Brinno MAC200 DN User manual

1
Motion Activated
Camera
User Manual
www.brinno.com
MAC200 DN

Register@online
http://www.brinno.com/support/register.html
contact us: [e-mail]
more information: www.brinno.com

WEL COME
BRINNO
FA MI LY !
TO
THE
Follow Brinno to receive the
latest product news
facebook.com/BrinnoInc

Thank you for purchasing this
Brinno Motion Activated Camera!
The Brinno Motion Activated Camera (MAC200 DN) is
a battery powered, motion activated security camera.
Forget the power cord, Ethernet line or DVR system, it is
your 100% DIY, 100% Wire-free, 100% portable security
anywhere anytime camera. Brinno’s new Hybrid Mode®
provides 10 X’s the Outlook Range over comparable
motion activated cameras.
The dual functionality of a fixed capture interval + Motion
Activation provides you with an unprecedented portable
level of protection. Brinno’s exceptional power saving
technology, provides super long lasting standby time,
combined with our “Rapid Wake Up” functionality, means
you will never miss a shot!

Motion Activated Camera Features
Parts of the Camera
Display Icons
LED indicator
Installation
Initial Set Up
Capture Mode
Motion Activated Mode
Time Lapse Mode
Hybrid Mode
Start Recording
Motion Activated Mode
Time Lapse Mode & Hybrid Mode
To Stop Recording
Basic Installation
01
03
05
07
08
09
12
17
14
18
15
19
20
Contents

MENU Setting
SD card capacity
Capture Mode
Overwrite
Timer
Playback Rate
Image Quality
Time Stamp
LED Display
Band Filter
Night Vision Mode
Set Latitude
Set Date and Time
FW version
Reset
Default Setting
What Size SD Card Should I Use
Battery Life
Specification
24
25
26
27
30
31
33
34
35
36
39
37
41
40
42
43
44
45

MAC200 DN
01
14 Months Battery Life
< 1 Sec. Rapid Wake Up
The Brinno MAC200 DN needs only 2D batteries for up to fourteen
months of power. No need for external power = truly portable.
All Brinno products have excellent power saving technology,
providing super long standby time. Combined with our “Rapid
Wake Up” technology, Brinno ensures you will never miss a shot!
10x Outlook Range
Motion Activation Mode provides coverage up to 6 meters.
Time Lapse Mode provides over 100 meters of coverage. Images
captured at a Fixed Capture Rate in the Time Lapse mode cover over
10 times the area of a standard Motion Activated Camera.
Dual Protection
Brinno’ new Hybrid Mode® provides the dual functionality of a fixed
capture interval + flexible Motion Activation, providing you with an
unprecedented level of portable protection.
Motion Activated Camera Features
2x2x

MAC200 DN 02
100% DIY
The Brinno MAC200 DN is a battery powered, motion activated
security camera. Forget the power cord, Ethernet line or DVR
system, it is your 100% DIY, 100% Wire-free, 100% portable security,
anywhere, anytime.
Output le format
Fast Playback Time Lapse Video, AVI format, resolution is 720P (1280x720).
Instant Video/ Fast Playback
The Brinno MAC200 DN captures and converts thousands of photos
into a Time Lapse video inside the camera. Review your daily activity
with the push of a button.
Package Contents
1. Motion Activated
Camera x 1
2. Tree strap x 1
3. Rubber strap x 1
4. Wall Mount x 1
5. User Manual x 1
123
45

MAC200 DN
03
1. Lens
2. Motion Sensor
3. LED Indicator
4. Operation Control Zone Latch
5. Operation Control Zone Cover
6. Battery Cover
7. Tree Strap Hole
8. Locking Hole
9. External Power Port
(DC IN 5V)
4
2
3
1
6
5
7
8
9
Front Back
Parts of the Camera

MAC200 DN 04
10. SD Card Slot
11. Micro USB port
12. LCD Panel
13. TIME / Next ( ) button
14. MENU / Previous ( ) button
15. OK button
16. Power Switch
11
10
12
1314 15
16
Inside Operation Control Zone

