BlueSpot 07911 User manual

AIR CUT OFF TOOL
User Manual
07911

01
Thank you for purchasing a BlueSpot product, you can find further information
on our range at www.BlueSpot.uk.com. Please ensure that you are using the
product correctly and that all guidance and cautions are followed in accordance
with the instructions. Please retain these instructions for future reference.
General Information
Please make sure that you read these instructions carefully in order to avoid injury when
using the air cut off tool. Follow all health and safety rules and regulations. If in doubt and
available please contact a more knowledgeable source.
DO NOT use if damaged.
• ALWAYS ensure you have read through all of the instructions and fully understand how
to operate the tool before beginning.
• ALWAYS ensure the air cut off tool and cutting wheels have been checked for any
damage before use. Any damage found needs to be repaired or replaced before use to
prevent damage to property or personal injury.
• ALWAYS ensure the air hose has been checked for any damage before use. Any damage
found needs to be repaired or replaced before use to prevent damage to property or
personal injury.
• ALWAYS ensure the air hose is kept away from heat and any sharp edges.
• DO NOT carry the tool by the air hose.
• ALWAYS ensure the air hose does not cause a trip hazard when in use.
• ALWAYS ensure the correct and approved eye and face protection is used when
operating the tool.
• If noise levels exceed safe levels wear approved ear protectors.
• ALWAYS ensure gloves and protective clothing are worn. Gloves should be tight fitting
with no hanging threads. Do not wear loose clothing.
• Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip
shoes.
• Ensure any long hair is tied back and jewellery is removed before operating the tool.
• ALWAYS ensure your hands and body are kept away from the working area of the tool.
• Maintain tool in good and clean condition for best and safest performance. For safest
performance ensure the tool is kept clean and is lubricated.
• Only use the recommended accessories for the air cut off tool.
Safe use
• Keep the work area clean, uncluttered and ensure there is adequate lighting.
• Keep children and unauthorised persons away from the work area.
• Before connecting the air cut off tool to the air supply make sure the tool is switched
off and your finger is not on the trigger.
• Only use air tool oil to lubricate the tool.
• BE AWARE that constant vibration can be harmful to hands and arms. Take frequent
breaks.
• ALWAYS ensure the parts on the air cut off tool including the wheel are secure before
operation.
• ALWAYS ensure the workpiece you will be working on is secure so you don’t have to
hold the workpiece while operating the tool.
• ALWAYS ensure your hands are kept away from the wheel and guard during operation.
• ALWAYS be careful when working with compressed air as it can be dangerous.
• DO NOT operate the air tool continually at full throttle without a work load on the tool.
• ALWAYS ensure the air tool is lubricated correctly before operation.
• DO NOT operate the air tool without the guards in place.
• DO NOT modify the tool.
• DO NOT operate the air tool whilst tired or under the influence of drugs, alcohol or any
medication.
• BE AWARE excessive air pressure may decrease the life of the tool and cause a
hazardous situation.
• NEVER use the air tool near flammable objects or in explosive environments.
• DO NOT use the air tool near live electrical wires.
• DO NOT use the air cut off tool in damp or wet conditions.
• NEVER leave the air cut off tool unattended. When the tool is not in use it should be
disconnected from the air source and stored correctly out of the reach of children.
• ALWAYS ensure air supply has been shut off and any pressure from the tool has been
discharged before removing the hose or storing the tool.
• DO NOT use combustible gases, carbon dioxide, oxygen or bottled gas with the air cut
off tool.
• NEVER use the air cut off tool to perform a task it was not designed to do.
• If the air cut off tool is damaged do not use.

