brielmaier S250 User manual

Translation of the original instructions
Motor mower S250
Before starting work, read these instructions!
Version 2021/09
Article number: 105863
Brielmaier Motormäher GmbH
Zeppelinstraße 1
D-88693 Deggenhausertal
Ein Unternehmen der Gruppe
Telephone: [phone]
Fax: [phone]
[email protected]
https://www.brielmaier.com

2 BA Motor mower S250 (Version 2021/09)

Brielmaier Motormäher GmbH
BA Motor mower S250 (Version 2021/09) 3
Foreword
These instructions enable the safe and efficient use of the motor mower
(hereinafter referred to as "machine"). The instructions are part of the
machine and must be stored in a place accessible to the user where the
machine is stored.
The user must have carefully read through and understood these
instructions before beginning any work. The basic prerequisite for working
safely is compliance with all specified safety notices and instructions in
these operating instructions. Furthermore, the local accident prevention
regulations and general safety regulations for the range of application of
the machine also apply.
Figures in these instructions are intended to aid general understanding and
may differ from the actual design.
Any other kinds of use shall be deemed not in accordance with the
specified use. Brielmaier Motormäher GmbH (hereinafter referred to as the
"manufacturer") cannot be held liable for any damage resulting from such
use. The risk in such cases shall be borne solely by the user.
These instructions are protected by copyright.
Except for internal purposes, the handing of these instructions to third
parties, their duplication of any kind, even of excerpts, and the use and/or
communication of the contents are not permitted without the written
consent of the manufacturer. In the event of any infringement, the user
will be liable to pay compensation for damages. The manufacturer reserves
the right to assert additional claims.
The manufacturer holds the copyright.
© Brielmaier Motormäher GmbH
Zeppelinstraße 1
88693 Deggenhausertal
Germany
https://www.brielmaier.com

Table of contents Brielmaier Motormäher GmbH
4 BA Motor mower S250 (Version 2021/09)
Table of contents
1 Motor mower Brielmaier............................................................................................................................. 6
1.1 Description ................................................................................................................................................................................... 6
1.2 Overview ...................................................................................................................................................................................... 7
1.3 Designation/type plate................................................................................................................................................................ 8
1.4 Machine elements ....................................................................................................................................................................... 9
1.4.1 Basic configuration........................................................................................................................................................ 9
1.4.2 Options........................................................................................................................................................................... 12
1.5 Description of the controls.......................................................................................................................................................... 17
1.5.1 Basic configuration........................................................................................................................................................ 17
1.6 Scope of delivery ......................................................................................................................................................................... 20
2 Safety............................................................................................................................................................ 21
2.1 Structure of the warnings/symbols in these instructions .......................................................................................................... 21
2.2 Intended use ................................................................................................................................................................................ 22
2.3 Foreseeable misuse...................................................................................................................................................................... 23
2.4 Fundamental dangers ................................................................................................................................................................. 23
2.5 Working zones and danger zones.............................................................................................................................................. 26
2.6 Safety equipment ........................................................................................................................................................................ 29
2.7 User requirements ....................................................................................................................................................................... 30
2.8 Responsibility of the owner ........................................................................................................................................................ 31
2.9 Personal protective equipment .................................................................................................................................................. 32
2.10 Signage......................................................................................................................................................................................... 33
2.11 Environmental protection........................................................................................................................................................... 34
3 Transport and storage ................................................................................................................................. 35
3.1 Safety during transport............................................................................................................................................................... 35
3.2 Load securing............................................................................................................................................................................... 36
3.3 Lifting and loading the machine using a crane......................................................................................................................... 36
3.4 Loading the machine using drive-on ramps............................................................................................................................... 37
3.5 Activating emergency operation/recovery................................................................................................................................. 38
3.6 Storing the machine .................................................................................................................................................................... 39
4 Start-up......................................................................................................................................................... 40
4.1 Safety during start-up ................................................................................................................................................................. 40
4.2 Checking and adding operating materials................................................................................................................................. 41
4.2.1 General........................................................................................................................................................................... 41
4.2.2 Adding petrol................................................................................................................................................................. 42
4.2.3 Checking and topping up engine oil............................................................................................................................ 43
4.2.4 Checking and topping up hydraulic oil........................................................................................................................ 44
4.3 Adjusting the handlebars............................................................................................................................................................ 46
4.4 Connecting/disconnecting the attachment................................................................................................................................ 47
4.5 Fitting/removing tyres ................................................................................................................................................................. 50
5 Operating the machine................................................................................................................................ 54
5.1 Safety during operation.............................................................................................................................................................. 54
5.2 Checks before operation............................................................................................................................................................. 54
5.3 Parking the machine safely without attachments..................................................................................................................... 55
5.4 Menu settings .............................................................................................................................................................................. 56
5.4.1 Possible settings............................................................................................................................................................. 56
5.4.2 Operation....................................................................................................................................................................... 56
5.4.3 Adjusting the attachment drive.................................................................................................................................... 57
5.5 Starting the engine ..................................................................................................................................................................... 58
5.6 Switching off the engine ............................................................................................................................................................ 59
5.7 Emergency stop ........................................................................................................................................................................... 60
5.8 Driving.......................................................................................................................................................................................... 61
5.8.1 Driving the machine ...................................................................................................................................................... 62
5.8.2 Steering .......................................................................................................................................................................... 62
5.8.3 Trim ................................................................................................................................................................................ 63
5.8.4 Adjusting the speed....................................................................................................................................................... 64
5.8.5 Loading the fine adjustment ........................................................................................................................................ 64

