Blaupunkt GX1000 User manual

WARRANTY
This product has 3 years warranty for manufacturing defects. The warranty period
will be counted from the date of purchase of the product, according to purchase
invoice. Product warranty only covers manufacturing defects, defects resulting from
improper use, such as dropping, improper transportation, connection to the mains
power supply not in compliance with the voltage specied in this manual, insertion
of foreign objects and natural wear of parts and parts Such as plastic parts (caps,
buttons, handles, latch locks, power cables, etc.) and metal parts (wires, motors, etc.).
Also not covered are damages due to agents of nature, lightning, ood, sea,
oxidation, humidity etc.). The product will lose its warranty if it presents defects,
which after analysis by our technicians, are characterised as being improperly used,
used for professional use or for the purpose for which it is not intended (according to
the Owner's Manual). This warranty will be void if it is found that the device has been
tampered with, has been repaired by a person or service not authorized by
Blaupunkt. The guarantee is only valid with the receipt/invoice provided at purchase.
Blaupunkt undertakes to provide the above-mentioned services in the warranty
period only in places where it maintains an authorised service. Consumers who are
not located near an authorised service centre should be responsible for the costs and
risks of transport to the authorized service of their choice.
Natural wear is not covered under warranty.
This product is for domestic use only.
Lawn Mower GX1000
INSTRUCTION MANUAL
To prevent injury or damage, read
and follow all instructions in this
manual before using the appliance.
SAVE THESE INSTRUCTIONS
Imported and Distributed by SKN Innovations Ltd. for Blaupunkt
17 Northumberland Sq.
NE30 1PX
0800 677 1923
[email protected]
www.bp-tools.co.uk

1
IMPORTANT SAFETY INFORMATION
Read the Operating Instructions carefully before use.
Save these instructions for future reference. Follow these basic
instructions to reduce the risk of electric shock and personal injury.
• The machine is only intended for household and hobby use and is not
suitable for commercial use.
• Save the instructions for future reference. These instructions should be
enclosed with the machine if you sell it, or pass it on.
• Read all the instructions, safety instructions and all the warning labels on
the machine before using it.
• Never allow children, or persons who are unfamiliar with the machine
and these instructions, to use it.
• Wear tight-tting clothing and non-slip shoes.
• Carefully inspect the area where the machine is to be used and remove
any stones, wires, or other foreign objects.
• Do not use the machine when other persons, especially children, or
animals are in the vicinity.
• Pay attention to any local regulations concerning noise.
• Only use the machine in daylight, or in good articial lighting.
AVOID THE RISK OF ELECTRIC SHOCK
• The machine must be connected to the mains supply with a residual
current device with a maximum tripping current of 30 mA.
• Only use extension cords approved for outdoor use, otherwise there is a
risk of electric shock. The minimum cross-sectional conductor area is 2 x
1.0 mm2. The machine is double insulated and does not need to be
earthed.
• Damaged or tangled power cords increase the risk of electric shock.
• Make sure to route the extension cord correctly.
• Always check the machine before use.
• Replace damaged or worn parts immediately.
• Always check that the machine is in good condition before use.
• The user is responsible for any accidents or risks to other persons or
property.
IMPORTANT SAFETY INFORMATION
• Switch o the motor before moving the machine over ungrassed
surfaces.
• Do not stand in front of the ejector opening when starting the motor
(applies to machines with side ejector).
• This machine is only intended for mowing lawns.
• Never disable or bypass safety devices on the machine.
• Check before starting that the blade can rotate freely. Disengage the
drive before starting.
• If the machine has to be tilted to start, do not tilt it more than is
absolutely necessary. Lift up the end furthest away from the user. Keep
your hands and feet away from moving parts.
• Always walk behind the handle when mowing.
• Always maintain a rm footing and good balance.
• Never lift or carry the machine when the motor is running. Switch o the
machine, unplug the power cord, and wait until all moving parts have
completely stopped.
• Work across slopes, never up or down. Do not use the machine on slopes
with a gradient of more than 15°.
• Be very careful when changing direction and when going backwards or
pulling the machine towards you.
• Use the machine carefully. Never run with the machine. Do not leave the
machine switched on when unattended.
• Stop the blade by releasing the starter handle. The motor and blade stop.
Never disable or bypass the starter handle function.
• There are covers on the machine to provide protection from personal
injury as a result of ejected objects. Never use the machine if the guards or
covers are dismantled or damaged.
• Switch o the machine, unplug the power cord and wait until all moving
parts have completely stopped before adjusting, replacing parts and
accessories, and before cleaning and/or maintenance.
• Do not use the machine if parts are missing or damaged – risk of serious
personal injury.
WARNING: Failure to follow these instructions can lead to the risk
of serious personal injury and/or damage to the product.
2

