USER INSTRUCTIONS EN
BVCert.6011825
MICROWAVE OVEN
CZ2100028

Table of Contents
Important : Before using your appliance, read this user guide
carefully to familiarise yourself more quickly with its operation.
Dear Customer,
You have just acquired a BRANDT product and we would like to thank you.
We have designed and made this product with you, your lifestyle and your requirements
in mind so that it meets your expectations. We have devoted our know-how, our
innovative spirit and the passion that has been guiding us for over 60 years.
In an effort to ensure that our products meet your requirements in the best possible
way, our Customer Relations department is at your disposal, to answer all your
questions and to listen to all your suggestions.
Visit our website www.brandt.com where you will nd our latest innovations, as well
as useful and complementary information.
BRANDT is delighted to assist you every day and hopes you get the most out of your
purchase.
The label «Origine France Garantie» assures the
consumer the traceability of a product by giving a clear
and objective indication of the source. The BRANDT
brand is proud to afx this label on products from our
French factories based in Orléans and Vendôme.
http://www.brandt.com/

3
Table of Contents
SAFETY INSTRUCTIONS ....................................................................... 4
ENVIRONMENT AND ENERGY SAVING ............................................. 7
Environment....................................................................................... 7
Energy saving tip .............................................................................. 7
INSTALLING YOUR APPLIANCE .......................................................... 8
Choice of location and installation ............................................... 8
Electrical connection ..................................................................... 10
DESCRIPTION OF YOUR APPLIANCE ............................................... 11
Presentation of the oven ................................................................ 11
Display and control keys............................................................... 11
Accessories ...................................................................................... 12
USING YOUR DEVICE ....................................................................... 13
Settings ............................................................................................. 13
Settings menu .................................................................................. 13
Cooking modes .............................................................................. 14
Starting a cooking .......................................................................... 15
CARING FOR YOUR DEVICE ............................................................ 17
Interior - exterior cleaning ............................................................. 17
ANOMALIES AND SOLUTIONS ......................................................... 17
AFTER-SALES SERVICE ...................................................................... 18
Interventions .................................................................................... 18
COOKING AID ................................................................................. 19
Functional aptitude tests ............................................................... 19

4
SAFETY INSTRUCTIONS
Important:
Before switching your appliance
on, please read this installation
guide carefully to familiarise
yourself quickly with its opera-
tion. Keep this manual with the
appliance. If you sell or give
the appliance to someone else,
make sure that you also give
them this manual.
Please read these instructions
before installing and using your
appliance. They have been
written for your safety and the
safety of others.
— This appliance is designed to
be used for domestic and simi-
lar applications such as:
kitchen areas for the staff of
shops, ofces and other pro-
fessional premises; farms; use
by customers in hotels, motels
and other residential environ-
ments; guest house type envi-
ronments.
— This appliance may be used
by children aged 8 years and
older, and by persons with
impaired physical sensory or
mental capacities, or without
experience or knowledge, if
they are supervised or have
received prior instructions on
how to use the appliance safely
and have understood the risks
involved Children must not be
allowed to play with the ap-
pliance. The appliance should
not be cleaned or maintained
by children unless supervised.
— Children should be super-
vised to prevent them from
playing with the appliance.
WARNING:
Accessible parts of the ap-
pliance become hot during use.
Be careful not to touch the
heating elements inside the
oven. Children under 8 years of
age should not be allowed near
the appliance, unless they are
constantly supervised.
It is dangerous for anyone
other than a qualied person
to perform maintenance or re-
pairs that requires the removal
of the cover providing protec-
tion against exposure to mi-
crowave power.
If the appliance is being used
in combination mode, it is re-
commended that children only
use the oven under adult su-
IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY AND
RETAIN FOR FUTURE USE.
This user guide is available for download on the brand’s website.

