Breville Flatbed Inverter LMO530 Series User manual

the Flatbed Inverter™
Instruction Book - LMO530

2
BREVILLE
RECOMMENDS
SAFETY FIRST
At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition we ask
that you exercise a degree of
care when using any electrical
appliance and adhere to the
following precautions.
IMPORTANT
SAFEGUARDS
READ ALL
INSTRUCTIONS BEFORE
USE AND SAVE FOR
FUTURE REFERENCE
•Carefully read all
instructions before
operation and save for
future reference.
•Remove and safely
discard any packaging
material and promotional
labels before using the
Breville Microwave for the
first time.
•To eliminate a choking
hazard for young children,
remove and safely discard
the protective cover that is
fitted to the power plug of
the Breville Microwave.
•Do not place the
microwave oven near the
edge of a bench or table
during operation. Ensure
all surfaces are level, clean
and free of water or any
other substances.
2 Breville Recommends Safety First
12 Components
15 Functions
19 Tips
20 Care & Cleaning
21 Troubleshooting
Contents

3
•Do not place the
microwave oven on or near
a hot gas or electric burner,
or where it could touch a
heated microwave oven.
•When using the
microwave oven, provide
adequate air space above
and on all sides for air
circulation (see page 14
Installation).
•Always operate the
microwave oven on a heat-
resistant surface. Do not
use on a cloth-covered
surface, near curtains or
other flammable materials.
•Do not use the microwave
oven on a metal surface,
for example, a sink drain
board.
•Always ensure the
microwave oven is
properly assembled before
connecting to the power
outlet and operating.
•The microwave oven is not
intended to be operated by
means of an external timer
or separate remote control
system.
•Never use the microwave
oven without food or
water in the microwave
oven cavity. Operating
the microwave oven
when empty could cause
damage to the appliance.
•Do not leave the
microwave oven
unattended when in use.
•Do not touch hot surfaces.
Allow the microwave oven
to cool before moving or
cleaning any parts.
•Do not place or store
anything on top of the
microwave oven.
•Always ensure the
microwave oven is turned
off at the power outlet and
the cord is unplugged
from the power outlet
before attempting to move
the appliance, when not
in use, if left unattended
and before disassembling,
cleaning or storing.

4
•Keep the appliance clean.
Follow the cleaning
instructions provided in
this book (page 20).
•Always turn the
microwave oven off by
pressing the STOP/
CANCEL button, switch
off at the power outlet and
unplug at the power outlet
when it is not in use.
•Before cleaning, always
press the STOP/CANCEL
button, switch off at the
power outlet and unplug
at the power outlet.
IMPORTANT
SAFEGUARDS
FOR ALL
ELECTRICAL
APPLIANCES
•Fully unwind the power
cord before use.
•Connect only to a 230V
or 240Vpower outlet.
•Do not let the power cord
hang over the edge of
a bench or table, touch
hot surfaces or become
knotted.
•To protect against electric
shock do not immerse the
power cord, power plug or
appliance in water or any
other liquid.
•The appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities,
or lack of experience
and knowledge, unless
they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their safety.
•Before use always check
with your doctor if you
have a pacemaker. Modern
pacemakers are protected
against interference, but
some older ones may be
adversely affected when
in close proximity to a
microwave oven.

5
•Children should be
supervised to ensure that
they do not play with the
appliance.
•It is recommended to
regularly inspect the
appliance. To avoid a
hazard do not use the
appliance if the power
cord, power plug or
appliance becomes
damaged in any way.
Return the entire
appliance to the nearest
authorised Breville service
centre for examination
and/or repair.
•Any maintenance other
than cleaning should
be performed at an
authorised Breville service
centre.
•This appliance is for
household use only. Do
not use this appliance
for anything other than
its intended use. Do not
use in moving vehicles
or boats. Do not use
outdoors. Misuse may
cause injury.
•The installation of
a residual current
device (safety switch
is recommended to
provide additional safety
protection when using
electrical appliances.
It is advisable that a
safety switch with a rated
residual operating current
not exceeding 30mA be
installed in the electrical
circuit supplying the
appliance. See your
electrician for professional
advice.
•Always turn the appliance
to the OFF position,
switch off at the power
outlet and unplug at the
power outlet when the
appliance is not in use.
•Before cleaning, always
turn the appliance to the
OFF position, switch off at
the power outlet, unplug
at the power outlet and
remove the power cord,
if detachable, from the
appliance and allow all
parts to cool.

