Brickhouse Security HD book camera User manual

HD book camera
Huge battery camera series
Please ensure that you read the complete user manual
carefully before using any part of the product.
- Keep this copy safe for future reference in case of
operational difficulties.
-

General overview
2
General Introduction
Main features:
- Put-It-There for easily hidden surveillance
- Hidden PIR to catch people moving
- Hidden battery
- Full HD 1080P 30FPS
- Audio could be able/disable
-3-5 meters night vision
Important Remindings:
-Please read the user manual before using the camera.
-Please test the position/angle, playback the video in advance,
to make sure it could catch what you want
-Please do not use this camera for illegal purpose. It is important
to follow the laws in your country/state
-We could not be responsible for missing any video record due to
wrong operation/Micro-SD problem/camera angle limit
This book camera is especially designed for long-time motion
detection and video recording as Max 24 month stand-by upon
one full-charge. So user could easily put the camera anywhere
for hidden surveillance for moths.
Besides, it has a hidden PIR sensor to catch motion accurately.
As we know, PIR is a best way to detect human moving.
Furthermore, there is a hidden huge battery as, which could
support
Max 24 month stand-by to catch motion.

HD b oo k ca mer a
Huge bat ter y cam era se rie s
Pl ease e nsur e tha t you re ad th e comp lete u ser m anua l
ca refu lly b efo re us ing an y par t of th e prod uct .
- Ke ep thi s cop y safe f or fu ture r efe renc e in ca se of
op erat iona l diff icu ltie s.
-
Important notice:
If there is anything missing, please contact us immediately
Product accessories
Camera Manual
3
USB cable
Warning sticker

Product structure
4
Camera lens
LED
REC
OFF
Indicator
Micro-SD
USB
Suggested operations:
1. Insert SD and set the time/date before using the camera
2. Directly switch the mode button to MD, which means PIR motion
detection. The Max stand by time could be 24 months to catch
any motion.
MD
PIR
Audio(on/off)
Reset

Detection ability
Important Notice:
- While using the camera, it should be placed in a perpendicular
direction to those objective people passing by
- Avoid using the camera in hot or extreme temperatures that
will lower down motion-detection accuracy
- Once it is switch to MD (PIR MOTION DETECTION MODE),
upon each trigger, there will be about 2 seconds delay to start
video record. Thus, please avoid to use it in somewhere people
passing quickly.
PIR angle 60 degrees
Camera angle 75 degrees
Motion detection distance:5-8 meters
5
Detection angle
60
5-8 meters
Camera angle
75

Charging information
It is suggested to charge it by a 2A USB power adaptor,with the
USB cable in package.
-Once it is low battery, it could not be power on at all, or the red
and blue will flash for 10 seconds and power off
-During charging please put the power switch to "off". And the
yellow indicator stays on during charging, and it goes off once
full charged
6

How to insert and take out Micro-SD card
Important notice:
- The camera has the ability to record video only when
Micro-SD is inserted.
- Please avoid by all means to insert or remove Micro-SD
when the camera is either powered ON or connected to the
computer. This can possibly cause damage to Micro-SD or
the entire camera.
- Please ensure that minimal effort is applied to the Micro-SD
when inserting it in or out of the camera. Use of force can
easily damage the Micro-SD or the product parts.
- Before using the product for the first time, ensure that the
Micro-SD is formatted. Please check for any saved data in
the Micro-SD to avoid unexpected loss.
We are not liable or responsible for malfunctions that result
from failure to follow the above guidelines.
Take Micro-SD outInsert Micro-SD card
7

First, user don't have to set time/date unless it is necessary.
Please follow the bellowing to set time/date
Step 1: Power off the camera, and connect it with PC by the
USB cable in the package. Switch the button to REC, after a
dozen of seconds, there will be a disk to open. Then please
open YW_TIME.txt.
Time and date setting
8
YW_TIME. txt
file Edit F ormat View Help
File name
yyyy/mm/dd 2015/03/23
23:15:12
yes
YW_TIME. txt
Step 2:Please change the numbers/letters
Step3: Disconnect it from PC and power on it. The time settings is
done and you will find time&date watermark in the video recordings.
hh:mm:ss
yes:auto-recycle the SD
no:no auto-recycling
[date]

Detailed parameters
9
ParameterItem
size 21*15*4CM
Product net weight 415g
Battery
Stand-by power consumption 10uA
PIR detection angle 60 degrees
PIR detection distance 5-8 meters
Camera angle about 75 degrees
Max PIR stand-by time 2 years
Day time recording power consumption 220mA
Max day time recoridng time a b out 30 hours
Night vision recording power consumption 820mA
Max night vision continuously recording time 9-10 hours
a b out 20 hours by 2A USB power
Full-Charging time adaptor
Resolution 1 0 8 0 P
FPS 30FPS
PIR MD video record about 1 minute per file
Record continuously about 2 minutes per file
Max SD storage 32GB
Loop recording optional
LiPo

Indicator status and meanings
IMPORTANT REMINDINGS: PLS DON'T PUT SD OUT DURING RECORDING
OR IT COULD POSSIBLY CAUSE DAMAGE TO SD. WHEN THE BATTERY IS
RUNNING OUT, IT WILL SAVE THE LAST FILE AND POWER OFF
Switch to REC
Switch to MD
NO SD
Low battery
SD full(if it is not auto-recycling)
Charging the camera
Full charged
Connect with PC as a U-disk
When connect with PC and
power on the camera to either
REC or MD
The blue flash 3 times and goes off,
it will record continuously by 2
minutes video each
The red and blue flash once, then
the red flash 3 times and goes off
The red or blue will flash for 10
seconds and it powers off
The red and blue will flash for 10
seconds and it powers off。
Or sometimes battery is totally
running out, it could not power on
at all.
The red and blue will flash for 10
seconds and it powers off
The yellow stays on(Suggested to
put the switcher to OFF when
charging)
The yellow be off
The yellow will stay and the
blue&red will flash
10
Motion detected
The red&blue flash once and red
will flash 3 times and goes off. It
will save to SD for about each 1
minute video
