BRIO RS2283VC User manual

Vacuum Cleaner Instruction Manual
Model RS2283VC
(Insert product image here)
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
TECHNICAL INFORMATION
Please make sure that your house installation voltage corresponds to
the voltage marked on the unit.
Mains supply: 220-240V ~ 50 Hz – AC only
Rated Power: 1200 Watts
1.

BEFORE FIRST USE
•Your vacuum cleaner has been packaged carefully to ensure the
product reaches you in good condition. If the product has been
damaged, dropped, has a malfunction in any way, or if the supply
cord is damaged, immediately contact your retailer for replacement
or repair.
•Carefully unpack your vacuum cleaner. Make sure you do not
discard any packaging material until all parts of the vacuum cleaner
have been found.
•Carefully wipe the exterior of the cleaner to remove any dust that
may have accumulated. Dry with a dry towel. Do not use harsh
abrasive cleaners. Remove any label or sticker.
WARNING! Do not immerse in water or any other liquids.
OPERATION
•Carry the vacuum cleaner to the area to be vacuumed.
•Fit the hose, extending tubes and floor tool to the vacuum cleaner.
Ensure that the vacuum dust bag is correctly fitted. WARNING!
Never use without the dust bag and main cloth filter fitted. Note. The
dust compartment door will not close without a dust bag correctly
fitted.
•Extend or retract the brush on the main floor tool as required for the
type of floor to be vacuumed. Extend brush for hard floors such as
tiles or wood and retract for rugs and carpet.
•Pull out the required amount of power cord from the vacuum
cleaner. WARNING! Do not uncoil past the yellow marker on the
power cord, as this is a warning that the power cord is close to its
full length. If the red indicator on the power cord is visible, retract
back to the yellow indicator. Damage to the recoiling mechanism
can result if this warning is ignored and will void warranty.
•Insert the power plug into a mains outlet corresponding with the
vacuum cleaner requirements of 220 – 240V ~ 50 Hz - AC only.
•Switch on power at the mains outlet.
•Set the suction control to the desired power level of the vacuum
cleaner.
•Depress the on/off switch to start or stop the vacuum cleaner. The
cleaner will now start to suction.
2.
•The vacuum cleaner has a manual air flow regulator attached to the
hose handle. This is used to briefly lower the suction level during
operation; the further open the regulator the weaker the suction
power.
•Regularly change the dust bag and ensure the main filter is clean.
When completed disconnect vacuum from the mains supply, retract cord
and empty dust bowl. Store vacuum cleaner along with all it
accessories.
DUST BAG REPLACEMENT
This vacuum cleaner uses model CS018VB dust bag, barcode number
9421009508068 vacuum dust bag available at The Warehouse LTD
nationwide.
CARE AND CLEANING
To clean the outer surface of the vacuum cleaner, use a soft damp cloth
and dry the appliance afterwards with a dry towel. Ensure that no
moisture enters the appliance. Stubborn spots can be cleaned with a
cloth moistened with mild liquid detergent. Do not use solvents to clean
plastic parts. Liquids such as solvents, petrol and oils that contain
chemical substances may damage, corrode or destroy the plastic parts
of the appliance.
Do not put any detergents or any cleaning agents into the vacuum
cleaner.
Clean only after unplugging the vacuum cleaner from the mains supply.
Keep the ventilation slots on the vacuum cleaner clean to prevent the
appliance from overheating.
Regularly clean the air exit filter (Located at rear of vacuum cleaner
behind the rear exhaust filter). Clean by hand in warm soapy water. Air
dry any filter before reinstalling. Do not use a hair dryer or similar
appliance to dry the filters.
Do not expose the vacuum cleaner to direct sunlight as the quality of the
vacuum cleaner finish may deteriorate.
3.

STORAGE: Unplug vacuum cleaner from the mains outlet. Retract the
power cord into the vacuum cleaner by depressing the cord rewind
button with one hand. WARNING! Feed the power cord into the
appliance with the other hand; do not allow the power cord to free wheel
at high speed and stop suddenly when the plug enters the appliance.
Store in its box or in a dry place with all of its accessories.
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed including the following:
1. Carefully read these instructions before using your appliance.
2. VERY IMPORTANT: Do not immerse in water or other liquids or
use near washbasins or sinks. Ensure that the appliance does
not get wet (water splashes etc.) and do not use it with wet
hands.
3. Safely dispose of plastic bags and other components of the
packaging. They may be potentially dangerous to children.
4. WARNING! Unplug from mains outlet when appliance is not in
use or cleaning.
5. An appliance dropped or damaged should not be used until
examined by a service engineer.
6. Do not permit the mains lead to come in contact with hot
objects.
7. If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person
in order to avoid a hazard.
8. CAUTION: Keep out of reach of children. This vacuum cleaner
is not intended for use by young children or infirm persons.
Young children must be supervised to ensure that they do not
play with the vacuum cleaner.
9. Use this appliance only for its intended use. Use only genuine
attachments supplied by an authorised Service Dealer.
10. This vacuum cleaner is intended for household use only and not
for commercial or industrial use.
11. The vacuum cleaner should not be used outdoors, or placed
near a hot gas or electrical burner.
4.
12. WARNING! Any appliance should never be left unattended
when plugged in.
13. If appliance is to be used by a third party, please supply the
instruction manual with it.
14. No liability can be accepted for any damage caused by non-
compliance with these instructions or any other improper use or
mishandling.
CAUTION
Do not attempt to service this appliance yourself. Refer servicing to
qualified service personnel.
5.

Guarantee Card
This product is guaranteed against faulty materials and workmanship for
a period of 12 months from the date of purchase. The obligation to the
purchaser under this warranty is limited to servicing the unit and
replacing defective parts when the product is returned freight prepaid to
the retailer. This warranty becomes void if the product has been
tampered with, damaged by accident, damaged in any other way by
improper use or has been purchased second hand. All production
orders have quality inspections. In the unlikely event of a deficiency,
please contact the retailer from whom this product was purchased.
WARRANTY FOR APPLIANCES USED COMMERCIALLY LIMITED TO 90 DAYS
Type of Appliance: 1200W Vacuum Cleaner
Model No.: BR2283VC Purchase Date:________________
Product Purchased From: ____________________________________
Name: ___________________________________________________
Address: _________________________________________________
_________________________________________________________
Phone Number: _____________________________
IMPORTANT!
Please retain this warranty card along with your purchase receipt.
Please do not post to the retailer or importer. If service is required, both
of these documents are to be returned with the appliance to your
retailer, otherwise a fee may be charged.