6
•Do not place this
appliance on or near a
heat source, such as hot
plate, microwave oven or
heaters.
•Position the appliance at
a minimum distance of
20cm away from walls,
curtains and other heat or
stream sensitive materials
and provide adequate
space above and on all
sides for air circulation.
WARNING
• Surfaces may be hot during and
after use.
WARNING
• Do not attempt to operate
the microwave oven with the
door open since the open-
door operation can result in
harmful exposure to microwave
energy. It is important not to
defeat or tamper with the safety
interlocks
WARNING
• Do not place any object
between the microwave oven
front face and the door or
allow soil or cleaner residue to
accumulate on sealing surfaces.
WARNING
• Do not put any foreign material
between the door and door jam
of the microwave oven as this
could cause excessive leakage
of microwave energy.
WARNING
• If the door or door seals are
damaged, the microwave oven
must not be operated until it
has been repaired by a Breville
Service Centre. It is particularly
important that the oven door
closes properly and that there is
no damage to the:
• (1) Door (bent), (2) hinges and
latches (broken or loosened),
(3) door seals and sealing
surfaces.

7
WARNING
• Liquids and other foods
must not be heated in sealed
containers since they are liable
to explode.
WARNING
• Only allow children to use
the microwave oven without
supervision when adequate
instructions have been given so
that the child is able to use the
microwave oven in a safe way
and understands the hazards of
improper use.
WARNING
• It is hazardous for anyone other
than a Breville Service Centre
to carry out any service or
repair operation that involves
the removal of the cover which
gives protection against
exposure to microwave energy.
WARNING
• When heating food in
microwave-safe or paper
containers, keep an eye on the
microwave oven due to the
possibility of ignition.
The appliance should not be
cleaned with a steam cleaner.
Microwave Oven specifications
Specification LMO530BLK
Power consumption 230-240V/50Hz, 1500W
Output 1000W
Outside dimensions (mm) 312mm(H)×539mm(W)×409mm(D)
Oven Cavity dimension (mm) 240mm(H)×354mm(W)×358mm(D)
Oven Capacity 30 Litres
Net Weight approx (kg) Approx. 11.5kg

8
SPECIAL SAFETY
INSTRUCTIONS
FOR YOUR
MICROWAVE
OVEN
•Wipe the microwave
oven cavity with a soft,
damp cloth after each
use. Leaving food residue,
grease or fat in the
cavity could cause the
microwave oven cavity to
overheat and may cause
the microwave oven to
smoke or catch fire.
•The microwave oven
should be cleaned
regularly and any food
splattering inside the
cavity should be removed.
Failure to maintain the
microwave oven in a
clean condition could
lead to deterioration of
the surface, adversely
affecting the life of the
microwave oven and
possibly resulting in a
hazardous situation.
•If the door seals or any
of the microwave oven is
damaged, the microwave
oven must not be
operated until it has been
inspected and/or repaired
at an authorised Breville
service centre.
•The microwave oven is
intended for heating food
and beverages. Drying
of food or clothing and
heating of warming pads,
slippers, sponges, damp
cloth and similar may lead
to risk of injury, ignition or
fire.
•Ensure all food containers
and/or plates are suitable
for use in the microwave
oven. This should be done
prior to preparing food
for heating or cooking
in the microwave oven.
Monitor foods and liquids
heating or cooking in
the microwave oven
at all times due to the
possibility of containers
igniting.

