Breville ikon BMO200 User manual

BMO200
Microwave Oven
Instructions
Breville is a registered trademark of Breville Pty. Ltd
ABN 98 000 092 928
© Copyright. Breville Pty. Ltd. 2008
ikon™ is a trademark of Breville Pty. Ltd.
Due to continual improvements in design or otherwise,
the product you purchase may differ slightly from the one
illustrated in this booklet.
Model BMO200 Issue 1/08
BMO200_IKON_MICROWAVE_V4.indd 1 4/7/08 11:49:45 AM

2
Contents
Page
Breville recommends safety first 4
Know your Breville ikon™ Microwave Oven 9
Operating your Breville ikon™ Microwave Oven 11
Cleaning and Cleaning 16
BMO200_IKON_MICROWAVE_V4.indd 2 4/7/08 11:49:46 AM

3
Contents Congratulations
on the purchase of your new Breville ikon™ Microwave Oven
BMO200_IKON_MICROWAVE_V4.indd 3 4/7/08 11:49:58 AM

4
Breville recommends safety first
We at Breville are very safety conscious. We design and manufacture consumer products with the
safety of you, our valued customer, foremost in mind. In addition we ask that you exercise a degree
of care when using any electrical appliance and adhere to the following instructions:
Important Safeguards for your Breville ikon™ Microwave Oven
Carefully read all instructions before operating
the Breville ikon™ Microwave Oven and save
for future reference.
Remove and safely discard any packaging
material and promotional labels before using
the Breville ikon™ Microwave Oven for the
first time.
To eliminate a choking hazard for young
children, remove and safely discard the
protective cover that is fitted to the power
plug of the Breville ikon™ Microwave Oven.
Do not place the Breville ikon™ Microwave
Oven near the edge of a bench or table during
operation. Ensure all surfaces are level, clean
and free of water or any other substances.
Do not place the Breville ikon™ Microwave
Oven on or near a hot gas or electric burner,
or where it could touch a heated oven.
When using the Breville ikon™ Microwave
Oven, provide adequate air space above and
on all sides for air circulation.
Always operate the Breville ikon™ Microwave
Oven on a heat-resistant surface. Do not use
on a cloth-covered surface, near curtains or
other flammable materials.
Do not use the Breville ikon™ Microwave
Oven on a metal surface, for example a sink
drain board.
Always ensure the Breville ikon™ Microwave
Oven is properly assembled before connecting
to the power outlet and operating. Do not
use the oven without the roller ring and glass
turntable tray in place. Ensure the turntable
tray is positioned correctly into the indents on
the rotating shaft.
•
•
•
•
•
•
•
•
•
The Breville ikon™ Microwave Oven is not
intended to be operated by means of an
external timer or separate remote control
system.
Never use the Breville ikon™ Microwave
Oven without food or water in the oven cavity.
Operating the microwave oven when empty
could cause damage to the appliance.
Do not leave the Breville ikon™ Microwave
Oven unattended when in use.
Do not touch hot surfaces. Allow the Breville
ikon™ Microwave Oven to cool before
moving or cleaning any parts.
Do not place or store anything on top of the
Breville ikon™ Microwave Oven.
Always ensure the Breville ikon™ Microwave
Oven is turned off at the power outlet and
the cord is unplugged from the power outlet
before attempting to move the appliance,
when not in use, if left unattended and before
disassembling, cleaning or storing.
Keep the appliance clean. Follow the cleaning
instructions provided in this book (page 17).
•
•
•
•
•
•
•
BMO200_IKON_MICROWAVE_V4.indd 4 4/7/08 11:49:58 AM

5
Breville recommends safety first continued
Important Safety Instructions – Read carefully and keep for future reference

WARNING: DO NOT ATTEMPT TO OPERATE THE OVEN WITH THE DOOR
OPEN SINCE OPEN-DOOR OPERATION CAN RESULT IN HARMFUL EXPOSURE TO
MICROWAVE ENERGY. IT IS IMPORTANT NOT TO DEFEAT OR TAMPER WITH THE
SAFETY INTERLOCKS.

