FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in
a particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied warranties of
merchantability or fitness for any purpose. Further the vendor reserves
the right to revise this publication and to make changes to the contents
here of without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without
first obtaining the vendor’s approval in writing.
The content of this user’s manual is subject to be changed without notice
and we will not be responsible for any mistakes found in this user’s
manual. All the brand and product names are trademarks of their
respective companies.

C
C
Co
o
on
n
nt
t
te
e
en
n
nt
t
t
ii
LAYOUT OF M6VLQ GRAND...............................................................1
COMPONENT INDEX.............................................................................2
ENGLISH...................................................................................................3
M6VLQ Pro Features ................................................................................................. 3
Package contents......................................................................................................4
How to setup Jumper ................................................................................................ 5
CPU Installation ......................................................................................................... 5
DIMM Modules: DIMM1/ DIMM2 ................................................................................ 6
Jumpers, Headers, Connectors & Slots................................................................... 7
ESPAÑOL.................................................................................................12
Características del M6VLQ Pro...............................................................................12
Contenido del Paquete............................................................................................ 13
Cómo instalar un Puente......................................................................................... 14
Instalación de la CPU .............................................................................................. 14
Módulos DIMM: DIMM1/ DIMM2.............................................................................. 15
Puentes, Cabezales, Conectores y Ranuras ......................................................... 16
WATCHDOG TECHNOLOGY..............................................................21
WARPSPEEDER.....................................................................................22
Introduction.............................................................................................................. 22
System Requirement............................................................................................... 22
Installation................................................................................................................ 23
Usage........................................................................................................................ 24
STUDIOFUN!TM (OPTIONAL) .............................................................32
Introduction.............................................................................................................. 32
Hardware Requirements..........................................................................................32
Installation and Usage............................................................................................. 32
TROUBLE SHOOTING.........................................................................33
SOLUCIÓN DE PROBLEMAS.............................................................34

1
Layout of M6VLQ Grand
※NOTE: ●represents the first pin.

2
Component Index
A. Power Source Selection for K. Front USB Header (JUSB1)
Keyboard and mouse (JKBV1) L. PCI BUS Slots (PCI1-3)
B. Power Source Selection for USB M. Communication Network Riser Slot
(JUSBV1) (CNR1)
C. Back Panel Connector N. System Fan Header (JSFAN1)
D. ATX Power Connector (JATXPWR1) O. Floppy Disk Connector (FDD1)
E. Front Audio Header (JAUDIO1) P. Front Panel Connector (JPANEL1)
F. CD Audio-In Header (JCDIN2) Q. Clear CMOS Function (JCMOS1)
G. CD Audio-In Header (JCDIN1) R. Case Open Connector (JCI1)
H. Power Source Selection for USB S. IDE Connectors (IDE1-2)
(JUSBV2) T. DIMM Modules (DIMM1-2)
I. Digital Audio Connector (JSPDIF1) U. CPU Fan Header (JCFAN1)
J. Front USB Header (JUSB2) V. Wake On LAN Header (JWOL1)

3
English
M6VLQ Pro Features
A. Hardware
CPU
Provides Socket 370.
Supports Celeron™ processor PPGA (FC-PGA & FC-PGA2) and the Pentium® III
Micro-Processor (FC-PGA & FC-PGA2) and VIA C3 Ezra and Ezra-T Samuel 2 for
high-end workstations and servers.
Front Side Bus at 66/100/133 MHz.
Chipset
North Bridge: VIA CLE266 CE.
South Bridge:VIA VT8235.
Main Memory
Supports up to 2 DDR devices.
Supports 200/266 MHz (without ECC) DDR devices.
Maximum memory size of 2GB.
Lan Chip (optional)
Chip: VIA VT6103.
Supports 10 Mb/s and 100 Mb/s auto-negotiation
Half/ Full duplex capability.
Slots
Three 32-bit PCI bus master slots.
One CNR slot.
On Board IDE
Supports four IDE disk drives.
Supports PIO Mode 4, Bride Mode and Ultra DMA 33/66/100/133 Bus Master
Mode.
Super I/O
Chip: ITE IT8705.
Provides the most commonly used legacy Super I/O functionality.
Environment Control initiatives
- H/W Monitor
- Fan Speed Controller
- ITE's "Smart Guardian" function
On Board AC’97 Sound Codec
Chip: VIA VT1612A.
AC’97 2.2 S/PDIF extension compliant codec.
18-bit stereo full duplex.