9
•Liquids or other foods
must not be heated in
sealed containers since
they are liable to explode.
•Some containers and/or
plates may appear suitable
for use in the microwave
oven but may be coated
in a glaze that will absorb
the microwave energy,
overheat and cause the
container to crack. The
glaze may also prevent
the food from heating/
cooking.
•Food and/or liquids should
not be heated or cooked
directly on the flatbed base
plate. Food and/or liquids
must be placed into a
suitable microwave proof
container before placing
onto the flatbed base plate
•Food and/or liquids should
not be heated or cooked in
plastic or paper containers
or bags, unless specified
as suitable for use by the
manufacturer, due to the
possibility of containers
exploding or igniting.
•Metal clips or twist ties
should be removed from
the packaging as these
could cause sparking and/
or fire.
•Do not use recycled paper
or kitchen paper towelling
when cooking. Recycled
paper may contain small
metal or other impurities
which could cause
sparking and/or fire.
•Do not use metal
containers or utensils
in the microwave oven
as these could cause
sparking and/or fire.
•Only use utensils that
are suitable for use in
microwave ovens.
•Food grade foil should not
be used in the microwave
oven as this could cause
sparking and/or fire.
•Ensure that lids and caps
covering containers are
removed prior to placing
liquids and/or foods into
the microwave oven.

10
•Feeding bottles and baby
food jars should have
lids and caps removed
before warming or
heating in the microwave
oven. To avoid burns or
scalding after heating,
the contents should be
stirred or shaken and the
temperature checked
before serving.
•Always ensure the
temperature of food or
drink which has been
heated or cooked in the
microwave oven has
been tested before eating,
drinking or serving to
others, especially children,
disabled or elderly people.
•The heating of liquids
and beverages in the
microwave oven can
result in delayed eruptive
boiling. Care must be
taken when handling any
containers containing hot
liquids or beverages.
•Do not heat popcorn
in the microwave oven
unless it has been
commercially packaged
for microwave use. There
may be a number of
un-popped kernels that
may overcook and burn
when popping popcorn.
Do not use oil unless
recommended by the
manufacturer. Do not
pop popcorn longer
than the manufacturer’s
instructions (popping
time should not exceed 3
minutes). Longer cooking
could cause scorching or
fire.
•Do not cook any
food surrounded by
a membrane (such as
potatoes, chicken liver,
egg yolks, oysters, etc)
without first piercing the
membrane several times
with a fork or similar
utensils.

11
•Fresh eggs in the shell and
whole hard-boiled eggs
should not be cooked or
heated in the microwave
oven as they may explode
during cooking, at the
end of cooking or after
removing from the
microwave oven.
•Do not heat oil or fat for
shallow or deep frying
in the microwave oven.
Doing so may cause the
microwave oven and/or
the oil to overheat and/or
ignite.
•If any smoke is observed,
switch off and unplug the
microwave oven at the
power outlet. Keep the
door closed to stifle any
flames.
•Do not attempt to operate
the microwave oven by
any method other than
those described in this
instruction book. Do not
disconnect the microwave
oven from the power
supply by pulling on the
cord to unplug from the
power outlet.
•When storing the
microwave oven loosely
wind the cord. Do not
wrap the cord around the
microwave oven.
•Only use the temperature
probe recommended or
supplied together with
this microwave oven. This
is only applicable if the
appliance has the facility
to use a temperature
sensing probe.
CAUTION
•Surfaces may be hot
during and after use.
If the product is not
maintained in a good
state of cleanliness, its
surface could be degraded
and affect the life span of
the product and lead to a
dangerous situation.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS

12
Components
A. Mirror Glass Window
B. LED display, Shows time, cooking progress
and pre-set functions
C. Control Panel, Cooking functions & Dial.
D. Flatbed Base Plate
E. Inverter Technology
F. Push Button Door release
A B C
FED

