Blagdon 1052283 User manual

pond and garden
LED feature light
Established over 50 years ago, Blagdon are
committed to producing a comprehensive range
of high quality, easy to use, pond equipment.
An ongoing programme of research and
development ensures excellent performance and
value for all their customers. This product excellence
is demonstrated by Blagdon’s award winning
range of water gardening equipment. As a result
Blagdon’s reputation for quality is unrivalled amongst
experienced pond gardeners and retailers alike.
Interpet, Vincent Lane,
Dorking, Surrey, RH4 3YX
Leaflet Code: 14/01/13

Congratulations on buying a Blagdon
Pond and Garden LED Feature Light.
This product has been designed to
create beautiful lighting effects.
Quick and easy to install with a wide
range of versatile installation options.
IMPORTANT
Please attach proof of purchase to this manual
and file in a safe place.
Getting to know your Pond and Garden LED Feature Light .............................................. 2
Spare parts ....................................................................................................................................... 2 - 3
Technical Specification .........................................................................................................................3
Installation ......................................................................................................................... 4 - 7
Electrical installation ..............................................................................................................................4
Location ................................................................................................................................................... 5
Adjusting the spotlights .................................................................................................................. 6 - 7
Maintenance ...........................................................................................................................8
LED Automatic Photo Sensor .............................................................................................................. 8
Faults - Problems Procedure ...................................................................................................9
Consumer Advice Contact Details .................................................................................................... 9
Guarantee ............................................................................................................................... 9
1. CONTENTS
1
pond and garden
LED feature light

GETTING TO KNOW YOUR POND
AND GARDEN LED LIGHT
Technical Specification
LED Feature Light 1 Way Set
Cable Mains 3m
Cable Low Voltage 5m
Transformer Voltage 230V
Transformer Hertz 50 Hz
Low Voltage 12V
Lamp Wattage 0.76w
Total Wattage Usage 2.5w
16
13
14
15
18
19
2 3
GETTING TO KNOW YOUR POND
AND GARDEN LED LIGHT
17
1
No. LED Feature Light - Parts Description Spare Code
1. Lamp cover N/A
2. Lens N/A
3. LED Lamp 0.76w 1051330
4. Lens 'O' ring 1052047
5. Lamp housing N/A
6. LED Main body N/A
7. Oval locking washer N/A
8. Light level sensor N/A
9. Optional sensor cover N/A
10. Garden spike locking nut N/A
11. `U' Bracket 1021357
12. Garden spike N/A
13. Feature Light Low voltage transformer 3.6w 1052344
14. Low voltage cable N/A
15. 7.5m Extension cable (sold separately) 1052191
16. 9mm bolt N/A
17. Metal washer N/A
18. Pond light support base N/A
19. Metal fixing nut 1021364
2
3
4
5
6
7
9
7
10
11
12
8

INSTALLATION
4 5
Electrical installation
The power supply must meet the specifications on the product.
The transformer is intended to be used with either a weatherproof
switchbox cable connector or permanently connected to the fixed
wiring in the main system other than by means of a plug and socket.
The cores in the supply cable are coloured in accordance with the following code:
Brown = Live, Blue = Neutral,
The electric cable is permanently connected and sealed in the transformer body.
If the supply cable is damaged the transformer must not be used.
Do not use the supply cable to lift the transformer as this may cause damage.
WARNING
A Residual Current Device (RCD), also know as the Residual
Current Circuit Breaker (RCCB), with a tripping current not
exceeding 30mA must be installed in the supply circuit.
A means of disconnection from the supply having a contact separation
of at least 3mm in all poles must be incorporated in the fixed wiring.
For permanent installations to the mains supply, it is necessary to conform to the regulations
of the local electricity authority and this would include the use of a metal or plastic conduit
to protect the cable.
Attention has been drawn to the fact that special rules may exist concerning the installation
of your transformer (i.e. local building regulations).
Always disconnect the mains electricity supply whilst the equipment is being installed,
repaired, maintained or handled. Consult a qualified electrician if in any doubt about
wiring this product to the main supply.
Warning - This transformer must not be used in ponds.
For external installation only.
Mains power supply
RCD (Recommended)
Outdoor
weatherproof
transformer
5 metres Low Voltage cable Fountain
Waterfall
Feature
Fixed to wall/fence using ‘multi-directional fixing bracket’ provided
Submerged in pond to light up fountain/waterfall
using ‘pond light support base’ provided
Illuminating a feature, tree or path
using ‘garden spikes’ provided
INSTALLATION
This diagram shows five possible installation options. Pack contains one LED light only.
3 metres
Mains cable

INSTALLATIONINSTALLATION
6 7
GARDEN SPIKE:
Insert the garden spike
into soil or gravel for
external installation.
POND LIGHT BASE:
The light base can be weighted
with stones or gravel for stability.
SPOTLIGHT ADJUSTMENT:
1. Release the oval
locking washer and
tighten when in position.
2. Release the fixing
nut and tighten
when in position.
2
1
LED ‘U’ BRACKET:
The LED ‘U’ bracket can be directly attached to a fence
or wall using the 9mm round bolt and nut supplied.
9mm bolt 9mm nut
Fence panel
or Wall
Recommended
10mm round hole
Stones
or gravel

8
FAULTS - PROBLEMS PROCEDURE
Before returning your Blagdon Pond and Garden LED Feature Light to your dealer or
contacting our Consumer Advice Department, please carry out the following steps.
This will solve most problems quickly and easily.
1. Ensure electrical procedure has been followed fully.
Check fuse and any cable connectors/switch boxes.
2. Return light to point of purchase for inspection and advice
(you may need proof of purchase).
You can help protect the environment. Please remember to respect the local regulations:
hand in non-working electrical equipment to an appropriate waste disposal centre.
Consumer Advice contact details
Interpet (Blagdon) Consumer Advice Department
Vincent Lane, Dorking, Surrey RH4 3YX
Fax: [phone] E-mail: customercar[email protected]
IMPORTANT
This guarantee is offered as an extra benefit and does not affect your statutory rights
as a consumer in any way. This product is guaranteed against defects in material and
workmanship for 3 years from the date of purchase, under normal usage. The guarantee
DOES NOT APPLY in case of improper use, negligence, lack of maintenance or accidental
damage either to the lights, transformer or to the replaceable parts. If the lights or transformer
fail due to a manufacturing fault within this period it will be either repaired or replaced free
of charge. Liability is limited to replacement of the faulty product only, no other costs will
be reimbursed. This guarantee is not transferable and does not affect your statutory rights.
This guarantee does not confer any rights other than those expressly set out above.
Excludes lamps, O rings, coloured lenses or washers.
GUARANTEE
MAINTENANCE
9
Before any operation, turn off the spotlight and disconnect the mains from the
power socket. The spotlight can now be removed from the pond. Unscrew the
lamp cover (1) to remove the transparent glass (2) and associated O ring (3).
When the spotlight has been dismantled in this way, the LED lamp (4) can be
removed and replaced. Reassemble in the reverse order.
LED Automatic Photo Sensor Detects when light levels are low/dusk
The LED automatic sensor is positioned on the side of the LED main body (8). Ensure
this is kept clean from dirt and algae as it needs sufficient light to activate correctly.
The optional sensor cover (9) can be used to cover the sensor; this would allow the
LED to be continuously on during both night and day. Simply uncover the sensor
for it to continue working as before.
This extremely efficient
lamp uses less than
1 watt of electricity which
automatically turns on at
dusk and off at dawn. 8
1 2
3 4
9
9
LED Sensor Uncovered
= On/Off Automatic
LED Sensor Covered
= On all the time