4
On Board Peripherals
a. Rear side
1 serial port.
1 VGA port.
1 parallel port. (SPP/EPP/ECP mode)
1 audio port in horizontalposition.
1 LAN jack.
PS/2 mouse andPS/2 keyboard.
2 USB2.0 ports.
b. Front Side
1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes.
4 USB2.0 ports.
1 S/PDIF Out Connector.
Dimensions
Micro ATX Form Factor: 19 X 24.4cm (W X L)
B. BIOS & Software
BIOS
Award legal Bios.
Supports APM1.2.
Supports ACPI.
Supports USB Function.
Software
Supports WatchdogTM, 9th TouchTM, FLASHER™, StudioFun!TM (optional),
WarpspeederTM.
Offers the highest performance forWindows 98 SE, Windows 2000, Windows Me,
Windows XP, SCO UNIX etc.
Package contents
HDD Cable X1
FDD Cable X1
User’s Manual X1
USB Cable X1 (optional)
Rear I/O Panel for ATX Case X1 (optional)
Fully Setup Driver CD X1
S/PDIF Cable X1 (optional)
StudioFun! Application CD X1 (optional)

5
How to setup Jumper
The illustration shows how jumpers are setup.When the Jumper cap is placed on pins, the
jumper is “close”. If no jumper cap is placed on the pins, the jumper is ”open”. The
illustration shows a 3-pin jumper whose pin 1and 2 are “close” when jumper cap is placed
on these 2 pins.
Jumperclose Jumperopen Pin1-2close
CPU Installation
Step1: Pull the lever sideways away from the socket and then raise the lever up to a
90-degree angle.
Step2: Look for the white dot/cut edge. The white dot/cut edge should point towards the
lever pivot. The CPU will fit only in the correct orientation.
Step3: Hold the CPU down firmly, and then close the lever.
Step4: Put the CPU fan on the CPU and buckle it. Connect the CPU fan power cable to
the JCFAN1. This completes the installation.
Step1 Step2 Step3 Step4

6
CPU Fan Header: JCFAN1
Pin No. Assignment
1 Ground
2 +12V
1
JCFAN1 3 FAN rpm Rate Sense
System Fan Header: JSFAN1
Pin No. Assignment
1 Ground
2 +12V
13
JSFAN1
3 FAN rpm Rate Sense
DIMM Modules: DIMM1/ DIMM2
DRAM Access Time: 2.5V Unbuffered DDR 200/266 MHz Type required.
DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin)
Total Memory Size with Unbuffered DIMMs
DIMM Socket
Location DDR Module Total Memory Size (MB)
DIMMB1 64MB/128MB/256MB/512MB/1GB
*1
DIMMB2 64MB/128MB/256MB/512MB/1GB
*1
Max is
2GB
***Only for reference***
Installing DDR Module
1. Unlock a DIMM slot by pressing the
retaining clips outward. Align a DIMM on
the slot such that the notch on the DIMM
matches the break on the slot.
2. Insert the DIMM firmly and vertically into
the slot until the retaining chip snap back in
place and the Dimm is properly seated.

7
Jumpers, Headers, Connectors & Slots
Floppy Disk Connector: FDD1
The motherboard provides a standard floppy disk connector that supports 360K,
720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector supports the
provided floppy drive ribbon cables.
Hard Disk Connectors: IDE1/ IDE2
The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO
Mode 0~4, Bus Master, and Ultra DMA 33/ 66/ 100/ 133 functionality. It has two
HDD connectors IDE1 (primary) and IDE2 (secondary).
The IDE connectors can connect a master and a slave drive, so you can connect
up to four hard disk drives. The first hard drive should always be connected to
IDE1.
Peripheral Component Interconnect Slots: PCI 1-3
This motherboard is equipped with 3 standard PCI slots. PCI stands for Peripheral
Component Interconnect, and it is a bus standard for expansion cards. This PCI
slot is designated as 32 bits.
Communication Network Riser Slot: CNR1
The CNR specification is an open Industry Standard Architecture, and it defines a
hardware scalable riser card interface, which supports modem only.
Power Connectors: JATXPWR1
PIN Assignment PIN Assignment
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 Ground 13 Ground
4 +5V 14 PS_ON
5 Ground 15 Ground
6 +5V 16 Ground
7 Ground 17 Ground
8 PW_OK 18 -5V
9 Standby Voltage
+5V 19 +5V
20
11
10
1
JATXPWR1
10 +12V 20 +5V