13
1
2
4
5
6
8
7
9
10
3
7. WEIGHT DEFROST
Use to defrost frozen meat, poultry and
seafood by weight. The defrosting time
and power level are automatically set
once the food category and the weight are
programmed.
8. START/+30SEC
Press to start a cooking program.
Press repeatedly to set quick start function.
9. STOP/CANCEL
Press to cancel setting or reset the oven
before setting a cooking program. Press
once to temporarily stop cooking, or twice
to cancel cooking altogether. It is also used
for setting child lock.
10.MENU/TIME(DIAL)
Turn the dial clockwise to input cooking
time. Turn the dial anti-clockwise to select
the Auto Cook menu.
1. LED digital display screen
Displays selected cooking time, cooking
function, power and time-of-day.
2. POWER LEVEL
Press to select microwave power level.
3. CLOCK
Press to set the current time.
4. WEIGHT ADJUST
Use to select the weight or amount of food.
5. MULTI STAGE COOKING
Use to set multi stage cooking program.
6. TIME DEFROST
Use to defrost frozen meat, poultry and
seafood by time. The defrosting power level is
automatically set once the defrosting time is
programmed.

14
Functions
BEFORE FIRST USE
Before first use remove all promotional stickers
and packaging material before using the
microwave oven for the first time.
To eliminate a choking hazard for young
children, remove and safely discard the
protective cover fitted to the power plug of
this microwave oven. Carefully unpack the
microwave oven and keep all the packing
material until all the parts of the microwave
oven have been found and the appliance has
been assembled. It is recommended to keep
all the packing material in a safe place in case
you wish to repack the product for shipping
purposes. To remove any dust that may have
accumulated during packing. Wipe the interior
and exterior of the microwave oven with a soft,
damp cloth then dry thoroughly.
WARNING
Do not immerse any part of your microwave
oven in water or any other liquid
INSTALLATION
1. Select a level surface that provide
enough open space for the intake and/or
outlet vents.
2. A minimum clearance of 20cm on each
side and 30cm above the microwave is
required between the microwave oven and
any adjacent walls.
• Do not remove the legs from the bottom of
the microwave oven.
3. Blocking the intake and/or outlet openings
can damage the microwave oven.
4. Place the microwave oven as far away from
radios and televisions as possible.
5. Operation of microwave oven may
cause interference to your radio or
television reception.
6. The microwave must not be placed
in a cabinet.
TURNING ON THE MICROWAVE
OVEN
1. Plug the power cord into a 230V or 240V
power outlet. Switch on at the power outlet.
The microwave oven is now on.
WARNING
Do not install the microwave oven over a range
cooktop or other heat-producing appliance.
If installed near or over a heat source, the
microwave oven could be damaged and the
warranty would be void. Check the microwave
oven for any damage, such as misaligned or
bent door, damaged door seals and sealing
surface, broken or loose door hinges and
latches and dents inside the cavity or on the
door. If there is any damage, do not operate the
microwave oven and contact a Breville service
centre.
Do not immerse the microwave oven, power
cord or plug in water or any other liquid.
30cm
20cm 20cm

15
SETTING THE CLOCK
When the power is activated, the LED
will display 1:00. Press the CLOCK button
once or twice to set the digital clock to
24 or 12 hours cycle respectively.
EXAMPLE: To set the oven clock time to 8:30.
1. Press CLOCK button once, the hour figures
will flash. Pressing once will show 24 hours
and twice will show 12 hours.
2. Turn MENU/TIME dial to indicate the hour
digit 8. Press the clock button to set the
hour figure. The minute figures will begin
to flash.
3. Turn MENU/TIME dial to indicate the
minute digits until the screen shows “: 30”
4. Press CLOCK to confirm the setting.
NOTE
You can press the CLOCK button once to
check clock time during cooking.
INTRODUCTION TO MICROWAVE
COOKING
• Microwaves are invisible waves of
electromagnetic energy similar to radio
waves. Instead of being converted to sound
as in a radio or mobile phones, it is converted
into a heat source which heats food from the
inside.
• Microwaves cook because food molecules
of water, fat and sugar react to the energy
provided by the microwaves. That energy is
absorbed by the food causing the molecules
to vibrate quickly. This movement creates
friction which causes the food to heat up and
therefore cook.
• The energy in a microwave is distributed
evenly throughout the cavity.
• Microwave cooking is considered the 'cool'
cooking method as only the food gets hot and
surrounding air stays cool.
• Microwaves are safe and can be economical.
• Microwave ovens don't need preheating
therefore the kitchen stays cooler. Cooking
is cleaner with less odours and washing up is
reduced.
• Microwave ovens cook foods rapidly. Some
foods are better cooked in a microwave
oven as they retain more flavour, texture and
goodness, such plain fish fillets, soft fruit,
vegetables and fat free cakes.
• In a microwave the heat is produced INSIDE
the food. In all other conventional cooking
methods, heat is applied from OUTSIDE
through transference of heat by convection or
radiation.
• Microwave energy penetrates the food to
a depth of about 25mm. Small foods under
5cm in diameter such as eggs are penetrated
to the centre from all sides. In larger foods,
energy creates heat in the outer layer; this
then moves to the centre by conduction, as it
does with conventional cooking.