SYMBOLS
The symbols below are used on the type plate on the machine. They
indicate information on the product, or instructions on how it should be
used.
3 4
SYMBOLS
SYMBOL
BETYDER
WARNING: Indicates danger, warning or important information.
WARNING: Read all the instructions before use, to minimise the risk of
personal injury.
Wear ear protection, safety glasses and a breathing mask.
Do not expose the machine to rain.
Keep onlookers, especially children and pets, at least 10 metres from the work
area.
Unplug the power cord before maintenance/cleaning, or
if the power cord is damaged.
SYMBOL
BETYDER
WARNING: The blades are sharp.
WARNING:
Avoid running over objects. Objects can be thrown out and cause
serious injury and/or material damage.
STOP!
The blades continue to rotate after the motor has been switched off. Wait
until all moving parts have completely stopped before making any adjustments.
WARNING: Unplug from the power cord immediately if it, or an extension cord,
gets damaged.
The product is double insulated.
WARNING: Keep the power cord away from the blades.
ELECTRICAL HAZARD! Risk of injury and/or property damage.
Complies with all relevant EU directives.
Products that have reached the end of their useful life must be recycled in
accordance with local regulations.

ASSEMBLY
HANDLEBAR (Fig. 1, 2)
1. Assemble the upper handlebar (4) to the lower handlebar (3) with the
handlebar securing knob (5), washer (10) and bolt (11).
2.Insert the two lower handlebar tubes into the holes on main body, and
x the with lock screw
(12) and washer (13).
GRASS COLLECTION BOX (Fig. 3)
1. Align the rear of the grass collection box-upper (2a), with the rear of the
grass collection
box-lower (2b).
2. Ensure that the locking tabs are aligned, and push together rmly, use
of a pair of pliers may make this easier.
3. Repeat this alignment of locking tabs on both the right hand and left
hand sides of the collection box, rmly pushing the locking tabs together.
KNOW YOUR PRODUCT
1. Lawnmower deck
2. Grass collection box
2 a) Grass collection box-upper
2 b) Grass collection box-lower
3. Lower handlebar
4. Upper handlebar
5. Handlebar securing knob
6. Safety button
7. Switch lever
8. Rear deector
9. Cable retainer
10.Washer (handlebar securing knob)
11.Bolt
12.Lock screw 13.Washer (lock screw)
5 6
Fig.2Fig.1
Fig.3

7 8
ATTACHING THE GRASS COLLECTION BOX (Fig.4)
1. Ensure that the grass collection box has been assembled correctly.
2. Lift the rear deector (8) on the mower deck.
3. Pass the collection box under the handlebar, align the attachment
hooks and place the collection box into position.
4. Lower the rear deector, so that it now rests on the grass collector box.
OPERATION
ADJUSTING THE CUTTING HEIGHT
NOTE: Stop, release switch lever and wait until the motor stops before
adjusting height. The blades continue to rotate for a few seconds after the
machine is switched o, a rotating blade can cause injury.
For the rst cut of the season, a high cutting adjustment should be
selected.
The cutting height can be selected among 20mm, 40mm, or 60mm by
adjusting the front and rear wheels.
Front wheel adjustment (Fig.5)
Pull the front wheel axle on either side of the mower deck in turn and
relocate it in the required position.
Rear wheel adjustment (Fig.6)
Pull the rear wheel axle along the slot and lift the wheel, then relocate it in
the required position.
OPERATION
Note:
1. Set the axle in the upper position for the lowest cutting height, the
middle position for the medium height, and lowest position for the
highest cut.
2. All wheels must be at the same position.
3. The lowest cutting height is only suitable for trimming a very level, short
lawn. High and medium positions are recommended for normal use.
Never use the mower with the wheels set in dierent positions.
STARTING AND STOPPING
NOTE: The blade continues to rotate for a few seconds after the
machine is switched o. Allow the motor/blade to stop rotating
before switching “on” again. Do not rapidly switch o and on.
Starting:
1. Set the mower to the required ‘cutting height’.
2. Press and hold the safety button(6).
3. Squeeze the switch lever(7) towards the handle.
Stopping:
Release the switch lever.
Fig.4
Fig.5 Fig.6