5
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS
pervision, due to the tempera-
tures involved.
— Metal food and beverage
containers must not be used
when microwave cooking.
— Take care not to move the
turntable when removing the
containers from the appliance.
— Use only microwave-safe
utensils.
— When heating food items
in plastic or paper containers,
keep an eye on the microwave’s
contents, since there is a risk of
spontaneous combustion.
— If smoke appears, stop or
unplug the oven and leave the
door closed to smother any
ames that may appear.
— Liquids and other foods must
not be heated in sealed contai-
ners, as they may explode.
Metal food and beverage
containers cannot be used for
microwave cooking.
— Heating beverages in a mi-
crowave oven can cause the
sudden and/or delayed spitting
of boiling liquid, so care should
be taken when handling their
containers.
— The contents of baby bott-
les and baby food jars must
be stirred or shaken and the
temperature must be checked
before consumption, so as to
prevent burns.
— Heating eggs in their shells
or whole hard-boiled eggs in a
microwave oven is not recom-
mended, since they may ex-
plode even after cooking has
ended.
— This appliance has been de-
signed for closed door cooking.
— A microwave oven is in-
tended for heating food and
drinks.
Drying food products or linen
or heating heat pads, slippers,
sponges, damp clothes or simi-
lar could cause injury or re.
WARNING:
If the door or door seal is da-
maged, the oven should not be
used until it has been repaired
by an authorised person.
It is recommended that the
oven is cleaned regularly and
that any food residue is remo-
ved.
— If the appliance is not cleaned
regularly, its surface could be-
come damaged, permanently
affecting the appliance’s ser-
vice life and possibly causing a
safety hazard.
Do not use abrasive cleaners
or hard metal scrapers to clean
the oven’s glass door; they
could scratch the surface and
cause the glass to crack.

Environment
Environment
6
SAFETY INSTRUCTIONS
Do not use a steam cleaner.
The electrical plug must remain
accessible after installation.
It must be possible to dis-
connect the appliance from
the power supply, either using
a plug or by tting a switch
on the xed wiring system in
accordance with installation
rules.
If the power cable is damaged,
it should be replaced by the
manufacturer, its after-sales
service department or by a si-
milarly qualied person in or-
der to avoid danger.
Centre the oven in the unit so
as to ensure a minimum dis-
tance of 10 mm between the
appliance and the surrounding
unit. The unit supporting the
appliance must be made of
heat-resistant material (or co-
vered with a heat-resistant ma-
terial). For greater stability, at-
tach the oven to the unit with 2
screws through the holes pro-
vided on the side panels.
WARNING:
Only allow children to use the
oven without supervision if
adequate instructions have
been given so that the child is
able to use the oven safely and
understands the dangers of in-
correct use.
This appliance is not designed
to operate above an oven in
pyrolysis mode.
This appliance must be ins-
talled at a height of 850mm
or more above the ground the
ground.
This appliance may be installed
in a cabinet column, as shown
in the installation diagram.

7
Environment
EnvironmentSAFETY INSTRUCTIONS
- Avoid cooking too large portions in the
microwave, prefer to cook twice.
- Avoid foods that require a lot of water for
cooking.
ENERGY SAVING ADVICE
CARE FOR THE ENVIRONMENT
- This appliance’s packing materials are recyclable.
Please recycle them and help protect the environ-
ment by depositing them in municipal containers
provided for this purpose.
- Your appliance also contains many re-
cyclable materials. It is therefore mar-
ked with this logo to indicate that used
appliances must not be mixed with other
waste.
The appliance recycling organised by your manu-
facturer will therefore be conducted in optimum
conditions, in accordance with European directive
2002/96/EC on electrical and electronic equipment
waste.
Consult your local authority or your retailer to lo-
cate your nearest used appliance drop-off points.
- We thank you for your help in protecting the
environment.