WARNING: DO NOT PLACE ANY OBJECT BETWEEN THE OVEN FRONT FACE
AND THE DOOR OR ALLOW SOIL OR CLEANER RESIDUE TO ACCUMULATE ON SEALING
SURFACES.

WARNING: IF THE DOOR OR DOOR SEALS ARE DAMAGED, THE OVEN MUST
NOT BE OPERATED UNTIL IT HAS BEEN REPAIRED BY A BREVILLE SERVICE CENTRE.
IT IS PARTICULARLY IMPORTANT THAT THE OVEN DOOR CLOSES PROPERLY AND
THAT THERE IS NO DAMAGE TO THE: (1) DOOR (BENT), (2) HINGES AND LATCHES
(BROKEN OR LOOSENED), (3) DOOR SEALS AND SEALING SURFACES.

WARNING: IT IS HAZARDOUS FOR ANYONE OTHER THAN A BREVILLE
SERVICE CENTRE TO CARRY OUT ANY SERVICE OR REPAIR OPERATION THAT
INVOLVES THE REMOVAL OF A COVER WHICH GIVES PROTECTION AGAINST
EXPOSURE TO MICROWAVE ENERGY.

WARNING: ONLY ALLOW CHILDREN TO USE THE OVEN WITHOUT
SUPERVISION WHEN ADEQUATE INSTRUCTIONS HAVE BEEN GIVEN SO THAT THE
CHILD IS ABLE TO USE THE OVEN IN A SAFE WAY AND UNDERSTANDS THE HAZARDS
OF IMPROPER USE.

WARNING: DO NOT PUT ANY FOREIGN MATERIAL BETWEEN THE DOOR AND
DOOR JAM OF THE BREVILLE MICROWAVE OVEN AS THIS COULD CAUSE EXCESSIVE
LEAKAGE OF MICROWAVE ENERGY.
Addendum
If the apparatus is not maintained in a good
state of cleanliness, its surface could be
degraded and affect the life span of the
apparatus and lead to a dangerous situation.
Specifications
Power Consumption: 230-240V, 50Hz, 1450W
Output: 900W
Outside Dimensions: 335mm (H) × 520mm (W)
× 440mm (D)
Oven Capacity: 30 Litres
Cooking Uniformity: Turntable System {Ø315m}
Net Weight: Approx. 15.23kg
These specifications may change without notice.
BMO200_IKON_MICROWAVE_V4.indd 5 4/7/08 11:49:58 AM

