Breville VMW207 User manual

microwave oven
instruction booklet
red collection
®

4
product safety
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
This product can be used by children aged 8 years and above, and persons
who require supervision, provided:
• they are familiar with the hazards associated with the product, and,
• they receive instruction by a competent person on how to safely use the
product.
Children must not play with the product. Cleaning and user maintenance must
not be done by children unless they are aged 8 or older and are supervised.
WARNING: If the door or door seals are damaged, the oven must not be used
until it has been repaired by a competent person.
WARNING: It is hazardous for anyone other than a competent person to
remove a cover which gives protection against exposure to microwave
energy.
WARNING: Liquids and other foods must not be heated in sealed containers
since they are liable to explode.
Only use cookware and utensils that are suitable for use in a microwave oven.
When heating food in plastic or paper containers, keep an eye on them as
theymaypossiblycatchreorburn.
This microwave oven should only be used for the purpose it was intended.
It must not be used for activities such as drying clothes, paper or any other
non-food item, or for sterilising purposes.
If smoke is emitted, switch off and unplug the oven. Keep the door closed in
ordertostieanyames.
Microwave ovens can heat liquids and beverages such that they can boil over
unexpectedly if the container they are in is moved or stirred immediately after
cooking. Always let the container stand for at least 20 seconds after heating
then stir it before carefully removing the container from the oven.
In order to avoid burns or injury, always stir or shake the contents of feeding
bottles and baby food containers after heating. Always check the temperature
of the contents before consumption.
Eggs in their shell and whole hard-boiled eggs should not be heated in a
microwave oven since they may explode even after cooking has ended.
The microwave oven should be cleaned regularly and any food deposits
removed. Failure to maintain the oven in a clean condition could adversely

5
product safety
affect the life of the appliance and possibly result in a hazardous situation.
This appliance is designed to be used on a work top or table only. Never
install it in a cupboard or cabinet.
If the supply cord is damaged, it must be replaced by the manufacturer, its
serviceagentorsimilarlyqualiedpersonsinordertoavoidahazard.
!Do not allow the power cord to overhang the work surface, or to become trapped,
kinked or pinched.
!Do not operate the oven when it is empty.
!The temperature of accessible surfaces may be high when the appliance is operating.
!The glass turntable and turntable roller must always be tted when operating the oven.
!Do not use the microwave oven cavity for any type of storage, such as cookbooks etc.
!Do not use the microwave for home canning. Microwave ovens are not designed for
canning. Improperly canned food may spoil and be dangerous to eat.
!Do not cook any food surrounded by a membrane such as egg yolk, potatoes, chicken
livers etc. without rst piercing the membrane several times.
!Do not insert ngers or any type of object or implement into the openings on the outer
case.
!Do not cook directly on the glass turntable. Always place food in a proper container
before heating it in the oven.
!Do not use metal pans or dishes with metal handles.
!Do not use anything with a metal trim.
!Do not use paper or plastic covered wire twist ties on plastic bags.
!Do not use melamine dishes because they will absorb microwave energy. This will
cause the dish to crack or char and slow down the cooking process.
!Use only a thermometer specically designed for microwave cooking.
!Do not attempt to deep fry food in the oven.
!Always follow the cooking instructions supplied by the manufacturer or in your
cookbook. Some foods e.g. Christmas puddings, jam, and mincemeat heat up very
quickly.
!When cooking foods with a high fat or sugar content do not use plastic containers.
!Plastic foam containers may melt or contaminate the food or liquid inside when
exposed to high temperatures.
!Wood will dry out when used in the microwave oven and may split or crack.
!The microwave oven must be earthed.

