Blyss EL1716B User manual

GB
IE
Wall hung electric replace
Model EAN
EL1716B 1800W 3663602672777
EL1716W 1800W 3663602672999
Version : 04

2
This instruction manual is important to your safety.
Read the entire manual carefully before using the appliance and
keep it for future reference.
Getting started...
Safety 3-5
Before you start 6-7
Quick start 8-17
In more detail…
Trouble shooting 18
Maintenance and cleaning 18
Environmental protection 19
Technical specications 19-20
Installation 21-23
Let’s
get started...

2 3
PLEASE READ THE SAFETY ADVICE CAREFULLY
BEFORE USING THE APPLIANCE
Warning: risk of re, electric shock, physical injuries and
material damage.
Before using this appliance, always follow the safety
advice during assembly, use and maintenance.
SAFETY ADVICE (Use)
- This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
- Children of less than 3 years should be kept away unless
continuously supervised.
- Children aged from 3 years and less than 8 years shall
only switch on/o󰀨 the appliance provided that it has
been placed or installed in its intended normal operating
position and they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.
Children aged from 3 years and less than 8 years shall
not plug in, regulate and clean the appliance or perform
user maintenance.
-CAUTION : Somepartsofthisproduct can becomevery
hot and cause burns. Particular attention has to be given
where children and vulnerable people are present.
- WARNING : In order to avoid overheating, do not
cover the heater.
- If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
Safety
Let’s
get started...

4
PLEASE READ THE SAFETY ADVICE CAREFULLY
BEFORE USING THE APPLIANCE
- The appliance must not be used outdoors.
- The appliance is intended for domestic use only, and is not
suitable for household room illumination. Do not use this
appliance for anything other than its intended purpose.
- Do not operate the appliance in a room where ammable
liquids, solvents or varnishes are stored and/or where
ammable vapours may exist.
- The appliance must be placed at a minimum distance of
one metre from ammable materials and objects (curtains,
bedding, textiles, paper, etc.)
- Do not attempt to disassemble this appliance, repair it or
perform any modications yourself. This appliance does
not contain any parts that can be used separately.
- Keep plastic packaging out of the reach of children.
-Airinletandoutletventsmustnotbecoveredorobstructed
under any circumstances. Do not insert any objects into
these vents.
- Do not exert pressure on or hit the walls of the appliance.
- Do not set objects (wood logs, stones, pottery, etc.) on
the electric replace other than those designed for this
purpose.
Safety

4 5
PLEASE READ THE SAFETY ADVICE CAREFULLY
BEFORE USING THE APPLIANCE
SAFETY ADVICE (Installation)
- Information on appliance installation is provided in the
Installation section on pages 21 to 23.
- The heater must not be located immediately below a
socket-outlet.
- WARNING : Means for disconnection having a contact
separation in all poles must be incorporated in the xed
wiring in accordance with the wiring rules.
- CAUTION : In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not
be supplied through an external switching device, such as
a timer, or connected to a circuit that is regularly switched
on and o󰀨 by the utility.
- WARNING : This appliance must only be used as a xed
appliance. It must be attached vertically and securely to a
vertical wall. Any other position is potentially dangerous.
- WARNING : This appliance is not protected against
splashes of water. It is not suitable for use in a bathroom.
- Do not use this heater in the immediate surroundings of a
bath, a shower or a swimming pool.
- CAUTION : to be installed by a professional in line with
the installation standards applicable in your country (NF
C15-100 for France or equivalent for other countries).
IMPORTANT : KEEP THIS INFORMATION FOR
FUTURE REFERENCE. READ CAREFULLY.
Safety Safety

6
Points to check before beginning
For domestic use only.
Children or any other persons incapable of using the appli-
ance safely must not use this appliance.
Please discard of plastic packaging appropriately and keep
it out of reach of children.
The appliance is conceived to be used as a supplementary
source of heat, not for the use as the main heating device.
Before you start
To install your product, please read the installation
guidelines at the end of the instruction manual.
You need (no included)
1 screwdriver
1 measuring tape
1 spirit level 1 drill and bit