8
Installation Installation
CHOICE OF LOCATION AND BUILDING IN
This appliance must be installed in a cabinet column as shown in the installation diagram.
Centre the oven in the cabinet so as to ensure a minimum gap of 10mm between the appliance and the
surrounding unit. The unit supporting the appliance must be made of heat-resistant material (or covered
with a heat-resistant material).
For greater stability, attach the oven to the unit with 2 screws through the holes provided on the side
panels.
N: xx-xx-xxxxx
xxxxxxxxx
xxxx MHz
xxxx W
xxx-xxxV ~ xxHz
Service conso.
xxxxxxxx
Made in France
Cl.B - Gr.2
UNPACKING
When you receive the appliance, unpack it or
have it unpacked immediately. Check its general
appearance. Make a note of any reservations on
the delivery slip and keep a copy.
Conseil
N’utilisez pas immédiatement votre appareil
(attendez environ 1 à 2 heures) après l’avoir transféré
d’un endroit froid vers un endroit chaud, car la
condensation peut provoquer un dysfonctionnement.
380
850
600
100
550
100
4 x 13 mm x2
x2
x1
x1
3.5 x 9.5 mm
592
540.5
390
331
23
120
380
100
390
5
5

9
Installation Installation
Tip
To be certain that you have properly installed your appliance, do not hesitate to call on a
household appliance specialist.
3.5 x 9.5 mm
(x 2)
4 x 13 mm
(x 2)
X mm
X mm
1 mm
X mm
2 mm
3 mm

Description of the oven
10
Installation Installation Description of the oven
Tips
Do not use your appliance immediately
(wait approximately 1 to 2 hours) after moving
it from a cold location to a hot location, as the
condensation may cause a malfunction.
Neutral
(N)
Phase
(L)
bleu
green yellow
Black,brown or
red
Warning
The safety wire (green-yellow) is connected
to the appliance’s terminal and must be
connected to the earth terminal of the elec-
trical set-up.
The fuse in your set-up must be 16 amperes.
ELECTRICAL CONNECTION
Your oven must be connected with a (standard)
power cable with 3 conductors of 1.5mm2(1 live
+ 1 neutral + earth) which must be connected to
a 220-240V~single-phase grid by means of a 1
live + 1 neutral + earth CEI 60083 standard power
socket or via an all-poles cut-off device in compli-
ance with the installation rules.
Terminal
We cannot be held responsible for any accident result-
ing from inexistent, defective or incorrect earthing.

Description of the ovenInstallation Installation
11
Description of the oven
11
THE CONTROL PANEL
D
Micro-wave indicator
Programming time and clock
indicator.
Timer indicator.
Weight indicator.
A
D
H
B
E
C
G
F
The 4 program-selection's keys :
is used to set the clock time or access the
timer.
The clock key :
is used to set the clock time or access the
timer.
The + et - keys :
are used to set the weight, program
cooking time and the timer.
The stop turntable key:
stops and re-starts the turntable.
The start key / +30 seconds :
starts any program.
Each press on this key adds an additional
30 seconds of cooking.
The cancel key :
a press on this key stops the cooking or
programming in progress.
The door open key
The display :
simplies programming by displaying
the function, cooking time, weight or
clock time :

How to use your appliance
12
Description of the oven Description of the oven
THE ACCESSOIRIES
• The turntable
OPERATING PRINCIPLE
Microwaves used for cooking are electromagnetic waves. They are commonly found in our environment
in the form of radio waves, light and infra-red rays.
Their frequency is in the 2450MHz range.
Their behaviour:
• They are reected by metals.
• They pass through any other material.
• They are absorbed by water, fat and sugar molecules.
When food is exposed to microwaves, its molecules begin moving rapidly, causing it to heat up.
The depth of penetration of the waves into the food is about 2.5 cm. If the food is thicker, cooking at its
centre occurs by conduction just like traditional cooking.
In essence, microwaves are simply causing a thermal change inside the food and are therefore not
harmful to health.
The turntable Aensures that food cooks evenly
without further attention.
It rotates in both directions. If it does not turn,
check that all components are properly positioned.
It may be used as a cooking dish. For easy removal,
recesses are provided on both sides.
Rotation is controlled by the drive hub C.
If you take out the support with the drive hub,
make sure you do not let water get into the motor
shaft orice.
Remember to put back the support, the support
wheels Band the turntable.
When the turntable is in the stopped position, large
dishes can be used which cover the entire surface
of the oven. In this case, it is necessary to turn the
container or mix its content half-way through the
program
Turntable management
If you feel there is insufcient space to rotate freely
in the oven, you can stop the turntable before or
during the execution of a program.
You may stop or start the turntable by pressing .
The symbol ashes in the display with the word
OFF, telling you to stop the turntable.
Warning :
Do not try to turn it manually, since
you could damage the drive system.
If the turntable does not turn properly,
check that there is nothing underneath it
stopping it from turning.