6
Retain the packaging in which the microwave oven was supplied so that in the event that
the equipment needs to be returned it can be suitably repacked.
Open the packaging carefully and remove each item for inspection. Ensure that all
packaging materials are removed from the inside of the door.
Check that all items have been supplied. The items supplied for this model of microwave
oven are:
• Microwave oven
• Glass tray (turntable)
• Turntable roller
• Instruction manual
Inspect the microwave oven and power lead for any damage. If any damage is found do
not use the oven. Contact the dealer where the product was purchased.
Precautions
To avoid possible exposure to microwave energy, it is important that you do not disarm or
tamper with the door safety interlocks.
Do not place any objects between the oven front face and the door, or allow soil or
cleaner residue to accumulate on the sealing surfaces.
Check the oven for any damage, in particular, that there is no damage to the door (such
as dents) its hinges and latches and the door seals and sealing surfaces. Do not operate
the oven if it is damaged in any way. It is particularly important that the oven door is not
misaligned and that it closes properly.
before first use

7
Setting up your microwave oven
Do not operate your oven if it is damaged.
Place the drive shaft into the circular recess in the oven oor. You may need to rotate it
slightly until it ts to the coupling correctly and slides down all the way. Place the turntable
roller ring into the recess in the oven oor. Place the glass turntable onto the shaft until
the lugs on the underside of the turntable engage with the drive shaft. Do not operate
your microwave oven without the drive shaft, roller ring or glass turntable tted.
Due to our policy of continuous improvement, the actual product may differ slightly from the one illustrated in these instructions.
getting started
q
w
e
r
t
1. Glass turntable
2. Drive shaft
3. Turntable roller ring
4. Oven light
5. Waveguide cover

8
Do not install the oven over equipment that produces heat, such as a range
cooker or cooking hob. Failure to follow this instruction could damage the oven
and would make the warranty void.
Do not place the oven in locations of moisture or high humidity or near
combustible materials.
Do not block the air intake and outlet vents. Do not place anything on top of the
oven. Failure to comply can damage the oven.
Do not remove the feet from the bottom of the oven.
Never operate the oven with the waveguide cover removed.
Requirements
Ensure that the voltage and frequency on the rating label of the oven is the same as that
of the household power supply.
Place the oven as far from TVs and radios as possible. Operation of a microwave oven
can cause interference to your TV and radio reception.
Select a at horizontal surface that provides enough open space for the oven inlet and
outlet vents and is strong enough to support the microwave oven.
For correct operation, the oven must have sufcient airow. Ensure there is sufcient
space around the oven as shown.
Route the mains lead away from all hot and sharp surfaces. Do not trap the lead under
the microwave.
Plug your oven into a standard outlet socket.
getting started
Clearance to rear
0cm
Clearance to left
20cm min
Clearance to right
20cm min
85cm min

9
controls
Display
Set or adjust clock
Stop cooking or
clear settings
Select defrost mode
Set weight or
cooking time or
intelligent auto cook
Select microwave power
Start cooking or select
quick start option

10
Microwave cooking basics
Never operate your microwave oven when it is empty as this can damage your
oven.
Do not cook directly on the glass tray. Always place the food in a microwave-proof dish.
Arrange the food with the thickest areas to the outside of the dish. Cook for the shortest
indicated time but do not under-cook. Add extra time if required. Severely over-cooked
food can smoke and may ignite.
Cover food while cooking. Covering prevents spatter and helps the food to cook more
evenly.
To speed cooking and ensure that food is cooked evenly it should be turned over or
stirred at least once during cooking. Larger items, such as joints of meat must be turned
at least once.
Rearrange small items of food such as meatballs halfway through cooking. To ensure
even heating, turn them over and move items from the centre of the dish to the outside of
the dish and items from the top of the dish to the bottom of the dish.
Cover thin pieces of food such as the ends of chicken legs with small pieces of aluminium
foil to prevent them becoming overcooked. Ensure that the foil is kept more than 25mm
(1 inch) from the inside walls of the oven.
Switching on
The microwave oven is turned on by plugging its mains lead into the mains outlet socket.
Open the door and the internal light should turn on. Close the door and it should turn off.
using your microwave oven