MAINTENANCE
SAFETY
Before any inspection, maintenance or cleaning of the mower is
conducted.
1. Ensure that the cutting blade has fully stopped rotating.
2. The mower is disconnected from the mains power supply.
BEORE EACH USE
NOTE: Care should be taken when turning the mower unit for inspection
or cleaning.
1. Remove any grass and debris from around the cutting height
adjustment lever, the air lter in the cowl and the underside of the mower
deck.
2. Ensure the grass collection bag is empty, and inspect for signs of
damage.
3. Check the condition of the rear deector, along with the mower deck.
4. Inspect the condition of the cutting blade - note: wear strong gloves
when working with or around the cutting blade.
5. Ensure that the cutting blade is not bent or cracked.
6. Check the condition of the blade and it’s mountings.
7. Check that the xing bolt is secure.
8. Check the power supply cable.
9. Inspect the ‘Switch control & safety button’.
10. Check that all securing nuts and bolts are tight.
WARNING: If signs of damage are found, the mower unit should
not be used until fully repaired by a qualied person.
9 10
ATTACHING THE GRASS COLLECTION BOX (Fig.4)
1. Ensure that the grass collection box has been assembled correctly.
2. Lift the rear deector (8) on the mower deck.
3. Pass the collection box under the handlebar, align the attachment
hooks and place the collection box into position.
4. Lower the rear deector, so that it now rests on the grass collector box.
OPERATION
ADJUSTING THE CUTTING HEIGHT
NOTE: Stop, release switch lever and wait until the motor stops before
adjusting height. The blades continue to rotate for a few seconds after the
machine is switched o, a rotating blade can cause injury.
For the rst cut of the season, a high cutting adjustment should be
selected.
The cutting height can be selected among 20mm, 40mm, or 60mm by
adjusting the front and rear wheels.
Front wheel adjustment (Fig.5)
Pull the front wheel axle on either side of the mower deck in turn and
relocate it in the required position.
Rear wheel adjustment (Fig.6)
Pull the rear wheel axle along the slot and lift the wheel, then relocate it in
the required position.
OPERATION
MOWING
Place the lawnmower on the edge of the lawn, as close to the power point
as possible. Work away from the power point.
Position the cable to opposite side (already cut) at the end of each turn.
WARNING: When mowing do not allow the motor to labour
particularly in heavy conditions. When the motor labours the
speed of the motor drops and you will hear a change in the
motor sound, when this occurs stop mowing, release the switch
lever and raise the height of cut.
Failure to do so could damage the machine.
HEAVY GROWTH
1. Areas of heavy growth should be mown without collecting the
clippings.
2. If collection is required, rstly mow the area using the maximum cutting
height setting, without the grass collection bag attached.
3. Allow the clippings to dry out.
4. Attach the grass collection bag and mow the area, again using the
maximum cutting height setting.
5. Progressively lower the cutting height setting and mow the area again
until the required nish is obtained.
NOTE: To prevent damage to the grass, do not remove more than
one third of the grass’s height on any one cut.
NOTE: When the blade becomes jammed or if the motor is
overloaded, remove the plug from the power supply.
Clear any obstruction and wait for a few minutes before
continuing to use the mower

