INSTRUCTION MANUAL
18"STAND FAN
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR
ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER
purchase, go to www.blackanddecker.com/instantanswers
If you can’t find the answer or do not have access to the Internet, call
844-299-0879 from 10:30 a.m. to 6:30 p.m. EST Mon. - Fri. to speak with an
agent. Please have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CATALOG NUMBER
BFSR18

Page 2

Thank you for purchasing our
BLACK+DECKER product. This
easy-to-use manual will guide you
in getting the best use of your fan.
Remember to record the model and
serial numbers. They are on a label
on the rear.
Staple your receipt to your manual.
You will need it to obtain warranty service.
Model number
Serial number
Date of purchase
PRODUCT REGISTRATION
CONTENTS
SAFETY INFORMATION
Important Safety Instructions......................................................................................................................................... 4-6
Electrical Requirements....................................................................................................................................................... 5
SET UP & USE
Parts & Features........................................................................................................................................................................ 7
Operation & Use ..................................................................................................................................................8-11
Replacing the Fuse................................................................................................................................................12
CLEANING & CARE...............................................................................................................................................12
TROUBLE SHOOTING & WARRANTY
Before You Call For Service ...............................................................................................................................13
Customer Service...................................................................................................................................................13
Troubleshooting......................................................................................................................................................13
Limited Warranty ................................................................................................................................................................... 14
Page 3

Page 4
SAFETY INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
1. READ ALL INSTRUCTIONS BEFORE USE
2. Never insert fingers, pencils, or any other object through the grill
when fan is running
3. Disconnect fan when moving from one location to another.
4. Disconnect fan when not in use and before cleaning.
5. To protect against risk of electrical shock, do not immerse fan in
water or any other liquid.
6. Do not let cord hang over edge of table or counter.
7. Be sure fan is on a stable surface when operating to avoid
overturning.
8. Do not use fan in window. Rain may create electrical hazard.
9. Close supervision is necessary when any appliance is used by or near
children.
10. This product employs overload protection (fuse). A blown fuse
indicates an overload or short-circuit situation. If the fuse blows,
unplug the product from the outlet. Replace the fuse as per the user
manual (follow product marking for proper fuse rating) and check
the product. If the replacement fuse blows, a short-circuit may be
present and the product should be discarded or returned to an
authorized service facility for examination and/or repair.
11. Do not operate any fan with a damaged cord or plug. Discard fan or
return to an authorized service facility for examination and/or repair.
12. Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from trac area and where it will not
be tripped over.
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
WARNING
When using electrical appliances, basic safety precautions
should be followed, including the following

Page 5
SAFETY INFORMATION
13. To reduce the risk of fire or electric shock, DO NOT use this fan with
any solid state speed control devices.
14. Do not use outdoors.
15. Ensure that the fan is switched o from the supply mains before
removing the grille.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
ELECTRICAL REQUIREMENTS
This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to fit into a polarized outlet only one way.
If the plug does not fit into the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician. Do not attempt to modify the plug in any way.
POWER SUPPLY CORD
1. If the power supply cord is too short, do not use an extension cord. Have a qualified
electrician or serviceman to install an outlet near the appliance.
2. If it is absolutely necessary to use longer cord sets or an extension cord, extreme
care must be exercised.
a) The marked electrical rating of the cord set or extension cord must equal to or
be greater than the electrical rating of the appliance. The longer cord should be
arranged so that it will not drape over the counter top or table top where it can be
pulled on by children or tripped over unintentionally.
NOTE: Neither BLACK+DECKER nor the dealer can accept any liability for damage
to the product or personal injury resulting from failure to observe the
electrical connection procedures.

Page 6
SAFETY INFORMATION
HANDLING ALKALINE BATTERIES
1. Should fluid from the battery accidentally get into your eyes, there is a threat
of loss of eyesight, do not rub them. Immediately rinse your eyes with clean tap
water and then consult a physician immediately.
2. Do not put the battery in a fire, expose it to heat, dismantle or modify it. If the
insulation or safety valve is damaged, the battery may leak fluid, overheat or
explode.
3. Do not insert the battery with the poles reversed. Doing so may cause some
abnormality or a short and the battery may leak fluid, overheat or explode.
4. Keep the battery out of the reach of children. If the battery is swallowed, contact a
physician immediately.
5. If the alkali fluid gets in your mouth, rinse your mouth with water and contact a
physician immediately.
6. If the alkali fluid gets on your skin or clothes, it may burn your skin, thoroughly
rinse the aected area with tap water.
7. Do not mix new and old batteries or other makes of batteries. The dierent
attributes may cause the battery to leak fluid, overheat or explode.
8. This battery was not made to be recharged. Recharging this battery may damage
the insulation or internal structure and may cause the battery to leak fluid,
overheat or explode.
9. Do not damage or remove the label on the exterior of the battery. Doing so may
cause the battery to short, leak fluid, overheat or explode.
10. Do not drop, throw or expose the battery to extreme impact. Doing so may cause
the battery to leak fluid, overheat or explode.
11. Do not alter the shape of the battery. If the insulation or safety valve is damaged,
the battery may leak fluid, overheat or explode.
12. Immediately remove batteries when they have lost all power. Leaving the batteries
in the unit for a long time may cause the batteries to leak fluid, overheat or
explode due to gas that is generated by the batteries.
Contact your local government for disposal practices in your area.
WARNING
When handling alkaline batteries, basic safety precautions
should be followed, including the following