6
Breville recommends safety first continued
Special safety instructions for your
Breville ikon™ Microwave Oven
Wipe the oven cavity with a soft, damp cloth
after each use. Leaving food residue, grease
or fat in the cavity could cause the oven
cavity to overheat and may cause the Breville
ikon™ Microwave Oven to smoke or catch
fire.
The Breville ikon™ Microwave Oven should
be cleaned regularly and any food residue
or splattering should be removed. Failure
to maintain the microwave oven in a clean
condition could lead to deterioration of
the surface, adversely affecting the life of
the appliance and possibly resulting in a
hazardous situation
If the door seals or any part of the Breville
ikon™ Microwave Oven are damaged, the
microwave oven must not be operated until
it has been inspected and/or repaired at an
authorised Breville Service Centre.
Ensure all food containers and/or plates
are suitable for use in the Breville ikon™
Microwave Oven. This should be done prior to
preparing food for heating or cooking in the
microwave oven. Monitor foods and liquids
heating or cooking in the microwave oven at
all times due to the possibility of containers
igniting.
Containers or plates suitable for use in the
Breville ikon™ Microwave Oven should not
exceed the width of the glass turntable tray
as this may impede the rotation of the tray
and result in food being unevenly cooked.
Liquids or other foods must not be heated
in sealed containers since they are liable to
explode.
Some containers and/or plates may appear
suitable for use in the Breville ikon™
Microwave Oven but may be coated in a
glaze that will absorb the microwave energy,
•
•
•
•
•
•
•
overheat and cause the container to crack.
The glaze may also prevent the food from
heating/cooking.
Food and/or liquids should not be heated or
cooked directly on the turntable tray. Food
and/or liquids must be placed into a suitable
microwave-proof container before placing
onto the turntable tray.
Food and/or liquids should not be heated
or cooked in plastic or paper containers or
bags, unless specified as suitable for use by
the manufacturer, due to the possibility of
containers exploding or igniting. Metal clips or
twists should be removed from packaging as
these could cause sparking and/or fire.
Do not use recycled paper or kitchen paper
towelling when cooking. Recycled paper may
contain small metal or other impurities which
could cause sparking and/or fire.
Do not use metal containers or utensils in
the Breville ikon™ Microwave Oven as these
could cause sparking and/or fire.
Food grade foil wrapping may be used in a
single layer to mask portion of the food to be
cooked and should not extend pass the edge
of the glass turntable tray. Food grade foil
should not be used in layers or fully cover the
food as this could cause sparking and/or fire.
Food grade foil should not be used to cover
any part of the glass turntable tray.
Ensure that lids and caps covering containers
are removed prior to placing liquids and/or
foods into the Breville ikon™ Microwave
Oven.
Feeding bottles and baby food jars should
have the lids and caps removed before
warming or heating in the Breville ikon™
Microwave Oven. To avoid burns or scalding
after heating, the contents should be stirred
or shaken and the temperature checked
before serving.
•
•
•
•
•
•
•
BMO200_IKON_MICROWAVE_V4.indd 6 4/7/08 11:49:58 AM

7
Breville recommends safety first continued
Always ensure the temperature of food or
drink which has been heated or cooked in
the Breville ikon™ Microwave Oven has been
tested before eating, drinking or serving to
others, especially children, disabled or elderly
people.
The heating of liquids and beverages in the
Breville ikon™ Microwave Oven can result in
delayed eruptive boiling. Care must be taken
when handling any containers containing hot
liquids or beverages.
Do not heat popcorn in the Breville ikon™
Microwave Oven unless it has been
commercially packaged for microwave use.
There may be a number of un-popped kernels
that may overcook and burn when popping
popcorn. Do not use oil unless recommended
by the manufacturer. Do not pop popcorn
longer than the manufacturer’s instructions
(popping time should not exceed 3 minutes).
Longer cooking could cause scorching or fire.
Do not cook any food surrounded by a
membrane (such as potatoes, chicken liver,
egg yolks, oysters, etc) without first piercing
the membrane several times with a fork.
Fresh eggs in the shell and whole hard-boiled
eggs should not be cooked or heated in the
Breville ikon™ Microwave Oven as they may
explode during cooking, at the end of cooking
or after removing from the microwave oven.
Do not heat oil or fat for shallow or deep
frying in the Breville ikon™ Microwave Oven.
Doing so may cause the microwave oven and/
or the oil to overheat and/or ignite.
If any smoke is observed, switch off and
unplug the Breville ikon™ Microwave Oven
at the power outlet. Keep the door closed to
stifle any flames.
•
•
•
•
•
•
•
Do not attempt to operate the Breville ikon™
Microwave Oven by any method other than
those described in this book.
Do not disconnect the Breville ikon™
Microwave Oven from the power supply by
pulling on the cord to unplug from the power
outlet.
When storing the Breville ikon™ Microwave
Oven, loosely wind the cord. Do not wrap the
cord around the microwave oven.
Important safeguards for all electrical
appliances
Unwind the cord fully before use.
To protect against electric shock do not
immerse the power cord, power plug or
appliance in water or any other liquid.
Do not let the cord hang over the edge of a
bench or table, touch hot surfaces or become
knotted.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance by
a person responsible for their safety.
Children should be supervised to ensure they
do not play with the appliance.
This appliance is for household use only.
Do not use this appliance for anything other
than its intended use. Do not use in moving
vehicles or boats. Do not use outdoors.
•
•
•
•
•
•
•
•
•