MAC200 DN
05
1. Capture mode:
•Motion mode
•Time Lapse
• Hybrid
2. Capture Interval/ Capture Rate:
Displayed in Time Lapse Mode/
Hybrid Mode
3. System date and time
Icon
(green)
(green)
(yellow)
(red)
Description
Battery full charged.
Battery partially charged.
Low battery-Replace as
soon as possible.
Out of battery-Replace
battery immediately.
4. Battery level
5
6
READY
M
9
8
7
4
Set Up screen Preview Screen
T.Lapse
20 Sec
2013/03/01
22:58:32
OK
1
2
3
At Set Up screen
Display Icons
10

MAC200 DN 06
5. Capture Mode:
•M (Motion mode)
•T (Time Lapse mode)
•H (Hybrid mode)
6. Preview Screen
7. Timer
8. Night Vision Mode
(ON /OFF /AUTO )
9. Overwrite
10. Battery Level
11. Battery Empty
Please replace battery immediately.
12. SD Card Full
Please download files to clear
SD card space.
13. SD Card Error
Please replace SD card.
14. Connected to computer via micro
USB camera.
BATTERY
EMPTY
11
FULL
SD
12
ERROR
SD
13 14
At Preview screen
A

MAC200 DN
07
Green light :
•Indicates image capture in process.
Red light :
•Low battery.
•Low recording memory on your SD card.
Orange light :
•PIR sensor is warming up.
LED color
LED indicator

MAC200 DN 08
Installation

MAC200 DN
09
We support up to 32GB SD cards. And we recommend you use
the maximum SD card to save your les.
Installing SD Card
Insert the SD card.
Initial Step-2
Installing the Batteries
Open battery door, insert 2 D
batteries and close battery door.
Initial Step-1
Initial Set Up

MAC200 DN 10
720P
OK
3
1. To turn on the camera as a Motion Activated Camera,
press to go to MENU setting, select Set Date &
Time, and press .
2. The number with the red background is the number
you are setting. Press for a lower number or
for a higher number. Press : Next to conrm
and go to the next number.
3. When nished press to exit and return to the Set
Up Screen.
4. ST: Standard Time
DT: Daylight Saving Time
2014/08/11
ST 23:59:35
2014/08/11
ST 23:59:35
OK :NEXT
Date & Time Date & Time
2
Initial Step-3
MENU 12/14
Set Date
& Time
1
OK

MAC200 DN
11
How Our Power Saving Technology Works
At Set Up Screen
After 10 seconds without activity on the set up screen, the
camera will go to preview screen automatically. You can press
or to go back to the set up screen.
At Preview Screen
After 60 seconds without activity on the set up or preview
screens, the LCD screen will turn off automatically to save
power. You can press to wake up.
Ready
60 sec
At Set Up Screen At Preview Screen
Motion
2Sec
OK
2011/ 06/ 30
23:56:39

MAC200 DN 12
Motion Activated Mode
Images captured by Motion Activation are in what
we consider the Hot Zone meaning close to the
device. Motion Activation captures direct threats
up close.
6m ( 20 ft )
Capture Rate Captures 2-3 frames per second.
Clip Length Once activated captures for
5 seconds.
Motion Sensor
Detecting Area
Detecting Angle: 100°
Detecting Distance: 6M
Motion Activated
Mode Capture Mode

MAC200 DN
13
Once activated the Motion Activated Camera will
capture for 5 seconds, during this period if the Motion
Sensor is activated again, it will extend the capture time for
5 more seconds. When the motion ceases and the Motion
Activated Camera nishes capturing, all the frames will be
stored into one AVI le.
Motion Sensor Activated
Capture for 5 seconds
Motion Sensor Activated
Capture for 5 seconds
Motion Sensor Activated
Capture for 5 seconds
No Activities,
capture nished.
Motion Activated
Mode
Capture Mode