Page 7
PARTS & FEATURES
SET UP & USE
Base
7-shape Bolt
Blade
Front grill PlasticnutMotorshaft
Clutchknob
Motorhousing
Rear grill
Case
Thumb
screw
Internal
pole
Touch
switch
Tighten
Spinner
Loosen
Fasten
Height
adjustment
ring
Extension
pole
Remote
Control
Holder

Page 8
SET UP & USE
ASSEMBLY OF BASE & COLUMN UNIT
1. Unscrew the 7-shape Bolt from the Extension Pole. (see Fig. 1)
2. Insert the extension pole in the base and tighten the 7-shape Bolt. (see Fig. 2)
3. From the extension pole, loosen the height adjustment ring and adjust the
internal pipe to the desired height.
NOTE: If you can’t find the internal pole, it has slid inside the extension pole. You
will need to retrieve it by pulling it out from the extension pole ( see Fig. 3).
4. To attach the upper portion of the fan to the extension pole, loosen the thumb
screw slightly on the bottom of the head unit. Place the head unit on the extension
pole and tighten the thumb screw in alignment with the groove on the internal
pole. (see Fig. 4).
CAUTION: Height adjustment ring must be fully fastened before the assembly of
the motor housing to the extension pole.
Fig. 1 Fig. 2
Fig. 3 Fig. 4
Loosen
Mounting Hole
Thumb Screw
Annular Groove

Page 9
GRILL & FAN BLADE ASSEMBLY
WARNING: Never attempt to run the fan without the grill in place and properly
secured. Failure to have the grill in place can result in serious injury.
1. Unscrew the spinner clockwise and the plastic nut counterclockwise to remove
both of them. Fix the rear grill so it sits perfectly flush to the motor then tighten the
plastic nut clockwise. (see Fig. 5)
2. Insert the blade into shaft, and make sure the rotor shaft pin is fitted into groove of
the blade. Turn the spinner counterclockwise to tighten the blade. (see Fig. 6)
3. Fasten the front grill and the rear grill to each other by using the grill clips.
(see Fig. 7)
Spinner
Tight
Loose
Plastic Nut
Spinner Tight
Blade Retaining
Pin
Slot
Clip
Fig. 5 Fig. 6 Fig. 7
SET UP & USE
REMOTE CONTROL BATTERY INSTALLATION
1. Press down on the battery compartment cover and slide it out.
2. Insert 2 “AAA” batteries (not included) making sure that the positive terminals are
facing the proper way.
3. Replace the cover.
NOTE: Use size “AAA” alkaline batteries. Do not use rechargeable batteries.
Remote Control
Battery Battery Cover
Fig. 10

SET UP & USE
OPERATION INSTRUCTIONS
REMOTE CONTROL (Fig. 8)
Point the remote control at the receptor on body of the fan and press the desired
button. The remote control will work at distances of up to roughly five meters
(16 feet) and an angle of 30 degrees left and right of the control panel.
1. ON/OFF KEY - The key is for switching the fan on and o. Press and the fan will
be started at low speed. Press again, it will be switched o.
2. TIMER KEY - When this key is touched, the auto shutto timer can be set to
either 1, 2 or 4 hours and the corresponding light will turn on. If the light doesn’t
come on after touching the key, the fan will run continuously.
3. SPEED KEY - After the fan has started, this key serves as a speed selector in
the sequence order “LOW-MEDIUM-HIGH-LOW, etc” when this key is pushed
repeatedly or held down.
4. WIND MODE KEY - Press this key to change from normal to natural wind mode.
It will go in sequence order NORMAL--NATURAL--NORMAL etc. The LED speed
indicator will flash when in NATURAL wind mode.
NOTE: NORMAL wind mode represents constant air flow while in NATURAL wind
mode, intensity will vary to simulate typical outdoor wind conditions. Wind
mode function can be activated from remote control only.
Page 10
4h HI
2h MED
1h LOW
ON/SPEED
OFF
TIMER
Fig. 8
Speed Power
Timer
Wind Mode