CAUTION: SURFACES MAY BE HOT DURING AND AFTER USE.
BMO200_IKON_MICROWAVE_V4.indd 7 4/7/08 11:49:59 AM

8
Breville recommends safety first continued
It is recommended to regularly inspect the
appliance. Do not use the appliance if power
supply cord, plug or appliance becomes
damaged in any way. Return the entire
appliance to the nearest authorized Breville
Service Centre for examination and/or repair.
Any maintenance, other than cleaning,
should be performed at an authorized Breville
Service Centre.
The installation of a residual current device
(safety switch) is recommended to provide
additional safety protection when using
electrical appliances. It is advisable that a
safety switch with a rated residual operating
current not exceeding 30mA be installed in
the electrical circuit supplying the appliance.
See your electrician for professional advice.
•
•
•
Before first use
Remove and safely discard any packaging
material and labels before using the Breville
ikon™ Microwave Oven for the first time.
Carefully unpack the Breville ikon™ Microwave
Oven and keep all the packing material until
all the parts of the microwave oven have been
found and the appliance has been assembled.
It is recommended to keep all the packing
material in a safe place in case you wish to re-
pack the product for shipping purposes.
To remove any dust that may have accumulated
during packing, wash the roller ring and glass
turntable tray in warm soapy water, rinse in
clean water then dry thoroughly. Wipe the
interior and exterior of the microwave oven with
a soft, damp cloth then dry thoroughly.

WARNING: CHECK THE OVEN FOR ANY DAMAGE, SUCH AS MISALIGNED OR
BENT DOOR, DAMAGED DOOR SEALS AND SEALING SURFACE, BROKEN OR LOOSE
DOOR HINGES AND LATCHES AND DENTS INSIDE THE CAVITY OR ON THE DOOR. IF
THERE IS ANY DAMAGE, DO NOT OPERATE THE OVEN AND CONTACT A BREVILLE
SERVICE CENTRE.
BMO200_IKON_MICROWAVE_V4.indd 8 4/7/08 11:49:59 AM

9
Know your Breville ikon™ Microwave Oven
6
2 3
9
Microwave oven window – allows the user to see
through the door while food is cooking
Oven air vent – allows air to move freely through
the microwave oven
Microwave oven cavity – where food is placed
inside the microwave oven
Control panel – user access panel for
programming the microwave oven
Door seal – keeps microwave energy within the
microwave oven cavity and prevents microwave
leakage
Indented Shaft – supports and rotates the glass
turntable tray
Roller ring – supports the glass turntable tray
during rotation
Glass turntable tray – made of heat resistant
glass. The turntable tray must always be in
1.
2.
3.
4.
5.
6.
7.
8.
position prior to use and food should not be
cooked directly on the tray
Door latch – prevents the microwave oven from
operating when the door is open
Control dial – user access for programming the
microwave oven
Not shown:
Door release handle – opens the door and stops the
microwave oven from operating
Door safety lock – prevents unsupervised operation
by young children
Oven cavity light – to observe food when heating or
cooking
Splatter shield – protects the microwave energy outlet
from splattering foods
9.
10.
5 10
1
7
4
8
BMO200_IKON_MICROWAVE_V4.indd 9 4/7/08 11:50:01 AM