Please make sure that you read these instructions carefully in order to avoid injury when
using the air cut off tool. Follow all health and safety rules and regulations. If in doubt and
available please contact a more knowledgeable source.
DO NOT use if damaged.
• ALWAYS ensure you have read through all of the instructions and fully understand how
to operate the tool before beginning.
• ALWAYS ensure the air cut off tool and cutting wheels have been checked for any
damage before use. Any damage found needs to be repaired or replaced before use to
prevent damage to property or personal injury.
• ALWAYS ensure the air hose has been checked for any damage before use. Any damage
found needs to be repaired or replaced before use to prevent damage to property or
personal injury.
• ALWAYS ensure the air hose is kept away from heat and any sharp edges.
• DO NOT carry the tool by the air hose.
• ALWAYS ensure the air hose does not cause a trip hazard when in use.
• ALWAYS ensure the correct and approved eye and face protection is used when
operating the tool.
• If noise levels exceed safe levels wear approved ear protectors.
• ALWAYS ensure gloves and protective clothing are worn. Gloves should be tight fitting
with no hanging threads. Do not wear loose clothing.
• Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip
shoes.
• Ensure any long hair is tied back and jewellery is removed before operating the tool.
• ALWAYS ensure your hands and body are kept away from the working area of the tool.
• Maintain tool in good and clean condition for best and safest performance. For safest
performance ensure the tool is kept clean and is lubricated.
• Only use the recommended accessories for the air cut off tool.
02
Safe use (continued)
• Keep the work area clean, uncluttered and ensure there is adequate lighting.
• Keep children and unauthorised persons away from the work area.
• Before connecting the air cut off tool to the air supply make sure the tool is switched
off and your finger is not on the trigger.
• Only use air tool oil to lubricate the tool.
• BE AWARE that constant vibration can be harmful to hands and arms. Take frequent
breaks.
• ALWAYS ensure the parts on the air cut off tool including the wheel are secure before
operation.
• ALWAYS ensure the workpiece you will be working on is secure so you don’t have to
hold the workpiece while operating the tool.
• ALWAYS ensure your hands are kept away from the wheel and guard during operation.
• ALWAYS be careful when working with compressed air as it can be dangerous.
• DO NOT operate the air tool continually at full throttle without a work load on the tool.
• ALWAYS ensure the air tool is lubricated correctly before operation.
• DO NOT operate the air tool without the guards in place.
• DO NOT modify the tool.
• DO NOT operate the air tool whilst tired or under the influence of drugs, alcohol or any
medication.
• BE AWARE excessive air pressure may decrease the life of the tool and cause a
hazardous situation.
• NEVER use the air tool near flammable objects or in explosive environments.
• DO NOT use the air tool near live electrical wires.
• DO NOT use the air cut off tool in damp or wet conditions.
• NEVER leave the air cut off tool unattended. When the tool is not in use it should be
disconnected from the air source and stored correctly out of the reach of children.
• ALWAYS ensure air supply has been shut off and any pressure from the tool has been
discharged before removing the hose or storing the tool.
• DO NOT use combustible gases, carbon dioxide, oxygen or bottled gas with the air cut
off tool.
• NEVER use the air cut off tool to perform a task it was not designed to do.
• If the air cut off tool is damaged do not use.

Maximum operating pressure
Recommended operating pressure
Air consumption
Air inlet
Minimum hose diameter
Load speed
Disc dimensions
Spindle thread
Weight
100PSI
90PSI
4CFM
1/4BSP
3/8"
18000RPM
3"
M6
750g
The BlueSpot Air Cut Off Tool is ideal for the cutting of a wide range of materials such as
radiator hoses, sheet metal and exhausts. This item can be used in conjunction with our 3"
cut off discs (19670) the free speed of the tool is 18,000 rpm. Average air consumption is
4CFM (114L/min) 1/4" BSP Inlet. A robust tool for professional and home use.
03
Introduction
Parts Diagram
Specification
1. Spark guard
2. Safety lever
3. Throttle lever
4. Air inlet
5. Air regulator screw
6. Hex key
7. Open end wrench
1
2
6
3
5
7
4

04
Operation
ALWAYS ensure that the air cut off tool has been properly lubricated before use.
ALWAYS check the air cut off tool for any damage before use. If damage is found it must
be repaired/replaced before use.
Installing/Removing Cutting Wheel
BE AWARE not to overtighten the bolt and flange.
1. Slot the open end wrench over the spindle to grip the two flat faces.
2. Hold the spindle firmly with the open end wrench so it is not able to rotate.
3. Whilst holding the spindle securely use your other hand to unscrew the bolt and flange
using the hex key.
4. Remove the cutting disc if in place.
5. Correctly fit the new cutting disc by ensuring the metal ring on the new cutting disc is
facing the spindle and not outwards.
6. Carefully refit the bolt and flange and tighten using the open end wrench and hex key.
7. Check the cutting disc is secure and correctly aligned by spinning it by hand.
Spindle (3)
Tighten
Loosen
Loosen
Tighten

05
Guard Adjustment
ALWAYS ensure the tool is disconnected from the air supply before making any adjustments
to the guard.
1. Use a wrench to loosen the large hex nut.
2. Rotate the guard to the desired position.
3. Carefully retighten the large hex nut.
ALWAYS ensure the guard is secure before use.
Operation
DO NOT switch the air cut off tool on/off when the cutting disc is in contact with the
workpiece. Always allow the tool to reach its full speed before placing onto workpiece and
stop completely before placing the tool down.
ALWAYS ensure the tool is held securely using both hands. Make sure your hand/fingers are
not near the guard/cutting disc.
DO NOT apply too much pressure to the tool when in use. Excessive pressure can damage
the cutting disc and increase wear and tear on the tool.
DO NOT use the tool for sideways grinding as it is not made for this and can cause the disc
to shatter.
BE AWARE that when the cutting disc begins to cut the tool will move sideways. Always
ensure you have a tight and secure grip of the tool.
NEVER allow the tool to run in ‘idle’ rotation for an extended period of time. This can
shorten the life of the tool.
ALWAYS ensure the air pressure has been correctly removed from the tool after shutting off
the air supply.
1. Ensure the instructions for installing the cutting disc have been followed and
the disc is correctly installed.
2. Remove the protective cap from the air inlet and place to one side.
3. Ensure the air cut off tool has been lubricated before use. Add 5 drops of air
tool oil in the air inlet.
4. Blow out the air line to remove any dirt or moisture.
5. Connect the air hose to the air inlet.
6. Set the air pressure to 90PSI.
7. The speed can be adjusted by using a slotted screwdriver to adjust the air regulator
screw beneath the housing.
8. Safely push the lever forward to release the throttle lever and gently press the lever.
9. The cutting disc will begin to spin. Allow the tool to reach the full operating
speed before using on the workpiece.
10. Apply moderate pressure. DO NOT force the tool.
11. To stop the tool release the throttle lever.
12. Allow the tool to stop before placing down.