11
using your microwave oven
Cookware test
There may be certain non-metallic containers that are not safe to use for microwave
cooking. If in doubt, you can test the COOKWARE following the procedure below.
• Place the empty container in the oven.
• Microwave on maximum power for 1 minute.
• Carefully feel the container. If it becomes very hot do not use it for microwave
cooking.
• Do not exceed 1 minute cooking time when carrying out this test.
The ideal material for a microwave utensil or container is one that is transparent to
microwave energy. It allows energy to pass through the container and heat only the food
inside.
Microwaves cannot penetrate metal so metal utensils and dishes, and dishes with
metallic trim should not be used in this oven.
Do not use recycled paper products as they may contain small metal fragments which
could cause sparks and/or a re.
Round and oval dishes are recommended in preference to square or rectangular dishes
as food in corners tends to overcook.
Cookware Suitable for microwave cooking
Heat resistant glass YES
Non-heat resistant glass NO
Heat resistant ceramic YES
Microwave-safe plastic dish YES
Kitchen paper YES
Metal tray NO
Metal rack NO
Aluminium foil or container (1) NO
(1) Aluminium foil may be used in small pieces to cover or shield food such as the ends of chicken
legs to prevent them becoming over-cooked. Ensure that the foil is kept more than 25mm (1”)
from the oven’s inner walls.

12
Materials you can use in your microwave oven
Material Notes
Aluminium foil Use for shielding only. Small, smooth pieces can be used to
cover thin parts of meat or poultry to prevent overcooking.
Arcing can occur if the foil is too close to the oven walls. The
foil should be at least 25mm (1 inch) away from the oven
walls.
Browning dish Follow the manufacturer’s instructions. The bottom of the
browning dish must be at least 5mm (3/16” inch) above the
turntable. Incorrect usage may cause the turntable to break.
Dinnerware Use microwave-safe dinnerware only. Follow the
manufacturer’s instructions. Do not use cracked or chipped
dishes.
Glass jars Always remove the lid. Heat food until it is only just warm.
Most glass jars are not heat resistant and may break.
Glassware Use only heat resistant oven glassware. Do not use cracked
or chipped glassware.
Oven cooking bags Follow the manufacturer’s instructions. Do not use metal ties
to close the bag. Make slits to allow steam to escape.
Paper plates and cups Use for short term cooking/warming only. Do not leave the
oven unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with
supervision for short term cooking only.
Parchment paper Use as a cover to prevent spattering or as a wrap for
steaming.
Plastic Makes sure that it is labelled ‘Microwave Safe’. Follow the
manufacturer’s instructions. Some plastic containers soften as
the food inside gets hot. Boiling bags and lightly closed plastic
bags should be slit, pierced or vented as directed on the
packaging or by the manufacturer.
Plastic wrap Use microwave-safe plastic wrap only. Use it to cover food
during cooking to retain moisture. Do not allow the plastic
wrap to touch the food.
Waxed paper Use as a cover to prevent spattering and retain moisture.
Thermometer Only use a thermometer that is suitable for use in a microwave
oven.
using your microwave oven

13
using your microwave oven
Never operate your microwave oven when it is empty as this will cause damage.
To pause cooking
To pause cooking at any time during the cooking sequence, you can either:
1. Open the oven door
2. Press the STOP/CLEAR button once.
To resume cooking close the door and press the START/+30SEC/CONFIRM button.
To stop cooking
To immediately stop cooking at any time:
1. Press the STOP/CLEAR button twice
or
1. Open the oven door
2. Press the STOP/CLEAR button.

