. DO NOT block the lateral and inferior part of the
rotisserie, as the motor can be seriously damaged, due to limited air circulation.
DO NOT modify or damage the feet or the wheels of the grill.
Always place the Churrasco grill under an exhaust hood.
In all the installation options, it is important to keep the components of the grill clean
(see Chapter 5, Cleaning and maintenance).
You must fire-up the Churrasco grill before starting roasting. All the firing-up
process must be done without any accessories on the grill.
Place the Churrasco grill at a distance of at least 100 mm away from the wall or
any other cooking appliance.

14
4.2 ASSEMBLY
a.
Plug the Churrasco grill into an
outlet with the following
specifications:
USA: 120V / 60Hz
EU: 220V / 50Hz
b.
Electrical Drawing:
The Churrasco grill must be properly grounded in
accordance with the European Union Standards.
c. Turn on or off the grill by pressing the ON/OFF button.

15
5.1 CLEANING
Perform the operations when the grill is cold to avoid burns.
Do NOT use chemical products to clean the grill.
Do NOT pour ashes into flammable or thermo deformable recipients made from
materials like plastic, rubber, wood or similar.
CAUTION! DO NOT splash water directly into the Churrasco grill and DO NOT
use any water or any kind of liquid, as this could cause an electric shock.
Clean with e grease remover and a cloth or brush.
✓It is necessary to clean the grill racks and/or the skewers after every use.
✓Remove the grill racks and/or the skewers and wash them with a grease remover and
a brush or cloth.
✓Do NOT use a corrosive grease remover to clean the outside of the grill.
✓Clean the exterior casing of the grill with a grease remover and a cloth.

16
5.2 MAINTENANCE
Make sure that the grill is cold before performing any maintenance operation.
Wear protective gloves or oven mitts.
It is forbidden to perform any modification to the equipment unless it has been
approved by BIOKAN Inc. before.
Do NOT use pieces or parts of other companies.
BIOKAN Inc. will not be responsible of damages provoked to people, parts or
installations caused by an improper use or maintenance of the Churrasco grill.
All inspections must be carried out by qualified personnel.
Instructions:
▪Grease the gears twice a year.
Put on protective gloves.
Switch off and plug out the grill.
Unscrew the bolts at the back to have access to the rotating system.
Pull the housing gently and remove it.
Grease the gears with a special temperature grease. Then turn on the grill by using
the switcher and after a few seconds turn it off. Grease the part of the gears that was
not accessible before.
▪Motor replacement.
Put on protective gloves.
Switch off and plug out the grill.
Unscrew the bolts laterally to have access to the motor.
Pull the housing gently and remove it.
Unscrew the old motor and replace it with the new one paying attention to all the
connections. CAUTION! It is recommended that the operations be done by qualified
personnel.

17
6.1 WARRANTY
BIOKAN Inc. guarantees ONE-year warranty from the purchase
date of this product, against any defect in the materials and the
components used during its fabrication.
THIS WARRANTY WILL NOT BE VALID UNDER THE FOLLOWING CIRCUMSTANCES
1. When the Buyer or the End user do not follow strictly the instructions of use in this manual.
2. When the product has been misused, damaged, or exposed to any liquid or corrosive
substance or for any other faults attributable to the Buyer or End user.
4. When the product has been modified or repaired by non-qualified personnel.
5. When the fault is due to the normal wearing out of the grill and its parts due to long term
use.
6. When the damage is caused by liquids, chemicals or products that should not be poured
inside the oven.
NOTES:
▪Repair or substitution is possible only when a product was originally defective (at the
time of delivery).
▪The Buyer or the End user is responsible for any damage caused due to wrong or
improper use.
▪The Buyer should inspect the products immediately after the delivery and any
complaints or arguments must be sent to our company within five (5) business days.
▪The risk of loss, destruction, or damage of the product during the shipping is the
Buyer’s or carrier’s responsibility, even if the shipping order has been given by our
Company at the request of the Buyer.
▪All repairs during the guarantee periods of 12 months, are performed in our factory in
Greece.
▪The Buyer is responsible for the shipping of the products and covers exclusively the
shipping cost.
▪If the problem to be repaired is caused by an incorrect use or installation a charge will
be applied, even if the product is in the warranty period.
No other warranty, verbal or written, different that the one expressed here will be
accepted by BIOKAN Inc.

18
7.1 CONTACT
CHARCOAL OVENS & GRILLS
By BIOKAN Inc.
www.biokan.gr
[email protected]
www.facebook.com/RoasterOvens
https://www.instagram.com/roaster_ovens
https://www.linkedin.com/company/biokan-oe
https://www.youtube.com/channel/UCjOpxGWZamP7FVeQ2Dx45yA
FACTORY
2nd km. Kozanis –Neas Nikopolis, 50100, Kozani, GREECE
Tel.: [phone]
HEAD OFFICES
312 Syggrou Av, Kallithea, 17673, Athens, GREECE
Tel.: [phone]