16
QUICK START
When the unit is in waiting state, press
START/+30 SEC to start cooking for 30
seconds with 100% microwave power. An
additional press will increase the cooking time
by 30 seconds incrementally. The maximum
cooking time is 10 minutes. Press START/+30
SEC once to start cooking.
MICROWAVE COOKING
To cook with microwave power only, press the
POWER LEVEL button a number of times to
select a cooking power level. Use the MENU/
TIME dial to set a desired cooking time. The
longest cooking time is 95 minutes. The oven
will start to cook after START/+30SEC button
is pressed.
Select power level by pressing the POWER
LEVEL button:
Press POWER LEVEL
Cooking power
Display
1 Time 100% 100
2 times 90% 90
3 times 80% 80
4 times 70% 70
5 times 60% 60
6 times 50% 50
7 times 40% 40
8 times 30% 30
9 times 20% 20
10 times 10% 10
11 times 0% 0
TIPS ON DEFROSTING
• The energy required for defrosting is much
less than for cooking as the microwave
causes the ice formed in the food to melt
rather than heat.
• Before defrosting meat in the microwave
oven, remove the freezer bag or wrapping
to prevent meat sitting in ‘drip’, which will
otherwise boil as the meat defrosts causing
meat to go grey and begin to stew. To remove
frozen meat from freezer wrappings, defrost
for a few minutes so the wrap is easy to
remove.
• Remove meat from Styrofoam tray as they are
not microwave-safe.
• Place meat onto a microwave safe rack and a
drip tray to catch juices.
• Check the meat throughout the defrosting
time. As outer portions of meat thaw, remove
them. If the edges of meat feel warm, stop
microwaving and allow meat to stand for a
few minutes or until edges are cold again.
• After defrosting the meat, it must be cooked
right away. Don’t leave it to stand for any
length of time at room temperature or in the
fridge.
WEIGHT DEFROST
The oven allows the defrosting of meat, poultry,
and seafood. The time and the defrosting
power are adjusted automatically once the
weight is programmed. The weight of the
frozen food varies between 100g and 1800g:
FOR EXAMPLE: To defrost 600g of Chicken
1. Place the 600g of frozen chicken to be
defrosted into the microwave and press the
WEIGHT DEFROST button.
2. Press WEIGHT ADJUST button repeatedly
to select the 600g weight.
3. Press START/+30 SEC button
NOTE
During defrosting program, the system will
pause and sound beeps to remind user to turn
food over, and then press START/+30 SEC to
resume the defrosting.

