USER’S GUIDE
Digital
Cordless
Handset
BCL-D10

© 2007 Brother Industries, Ltd.

i
Brother numbers
IMPORTANT
For technical help, you must call the country where you bought the machine/cordless handset.
Calls must be made from within that country.
FAQs (frequently asked questions)
The Brother Solutions Center is our one-stop resource for all your Fax Machine/Multi-Function
Center needs. You can download the latest software documents and utilities, read FAQs and
troubleshooting tips, and learn how to get the most from your Brother product.
http://solutions.brother.com
For Customer Service
Service Center Locator (USA only)
For the location of a Brother authorized service center, call 1-800-284-4357.
Service Center Locations (Canada only)
For the location of a Brother authorized service center, call 1-877-BROTHER.
In USA: 1-800-284-4329 (voice)
1-901-379-1215 (fax)
1-800-284-3238 (TTY service for the hearing-impaired)
In Canada: 1-877-BROTHER (voice)
[phone] (fax)

ii
Ordering accessories and supplies
For best quality results use only genuine Brother accessories, which are available at most Brother
retailers. If you cannot find the accessory you need and you have a Visa, MasterCard, Discover,
or American Express credit card, you can order accessories directly from Brother. (In the USA,
you can visit us online for a complete selection of the Brother accessories and supplies that are
available for purchase.)
Note
In Canada, only Visa and MasterCard are accepted.
Compilation and Publication Notice
Under the supervision of Brother Industries Ltd., this manual has been compiled and published,
covering the latest product descriptions and specifications.
The contents of this manual and the specifications of this product are subject to change without
notice.
Brother reserves the right to make changes without notice in the specifications and materials
contained herein and shall not be responsible for any damages (including consequential) caused
by reliance on the materials presented, including but not limited to typographical and other errors
relating to the publication.
In USA: 1-877-552-MALL (6255)
1-800-947-1445 (fax)
http://www.brothermall.com
In Canada: 1-877-BROTHER
http://www.brother.ca
Description Item
Cordless Handset BCL-D10
Battery BCL-BT10
User’s Guide LS2932001 (English for USA and Canada)
LS2932002 (French for Canada)

iii
Brother®One Year Limited Warranty and Replacement Service
(USA only)
Who is covered:
This limited warranty (“warranty”) is given
only to the original end-use/retail purchaser
(referred to in this warranty as “Original
Purchaser”) of the accompanying product,
consumables and accessories (collectively
referred to in this warranty as “this
Product”).
If you purchased a product from someone
other than an authorized Brother reseller in
the United States or if the product was used
(including but not limited to floor models or
refurbished product), prior to your
purchase you are not the Original
Purchaser and the product that you
purchased is not covered by this warranty.
What is covered:
This Product includes a battery,
Except as otherwise provided herein,
Brother warrants that the Product and
battery will be free from defects in materials
and workmanship, when used under
normal conditions.
This warranty applies only to products
purchased and used in the United States.
For products purchased in, but used
outside, the United States, this warranty
covers only warranty service within the
United States (and does not include
shipping outside the United States).
What is the length of the Warranty Periods:
Product: one year from the original
purchase date.
Battery: 90 days from the original purchase
date or the rated life, whichever comes first.
What is NOT covered:
This warranty does not cover:
1 Physical damage or normal wear and tear
to this Product;
2 Damage caused by improper installation,
improper or abnormal use, misuse, neglect
or accident (including but not limited to
transporting this Product without the proper
preparation and/or packaging);
3 Damage caused by another device, power
surges or lightening;
4 Conditions beyond the control of Brother,
such as common carrier provided services,
and
5 Problems arising from other than defects in
materials or workmanship.
This limited warranty is VOID if this Product
has been altered or modified in any way
(including but not limited to attempted warranty
repair without authorization from Brother
and/or alteration/removal of the serial
number).
What to do if you think your Product is
eligible for warranty service:
Report your issue to our Customer Service
Hotline at 1-800-284-4329 Supply Brother
with a copy of your dated bill of sale showing
that this Product was purchased within the U.S
What Brother will ask you to do:
After contacting Brother you may be required
to deliver (by hand if you prefer) or send the
Product properly packaged, freight prepaid, to
the Brother Service Center together with a
photocopy of your bill of sale. You are
responsible for the cost of shipping,
packing product, and insurance (if you
desire). You are also responsible for loss
or damage to this Product in shipping.
What Brother will do:
If the problem reported concerning your
Product is covered by this warranty and if you
first reported the problem to Brother within the
applicable warranty period, Brother will repair
or replace the Product at no charge to you for
parts or labor. The decision as to whether to
repair or replace the Product is made by
Brother in its sole discretion. Brother reserves
the right to supply a refurbished or
remanufactured replacement Product and use
refurbished parts provided such replacement
products conform to the manufacturer’s
specifications for new product/parts. The
repaired or replacement Product will be
returned to you freight prepaid or made
available for you to pick up at the Brother
Service Center.