Brielmaier Motormäher GmbH Table of contents
BA Motor mower S250 (Version 2021/09) 5
5.8.6 Switching the direction of travel.................................................................................................................................. 65
5.9 Using attachments....................................................................................................................................................................... 65
5.10 Limit load control ........................................................................................................................................................................ 67
5.11 Use the running board ................................................................................................................................................................ 68
6 Operation with radio remote control (optional) ....................................................................................... 69
6.1 Safety during operation.............................................................................................................................................................. 69
6.2 Note about software versions..................................................................................................................................................... 69
6.3 Danger zone ................................................................................................................................................................................ 69
6.4 Overview ...................................................................................................................................................................................... 70
6.5 Safety functions ........................................................................................................................................................................... 72
6.5.1 Overview ........................................................................................................................................................................ 72
6.5.2 Switching the machine on again after a safety function has been triggered ........................................................... 72
6.6 Operation..................................................................................................................................................................................... 72
6.6.1 Switching the radio remote control on........................................................................................................................ 72
6.6.2 Starting the engine........................................................................................................................................................ 73
6.6.3 Driving and steering...................................................................................................................................................... 74
6.6.4 Finely adjusting the speed ............................................................................................................................................ 75
6.6.5 Attachments................................................................................................................................................................... 75
6.6.6 Switching off the remote control................................................................................................................................. 76
7 Maintenance................................................................................................................................................. 77
7.1 Safety during maintenance work ............................................................................................................................................... 77
7.2 Notes on the maintenance plan ................................................................................................................................................. 78
7.3 Maintenance plan........................................................................................................................................................................ 79
7.4 Spare parts ................................................................................................................................................................................... 80
7.5 Maintenance work ...................................................................................................................................................................... 80
7.5.1 Tyres ............................................................................................................................................................................... 80
7.5.2 Clean the hydraulic oil cooler ....................................................................................................................................... 80
7.5.3 Cleaning the engine air filter........................................................................................................................................ 81
7.5.4 Cleaning the intake manifold and engine oil cooler .................................................................................................. 82
7.5.5 Greasing the lubrication points .................................................................................................................................... 82
7.5.6 Maintaining the battery................................................................................................................................................ 83
7.5.7 Changing the engine oil and the engine oil filter....................................................................................................... 87
7.5.8 Replace the hydraulic oil filter...................................................................................................................................... 89
7.5.9 Bleeding the hydraulic oil cooler.................................................................................................................................. 90
7.5.10 Setting parameters ........................................................................................................................................................ 90
7.5.11 Change fuses.................................................................................................................................................................. 93
7.6 After completing the maintenance work .................................................................................................................................. 94
8 Troubleshooting........................................................................................................................................... 95
8.1 Safety during troubleshooting ................................................................................................................................................... 95
8.2 Faults during operation .............................................................................................................................................................. 95
8.3 Fault table .................................................................................................................................................................................... 96
8.4 Electronics troubleshooting ........................................................................................................................................................ 98
8.5 After completing the troubleshooting work............................................................................................................................. 98
9 Removal and disposal.................................................................................................................................. 99
9.1 Safety during removal and disposal ........................................................................................................................................... 99
9.2 Removal work .............................................................................................................................................................................. 99
9.3 Disposal ........................................................................................................................................................................................ 100
10 Technical data ..............................................................................................................................................101
10.1 Specifications ............................................................................................................................................................................... 101
10.2 Emissions ...................................................................................................................................................................................... 103
10.2.1 Vibration measurements............................................................................................................................................... 103
10.2.2 Noise emission................................................................................................................................................................ 104
11 Annex............................................................................................................................................................105
11.1 Hydraulic diagram ....................................................................................................................................................................... 105
11.2 Electrical circuit diagram............................................................................................................................................................. 106
11.3 Declaration of Conformity .......................................................................................................................................................... 107
Index .............................................................................................................................................................108