10
Know your Breville ikon™ Microwave Oven continued
LED DISPLAY SCREEN – shows selected cooking
time, power, symbols and time-of-day
NUMBERS (1-8) – programs for the Auto Menu
settings
MICROWAVE – use to set the power level. To
check selected power level during time cooking
press ‘MICROWAVE’ buttons
AUTO REHEAT – use to reheat food by weight
CLOCK – press button to set the time-of-day or
recall the time-of-day display. The time-of-day
will be displayed at all times except when the
oven is operating. In the event of a power failure
or if the microwave oven is unplugged, the clock
will have to be reset
START/CONFIRM/+30 SEC – press button to start
the cooking or defrosting functions. The cooking
symbol will appear on the display and the interior
oven light will turn on, the interior fan will operate
and the turntable will rotate
1.
2.
3.
4.
5.
6.
POTATO – use to cook potato by weight
TIME/WEIGHT DEFROST – use to defrost frozen
meat, poultry and seafood by weight. The
defrosting time and power level are automatically
set once the food category and the weight are
programmed
STOP/CLEAR – press button to cancel the
selected power level, cook or defrost times that
previously programmed. The time-of-day clock
cannot be cancelled by pressing the STOP/CLEAR
button
TIMER/AUTO MENU/WEIGHT – turn dial to select
timer, auto menu or weight options for individual
settings
7.
8.
9.
10.
6
3
1
2
9
10
7
4 8
5
BMO200_IKON_MICROWAVE_V4.indd 10 4/7/08 11:50:01 AM

11
Operating your Breville ikon™ Microwave Oven
Installation
Make sure that all the packing materials are
removed from the inside of the door.
This microwave oven must be placed on a
flat, stable surface to hold its weight and
the heaviest food likely to be cooked in the
oven.
Do not place the oven where heat, moisture
or high humidity are generated, or near
combustible materials.
For correct operation, the oven must have
sufficient airflow. Allow 20cm of space
above the oven, 10cm at back and 5cm
at both sides. Do not cover or block any
openings on the appliance. Do not remove
feet. This microwave oven must not be
placed in a cabinet.
Do not operate the oven without glass tray,
roller support, and shaft in their proper
positions.
Make sure that the power supply cord is
undamaged and does not run under the
oven or over any hot or sharp surface.
The power outlet must be readily accessible
so that the oven can be easily unplugged in
an emergency.
Do not use the oven outdoors
Assembling the glass turntable tray
Place the Roller Ring into position in the
indented space in the oven cavity base.
Insert the Glass Turntable Tray into position,
matching the indents on the base of the
Turntable Tray with the indents in the shaft
located in the centre of the oven cavity
base.
1.
2.
3.
4.
5.
6.
7.
8.
1.
2.
Setting the clock
When power is activated, the LED will display
‘0:00 and the buzzer will beep once.
Press ‘CLOCK’, the hour figures will flash.
Turn dial to adjust the hour figures, the
input time should be within 0-23.
Press ‘CLOCK’, the minute figure will flash.
Turn dial to adjust the minutes figures, the
input time should be within 0-59.
Press ‘CLOCK’ to finish clock setting. ‘:’ will
flash, and the time will illuminate.
If the clock is not set, it will not function when
powered.
During the process of clock setting, if you
press ‘STOP/CLEAR’, the oven will go back to
the previous status automatically.
Note
1.
2.
3.
4.
5.

WARNING: DO NOT IMMERSE THE MICROWAVE OVEN, POWER CORD OR
PLUG IN WATER OR ANY OTHER LIQUID.
BMO200_IKON_MICROWAVE_V4.indd 11 4/7/08 11:50:01 AM

