Birko TempoTronic 2.5L Manual

Installation & Operating Instructions
Birko TempoTronic Over-Sink Boiling Water Heaters (from September 2008).
Page 1
OVERSINK BOILING WATER
Boiling water always on tap in kitchens large or small.
Key Features
Choice of models delivering 15 to 150 cups of boiling water at one time.
Choice of white steel case or stainless steel case at no additional cost.
Stainless steel tank for minimal maintenance.
Can be supplied with an external five-micron filter as an optional extra.
Installation with an approved external water filter is strongly recommended.
Key Specifications
Note: Cup size is 167 ml. Installation with an external water filteris recommended for protection of the Heater
and users. Installation of a water filter inhibiting the accumulation of mineral scale is essential in known hard
water areas and a sediment filter is essential where water contains excessive sediments.
Please Read These Warnings First
Read all installation instructions and precautions before installing the heater.
Never attempt to install any heater without reading all of the instructions.
All plumbing connections must be made in accordance with AS/NZS3500.
In hard water areas where mineral scale accumulation in the boiling chamber of the heater may become a
problem, consideration should be given to the maintenance required.
Do not use jointing paste on plumbing fittings - use only Teflon Tape.
This appliance is not intended for use by persons (Including Children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for their
safety.
Children should be supervised to ensure they do not play with the appliance
If the power supply cord is damaged it must be replaced by a Birko Service Provider or qualified technician.
Do not remove the cover of the heater under any circumstances without first isolating the heater from the
power supply.
Do not use strong, corrosive or abrasive cleaners to clean the exterior.
Frost protection: If this heater is located where ambient air temperature could fall below 5ºC when the
heater is not in use, do not turn off the appliance electrically. This safeguard does not offer the same
protection to the connecting pipework and fittings.
The ambient temperatures this unit should operate with is 5ºC - 50ºC.
Positioning
Mount the heater in a vertical position over a draining board or sink.
Tap outlet should be > 200 mm and < 600 mm above the draining board.
Avoid installation in any area where heater is exposed to excessive steam.
Minimum operating water pressure is 200 kPa, maximum 1000 kPa. (0.2mPa - 1.0mPa)
Do not install where water is microbiologically unsafe or of unknown quality.
Do not install in an area that may be cleaned by a water jet.
Not for outdoor use.
C
B
D
E
A
Model 2.5L 5L 7.5L 10L 15L 20L 25L
Boiling water delivery (cups) 15 30 45 60 100 120 150
Boiling water capacity (litres) 2.5 5 7.5 10 15 20 25
Boiling water recovery (cup/hour) 120 120 120 120 120 120 120
Boiling water element (amps) 10 10 10 10 10 10 10
Supply voltage (volts) 220-240 220-240 220-240 220-240 220-240 220-240 220-240
Minimum water pressure (bar) 2 2 2 2 2 2 2
Maximum water pressure (bar) 10 10 10 10 10 10 10
Overall height A (mm) 430 510 510 565 565 630 630
Overall width B (mm) 315 365 365 425 425 490 490
Depth including tap C (mm) 210 240 240 310 310 340 340
Depth cabinet only D (mm) 125 170 170 240 240 270 270
Tap centre to unit base E (mm) 185 160 160 160 160 170 170