How to use your applianceDescription of the oven Description of the oven
13
SETTINGS
• setting the time
• changing the time
• Using the timer
When you switch the oven on or after a power cut, 12:00 ashes.
Set the time using the and keys and then press the key to conrm.
Hold the key pressed until the time ashes. Adjust the time with the and keys and then press
the key to conrm.
Your appliance will now show the right time.
Press the key and the timer indicator is displayed; the time set ashes.
Adjust the time setting using the and keys and then press the key to conrm. At the end of
the time, an audible signal sounds; press a key to stop it.
The timer function cannot be accessed during cooking.
LOCKING THE CONTROLS
Press the key until the symbol is displayed.
To unlock, hold the key pressed until the symbol disappears from the screen.
SETTINGS MENU
You can adjust a number of settings on your oven:
sounds and demonstration mode.
Hold the and keys pressed for a few seconds to access the settings menu.
Key sounds- beeps:
ON position, so unds active.
OFF position, no sounds
DEMO mode
Position ON, mode active.
Position OFF, normal mode.
When "MENU" is displayed, press .
Then navigate between the different parameters by pressing again and change the selection of the
parameter (ON or OFF) by pressing the key .
The validation is done automatically when you exit the settings menu by pressing STOP.

14
How to use your appliance How to use your appliance
COOKING FUNCTIONS
Fonctions Manuelles
To cook fresh vegetables and soup. To heat up all liquids.
To reheat all fresh or frozen pre-cooked dishes and frozen vegetables. To bring pre-cooked
dishes and frozen vegetables up to temperature.
To cook sh and poultry. To nish programs begun with the «FAST COOK» setting such as
beans, lentils or milk-based dishes.
To nish programs begun with the «FAST COOK» setting, which might otherwise overcook on
the outside, for instance veal or pork roast.
900 W :
700 W :
500 W :
350 W :
To defrost meat, fish, fruit, bread or delicate dishes.
Manual defrosting :
Manual cooking (or reheating) :
Automatic cooking functions
Automatic cooking :
Automatic defrosting :
fresh vegetables
sh
ready meals
meat and poultry
bread
vegetables

15
How to use your appliance How to use your appliance
Cooking start (or reheating)
You have at your disposal several microwave powers:
350 W - 500 W - 700 W and 900 Watts.
- Select a power by successively pressing the microwave key until you obtain the desired one. A
cooking time ashes in the display. You can change this cooking time with the and keys.
- Conrm with the key, cooking starts, the tray turns and the interior lighting comes on.
MANUAL COOKING FUNCTIONS
Defrosting start (at 150 W)
- Press the key, a cooking time flashes in the display. You can change this cooking time with the and
keys .
- Conrm with the key, cooking starts, the tray turns and the interior lighting comes on.
"Quick" start
- Open the door. Place the food in the appliance, close the door.
You can start cooking for 30 seconds at full power (900W) just by long pressing, then each short press
on will add an additional 30 seconds of cooking.
During the program
- You can change the power by pressing the microwave key (or the key).
The cooking time is then modified according to the power chosen. You can modify it with the and keys.
- If you open the door before the end of a program, close the door and press key to continue cooking.
- If the door is not closed properly, the appliance will not work.
Note : a beep sounds halfway through the program and "TURN" is displayed indicating that the
food should be turned over for a better result.
After turning the food over, close the door and press the key to continue defrosting.
At the end of a program
- A triple acoustic signal indicates the end of cooking. This signal is repeated every minute for ten
minutes; to stop it, open the door.
- The ventilation can continue to operate to cool the oven. This is normal, it will stop automatically.