12
Operating your Breville ikon™ Microwave Oven
continued
Microwave cooking
Press ‘MICROWAVE’ the LED will display
‘P100’.
Press ‘MICROWAVE’ four times or turn dial
to choose the power you want, and ‘P100’,
‘P80’, ‘P50’, ‘P30’ or ‘P10’ will display for
each added press.
Then press ‘START/+30Sec./CONFIRM’ to
confirm, and turn dial to set cooking time
from 0:05 to 95:00.
Press ‘START/+30Sec./CONFIRM’ again to
start cooking.
Example: If you want to use 80% microwave
power to cook for 20 minutes, you can operate
the oven as the following steps.
Press ‘MICROWAVE’ once, the screen
display ‘P100’.
Press ‘MICROWAVE’ once again or turn dial
to choose 80% microwave power.
Press ‘START/+30Sec./CONFIRM’ to
confirm, and the screen displays ‘P80’.
Turn dial to adjust the cooking time until the
oven displays ‘20:00’.
Press ‘START/+30Sec./CONFIRM’ to start
cooking.
1.
2.
3.
4.
1.
2.
3.
4.
5.
Microwave power levels
PRESS
‘MICROWAVE’
MICROWAVE
POWER
DISPLAY
1 time 100% P 100
2 times 80% P 80
3 times 50% P 50
4 times 30% P 30
5 times 10% P 10
Quick start
In waiting state, press ‘START/+30 Sec/
CONFIRM’ to start cooking with 100%
power, then each added press will increase
30 seconds cooking time up to 95 minutes.
In microwave or time defrost state, each
press of ‘START/+30 Sec/CONFIRM’ can
increase 30 seconds of cooking time.
In waiting state, turn dial anti-clockwise
to set cooking time with 100% microwave
power, then press ‘START/+30 Sec/
CONFIRM’ to start cooking.
Auto menu and weight defrost cannot be set
from here.
Note
Defrost by weight
Press ‘TIME/WEIGHT DEFROST’ once, and
the oven will display ‘deF1’.
Turn dial to select the weight of food from
100 to 2000g.
Press ‘START/+30 Sec/CONFIRM’ to start
defrosting.
1.
2.
3.
1.
2.
3.
BMO200_IKON_MICROWAVE_V4.indd 12 4/7/08 11:50:02 AM

13
Defrost by time
Press ‘TIME/WEIGHT DEFROST’ twice, and
the oven will display ‘deF2’.
Turn dial to select the defrost time.
Press ‘START/+30 Sec/CONFIRM’ to start
defrosting.
Auto reheat
Press ‘AUTO REHEAT’ once and the LED will
display ‘200’.
Press ‘AUTO REHEAT’ several times or turn
dial to choose the weight of food, and ‘400’
or ‘600’ g will be selected.
Press ‘START/+30 Sec/CONFIRM’ to start
cooking.
Potato
Press ‘POTATO’ once and the LED will
display ‘200’.
Press ‘POTATO’ several times or turn dial
to choose the weight of food, and ‘400’ or
‘600’ g will be selected.
Press ‘START/+30 Sec/CONFIRM’ to start
cooking.
Auto menu cooking
Turn dial right to choose the menu, and ‘A-
1’ to ‘A-8’ will display, which means pizza,
chicken pieces, meat, vegetable, fish, pasta,
soup and porridge.
Press ‘START/+30 Sec/CONFIRM’ to
confirm.
Turn dial to choose the default weight as
the menu chart.
Press ‘START/+30 Sec/CONFIRM’ to start
cooking.
Example: If you want to use ‘AUTO MENU’ to
cook fish weighing 350g.
1.
2.
3.
1.
2.
3.
1.
2.
3.
1.
2.
3.
4.
Turn dial clockwise till ‘A-5’ is displayed.
Press ‘START/+30 Sec/CONFIRM’ to
confirm.
Turn dial to select the weight of fish until
‘350’ is displayed.
Press ‘START/+30 Sec/CONFIRM’ to start
cooking.
Auto menu chart
MENU WEIGHT (g) DISPLAY (g)
A–1
Pizza
200 200
400 400
A–2
Chicken
Pieces
200 200
400 400
600 600
800 800
A–3
Meat
250 250
350 350
450 450
A–4
Vegetables
200 200
300 300
400 400
A–5
Fish
250 250
350 350
450 450
A–6
Pasta
50 (with 450
cold water)
50
100 (with 800
cold water)
100
A–7
Soup
200ml 200ml
400ml 400ml
A–8
Porridge
550 550
1100 1100
1.
2.
3.
4.
Operating your Breville ikon™ Microwave Oven
continued
BMO200_IKON_MICROWAVE_V4.indd 13 4/7/08 11:50:02 AM