6 7
1- Main body
2- Control panel
3- Remote control
x01 Wall support
x01 Wall bracket
x07 (ST4.2x40)
x07 (Ø6x35)
x02 (ST3.5x8))
The screws and wall plugs supplied are suitable for solid walls.
For all other types of wall, please use suitable screws and wall
plugs.
Points to check before beginning Your product
Before you start
3
1 2

8
The controls
Quick start
OK
MENU
A
MASTER POWER SWITCH (A)
- Open the cover and push button A down (I) to “ON” position or push but-
ton A down (O) to “OFF” position.
STANDBY ( )
- Press button to start or stop the ame e󰀨ect.
Default interface displays as following :
- The heating icon will display and start heating
when the room temperature is less than the default
setting (10°C), on the contrary it will not display and
heat.
- The clock icon will be ashing because the
time is not set yet. Please follow the steps in “Time
Setting” to set the time.
.Two short beeps that increase in pitch sound when switched on and
three beeps that decrease in pitch sound when switched o.
.When switches on, the heating level, set temperature and clock icon
are displayed. The display will be disappeared after 60 second without
any operation. Press any button to display again.
LOCKING THE BUTTONS ()
- Press and hold button

for more than 6 sec-
onds to lock or unlock the buttons, “LOC” is
displayed and indicated that the buttons are
locked. Once it’s locked “LOC” will be ashing for 6
seconds then disappear, press any button “LOC”
will ash again.
- Long press button for 6 seconds to unlock the buttons.
.Please note the button is never locked.

8 9
Quick start
HEATING ON / OFF
HEATING MODE QUICK START
- Press button +or - to quick start heat setting (even though it’s under
weekly program) as following:
- Press either button +or -to see the current tem-
perature on screen.
- Press button +or - to adjust the temperature as
desired.
. If the set temperature is higher than the room temperature detected
by appliance, the heating starts. The heating will not start if the set
temperature is lower than the room temperature.
NOTE: The temperature range including OFF and from 10°C to 30°C.
OFF for no heating, 10°C to 30°C is the selectable temperatures.
LOW/HIGH HEATING & SETTING THE TEMPERATURE
HIGH HEATING
- At default interface, press button
≡
to display “H” and ashing
icon as following:
- Press

button to set temperature.
. The default temperature is 10°C (50°F).
- Press button +or - to adjust temperature.
. If the set temperature is higher than the room
temperature detected by appliance, the heating
starts. The heating will not start if the set tempera-
ture is lower than the room temperature.

10
Quick start
LOW HEATING
- At default interface, press button
≡
twice to display “L” and ashing
icon as following:
- Press button to set temperature.
- Press button +or - to adjust temperature.
. The default temperature is 10°C (50°F).
. If the set temperature is higher than the room
temperature detected by appliance, the heating
starts. The heating will not start if the set tempera-
ture is lower than the room temperature.
CELSIUS/FAHRENHEIT SETTING
The default temperature readout is Celsius.
- Long press button
≡
for 3 seconds.
- Press button +or - to change the temperature readout from Celsius “C“
to Fahrenheit “F“.
BRIGHTNESS CONTROL
- At default interface, press button
≡
to select the Brightness Control, it’s
displayed “bri” and ashing icon as following:
- Press button to start the brightness setting.
- Press button +or -to select the brightness level.
. 5 brightness levels are selectable.
. Default setting is 3.
5 is the highest level as shown following:
Quick start

10 11
Quick start Quick start
REGULAR TIMER
- At default interface, press button
≡
to select the regular timer, it’s dis-
played “Hour” and ashing icon as following:
- Press button to start the regular timer setting.
- Press button +or -to select the desired time.
The time sequence will read 00, 30 min, 1H, 2H,
3H, 4H, 5H, 6H, 7H, 8H or 9H.
The default setting is 00:00 as shown following:
NOTE:
.This appliance doesn’t have down light function (“doLi”).
.The display will return to default interface after 15 seconds without any
operation on control panel or remote control.