14
Setting the clock
The clock displays the time of day in 24-hour format.
To set the clock carry out the following:
1. Press the CLOCK/PRESET button once.
2. Turn the WEIGHT/TIMER/AUTO MENU knob until the required hour appears on the
display.
3. Press the CLOCK/PRESET button again.
4. Turn the WEIGHT/TIMER/AUTO MENU knob until the required minutes are
displayed.
5. Press the CLOCK/PRESET button to conrm the setting.
6. The time of day will now be displayed.
using your microwave oven

15
using your microwave oven
Microwave cooking
To cook with microwave power alone, press the MICROWAVE button a number of times
to select a cooking power level, press the START/+30SEC/CONFIRM button to conrm
the power setting and then use the WEIGHT/TIMER/AUTO MENU knob to set the
desired cooking time. The longest cooking time is 95 minutes.
Press MICROWAVE button Microwave power (W) Display
Once 800 P100
Twice 640 P80
3 times 400 P50
4 times 240 P30
5 times 80 P10
Example: To cook for 1 minute at 50% of microwave power.
1. Place the food in a suitable container on the turntable and close the door.
2. Press the MICROWAVE button 3 times. The display will show P50.
3. Press the START/+30SEC/CONFIRM button.
4. Rotate the WEIGHT/TIMER/AUTO MENU knob until the display shows 1:00.
5. Press the START/+30SEC/CONFIRM button.
6. The display shows the set cooking time and then counts down in 1 second
increments.
7. When the cooking time has elapsed, the oven will beep.
8. Open the door and remove the food.

16
Multistage cooking (programmed sequence)
The oven may be set to carry out a sequence of up to two cooking stages. The Time
Defrost function can be used as part of the sequence before the cooking stage. The
possible sequences are:
• Time defrost > microwave cooking
• Microwave cooking rst stage > microwave cooking second stage
The following example describes setting a Time Defrost followed by a Microwave cooking
sequence.
1. Place the food in a suitable container on the turntable and close the door.
2. Press the WEIGHT/TIME DEFROST button twice. dEF2 will be displayed.
3. Rotate the WEIGHT/TIMER/AUTO MENU knob until the required defrosting time is
displayed.
4. Press the MICROWAVE button.
5. The display will show P100 to indicate full power. If required, press the
MICROWAVE button until the required power level is displayed.
6. Press the START/+30SEC/CONFIRM button.
7. Rotate the WEIGHT/TIMER/AUTO MENU knob until the required cooking time is
displayed.
8. Press the START/+30SEC/CONFIRM button.
9. The cooking sequence will begin.
10. When the sequence has ended the oven will beep.
This example describes how to set a two stage microwave cooking sequence. The rst
stage will cook on full power for 2 minutes and the second stage will cook on 50% power
for 1 minute.
1. Press the MICROWAVE button. The display will show P100 to indicate full power.
2. Press the START/+30SEC/CONFIRM button.
3. Rotate the WEIGHT/TIMER/AUTO MENU knob until the display shows 2:00.
4. Press the MICROWAVE button three times. The display will show P50 to indicate
50% power.
5. Press the START/+30SEC/CONFIRM button.
6. Rotate the WEIGHT/TIMER/AUTO MENU knob until the display shows 1:00.
7. Press the START/+30SEC/CONFIRM button.
8. The cooking sequence will begin.
9. When the sequence has ended the oven will beep.
using your microwave oven

17
using your microwave oven
Delayed (timed) start cooking
You can program your oven to delay the start of cooking e.g. if you are going out and you
would like your meal to be ready on your return. Before programming the start time, make
sure that your oven clock is set correctly. Delayed start cooking is programmed in two
stages. First, the cooking power and time is entered, then the time that you want the oven
to start cooking is entered (in 24 hour format).
1. Place the food in a suitable container on the turntable and close the door.
2. Press the MICROWAVE button as required to set the desired cooking power level.
3. Press the START/+30SEC/CONFIRM button.
4. Rotate the WEIGHT/TIMER/AUTO MENU knob to set the required cooking time.
5. Press the CLOCK/PRESET button. The current time will be displayed with the hours
digits ashing.
6. Turn the WEIGHT/TIMER/AUTO MENU knob to set the desired start time hour (in 24
hour format).
7. Press the CLOCK/PRESET button. The minutes digits will now ash.
8. Turn the WEIGHT/TIMER/AUTO MENU knob to set the desired start time minutes.
9. Press the START/+30SEC/CONFIRM button.
10. At the programmed time, your microwave oven will start cooking.
Delayed start cooking can be cancelled at any time by pressing the STOP/CANCEL
button.