14
Operating your Breville ikon™ Microwave Oven
continued
Inquiring function
In states of microwave cooking, press
‘MICROWAVE’, and the current microwave
power will be displayed for 3 seconds. After
three seconds, the oven will turn back to the
former state.
2. In cooking state, press ‘CLOCK’ to display
the current time. Then it will flash in the
LED for 3 seconds.
Multi-section cooking
At most 2 sections can be selected for cooking.
In multi-section cooking, if one section is
defrosting, then defrosting shall be placed in the
first section.
Example: If you want to defrost food for 5
minutes and then cook with 80% microwave
power for 7 minutes, do the following:
Press ‘TIME/WEIGHT DEFROST’ twice and
the oven will display ‘deF2’.
Turn dial to select the defrost time until
‘5:00’ is displayed.
Press ‘MICROWAVE’ once, and screen will
display ‘P100’.
Press ‘MICROWAVE’ once again or turn dial
to choose 80% microwave power.
Press ‘START/+30 Sec/CONFIRM’ to
confirm, and the screen will display ‘P80’.
Turn dial to adjust the cooking time until the
oven displays ‘7:00’.
Press ‘START/+30 Sec/CONFIRM’ to start
cooking, and buzzer will sound once for the
first section, defrosting time counts down;
buzzer will sound once again entering the
second cooking. When cooking is finished,
buzzer will sound five times.
1.
2.
1.
2.
3.
4.
5.
6.
7.
Setting the door safety lock
The safety lock prevents unsupervised operation
by young children. While in lock mode, the door
can be opened, however the microwave cannot
be turned on.
To set, press and hold ‘STOP/CLEAR’ pad
for 3 seconds. There will be a long beep
denoting unit is entering the children-
lock state, and a ‘LOCK’ symbol will be
displayed.
To unlock, press and hold ‘STOP/CLEAR’
pad for 3 seconds, and there will be a long
beep denoting that the lock is released.
Cooking end reminding function
When cooking ends, there will be 5 beeps
which denotes completion of cooking.
Display specification
In waiting state, LED will display clock and
‘:’ will flash.
In function setting state, LED will display the
related setting.
In the operation and suspending state, LED
will display the residual cooking time.
1.
2.
1.
2.
3.
BMO200_IKON_MICROWAVE_V4.indd 14 4/7/08 11:50:02 AM

15
Operating your Breville ikon™ Microwave Oven
continued
Hints and tips for microwave cooking
Foods that are high in liquid, fat and sugar
cook well in the Breville ikon™ Microwave
Oven.
Drier foods require shorter cooking time.
Always arrange food carefully. Place the
thickest areas towards the outside of the
dish.
Place smaller items, such as 1-cup drinks,
towards the outer edge of the glass turntable
tray.
Place larger items, such as chicken or cake,
in the centre of the glass turntable tray.
Larger items, such as chicken or cake, should
be raised on a microwave-safe rack for more
even cooking.
Pay close attention to the cooking time. Cook
for the shortest amount of time indicated
and add more time as needed. Food that is
severely overcooked can smoke or ignite.
Cover foods loosely with vented lids or
microwave safe plastic wrap while heating or
cooking. Covering foods prevent splattering
and helps foods cook evenly.
Turn foods over once during microwaving to
speed cooking of such foods as chicken and
hamburgers. Large items like roasts must be
turned over at least once.
Rearrange foods such as meatballs halfway
through cooking both from top to bottom and
from the centre of the dish to the outside.
•
•
•
•
•
•
•
•
•
•
Microwave utensils
Containers, plates, dishes, etc. used in the
Breville ikon™ Microwave Oven should
always be microwave-safe. Check if stated
on the underside of the utensil or contact the
manufacturer.
To test if a container, plate or dish
is microwave-safe, place it into the
microwave oven with 1 cup of cold water
(in a microwave-safe cup) and heat on High
(100%) Power for 1 minute. If the container
is hot and the water is cold, the container is
not suitable for microwave oven use. If the
container is cold and the water is hot, then
the container is suitable for microwave oven
use.
Metal containers and utensils should not be
used in the Breville ikon™ Microwave Oven.
•
•
•
BMO200_IKON_MICROWAVE_V4.indd 15 4/7/08 11:50:02 AM