12
MODE SELECTION
- At default interface, press button
≡
to select Mode Selection, it’s dis-
played “ΠΠodE” as following:
- Press button to access Mode menu.
- Press button +or -to select the desired mode.
OPEN WINDOW DETECTION MODE
- Press button
≡
to select “ΠΠodE“ menu.
- Press  to validate,
- Press button +or - to access Open Window Detection Mode “OPEN”.
- Press to validate.
- Press button +or -to
select “ON” or “OFF” to
turn on or turn o󰀨 the Open
Window Detection Mode.
- Press to validate.
. After activate the Open Window Detection, the appliance will auto-
matically shut o the heating when it detects the room temperature
decreased more than 4°C in 10 minutes and maintain the decreased
temperature not less than 20 minutes.
. To restart the heating, adjust the set temperature then press button
to validate the setting. The Open Window Detection Mode will be OFF
after reset the temperature.
Quick start
Secondary programmes and functions

12 13
Quick start
Secondary programmes and functions
Quick start
TIME SETTING
- Press button
≡
to select “ΠΠodE“ menu.
- Press to validate.
- Press button +or - to access Time Setting “TIME” :
- Press to validate.
- Press button +or - to select day, “d1” for Mon-
day, “d2” for Tuesday, “d3” for Wednesday, “d4” for
Thursday, “d5” for Friday, “d6” for Saturday or“d7”
for Sunday.
- Press to validate the day.
- Press button +or - to set time (hour).
- Press to validate the hour.
- Press button +or - to set time (minute).
- Press to validate the time setting.
- To exit the setting during operation, press button
≡
.
. If icon permanently ashes, this indicates that the time is oset
following a power cut. It’s ashing as a time has not been set.

14
Quick start
WEEKLY PROGRAMMING
. The time must be set before any programming.
. The program includes a time period or several time periods during
which the electric replace is under heating mode. Outside of the time
periods, the electric replace is non-heating.
. The time period may overlap another time period.
Program denition:
Time period 1:
Monday to Friday from 05:15 for 4 hours high heating.
Time period 2:
Saturday to Sunday from 06:20 for 4 hours low heating.
Time period 3:
Monday to Friday from 17:45 for 4 hours high heating.
Time period 4:
Saturday to Sunday from 16:30 for 4 hours low heating.
- Press button
≡
to select “ΠΠodE“ menu.
- Press to validate.
- Press button +or - to access Weekly Programming “ProG” :
- Press to validate
- Press button +or -to
select “ON” or “OFF” to
turn on or turn o󰀨 the
weekly program.
- Press to validate.
- To exit the setting during operation, press button
≡
.
Quick start

14 15
Quick start
MANUAL SETTING FOR WEEKLY PROGRAMMING
- Press button
≡
to select “ΠΠodE“ menu.
- Press  to validate, then button +or -to access Manual Setting
“ΠΠAΠU” :
- Press to validate.
1- Press button +or - to select the rst activation day.
- Press to validate.
2- Press + or – to select the last activation day.
- Press to validate.
Following example : For selecting “d1” (Monday) as rst
activation day, and “d7” (Sunday) as last
activation day.
3- Press button +or -to
select the heating level : “H”
for high heating and “L” for
low heating.
- Press to validate.
4- Press button +or -to set your desired temper-
ature.
- Press to validate.

16
Quick start
5- Press button +or -to set the hour of the activa-
tion time.
- Press to validate.
6- Press button +or -to set the minutes of the
activation time (in steps of 5 minutes).
- Press to validate.
7- Press button +or -to set the duration of the
time period (in steps of 30 minutes).
- Press to validate.
. Till now 1st time period of program is completed. It’s displayed “CON”
(conrm).
NOTES : The program cannot run into the next day. The maximum
duration can therefore not exceed midnight (for example, if the start
time is 20:30, the maximum duration displayed is 4 hours and the real
maximum duration is 3 hours 30 minutes).
- To continue the setting for 2nd time period, press
to continue. After , the screen will return to the
interface of day selection (step 1).
OR
- To nish the setting, press button +or - to nd
“FINSH”.
- Press  to nish the setting.
NOTE :
. Maximum 24 time periods could be used.
. Multi time periods could be used for one day.
. Same time period could be used for multiple days.