16
How to use your appliance How to use your applianceCleaning
Start cooking or defrosting.
The automatic functions select the appropriate cooking or defrosting parameters for you based on the
food to be prepared and its weight.
AUTOMATIC COOKING FUNCTIONS
Cooking
A01 - fresh vegetables
A02 - sh
-Press the cooking key or defrosting key depending on the food used.
The program "01" corresponding to your choice ashes.
- Press the cooking key (or defrosting key) again to switch from one program to another. A weight is
proposed to you, it ashes in the display.
- Enter the actual weight of the food with the and keys (in 50 g increments).
- Conrm with the start key, cooking starts.
Note :
In the functions "A01, d02 et d03" a beep sounds at mid-program and "TURN" is displayed indicating
that the food must be turned over for a better result.
After turning the food over, close the door and press the key to continue defrosting.
Defrosting
d01 - ready meals
d02 - meat and poultry
d03 - bread
d04 - vegetables

How to use your appliance How to use your appliance
17
Cleaning
PROBLEMS AND SOLUTIONS
17
The appliance does not start.
Check that it is plugged in properly.
Check that the oven door is properly closed.
The appliance is noisy and the turntable does not rotate properly.
Clean the wheels and the rolling area under the turntable.
Ensure that the wheels are properly positioned.
You see steam on the window.
Wipe away the condensation with
a cloth.
Food is not heated during a microwave program.
Ensure that the utensils are suitable
for microwave ovens and that the power level
is suitable.
Check that the oven is not in
«DEMO» mode (see settings menu)).
There are sparks coming from the appliance.
Clean the appliance properly: remove any grease, food deposits, etc.
Remove any metal items from the walls of the oven.
CLEANING THE INNER AND OUTER SURFACES
The use of abrasive products, alcohol or thinners is not recommended as they are likely to damage the
appliance. Use a damp sponge and a little soap.
If the oven smells bad or is dirty, boil a cup of water with lemon juice for 2 minutes and clean the walls
with a small amount of washing up liquid.
The turntable can be removed for easy cleaning. To remove it, pick it up using the hand-holds provided
for the purpose. If you remove the drive hub, take care not to allow water to enter the motor shaft hole.
Remember to put back the support, the support wheels and the turntable.

18
Service Calls
18
SERVICE CALLS
Any repairs made to your appliance must
be carried out by a qualified professional
authorised to work on the brand. When calling,
please provide the complete references of
your appliance (commercial reference, service
reference, serial number), so that we can handle
your call better. This information appears on
the manufacturer’s nameplate attached to your
equipment.
GENUINE REPLACEMENT PARTS
During maintenance work, request that only certied
genuine replacement parts are used.
N: xx-xx-xxxxx
xxxxxxxxx
xxxx MHz
xxxx W
xxx-xxxV ~ xxHz
Service conso.
xxxxxxxx
Made in France
Cl.B - Gr.2
B: Product number
C: Service information
H: Serial number

PERFORMANCE IN USE
19
The International Electrotechnical Commission, SC.59K, has established a standard for comparative
performance tests conducted on various micro-wave ovens. We recommend the following for this
appliance:
Test Load Approx.
time Power level selector Cookware/Tips
Custard
(12.3.1) 1000 g 16-18 min 500 W Pyrex 227 On the turntable
Savoie cake
(12.3.2) 475 g 7-8 min 700 W Pyrex 827 On the turntable
Meatloaf
(12.3.3) 900 g 12-15 min 700 W Pyrex 838
Cover with plastic lm.
On the turntable
Defrosting
meat
(13.3) 500 g 14-15 min 150 W On a at plate
On the turntable
Defrosting
raspberries
(B.2.1) 250 g 7-8 min 150 W On a at plate
On the turntable
Function performance tests according to IEC/EN/NF EN 60705

BRANDT FRANCE, Etablissement de CERGY, 5/7 avenue des Béthunes, 95310 SAINT OUEN L’AUMÔNE. SAS
au capital social de 100.000.000 euros RCS NANTERRE 801 250 531.
CZ2100028_01