8
Front Panel Connector: JPANEL1
Front USB Header: JUSB1/2
Pin Assignment Pin Assignment
1 +5V(fused) 2 +5V(fused)
3 USBP4- 4 USBP5-
5 USBP4+ 6 USBP5+
7 Ground 8 Ground
2
1
10
9
JUSB1/2 9 KEY 10 NA
Power Source Selection for Keyboard/ Mouse: JKBV1
JKBV1 Assignment Description
1
3
Pin 1-2 close
+5V
+5V for keyboard and mouse
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
(+) (-)
(+) (-)(+)
Pin Assignment Function Pin Assignment Function
1 +5V 2 Sleep Control
3 NA 4 Ground Sleep
Button
5 NA 6 NA NA
7 Speaker
Speaker
Connector
8 Power LED (+)
9 HDD LED (+) 10 Power LED (+)
11 HDD LED (-) Hard Drive
LED 12 Power LED (-)
POWER
LED
13 Ground 14 Power Button
15 Reset Control Reset
Button 16 Ground Power-on Button
17 NA 18 KEY
19 NA 20 KEY
21 +5V 22 Ground
23 IRTX
IrDA
Connector
24 IRRX
IrDA
Connector
JPANEL1

9
1
3
Pin 2-3 close
+5V Standby
Voltage
PS/2 Mouse and PS/2 Keyboard are
powered with +5V standby voltage
Note: In order to support this function “Power-on the system via keyboard
and mouse”, “JKBV1” jumper cap should be placed on pin 2-3.
Power Source Selection for USB: JUSBV1/ JUSBV2
JUSBV1/JUSBV2 Assignment Description
1 3
Pin 1-2 close
+5V JUSBV1: 5V for USB connectors
located at the JUSBLAN1 connector
port
JUSBV2: 5V for USB connectors
located at the JUSB1/2 connector ports
1 3
Pin 2-3 close
+5V Standby
Voltage JUSBV1: JUSBLAN1 port powered with
standby voltage of 5V
JUSBV2: JUSB1/2 ports powered with
standby voltage of 5V
Note: In order to support this function “Power-on the system via USB
devices”, “JUSBV1/ JUSBV2” jumper cap should be placed on pin 2-3
respectively.
Clear CMOS Jumper: JCMOS1
JCMOS1 Assignment
1
3
Pin 1-2 Close
Normal Operation (default)
1
3
Pin 2-3 Close
Clear CMOS Data

10
※Clear CMOS Procedures:
1. Remove AC power line.
2. Set the jumper to “Pin 2-3 Close”.
3. Wait for five seconds.
4. Set the jumper to “Pin 1-2 Close”.
5. Power on the AC.
6. Reset your desired password or clear the CMOS data.
Case Open Connector: JCI1
Pin Assignment
1 Case Open Signal
1
JCI1 2 Ground
CD-ROM Audio-In Header: JCDIN1/ JCDIN2
Pin Assignment
1 Left Channel Input
2 Ground
3 Ground
1
4
JCDIN1/2 4 Right Channel Input
Front Panel Audio Header: JAUDIO1
1
29 10
JAUDIO1
Pin Assignment Pin Assignment
1 Mic In 2 Ground
3 Mic Power 4 Audio Power
5 Right Line Out/ Speaker
Out Right 6 Right Line Out/ Speaker Out Right
7 Reserved 8 Key
9 Left Line Out/ Speaker
Out Left 10 Left Line Out/ Speaker Out Left
The following procedures are for resetting the
BIOS password. It is important to follow these
instructions closely.

11
Digital Audio Connector: JSPDIF1
Pin Assignment
1 +5V
2 SPDIF_OUT
31
JSPDIF1 3 Ground
Wake On LAN Header: JWOL1
Pin Assignment
1 +5V Standby
2 Ground
13
JWOL1
3 Wake up
Back Panel Connectors
PS/2
Keyboard
PS/2
Mouse
COM1
Parallel Port Game Port
JPRNT1 JGAME1
JCOM1
JKBMS1
USB
LAN
(Optional)
JUSBLAN1
Speaker
Out Line In
Mic
In
JVGA1
VGA1