18
using your microwave oven
Defrosting
The oven has two modes of defrosting available: Weight Defrost and Time Defrost.
The Weight Defrost mode requires that you know the weight of the food to be defrosted.
The maximum allowable weight is 2 kg.
The Time Defrost mode requires you to know the defrost time for the food to be defrosted.
The maximum defrost time is 95 minutes.
To achieve even defrosting, the food should be turned or stirred at least once during the
cycle or more often with larger amounts of food.
To Defrost by Weight
1. Place the food in a suitable container on the turntable and close the door.
2. Press the WEIGHT/TIME DEFROST button once.
3. The display will show dEF1.
4. Rotate the WEIGHT/TIMER/AUTO MENU knob until the weight of the food to be
defrosted is displayed. Turning the knob clockwise increases the weight, anti-
clockwise decreases it. The display shows the weight in grams.
5. Press the START/+30SEC/CONFIRM button.
6. When the cooking time has ended, the oven will beep.
7. After the required standing time, remove the defrosted food from the oven.
To Defrost by Time
1. Place the food in a suitable container on the turntable and close the door.
2. Press the WEIGHT/TIME DEFROST button twice.
3. The display will show dEF2.
4. Rotate the WEIGHT/TIMER/AUTO MENU knob until the time required for the food to
be defrosted is displayed, clockwise to increase, anti-clockwise to decrease.
5. Press the START/+30SEC/CONFIRM button.
6. When the cooking time has ended, the oven will beep.
7. After the required standing time, remove the defrosted food from the oven.

19
using your microwave oven
Intelligent Auto Cook menu
The Intelligent Auto Cook feature means that it is not necessary to program the cooking
time or select the correct power. All you need to do is specify the type and quantity of food
that you want to cook and the intelligent programs do all the rest for you. The food types
and weights available are listed in the Intelligent Auto Cook Menu table.
Example: To use the intelligent auto cook menu function to cook 450g of sh:
1. Place the food in a suitable container on the turntable.
2. Turn the WEIGHT/TIMER/AUTO MENU knob clockwise until code ‘A-3’ is displayed.
3. Press the START/+30SEC/CONFIRM button.
4. Turn the WEIGHT/TIMER/AUTO MENU knob until 450g is displayed
5. Press the START/+30SEC/CONFIRM button.
6. Cooking will begin.
7. When the cooking time has ended, the oven beeps.
8. After the required standing time, remove the food from the oven.
Display Food Time/Weight/Auto Menu Knob
A-1 Auto Reheat (1) Selects a 200, 400 or 600g plate of food
A-2 Vegetables Selects a 200, 300 or 400g portion of vegetables
A-3 Fish Selects a 250, 350 or 450g portion of sh
A-4 Meat (2) Selects a 250, 350 or 450g portion of meat
A-5 Pasta (3) Selects a 50 or 100g portion of pasta
A-6 Potato (4) Selects 200, 400 or 600g (1, 2 or 3) potatoes
A-7 Pizza Selects a 200 or 400g pizza
A-8 Soup Selects a 200 or 400ml portion of soup
(1) The auto reheat setting is designed to reheat a 200, 400 or 600g plate of food. Always check
that reheated food is piping hot throughout before eating. Don’t use the auto reheat program
to cook microwave meals or frozen meals. Always follow the manufacturer’s instructions when
cooking such food items.
(2) We recommend that in Intelligent Auto Cook mode, meat should be cooked off the bone. Cook
chicken, poultry, etc. until the juices run clear.
(3) For a 50g portion of pasta add 450ml of cold water. For a 100g portion of pasta, add 800ml of
cold water.
(4) The potato program is based on a 200g (medium size) potato and can cook 1, 2 or 3 potatoes.
Place the potatoes in a suitable container on the turntable. Always place the potatoes around
the edge of the turntable or dish being used. Don’t put them together in the centre of the dish as
this will cause uneven cooking. Always maintain a gap between each potato.