17
TIME DEFROST
The oven can quickly defrost food based on the
time you entered. The maximum defrosting
time you can set is 95 minutes:
FOR EXAMPLE: To defrost Chicken
1. Press TIME DEFROST button once.
2. Turn MENU/TIME dial to set cooking time.
3. Press START/+30 SEC button
NOTE
During defrosting program, the system will
pause and sound beeps to remind user to turn
food over, and then press START/+30 SEC to
resume the defrosting.
MULTI STAGE COOKING
Your oven can be programmed for up to 2
automatic cooking sequences.
Suppose you want to set the following cooking
program.
Microwave cooking
FOR EXAMPLE: To cook lasagne at 100%
power for 5 minutes and 60% for 8 minutes
1. Input a power level by pressing the POWER
LEVEL button once to show 100.
2. Turn the MENU/DIAL to 5 minutes.
3. Press the MULTI STAGE COOKING
button.
4. Input a power level by pressing the POWER
LEVEL button to set it at 60%.
5. Turn the MENU/DIAL to 8 minutes.
6. Press START/+30 SEC button
NOTE
Speed Defrost, Auto Defrost, Quick Start
and Auto Cook cannot be set in Multi Stage
cooking program.
CHILD LOCK
Use to prevent unsupervised operation of the
oven by little children. The CHILD LOCK
indicator will show up on the display screen;
the oven cannot be operated while the CHILD
LOCK is set.
To set the CHILD LOCK: Press and hold the
STOP/CANCEL button for 3 seconds, a beep
sounds and the LOCK indicator illuminates on
the display.
To cancel the CHILD LOCK: Press and hold
the STOP/CANCEL button for 3 seconds until
lock indicator on display goes off.
SYSTEM PROTECTION
During cooking, the system will detect
whether there is an error. If there is an error,
for example, the sensor was to short circuit or
if there is an open circuit, the system will stop
automatically with the display showing E-1 and
the oven will beep every two seconds until the
STOP/CANCEL button is pressed.

18
AUTO COOK
NOTE
The Auto Cook menu selections can only be
made by turning the Menu/Time dial
anti-clockwise.
This microwave oven comes pre-programmed
with 8 Auto Cook menus.
When using any of the auto cook menus, only
the quantity or weight of the item needs to be
selected as the power level and duration for
cooking is automatic.
To select from the Auto Cook menu, rotate the
MENU/TIME dial anti-clockwise to the menu
item desired. Press WEIGHT ADJUST to enter
the assigned weight or quantity of the item to
be cooked. The oven begins cooking once the
START/+30 sec button is pressed.
FOR EXAMPLE: to cook 150g of porridge.
1. Turn MENU/TIME dial anti-clockwise until
06 is displayed.
2. Press WEIGHT ADJUST button
repeatedly until the weight of 150g is
indicated on the display.
3. Press START/+30 SEC button.
Auto Cook Menu
Code Food/cooking mode
1. For milk/coffee and potato, the screen
will show the number of serving
instead of food weight when pressing
WEIGHT ADJUST button.
2. The result of auto cooking depends on
factors such as fluctuation of voltage,
the shape and size of food, your
personal preference as to the doneness
of certain foods and even how well you
happen to place food in the oven.
3. For Spaghetti, add boiling water
before cooking.
MICROWAVE OVEN MENU GUIDE
Auto
Function
Auto
Manual
Weight/
Portion
Default
Time
Press 1 Milk/Coffee 1 Portion/200ml 1.2
2 Portions/400ml 2.2
3 Portions/600ml 3.2
Press 2 Rice 150g 15
300g 18
450g 21
600g 24
Press 3 Spaghetti 100g 12
200g 17
300g 18
Press 4 Potato 1 Portion/230ml 4
2 Portions/460ml 7
3 Portions/690ml 11
Press 5 Auto Reheat 200g 1.2
300g 1.5
400g 2.2
500g 2.5
600g 3.2
700g 3.5
800g 4.2
Press 6 Porridge 50g 2
100g 2.3
150g 4
Press 7 Pizza 150g 0.4
300g 1.1
450g 1.4
Press 8 Popcorn 100g 2