12
Español
Características del M6VLQ Pro
A. Hardware
CPU
Proporciona Socket 370.
Soporta procesador Celeron™ PPGA (FC-PGA & FC-PGA2) y Pentium® III
Micro-Procesador (FC-PGA & FC-PGA2) y VIA C3 Ezra and Ezra –T Samuel 2
para estaciones de trabajo y servidores de alta capacidad.
Front Side Bus a 66/100/133 MHz.
Chipset
North Bridge: VIA CLE266 CE.
South Bridge:VIA VT8235.
Memoria Principal
Soporta hasta 2 dispositivos DDR.
Soporta dispositivos DDR 200/266 MHz (sin ECC).
Tamaño máxima de memoria 2GB.
Lan Chip (opcional)
Chip: VIA VT6103.
Soporta 10 Mb/s y 100 Mb/s auto-negociación
Half/ Full duplex.
Ranuras
Tres ranuras 32-bit PCI bus master.
Una ranura CNR.
IDE Onboard
Soporta cuatro IDE disk drives.
Soporta Modo PIO 4, Modo Bride y Ultra DMA 33/66/100/133 Modo Bus Master.
Super I/O
Chip: ITE IT8705.
Proporciona el más alto funcionamiento de uso común para Super I/O.
Environment Control initiatives
- Monitor H/W
- Controlador de Velocidad del Ventilador
- Función ITE "Smart Guardian"
AC’97 Sound Codec Onboard
Chip: VIA VT1612A.
AC’97 2.2 S/PDIF extensión del codec.
18-bit estéreo full duplex.

13
Periféricos Onboard
a. Parte Trasera
1 puerto en serie.
1 puerto VGA.
1 puerto paralelo.(modos SPP/EPP/ECP)
1 puerto deaudio en posición horizontal.
1 LAN jack.
Ratón PS/2y teclado PS/2.
2 puertos USB2.0.
b. Parte Delantera
1 puerto para disquetera soportando 2 FDDs de 360K, 720K, 1.2M, 1.44M y
2.88Mbytes.
4 puertos USB2.0.
1 Conector S/PDIF Out.
Dimensiones
Forma de Factor Micro ATX: 19 X 24.4cm (W X L)
B. BIOS & Software
BIOS
Award legal Bios.
APM1.2.
ACPI.
Función USB.
Software
Soporta WatchdogTM, 9th TouchTM, FLASHER™, StudioFun!TM (opcional),
WarpspeederTM.
Ofrece el más alto funcionamiento para Windows 98 SE, Windows 2000,
Windows Me, Windows XP, SCO UNIX etc.
Contenido del Paquete
Cable HDD X1
Cable FDD X1
Manual del Usuario X1
Cable USB X1 (opcional)
Panel trasero I/O para carcasa ATX X1 (opcional)
Configuración completa del CD X1
Cable S/PDIF X1 (opcional)
Aplicación del CD StudioFun! X1 (opcional)

14
Cómo instalar un Puente
La ilustración muestra cómo instalar un puente. Cuando el Jumper Cap está ubicado en
los contactos, el puente está en “close”. Si no hay Jumper Cap ubicado en los contactos,
el puente está en ”open”. La siguiente ilustración muestra un contacto 3 en el que los
contactos 1 y 2 están “close” cuando el Jumper Cap está ubicado en los dos contactos.
Puente open Puente close Contacto 1-2 close
Instalación de la CPU
Paso 1: Empuje la palanca hacia afuera del socket y levante la palanca hasta un ángulo de
90 grados.
Paso 2: Fíjese por el punto blanco o márgen cortado. El punto blanco o márgen cortado
debería apuntar hacia el pivote de la palanca. La CPU solamente se fijará en
una sola correcta orientación.
Paso 3: Tome el CPU firmemente hacia abajo, y cierre la palanca para completar la
instalación.
Paso 4: Ponga el ventilador de la CPU en el CPU y asegúrelo. Conecte el cable de
corriente del ventilador de la CPU al JCFAN1. Ésto completa la instalación.
paso1 paso2 paso3 paso4

15
Cabezal del Sistema de Ventilación del CPU: JCFAN1
Conrtacto No. Asignación
1 Tierra
2 +12V
1
JCFAN1 3 FAN rpm Rate Sense
Cabezal del Sistema de Ventilación: JSFAN1
Contacto No. Asignación
1 Tierra
2 +12V
13
JSFAN1
3 FAN rpm Rate Sense
Módulos DIMM: DIMM1/ DIMM2
DRAM Tiempo de Acceso: 2.5V Unbuffered DDR 200/266 MHz Tipo requerido.
DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulo DIMM (184 contactos)
Total del Tamaño de Memoria Unbuffered DIMMs
Localización
del Socket
DIMM
Módulo DDR Total del Tamaño
de Memoria (MB)
DIMMB1 64MB/128MB/256MB/512MB/1GB
*1
DIMMB2 64MB/128MB/256MB/512MB/1GB
*1
Máximo
2GB
***Solamente para referencia***
Instalación del Módulo DDR
1. Abra una ranura de DIMM presionando el clip
de retención hacia afuera. Aliñe el DIMM en la
ranura tales que la muesca en el DIMM encaje
en la cumbrera de la ranura.
2. Inserte el DIMM verticalmente y firmemente en
la ranura hasta que el clip de retención vuelva a
su posición original y el DIMM esté
correctamente colocado.