1 | Motor mower Brielmaier Brielmaier Motormäher GmbH
6 BA Motor mower S250 (Version 2021/09)
1 Motor mower Brielmaier
1.1 Description
Motor mower description The machine is a single-axle attachment carrier for use on steep and flat
terrain.
A 4-stroke petrol engine drives a triple gear pump, which supplies oil
engines for the wheel and mower drive using valve technology.
Each wheel is individually driven by its own hydraulic engine.
Available attachments Various attachments can be fitted to the machine and driven via the
hydraulic connections, e.g.
– Mowing units
– Mulcher
– Rake tedder/rakes
– Snow blowers, snowplough blade
– etc.
All attachments are fitted with a quick-change system.
NOTE
For information on the attachments, refer to the instructions of the
respective attachments.

Brielmaier Motormäher GmbH Motor mower Brielmaier | 1
BA Motor mower S250 (Version 2021/09) 7
1.2 Overview
1
23 4 5 6 7
8
9
10
11
12
13
14
15
1 Tyres 9 Control panel
2 Exhaust guard 10 Oil mist separator
3 Hydraulic block 11 Engine cooling intake
manifold
4 Radio antenna with receiver
(optional for radio remote
control)
12 Combustion engine
5 Battery compartment 13 Rod trunnion
6 Toolbox 14 Hydraulic oil cooler
7 Fuel tank 15 Hydraulic oil expansion tank
8 Steering bar

1 | Motor mower Brielmaier Brielmaier Motormäher GmbH
8 BA Motor mower S250 (Version 2021/09)
1.3 Designation/type plate
Attachment point The type plate is located on the left side of the battery compartment.
Zeppelinstr. 1
D-88693 Deggenhausertal
244
108.00001.xx
Information The type plate contains the following information:
– Manufacturer
– Address
– Device designation
– Serial number
– Type
– Dimensions
– Year of manufacture
NOTE
When ordering spare parts or making other enquiries regarding the
machine, please specify the device designation, type and serial number.

Brielmaier Motormäher GmbH Motor mower Brielmaier | 1
BA Motor mower S250 (Version 2021/09) 9
1.4 Machine elements
1.4.1 Basic configuration
Transport lugs
2
1
The transport lug on the handlebar mounting (1) and the transport lug on
the rod trunnion (2) are used to hold the machine securely in place for
transport.
Rod trunnion
The attachment is coupled and uncoupled at the rod trunnion of the
machine by a quick-release coupling.
Hydraulic block
1
The hydraulic actuators are installed in the hydraulic block.
The hydraulic block includes the proportional pressure control valve "PCV"
(1). It has been fitted as standard since 2019 and enables a soft start as well
as the oil pressure on the attachment to be adjusted.