19
Tips
SOME IMPORTANT TIPS FOR
MICROWAVING COOKING
1. To help equalize energy in the food so that
it cooks evenly follow these helpful tips.
Arrange foods with varying size ends, such
as chicken drumsticks and broccoli with
the thicker or tougher part positioned to the
outside of the dish. This ensures the parts
that require more cooking will receive more
energy, so the food will cook evenly.
2. Covering the dish during cooking holds in
the heat and steam to speed up the cooking
time. Use a microwave-safe lid or plastic
wrap that has been vented by turning back
one edge at the side of the dish to form a
narrow vent to release excess steam.
3. Choose cooking dishes that are shallow
and preferably have straight sides. Shallow
dishes enable the food to cook faster and
straight edges prevent the edges from
being overcooked.
4. Use round shaped microwave dishes. Round
shapes cook more evenly than square or
rectangular dishes which absorb most of
the energy in the corners causing food to
overcook and toughen.
5. Stir foods from the outside to centre of
the dish once or twice during cooking to
equalize heat and speed microwaving.
6. Turn medium to large food items over once
during microwaving. This enables even
exposure to microwaves.
7. Elevating some types of food such as cakes,
roast vegetables and dough products can
be advantageous. It allows more energy to
penetrate the food from all sides, base and
top. Use a microwave-safe plastic or ceramic
rack.
8. Do not elevate any special browning dishes,
jugs of sauce or custard, small quantities of
food or mugs of beverages.
9. Internal temperatures of foods continue
to rise so that they continue cooking even
after they have been removed from the
microwave oven. It is better to undercook
food as it will continue to cook once
removed from the microwave.
MICROWAVE UTENSILS
• Containers, plates, dishes, etc. used in the
microwave oven should always be microwave-
safe. Check if they are microwave-safe on
the underside of the utensil or contact the
manufacturer.
• To test if a container, plate or dish is
microwave-safe, place it into the microwave
oven with 1 cup of cold water (in a microwave-
safe cup) and heat on High (100%) Power
for 1 minute. If the container is hot and the
water is cold, the container is not suitable for
microwave oven use. If the container is cold
and the water is hot, then the container is
suitable for microwave oven use.
• Metal containers and utensils should not be
used in the microwave oven.

20
Care & Cleaning
• If storing the microwave oven, press the
STOP/CANCEL button, switch off at the
power outlet then unplug the power cord.
Ensure the microwave oven is completely
cool, clean and dry. Do not place heavy
objects on top. Store the microwave oven
upright.
BEFORE YOU CALL FOR SERVICE
• Check to ensure that the microwave oven is
plugged in securely. If it is not, remove the
plug from the power outlet, wait 10 seconds
and plug it in again securely.
• Check for a blown circuit fuse or a tripped
main circuit breaker. If these seem to be
operating properly, test the power outlet with
another appliance.
• Check to ensure that the control panel is
programmed correctly and the timer is set.
• Check to ensure that the door is securely
closed engaging the door safety lock system.
Otherwise, the microwave energy will not
flow into the microwave oven.
NOTE
If none of the above rectify the situation,
then contact your Breville service centre.
Do NOT try to adjust or repair the microwave
oven yourself.
• Switch off the microwave oven at the power
outlet and remove the plug from the power
outlet before cleaning.
• Keep the inside of the microwave oven clean.
When food splatters or spilled liquids adhere
to the microwave oven internal walls, wipe
with a damp cloth. Mild detergent may be
used if the cavity gets very dirty. Avoid the
use of spray and other harsh cleaners as they
may stain, streak or dull the door surface.
• The outside surfaces should be cleaned with
a damp cloth. To prevent damage to the
operating parts inside the microwave oven
cavity, water should not be allowed to seep
into the ventilation openings.
• Wipe the door and window on both sides of
the door seals and adjacent parts frequently
with a damp cloth to remove any spills or
spatters. Do not use an abrasive cleaner.
• Do not allow the control panel to become wet.
Clean with a soft, damp cloth. When cleaning
the control panel, leave the microwave oven
door open to prevent it from accidentally
turning on.
• If steam accumulates inside or around the
outside of the oven door, wipe with a soft dry
cloth. This may occur when cooking foods
high in moisture or if the microwave oven is
operated under high humidity conditions,
this is normal.
• Remove odours from your microwave oven
by combining a cup of water with the juice
of one lemon in a deep microwave-safe bowl,
microwave on High PL10 for 5 minutes. Wipe
the microwave oven cavity thoroughly and
dry with a soft cloth.
• When it becomes necessary to replace the
oven light, please consult your Breville
service centre to have it replaced.
• Please do not dispose this appliance with
domestic rubbish; it should be taken to the
appropriate disposal centre provided by the
local council municipalities.