06
DO NOT switch the air cut off tool on/off when the cutting disc is in contact with the
workpiece. Always allow the tool to reach its full speed before placing onto workpiece and
stop completely before placing the tool down.
ALWAYS ensure the tool is held securely using both hands. Make sure your hand/fingers are
not near the guard/cutting disc.
DO NOT apply too much pressure to the tool when in use. Excessive pressure can damage
the cutting disc and increase wear and tear on the tool.
DO NOT use the tool for sideways grinding as it is not made for this and can cause the disc
to shatter.
BE AWARE that when the cutting disc begins to cut the tool will move sideways. Always
ensure you have a tight and secure grip of the tool.
NEVER allow the tool to run in ‘idle’ rotation for an extended period of time. This can
shorten the life of the tool.
ALWAYS ensure the air pressure has been correctly removed from the tool after shutting off
the air supply.
1. Ensure the instructions for installing the cutting disc have been followed and
the disc is correctly installed.
2. Remove the protective cap from the air inlet and place to one side.
3. Ensure the air cut off tool has been lubricated before use. Add 5 drops of air
tool oil in the air inlet.
4. Blow out the air line to remove any dirt or moisture.
5. Connect the air hose to the air inlet.
6. Set the air pressure to 90PSI.
7. The speed can be adjusted by using a slotted screwdriver to adjust the air regulator
screw beneath the housing.
Operation (continued)
8. Safely push the lever forward to release the throttle lever and gently press the lever.
9. The cutting disc will begin to spin. Allow the tool to reach the full operating
speed before using on the workpiece.
10. Apply moderate pressure. DO NOT force the tool.
11. To stop the tool release the throttle lever.
12. Allow the tool to stop before placing down.
ContactDistance to Spot SizeDisposal
ALWAYS ensure the tool is cleaned after use.This will help to prolong the life of the tools and
parts.
ALWAYS ensure the tool has been disconnected from the air supply.
NEVER use engine oil. ALWAYS ensure air tool oil is used.
Daily Maintenance
• ALWAYS ensure the compressor reservoir, air lines and water trap have all been drained
before connecting to the air supply.
• ALWAYS inspect the tool before use and check for any damage or missing parts.
• Add approximately 1.5ml of air tool oil down the air inlet. Operate the tool at low speed to
thoroughly lubricate.
• Clean the body of the tool with a dry cloth.
After 48 hours running time
• Thoroughly check the product for wear and damage.
Cleaning & Maintenance
ContactDistance to Spot SizeDisposal
ALWAYS ensure the air hose has been disconnected properly before storing.
ALWAYS oil the air cut off tool before storing.
ALWAYS ensure the air cut off tool is stored out of reach of children.
Store the tool in a secure, dry place.
Storage

Problem Possible Causes Solution
Check and set the correct air
pressure. Check for loose
connections and secure.
Loss of pressure /
Tool operating
slowly
Low air pressure
Clear the blockage by operating the
tool in short bursts.
Air blockage
Clean the mesh filter.
Gauze mesh filter blocked
Refer to the instructions and pour oil
into the air inlet.
Check all fittings and the hose for
air leaks.
Air leak
Replace worn components. Rotor
vanes would need to be replaced
as an entire set if needed.
Rotate drive manually when
disconnected from the air line –
this will free the mechanism.
Dirt or gum within mechanism
Check for cracks, deformations or
splinters.
Replace the cutting disc if damage
is found.
Cutting disc damaged
Remove the cutting disc and
check for damage. Refit.
Cutting disc fitted incorrectly
Refer to the instructions and pour
oil into the air inlet.
Tool will not start
/ Tool seized
Dirt or rust in mechanism
Refer to the manual on the
proper lubrication of the tool.
Tool overheats Lubrication of the tool is wrong
Inspect the bearings / check if the
flange is burred or notched / check if
the spindle is bent. Replace if needed
and lubricate. Also check if the
flange is burred or notched.
Replace if needed and lubricate.
Abnormal/strong
vibrations
Bearings/parts worn
07
Troubleshooting

08
Notes
ContactDistance to Spot SizeDisposal
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and
packaging should be sorted, taken to a recycling centre and disposed of in a manner which is
compatible with the environment. When the product becomes completely unserviceable and
requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Environmental Protection
Always check and adhere to national regulations when disposing of any tools that are no longer
functional and cannot be repaired.
• Contact your local waste disposal authority for information on how to correctly
dispose of tools.
Disposal
Contact
Find out more about the BlueSpot® Lifetime Guarantee at www.BlueSpot.uk.com
Tel: [phone]
Email: [email protected]
Orme Business Centre,
Greenacres Road,
Oldham,
OL4 3NS

09
ContactDistance to Spot SizeDisposal
Notes