MAINTENANCE
LUBRICATE THE WHEELS, PIVOT POINTS AND LINKAGES AFTER 25 HOURS
OF USE
REPLACE THE CUTTING BLADE AFTER 50 HOURS OF USE
GENERAL MAINTENANCE
1. Remove all grass debris from the top and underside of the mower deck,
as well as from around the ventilation holes, immediately after use - note:
wear strong gloves when working with or around the cutting blade.
2. Motor unit - this motor unit is maintenance free and should not be
accessed by anyone other than an approved maintenance engineer.
3. Switch control & safety button - is maintenance free and should not be
accessed by anyone other than a approved maintenance engineer.
CUTTING BLADE
1. The cutting blade has sharp edges, always wear strong gloves to protect
your hands when working with or around the cutting blade.
2. Always work away from the cutting edges of the blade to avoid the risk
of injury.
3. Care should be taken when turning or lifting the mower unit.
4. It is recommended that the cutting blade is replaced every two years or
after 50 hours operation, which ever occure the sooner.
5. Damaged or worn blades should by replaced immediately.
BLADE REPLACEMENT (Fig. 7)
MAINTENANCE
WARNING: Unbalanced blades will cause the lawnmower to
vibrate-risk of accident!
1. Disconnect the mower from power supply before removing or retting
the blade.
2. Turn the mower unit on to its side.
3. Firmly grip the end of the cutting blade - with a gloved hand.
4. Remove the xing bolt, with the spanner provided.
5. Carefully remove the cutting blade.
6. Ensure that the ‘New’ cutting blade is the correct way up, with the
turned edges facing towards the motor.
7. Locate the ‘New’ blade into position on the carrier pins. The blade with
texts should face outward.
8. Secure the xing bolt and tighten.
9.Return the mower unit to an upright position.
POWER SUPPLY CABLE
Before use, the power supply cable should be inspected for signs of
damage or ageing.
DO NOT USE ANY POWER TOOLS IF THE CABLE IS DAMAGED OR WORN.
NOTE: All electrical inspections and repairs should be conducted
by a qualied electrician.
STORAGE FOR LONGER PERIODS
NOTE: To ensure your mower is maintained in good working
order, if the storage period exceeds one month it is important
that the following is adopted:
1. Clean all areas of the mower, ensure that the grass collection box is
empty and clean.
2. Lubricate the wheels, pivot points and linkages.
11 12
Fig.7

13 14
MAINTENANCE
3. Cover all metal parts with oil to prevent corrosion.
4. Cover the mower with a protective sheet and store in a dry area.
NOTE: Switch o the machine, unplug the power cord and wait until all
moving parts have completely stopped before cleaning and/or maintenance.
• Do not ush the machine with water.
• The penetration of water can damage the electrical parts.
• Clean the machine with a dry cloth, brush or the equivalent.
NOTE: Have the machine checked by an authorised service centre if:
–– The lawn mower blade strikes an object. –– The motor suddenly stops.
–– The blade is bent (do not attempt to straighten it).
–– The motor shaft is bent (do not attempt to straighten it).
–– There is a short-circuit/electrical fault when the power cord is plugged
in. –– The gear or drive is damaged.
–– The V-belt is damaged.
SHARPENING/REPLACING THE BLADE
The blade should be checked and if necessary sharpened and/or balanced
at the end of the season by a qualied person.
The insulation on the machine should also be checked in conjunction with
removing the blade at the end of the season.
Storage
Clean the machine well on completion of the work. Allow the motor to
cool before putting the machine away. Store the machine in a dry place.
The machine will take up less space if the top handle is folded down.
Unscrew the wing nuts about 6 turns.
IMPORTANT: Make sure the power cord is not clenched when folding
down the handle.
PROBLEM
ACTION
The motor will not start.
1.
Check the power cord, RCD and fuse.
2.
Start the machine in short grass or on an
area that has already been cut.
3.
Clean the outfeed opening and cover.
The blade must rotate freely.
4.
Set a suitable cutting height.
The motor speed drops
1.
Set a suitable cutting height.
2.
Clean the outfeed opening and cover.
3.
Have the blade sharpened at an
authorised service centre.
Not all the grass goes into the catcher
1.
Set a suitable cutting height.
2.
Allow the lawn to dry.
3.
Have the blade sharpened at an
authorised service centre.
4.
Clean the grille on the grass catcher.
5.
Clean the outfeed opening and cover.
TROUBLESHOOTING
TECHNICAL INFORMATION
Voltage - 230–240 VAC Frequency - 50 Hz
Rated output - 1000 W Speed (no load) - 3450 rpm
Cutting height - 20, 40 or 60 mm Max. cutting diameter - 320 mm
Net weight - 8.8/8 kg Protection rating - IPX4
Sound pressure level, LpA - 82.5 dB(A), K = 3 dB(A)) Measured sound power level, LwA - 91.1 dB(A)
Guaranteed sound power level, LwA - 94 dB(A) Vibration level - 3.79 m/s2, K = 1.5 m/s2
Type of catcher - Plastic catcher box
Always wear ear protection!
The declared vibration value, which has been measured by a standardised
test method, can be used to compare dierent tools with each other and
for a preliminary assessment of exposure.
WARNING! The actual vibration level when using power tools may dier from
the specied maximum value, depending on how the tool is used. It is
therefore necessary to determine which safety precautions are required to
protect the user, based on an estimate of exposure in actual operating
conditions (taking into account all stages of the work cycle, e.g. the time when
the tool is switched o and when it is idling, in addition to the start-up time).