1 | Motor mower Brielmaier Brielmaier Motormäher GmbH
10 BA Motor mower S250 (Version 2021/09)
Hydraulic oil expansion
tank
The hydraulic oil heats up and expands during operation. The larger
volume is absorbed by the hydraulic oil expansion tank.
NOTICE
Damage to equipment if hydraulic oil is filled in incorrectly.
Filling hydraulic oil into the hydraulic oil expansion tank may cause
damage to equipment.
4Never fill hydraulic oil directly into the hydraulic oil expansion tank.
Steering bar
The control panel and grips are located at the top of the steering bar. The
steering bar can be placed in different positions and individually adapted
to the operator:
– Vertical inclination
– by 200 mm in length
– Upper part of handlebars - bar angle
Combustion engine
The machine is powered by a petrol engine and started by an electric
starter.
Fuel tank
The fuel is filled into the fuel tank:
Super 95E5 (ROZ95)
For filling quantity and specifications, see chapter Technical data [}101].

Brielmaier Motormäher GmbH Motor mower Brielmaier | 1
BA Motor mower S250 (Version 2021/09) 11
Air filter housing
The air filter is located in the air filter housing. The air filter prevents dust
particles from entering the engine.
For cleaning instructions, see chapter Cleaning the intake manifold and
engine oil cooler [}82].
Oil mist separator
The oil mist separator collects the oil droplets captured when the
crankshaft is ventilated and returns the oil to the engine. The air
containing exhaust gases is mixed with the combustion air via the air filter
housing.
Toolbox
1
2
The toolbox (1) contains a tool bag (2) with a selection of the required
tools, the connection plug for charging the battery, the diagnostics
connector, the connections for the radio remote control and electrical
fuses.
Battery
The battery is located in the battery compartment below the toolbox.

1 | Motor mower Brielmaier Brielmaier Motormäher GmbH
12 BA Motor mower S250 (Version 2021/09)
Parking support
In order to park the machine safely without an attachment, it is equipped
with a parking support. The parking support can be folded up and down.
NOTICE
Risk of overloading the support foot!
If the support foot is overloaded by lashing, there is a risk of damage to
equipment.
4Do not use the parking support to lash the machine on a loading area.
1.4.2 Options
Tyres Different tyre variants are available depending on the location and
deployment of the machine.
For variants, dimensions, and weights refer to chapter Technical data
[}101].
Spiked rollers
Pneumatic tyres
Terra tyres

Brielmaier Motormäher GmbH Motor mower Brielmaier | 1
BA Motor mower S250 (Version 2021/09) 13
Spacer for twin tyres
Quick-change system for
dual tyres
Different quick-change system models are available for dual tyres.

1 | Motor mower Brielmaier Brielmaier Motormäher GmbH
14 BA Motor mower S250 (Version 2021/09)
Work lights
Two work lights can be mounted as a unit on the upper part of the
handlebars.
The work lights are mounted on a magnetic plate. This can be removed
without tools if the lighting is not required. The headlights are connected
via a plug-in contact.
Running board
To ride on the machine, the running board option can be installed below
the handlebars.
The running board is foldable and can also be folded up while driving with
your foot. It does not have to be disassembled to run behind the machine.
Radio remote control
All important functions of the machine and attachments can be controlled
from a distance of up to 100 metres using the radio remote control. If the
radio remote control features a display, the machine's status data is
presented.
NOTE
For more detailed information on the radio remote control, see chapter
Operation with radio remote control (optional) [}69].
Support wheel
The support wheel prevents the machine from tipping backwards when
using the radio remote control. Combination with the folding running
board option is possible.

Brielmaier Motormäher GmbH Motor mower Brielmaier | 1
BA Motor mower S250 (Version 2021/09) 15
Handle guard
To protect the hands, an optional handle guard can be mounted on the left
and right of the handles. The handle guard can also be retrofitted on older
machine types.
Fuel pump protective cover
Optionally, a protective cover can be mounted over the fuel pump. This
protects the pump and sensitive components such as cables, connectors and
hoses from mechanical damage.
Intake manifold-
extension
Optionally, an extension piece can be mounted between the intake
manifold on the engine and the air intake grille without tools. Due to the
raised position, the intake grille gets less contaminated.
Underride guard
An underride guard can be fitted as an option to protect against damage
from below. The underride guard can also be retrofitted on older machine
types.

