RIDGE INSTALLATION
GUIDE
Fig.2 Ventilating Ridge Fixings
CLOSE FITTING / VENTILATED
RIDGES
The EUROSIX range of closed ridges and vents are
available in the following sizes:
Girths 750mm (12.5° and 15° only) or 900mm,
in pitches of 5° to 22.5° in 2.5° increments.
1800mm girth available from stock. Please contact
our technical department for more details.
Both slopes of the roof must be sheeted starting at
the same gable end and the corrugations must be
accurately aligned up and over both slopes of the
roof. It is vital that the ridge and the top sheets are
mitred. Fix the ridge in exactly the same way as the
sheets, and ensure the fasteners are a minimum of
100mm from the tail end of the ridge.
Fig.1 Closed Ridge Fixings
750mm or 900mm girth to underside of sheet
Standard 100mm
radius
100mm
300mm
EUROSIX
sheet
EUROSIX
sheet
750mm or 900mm girth to underside of sheet
Standard 100mm
radius
100mm
300mm
EUROSIX
sheet
EUROSIX
sheet
300mm max
300mm max

01934 641 446www.briarwoodproducts.co.uk
RIDGE INSTALLATION
GUIDE
PURLIN SETTING OUT
All 750mm and 900mm cranked ridges (both closed
and ventilated) must overlap the EUROSIX straight
sheet by 300mm (this creates a non fragile ridge
detail).
If the sheets have to be laid with 300 mm laps
because of the exposure rating, use the smaller
dimension.
If using 750mm girth EUROSIX ridges on roofs
with pitches of 12.5 and 15, a 300mm overlap will
encroach on the curved part of the ridge, this is
correct. However to ensure no damage occurs, use
8mm butyl strips as a spacer between the ridge and
the sheet.
The tables below provide the setting out details for
a range of purlin sizes.
PITCH A PURLIN DEPTH B
B = 75 B = 125 B = 175 B = 225
5° 193 189 185 181
7½° 191 184 177 171
10° 187-337 178-328 170-320 161-311
12½° 184-334 173-323 162-312 151-301
15° 182-332 168-318 155-305 142-292
17½° 179-329 164-314 148-298 132-282
22½° 175-325 155-305 134-284 113-263
Dimension C for 750mm EUROSIX Ridges
PITCH A PURLIN DEPTH B
B = 75 B = 125 B = 175 B = 225
12½° 109-259 98-248 87-237 76-226
15° 107-257 93-243 80-230 67-217
Dimension C for 900mm EUROSIX Ridges