16
Puentes, Cabezales, Conectores y Ranuras
Conector de Disquetera: FDD1
La placa madre proporciona un conector estándar para disquete que soporta
disquetera de 360K, 720K, 1.2M, 1.44M y 2.88M. Éste conector utiliza cables
proporcionados por el disquete.
Conector del Disco Duro: IDE1/ IDE2
La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO
0~5, Bus Master, y funcionalidad Ultra DMA 33/ 66/ 100. Tiene dos conectores
HDD: IDE1 (primario) y IDE2 (secundario).
Los conectores IDE puede conectar a un disco master y uno esclavo, así puede
conectar hasta cuatro discos duros. El primer disco duro debe estar siempre
conectado al IDE1.
Ranuras de Interconexión del Componente Periférico: PCI1-3
Ésta placa madre está equipada con 3 ranuras estándar PCI. PCI es la sigla para
Interconexión del Componente Periférico, y es un bus estándar para tarjetas de
expansión. Ésta ranura PCI está diseñado con 32 bits.
Ranura de Banda de Suspensión de Comunicación y Red: CNR1
La especificación CNR es una abierta Industria de Arquitectura Estándar, que
define una tarjeta de interface escalable del hardware en el que soporta solamente
modem.
Conectores de Corriente: JATXPWR1
Contactos Asignación Contactos Asignación
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 Tierra 13 Tierra
4 +5V 14 PS_ON
5 Tierra 15 Tierra
6 +5V 16 Tierra
7 Tierra 17 Tierra
8 PW_OK 18 -5V
9 Voltaje Standby
+5V 19 +5V
20
11
10
1
JATXPWR1
10 +12V 20 +5V

17
Conector del Panel Frontal: JPANEL1
Cabezal Frontal USB: JUSB1/2
Contactos Asignación Contactos Asignación
1 +5V (fused) 2 +5V (fused)
3 USBP4- 4 USBP5-
5 USBP4+ 6 USBP5+
7 Tierra 8 Tierra
2
1
10
9
JUSB1/2 9 KEY 10 NA
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
(+) (-)
(+) (-)(+)
Contacto Asignación Función Contacto Asignación Función
1 +5V 2 Control de
Suspension
3 NA 4 Tierra
Botón
de Suspension
5 NA 6 NA NA
7 Altavoz
Conector
del Altavoz
8 Corriente LED (+)
9 HDD LED (+) 10 Corriente LED (+)
11 HDD LED (-) LED
del Disco Duro 12 Corriente LED (-)
Corriente
LED
13 Tierra 14 Botón de
Encendido
15 Control de
Reinicio
Botón
de Reinicio 16 Tierra
Botón de
Encendido
17 NA 18 KEY
19 NA 20 KEY
21 +5V 22 Tierra
23 IRTX
Conector IrDA
24 IRRX
Conector IrDA
JPANEL1

18
Fuente de Corriente Selección para Teclado/ Ratón: JKBV1
JKBV1 Asignación Descripción
1
3
Contacto 1-2 close
+5V
+5V para teclado y ratón
1
3
Contacto 2-3 close
Voltaje
Standby +5V
Ratón PS/2 y Teclado PS/2 son
encendidos con un voltaje standby de
+5V
Nota: Para soportar la función “Encendiendo el sistema por medio del
teclado y ratón”, el jumper cap del “JKBV1” debe ser ubicado en el contacto
2-3.
Fuente de Corriente Selección para USB: JUSBV1/ JUSBV2
JUSBV1/JUSBV2 Asignación Descripción
1 3
Contacto 1-2 close
+5V JUSBV1: 5V para conectores USB
ubicados en el puerto JUSBLAN1
JUSBV2: 5V para conectores USB
ubicado el el puerto JUSB1/2
1 3
Contacto 2-3 close
Voltaje
Standby +5V JUSBV1: puerto JUSBLAN1
encendidos con voltaje standby de 5V
JUSBV2: puertos JUSB1/2 encendidos
con voltaje standby de 5V
Nota: Para soportar la función “Encendiendo el sistema por medio del
dispositivo USB”, el jumper cap del “JUSBV1/ JUSBV2” debe ser ubicado en
el contacto 2-3 respectivamente.