1 | Motor mower Brielmaier Brielmaier Motormäher GmbH
16 BA Motor mower S250 (Version 2021/09)
Intermediate plate for the
catch tray offset
1
2
When using spiked rollers with a large diameter, the quick-release coupling
(1) on the attachment must be moved up. When using an extended
mowing unit frame, the quick-release coupling on the attachment must be
moved down. An intermediate plate (2), which is available as an option, is
required for both mounting methods.
Proportional control valves
The standard proportional pressure control valve (PCV) is the right fitting
for most applications.
The proportional pressure control valve (PCV) should only be exchanged for
the proportional flow control valve (FCV) after consulting the
manufacturer/specialist dealer if:
– the speed should be adjustable on the attachment.
– the oil volume of the motor mower (approx. 32 litres/min at 3600 rpm)
is too large for the attachment.
Both proportional control valves allow a soft start of the attachment.
NOTE
We do not recommend a proportional flow valve for attachments
designed for other oil flow rates. Instead, we recommend replacing the
oil engine in the attachment.

Brielmaier Motormäher GmbH Motor mower Brielmaier | 1
BA Motor mower S250 (Version 2021/09) 17
1.5 Description of the controls
1.5.1 Basic configuration
Battery disconnector
The battery disconnector is used to disconnect the earth connection
between the battery and machine. To start up the machine, the battery
disconnect key must be inserted and turned 90°.
– Only operate the battery disconnector when the engine is switched off.
– Make sure that the battery disconnector is turned on to charge the
battery.
– If the machine is parked for a long time without charging, switch off
the battery disconnector.
Handles (left and right) The handles are attached to the left and right of the steering bar. Various
controls are located on the handles:
1234567
8
9
10
1 "Speed level -" button 6 "Menu" button
2 "Change driving direction"
button
7 "+" button
3 "Speed level +" button 8 Steering twist handle
4 Dead man's lever 9 Accelerator lever
5 "-" button 10 Clutch/brake lever

1 | Motor mower Brielmaier Brielmaier Motormäher GmbH
18 BA Motor mower S250 (Version 2021/09)
Control panel
The control panel is located between the handles within the operator's
field of view. The control panel has various displays and buttons:
1 2 3 4 56789
10
11
12
13
14
15
16
17
18
Menu lights
1 Engine speed 5 Fault indication / km/h
2 Trim 6 Temperature/voltage
3 Oil pressure of the attachment
drive (standard)
7 Operating hours
4 Oil quantity of the attachment
drive (optional)
Warning lights
8 Tool spanner 11 Fault
9 Hydraulic oil temperature too
high
12 Dead man's lever status
10 Engine oil level 13 Charge control/battery voltage
Buttons
14 "Attachment ON/OFF" button 16 "Engine ON/OFF" button
15 "Headlights ON/OFF" button
Additional displays and controls
17 Display 18 Key

Brielmaier Motormäher GmbH Motor mower Brielmaier | 1
BA Motor mower S250 (Version 2021/09) 19
Display (control panel)
A
B
C
1 2 345
1 Direction of travel
2 Speed level
3 Attachment type
4 Clutch/fine adjustment
5 Attachment status
The following display contents are presented here as examples:
A (1) Forward direction of travel
(2) Speed level "0"
(3) AddOn-Box attachment
(4) Clutch not actuated
(5) Attachment active (quick start/pressure limit)
B (1) Reverse direction of travel
(2) Speed level "1"
(3) Rake tedder attachment
(4) Clutch lightly applied (flashes quickly)
(5) Active attachment (soft start/maximum pressure), e.g. mulcher
C (1) Reverse direction of travel
(2) Speed level "3"
(3) Radio antenna
(4) Fine adjustment active (flashes slowly)
(5) Active attachment (soft start/maximum pressure), e.g. mulcher

1 | Motor mower Brielmaier Brielmaier Motormäher GmbH
20 BA Motor mower S250 (Version 2021/09)
Quick-release lever
Rod trunnion
The quick-release lever on the rod trunnion makes connecting and discon-
necting the attachment easy.
When the attachment is fitted, the spring pin must be inserted to secure it.
Quick-release lever
Handlebar position
1
2
3
The handlebars have three clamping levers for adjusting the height and
length of the handlebars position and the angle of the upper part / control
panel (see also chapter Adjusting the handlebars [}46]).
1.6 Scope of delivery
The following components are included in the scope of delivery:
1 Basic unit (single-axle attachment carrier)
1 Tool kit
1 Battery charger
1 Operating instructions
1 Warranty certificate
1 Handover document