16
Switch off the microwave oven at the power
outlet and remove the plug from the power
outlet before cleaning.
Keep the inside of the oven clean. When food
splatters or spilled liquids adhere to oven
walls, wipe with a damp cloth. Mild detergent
may be used if the oven gets very dirty. Avoid
the use of spray and other harsh cleaners
as they may stain, streak or dull the door
surface.
The outside surfaces should be cleaned with
a damp cloth. To prevent damage to the
operating parts inside the oven, water should
not be allowed to seep into the ventilation
openings.
Wipe the door and window on both sides of
the door seals and adjacent parts frequently
with a damp cloth to remove any spills or
spatters. Do not use abrasive cleaner.
Do not allow the control panel to become wet.
Clean with a soft, damp cloth. When cleaning
the control panel, leave oven door open to
prevent oven from accidentally turning on.
If steam accumulates inside or around the
outside of the oven door, wipe with a soft dry
cloth. This may occur when cooking foods
high in moisture or if the microwave oven is
operated under high humidity conditions, this
is normal.
It is occasionally necessary to remove the
glass turntable tray for cleaning. Wash the
tray in warm sudsy water, rinse in clean
water and dry thoroughly.
The roller ring and oven floor should be
cleaned regularly to ensure the turntable tray
rotates correctly and avoid excessive noise.
Simply wipe the bottom surface of the oven
with a soft damp cloth. The roller ring may be
washed in mild sudsy water, rinse in clean
water and dry thoroughly. When removing the
•
•
•
•
•
•
•
•
roller ring from cavity floor for cleaning, be
sure to replace in the proper position.
Remove odours from your oven by combining
a cup of water with the juice of one lemon
in a deep microwave-safe bowl, microwave
on High (100%) for 5 minutes. Wipe the oven
cavity thoroughly and dry with a soft cloth.
When it becomes necessary to replace
the oven light, please consult your Breville
Service Centre to have it replaced.
Please do not dispose this appliance with
domestic rubbish; it should be taken to the
appropriate disposal centre provided by the
local council municipalities.
Before you call for service
Check to ensure that the oven is plugged in
securely. If it is not, remove the plug from the
power outlet, wait 10 seconds and plug it in
again securely.
Check for a blown circuit fuse or a tripped
main circuit breaker. If these seem to be
operating properly, test the power outlet with
another appliance.
Check to ensure that the control panel is
programmed correctly and the timer is set.
Check to ensure that the door is securely
closed engaging the door safety lock system.
Otherwise, the microwave energy will not
flow into the oven.
If non of the above rectify the situation, then
contact your Breville Service Centre. Do NOT
try to adjust or repair the oven yourself.
Note
•
•
•
•
•
•
•
Care and Cleaning
BMO200_IKON_MICROWAVE_V4.indd 16 4/7/08 11:50:03 AM

17
Notes
BMO200_IKON_MICROWAVE_V4.indd 17 4/7/08 11:50:03 AM

18
Notes
BMO200_IKON_MICROWAVE_V4.indd 18 4/7/08 11:50:03 AM

Notes
19
Notes
BMO200_IKON_MICROWAVE_V4.indd 19 4/7/08 11:50:03 AM

Australian Customers
✉ Breville Customer Service Centre
PO Box 22
Botany NSW 2019
AUSTRALIA
☎ Customer Service: 1300 139 798
Fax [phone]
Email Customer Service:
[email protected]
New Zealand Customers
✉ Breville Customer Service Centre
Private Bag 94411
Greenmount
Auckland, New Zealand
☎ Customer Service: 0800 273 845
Fax [phone]
Email Customer Service:
[email protected]
Breville Customer Service Centre
Breville is a registered trademark of Breville Pty. Ltd
ABN 98 000 092 928
© Copyright. Breville Pty. Ltd. 2008
ikon™ is a trademark of Breville Pty. Ltd.
Due to continual improvements in design or otherwise,
the product you purchase may differ slightly from the one
illustrated in this booklet.
Model BMO200 Issue 1/08
www.breville.com.au
BMO200_IKON_MICROWAVE_V4.indd 1 4/7/08 11:49:31 AM
