Blueview NMF1010 User manual

NMF1010
Top bending
Side bending

2
NMF1010
LED NEON FLEX
(8)
Features
Color options: Single color ;
CRI@90+, support external dimmer;
Good linear effect and better environmental adaptability;
Can be bent on top and side, easy to shape;
A variety of specifications are available,support customization;
Power Supply Mode: single feed,max run 5m; double feed,max run 10m.
Warranty: 5 years indoors, 3 years outdoors;
-
-
-
-
-
-
-
IP67 DC 24V
3Years 5Years
114°
Optical & Electrical Parameters
2300K
2600K
2900K
3300K
4100K
4900K
6200K
Red
Green
Blue
Yellow
Orange
>90
/
24V DC
24V DC
114°
114°
64
64
67
70
71
71
70
24
70
15
18
28
8.0 W/m
8.0 W/m
495
502
530
552
556
554
548
186
635
116
132
200
NMF1010-Single color
NMF1010-Single color
NMF1010-Single color
ColorModel No. CRIVoltage Lm/m Lm/W Rated PowerBeam Angle
Yes
Yes
Dimmable
Other Parameters
120 50.0mm5000.0mm -20~+60℃-20~+70℃
Model No. LED QTY (pcs/m)
5000.0[196.85]
5015.0[197.44]
5004.0[197.00]
5000.0[196.85]
Min. Cuttable LengthStandard Run Working Temperature Storage Temperature
The given data are typical values. Due to tolerances of the production process and the electrical components, values for light output and electrical power can vary up to 10%.
Note:
Profile Drawings
Unit: mm[inch]
OUTDOOR INDOOR
Side bending Side bending
Top bending
E354137

3
NMF1010
LED NEON FLEX
(8)
Bending Diameter
Sectional view
Front cap Front capClosing End-cap Closing End-cap
Remarks: "L" is the standard size of the light strip, can be customized according to the multiple of the minimum cutting unit length.
IP Process Technology
Glue Process (IP67)
Glue process the end cap after cutting, warranty will be provided upon IP65 rated.
No warranty will be provided if the injection moulded(IP68) end cap destroyed or reprocessed.
Corresponding molding equipment and mold needed for self-processing injection moulded end cap, contact the sales for more information.
Molding Pressed (IP67)
Luminous Intensity Distribution Diagram Average Illumination
AVERAGE BEAM ANGLE(50%): 114.2°
C 0 /180,113.8°
Unit：cd
C 90/270,114.5°
Note: above data tested with NMF1010-W at 2300K , for other data,please consult sales rep.
Flux Out: 374.1lm
Height Eavg，Emax Beam Angle: 107.82° Diameter
0.5m
1.0m
1.5m
2.0m
2.5m
3.0m
3.5m
4.0m
4.5m
5.0m
251.5,767.4lx
62.86,191.9lx
27.94,85.27lx
15.72,47.96lx
10.06,30.70lx
6.985,21.32lx
5.132,15.66lx
3.929,11.99lx
3.104,9.474lx
2.515,7.674lx
137.18cm
274.37cm
411.55cm
548.74cm
685.92cm
823.11cm
960.29cm
1097.48cm
1234.66cm
1371.85cm
Single color Single color
Left / Right / Bottom Bottom
Color Color
Outlet Direction Outlet Direction
Glue Process (IP67) Molding Pressed (IP67)

4
NMF1010
LED NEON FLEX
(8)
Recommended power supply upon working length
1m 0.32 A 24V DC
24V DC
7.73 W 12 W Single Feed
5m 1.44 A 34.56 W 50 W Single Feed
Working Length Recommended Power Supply Power Supply ModeRated VoltageMeasured Current Measured Power
NMF1010-single color
Product accessories
Item:
Dimensions L*W*H:
Quantity / 5m:
Free/Optional
Front cap
24*18.4*12.9mm
1pcs
Free
ASY-NMF1010-N00NNH-EC
Item:
Dimensions L*W*H:
Quantity / 5m:
Free/Optional
Front cap
2*10*12mm
1pcs
Optional
--
Item:
Dimensions L*W*H:
Quantity / 5m:
Free/Optional
Aluminum Channel
1000*12*12.5mm
5pcs
Optional
ASY-NMF1010-A2NN1000-MT
Item:
Dimensions L*W*H:
Quantity / 5m:
Free/Optional
S-type track
500*11.12*9.98mm
15pcs
Optional
ASY-NMF1010-MNN0500-MT
Item:
Dimensions:
Quantity / 5m:
Free/Optional
Silicone Glue
45g/pc
1pcs
Optional
WR-7516
Item:
Dimensions L*W*H:
Quantity / 5m:
Free/Optional
Closing End-cap
20*12.4*12.9mm
1pcs
Free
ASY-NMF1010-N00NNX-EC
Item:
Dimensions L*W*H:
Quantity / 5m:
Free/Optional
Closing End-cap
3*12.5*6.5mm
1pcs
Optional
--
Item:
Dimensions L*W*H:
Quantity / 5m:
Free/Optional
Aluminum track
25*12*12.5mm
15pcs
Optional
ASY-NMF1010-A4NN0025-MT
Item:
Dimensions L*W*H:
Quantity / 5m:
Free/Optional
Screws
PA3*10
30pcs
Optional
PA3
(Molding Pressed)
(Molding Pressed)
Schematic diagram of installing aluminum groove
Aluminum clip
Accessories can be added according to customer requirements;
If customers need to process molded caps by themselves, they need to be equipped with corresponding molds and molding equipment;
If the customer processes the molded cap for the second time, and the waterproofing fails to meet our company's standard, the hidden quality risks are not covered by the warranty;
25 12.3 Optional
OptionalAluminum channel 1000 12.0
Name TypeL(mm) W(mm)
Note:

5
NMF1010
LED NEON FLEX
(8)
Products and Tools
CutterLED power supply Electric iron Electric drill
Closing-end cap installation
First put some glue inside of the plug, then
push into the strip light
At welding part, note the positive and negative poles of lines and board; positive to positive and negative to negative.
Each connection point must use 10g silicone glue, and add waterproof and insulation treatment;
The customer selects the appropriate operations according to actual needs;
Please handle with care during the installation. The corners should meet the minimum bending diameter of the product, and you need to use our matching accessories to install,
so as to avoid unnecessary losses to you;
If you don’t know enough about the product, please feel free to consult before buying. We will consider it for you and try our best to bring you a good buying experience;
Wipe off the excess glue and wait for
the glue to solidify.
-
-
-
-
-
Installation
Front cap installation
Weld the wire to the PCB board. First put waterproof glue inside of the end
exit, then push into the strip light.
Wipe off the excess glue and wait for the
glue to solidify.
Aluminum channel installation
Fix the installation channel with screws Put the strip into the channel Finished

6
NMF1010
LED NEON FLEX
(8)
Note:
At the welding place, pay attention to the positive and negative of the line and the strip; they must
be connected correctly.
Each connection must use 10g silica gel for waterproof and insulating treatment;
The mounting screws must be vertical to the mounting surface and must be fastened, as shown in
the figure on the right;
The customer can choose the appropriate operation steps according to the actual needs;
During the mounting, pay attention to the minimum bending diameter of the product at the corners.
It's better to use our matching accessories to install, so as to avoid unnecessary losses;
If you don’t know enough about the product, please feel free to consult us.
-
-
-
-
-
-
Roll the product to a reel,
then wrap it with PE film
Put the carton boxes packed with
products into a bigger box
Label the carton box; Use packing belt to pack. Add
edge protectors if necessary
Label the reel;
Seal the carton box;
Put the prepared products
into a carton box;
Packaging Information
Put the reel and accessories
bag on the work table
Carton Size (mm) Meter/Reel Reel/Carton Gross Weight (kg)Product Size L*W (mm)
Model No. Net Weight (kg)
5000*10 5 / (1±10%) 15.50 (1± 10%)18390*390*325NMF1010
Each roll(5m) of this product is loaded with a reel, and the reel is packed in an aluminum foil bag, and finally in an outer box.
For other customized length packaging, please ask our sales rep.
The above-mentioned packaging quantity and weight are only for the illustrated packaging method. For other packaging methods, the packaging quantity and weight will be
different. The actual weight is subject to the actual product.

7
NMF1010
LED NEON FLEX
(8)
Warning Mark
Light Surface
Cuttable identifier Neat and smooth cut Insert a stick on the reel and place
it on the packing box,and rotate the
reel to get the product.
use in concave direction
Light Surface
Light Surface
use in convex direction
Correct usage of products
Do not use in distortions
Do not bend many times,for it can
endanger electronic lines.
Do not use on wringing(twist) Do not bend at right angles Do not throw or pull when taking
products
Do not make irregular cuts.
Warning
Attentions before installation
Do not disassemble or retrofit the light. Do not touch the surface of the light with a sharp object.
Do not do live-line working during installation,especially for high voltage product.
Do not use any organic chemical solvents.
Use neutral glass adhesive to fix this product and it needs to be dried 4 hours in the open environment after operation.
Treat the ends and the circuit connection points that are not connected to the main line with insulation,waterproof, and anti-corrosion in the installation.
Use 18AWG (0.75mm2 cross-sectional area) or thicker core wire to avoid adverse consequences caused by overheating, if the power cable need to
lengthen.
Make sure the input voltage meets the requirements and lines are connected correctly before lighting on
This product is for signage, and do not use as general lighting.
Series connection within the max run.
The length of the power cable between the power supply and the led strip should not exceed 2 meters.Otherwise, large circuit loss will lead to
inconsistent brightness.
Installation, maintenance and repair should be operated by a qualified technician.
Before installation, check that the product parameters are consistent with the requirements (Seeing product specifications or product labels)
Load voltage, current, power and power supply should be matched with the product.
Follow the instructions of wiring diagram (first connect the load and then the power supply) to avoid short circuit
Make sure the correct connection of positive and negative poles between products and power supply. Otherwise, the light will not be on.
Make sure the power cord firmly screwed into the terminal and it should not be pulled out by hands.
The terminal should have waterproof and anti-corrosive treatment.
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-

8
NMF1010
LED NEON FLEX
(8)
BLUEVIEW ELEC-OPTIC TECH CO.,LTD
□ Tel: [phone]
□ Fax: [phone]
□ Web.: Web.: www.blueviewled.com
□ Email: [email protected]
□ Add.: No. 1000, Section 2, Konggang 2nd Road, Shuangliu, Chengdu 610207, Sichuan, CHINA
Packaging information
Recycling
Statements and Recycling
Repair should be operated by a qualified technician or supplier, if the external circuit or main line of this product is damaged.
The parameters given in this manual are typical values and for reference only
All illustrations and drawings in this manual are for reference.
This product is subject to change without notice.
LED lighting products belongs to electronic products, please do recycling treatment according to the relevant WEEE directives.
-
-
-
-
-