Installation & Operating Instructions
Birko TempoTronic Over-Sink Boiling Water
Page 2
OVERSINK BOILING WATER
Fastening
Remove the heater’s outer case by removing screws at top and bottom.
Fasten the chassis to the wall using the mounting holes provided.
Be sure to use fastenings of sufficient strength to hold weight when filled.
Plumbing
Connect water inlet to cold water supply via half inch compression fitting (supplied) and isolating valve (not
supplied). Never connect to hot water supply.
Connect vent outlet via half inch compression fitting to a vent pipe or tun dish as required by AS/NZS3500. The
vent may discharge water or steam.
Electrical
Heater is equipped with 1.8 metre power cord and plug to connect to a 10 amp 220-240 volt power outlet. If the
cord is damaged it must be replaced by Birko service or a qualified tradesman. For fixed wiring use a licensed
electrician.
Note: heater is electronically controlled and will not operate with a portable generator power supply or a split
system transformer.
Safety
Take care when using the heater otherwise scalding may occur.
Heater is fitted with a manual-reset safety device for boil-dry protection.
Heater is also fitted with a manual-reset thermostat to detect excessive steam in the event of any failure of the
electronic controls or water solenoid valve.
If either safety feature is actuated, the heater must be serviced by a Birko Service Provider or a suitably qualified
technician. It is not user-serviceable.
Commissioning
Once the heater is installed, replace the heater cover and fit the tap.
To fit the tap, screw it clockwise into the socket a maximum of 4 full turns.
If tap is not completely tight, remove and fit more sealing tape before refitting.
Turn on the water and check all connections for leaks.
Turn on the power and wait 20 minutes before using.
Priming Mode
When the power is turned on for the first time, the unit will prime itself automatically, covering the heating
element. The element will switch ON and boil that amount of water. This will take 10 to 15 minutes and will start
the heat-and-refill process until the boiling chamber is filled. The heater then goes into standby mode, keeping the
stored water close to boiling point. Do not install in an area that may be cleaned by a water jet.
Maintenance
To drain the heater, turn off the power supply and water supply and turn on the outlet tap of the heater to drain the
boiling chamber.
Remove the tap and the front cover.
Shield the electronic controller from possible water damage.
Carefully remove the hose from the nipple at the base of the tank and drain the rest of the contents of the tank.
Beware of splashing water as it may be close to boiling point and could scald.
Do not clean with a water jet.
Descaling
Periodic descaling is recommended and is dependent on the hardness of the water. We recommend a
descaling procedure be carried out every 3 to 6 months in hard water areas and 12-24 months in soft water
areas.
NOTE: This procedure involves the partial dismantling of the appliance and should only be carried out by a
factory trained service provider. Failure to have the appliance correctly serviced, by an authorised service
provider, may affect the product’s warranty.

Installation & Operating Instructions
Birko TempoTronic Over-Sink Boiling Water
Page 3
OVERSINK BOILING WATER
17
16
18
Teflon Tape
9b
Ref Part No Description
1 1311010 Water Solenoid Valve
2 1311044 Condenser Assembly
3 Cold Water Inlet (half inch BSP)
4 1311043 Thermistor Steam Sensor
5a Element & Tank Assembly
5b 1311032 Element Assembly 5 to 25 Litre
6 1311006 Manual Rest Thermostat (boil dry protection)
7 Steam Vent Outlet (half inch BSP)
8 1311125 Manual Reset Thermostat (steam vent O/Flow)
Spare Parts
1
7
30mm
85mm
65mm
45mm
Reducer 1/2”
BSP
(Olive Compression Union)
FRONT VIEW SIDE VIEW
55mm
9a Water Outlet Fitting (half inch BSP)
9b 1311056 Tap Assembly
10 Sensor - Red tip (minimum water level)
11 Sensor - White tip (maximum water level)
13 Maximum Water Level
14 1310842 Power Cord & Plug Assembly
15 1311042 Tempo Tronic PCB Assy
16 1311057 Tap Cup Seal
17 1311064 Tap Insert
2.5L 5-75L 10-15L 20-25L
A56.4 41.4 41.4 41.4
B198.0 278.0 335.0 399.0
C418.45 488.45 545.45 609.45
D42.45 42.45 42.45 42.45
E143.4 143.4 143.4 143.4
F200
H430.8 500.8 557.8 621.8
Wall Mounting Dimmensions (mm)
2.5- 15L 20-25L
Washer
15
14
2
7
6
5
3
1
11 10
13
9a
8
4

Installation & Operating Instructions
Birko TempoTronic Over-Sink Boiling Water
OVERSINK BOILING WATER
Page 4
In order to help preserve our environment we ask that you dispose of this product correctly.
Please contact your local city council for collection centre details
Regulatory compliance mark
Birko Heaters Australia Pty Ltd.,
ABN 39 103 881 625
67 Allingham St
Condell Park
N.S.W. 2200
AUSTRALIA
Local Ph: 1300 724 955
Local Fax: [phone]
[email protected]
www.birkoheaters.com
The term ‘Birko’ is a registered trade mark of Birko Heaters Australia Pty Ltd.
6001007 - January 2013 v1.01