20
using your microwave oven
Child-proof lock
When the child-proof lock is set, it disables the control panel buttons. This prevents
unsupervised operation by young children, or any other person who does not know how
to reset the lock. This child-proof lock may only be set when the oven is not cooking.
To activate the child-proof lock:
• Press and hold the STOP/CLEAR button for approximately 3 seconds.
A long beep will sound, the display will show and the control panel will be locked.
To deactivate the child-proof lock:
• Press and hold the STOP/CLEAR button for approximately 3 seconds.
A long beep will sound and the control panel will be unlocked.
Quick start cooking
The Quick Start cooking feature allows you to begin microwave cooking at the press of
a single button. The microwave power is xed at maximum (100%) and the maximum
cooking time using this method is 95 minutes. Each press of the Start/Quick Start button
increases the cooking time by 30 seconds.
1. Place the food in a suitable container on the glass tray and close the door.
2. Press the START/+30SEC/CONFIRM button in quick succession the required
number of times. For example, to cook for 1 minute 30 seconds, press the
START/+30SEC/CONFIRM button 3 times.
3. Cooking will start immediately and the timer will begin to count down.

21
Before carrying out any cleaning, turn off the oven and remove the plug from
the mains supply socket.
The door seal area must be kept clean at all times to eliminate the possibility of
microwave energy escaping.
It is hazardous for anyone other than a competent person to carry out any service
or repair operation which involves the removal of a cover which gives protection
against exposure to microwave energy or high voltage.
General
Most cleaning can be carried out with a damp cloth and mild detergent solution, rinsed
with a clean damp cloth and wiped dry.
Never use sprays or harsh cleaners, cleaning powders or scouring or other abrasive
pads.
Cleaning should be carried out on a weekly basis, more often if required.
Excessive oil spatters on the inside top will be difcult to remove if left longer. Wipe
spatters inside the oven with a damp paper towel soon after cooking, especially after
cooking chicken or bacon.
Oven
Clean the inside of the oven with a soft cloth damped with a mild detergent solution
to remove any food spatters. Pay particular attention to the mica waveguide cover and
surrounding area.
The outside surface should be cleaned in the same way. Do not use a wet cloth as this
could cause water to seep into ventilation openings and damage the operating parts.
Wipe the observation window in the door both inside and outside with the damp cloth.
If steam (condensation) accumulates inside or around the outside of the door, wipe it
away with a soft cloth.
Control panel
If the control panel becomes dirty, clean with a soft dry cloth. A lightly damp cloth may be
used for stubborn marks. Do not use sprays or harsh cleaners as they may stain or dull
the panel.
care and maintenance

22
care and maintenance
Removable items
The glass turntable may be removed for cleaning. Wash it in warm soapy water or in a
dishwasher. Be careful not to chip or scratch the glass as this may cause the turntable to
break during use.
The turntable roller and oven oor should be cleaned regularly to allow the glass
tray to rotate easily and quietly. Wash the turntable roller in warm soapy water or in a
dishwasher.
Ensure that the items are replaced correctly. Refer to the Getting Started section in this
guide for details.
Removing odours
Odours can be removed from the microwave oven by adding the juice and skin of one
lemon to a cup of water, then microwave for 5 minutes in a deep microwavable bowl.
Afterwards wipe the inside of the microwave oven thoroughly and dry with a soft cloth.
Maintenance
The only electrical user replaceable items in this microwave oven are the mains plug and
the mains fuse in the plug.
For all repairs you are advised to contact your local approved service centre for this
equipment. Your supplier will be able to advise you in this matter.