16 17
Quick start Quick start
USING THE REMOTE CONTROL
. This heater includes a remote control.
. To operate the appliance using the remote control, the Master Power
Switch (A) must be the ON position.
. All the buttons on remote control are exactly the same functions as on
control panel.
REMOTE CONTROL
Before using for the rst time, pull the tab out of the remote control to
activate the battery.
- Replace the CR2025 (3V) button battery and ensure that the battery
polarity is correct.
Battery
1- Push
2- Open

18
Problem Solutions
- The appliance does not
switch on. Check that a circuit breaker has not cut the pow- er to the appliance.
- The device does not heat. - Switch o󰀨 the appliance for a few minutes to
reset the thermal circuit breaker.
- Clean the vents above the appliance.
- The appliance gives o󰀨 a
smell. This can happen the rst time the appliance is
used or if it has remained unused for a pro-
longed period of time. The smell should disap-
pear quickly.
- Clean the vents underneath the appliance.
Trouble shooting
Environmental protection
This symbol is known as the ‘Crossed-out Wheelie Bin
Symbol’. When this symbol is marked on a product or
battery, it means that it should not be disposed of with your
general household waste. Some chemicals contained within
electrical/electronic products or batteries can be harmful
to health and the environment. Only dispose of electrical/
electronic/battery items in separate collection schemes,
which cater for the recovery and recycling of materials
contained within. Your co-operation is vital to ensure the
success of these schemes and for the protection of the
environment.
Disposal of an exhausted batteries
To preserve natural resources, please recycle or dispose of the
batteries properly.
Consult your local waste authority for information regarding available
recycling and /or disposal options.
yyWxx : Manufacturing date code ; year of manufacturing (20yy)
and week of manufacturing (Wxx).
Trouble shooting
Environmental protection

18 19
Maintenance and cleaning
- Warning : Never use detergent, chemical agents or solvents as they could
damage plastic parts.
- WARNING : Let the appliance cool down completely before handling or
cleaning.
- To prevent risk of re or electrocution, do not pour water or any other liquid
inside the appliance.
- Clean the outside wall of the appliance by rubbing it gently with a soft,
damp cloth, either with or without soap.
- Regularly clean the air inlet and outlet vents of the fan.
Maintenance and cleaning
Technical specications
IMPORTANT : Always disconnect from the power
supply before cleaning or maintenance.
Trouble shooting
Trouble shooting
Environmental protection
- Model : EL1716B EL1716W
- Color : Black White
- Power : 1800 W
- Dimensions (WxHxD) : 100x50x16 cm
- Supply : 220-240V ~ 50Hz
- Class I
- IP20 : This appliance is not protected against splashes of water.
It is not suitable for use in a bathroom.
- Lighting : LED non-replaceable
: Complies with all relevant European Directives.
Technical specications

20
Technical specications
Information requirements for electric local space heaters
Model identier(s): EL1716B / EL1716W
Item Sym-
bol Value Unit
Heat output
Nominal heat output Pnom 1,8 kW
Minimum heat output
(indicative) Pmin 0kW
Maximum continuous
heat output Pmax,c 1,8 kW
Auxiliary electricity consumption
At nominal heat
output elmax 0kW
At minimum heat
output elmin 0kW
In standby mode elSB 0kW
Contact details Kingsher International Products Limited 3 Sheldon Square
London W2 6PX
United Kingdom
Item Unit
Type of heat input, for electric storage local space
heaters only (select one)
manual heat charge control, with integrated
thermostat no
manual heat charge control with room and/or
outdoor temperature feedback no
electronic heat charge control with room and/or
outdoor temperature feedback no
fan assisted heat output no
Type of heat output/room temperature control
(select one)
single stage heat output and no room
temperature control no
Two or more manual stages, no room
temperature control no
with mechanic thermostat room temperature
control no
with electronic room temperature control no
electronic room temperature control plus day
timer no
electronic room temperature control plus week
timer yes
Other control options (multiple selections
possible)
room temperature control, with presence
detection no
room temperature control, with open window
detection yes
with distance control option no
with adaptive start control no
with working time limitation no
with black bulb sensor no