iv
If the Product is not covered by this warranty
(either stage), you will be charged for shipping
the Product back to you and charged for any
service and/or replacement parts/products at
Brother's then current published rates.
The foregoing are your sole (i.e., only) and
exclusive remedies under this warranty.
What happens when Brother elects to
replace your Product:
When a replacement Product is authorized by
Brother, and you have delivered the Product to
the Brother Service Center, the Brother
Service Center will provide you with a
replacement Product or Brother will send to
you a replacement Product with the
understanding that you will, after receipt of the
replacement Product, supply the required
proof of purchase information, together with
the Product that Brother agreed to replace.
You are then expected to pack the Product
that Brother agreed to replace in the package
from the replacement Product and return it to
Brother using the pre-paid freight bill supplied
by Brother in accordance with the instructions
provided by Brother. Since you will be in
possession of two Products, Brother will
require that you provide a valid major credit
card number. Brother will issue a hold against
the credit card account number that you
provide until Brother receives your original
Product and determine that your original
Product is entitled to warranty coverage. Your
credit card will be charged up to the cost of a
new Product only if: (i) you do not return your
original Product to Brother within five (5)
business days; (ii) the problems with your
original Product are not covered by the limited
warranty; (iii) the proper packaging
instructions are not followed and has caused
damage to the product; or (iv) the warranty
period on your original Product has expired or
has not been sufficiently validated with a copy
of the proof of purchase (bill of sale). The
replacement Product you receive (even if
refurbished or remanufactured) will be
covered by the balance of the limited warranty
period remaining on the original Product, plus
an additional thirty (30) days. You will keep the
replacement Product that is sent to you and
your original Product shall become the
property of Brother. Retain your original
Accessory Items and a copy of the return
freight bill, signed by the courier.
Limitations:
Brother is not responsible for damage to or
loss of any equipment, media, programs or
data related to the use of this Product. Except
for that repair or replacement as described
above, Brother shall not be liable for any
direct, indirect, incidental or consequential
damages or specific relief. Because some
states do not allow the exclusion or limitation
of consequential or incidental damages, the
above limitation may not apply to you.
THIS WARRANTY IS GIVEN IN LIEU OF ALL
OTHER WARRANTIES, WRITTEN OR
ORAL, WHETHER EXPRESSED BY
AFFIRMATION, PROMISE, DESCRIPTION,
DRAWING, MODEL OR SAMPLE. ANY AND
ALL WARRANTIES OTHER THAN THIS
ONE, WHETHER EXPRESS OR IMPLIED,
INCLUDING IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE HEREBY
DISCLAIMED.
This Limited Warranty is the only warranty
that Brother is giving for this Product. It is
the final expression and the exclusive and
only statement of Brother's obligations to
you. It replaces all other agreements and
understandings that you may have with
Brother or its representatives.
This warranty gives you certain rights and
you may also have other rights that may
vary from state to state.
This Limited Warranty (and Brother's
obligation to you) may not be changed in
any way unless you and Brother sign the
same piece of paper in which we (1) refer
to this Product and your bill of sale date, (2)
describe the change to this warranty and
(3) agree to make that change.
Important: We recommend that you keep
all original packing materials, in the event
that you ship this Product.
© 2006 Brother International Corporation

v
BROTHER CORDLESS HANDSET LIMITED WARRANTY
(Canada only)
Pursuant to the limited warranty of 1 year from the date of purchase for labour and parts,
Brother International Corporation (Canada) Ltd. ("Brother"), or its Authorized Service
Centres, will repair or replace (at Brother's sole discretion) this product free of charge if
defective in material or workmanship. This warranty applies only to products purchased and
used in Canada. This limited Warranty does not include cleaning, consumables (including,
without limitation batteries) or damage caused by accident, neglect, misuse or improper
installation or operation, any damage caused from service, maintenance, modifications, or
tampering by anyone other than a Brother Authorized Service Representative, or if shipped
out of the country. The battery included with this product is covered exceptionally for a period
of 90 days or the rated life, whichever comes first.
The use of supplies or consumable items that are non-Brother products may void your
warranty. This limited warranty ceases when this product is rented, sold, or otherwise
disposed of. Operation of the Product in excess of the specifications or with the Serial
Number or Rating Label removed shall be deemed abuse and all repairs thereafter shall be
the sole liability of the end-user/purchaser.
In order to obtain warranty service, the Product must be delivered or shipped freight prepaid
by the end-user/purchaser to a "Brother" Authorized Service Centre, together with your
Canadian Proof of Purchase in the form of a Sales Receipt.
When shipping or transporting your Product, please refer to your Operation Manual for the
proper packaging procedures. Improper packaging may cause severe damage to the
machine during shipping and will void the warranty.
BROTHER DISCLAIMS ALL OTHER WARRANTIES EXPRESSED OR IMPLIED
INCLUDING, WITHOUT LIMITATIONS, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, EXCEPT TO THE
EXTENT THAT ANY WARRANTIES IMPLIED BY LAW CANNOT BE VALIDLY WAIVED.
No oral or written information, advice or representation provided by Brother, its Authorized
Service Centres, Distributors, Dealers, Agents or employees, shall create another warranty
or modify this warranty. The warranty states Brother's entire liability and your exclusive
remedy against Brother for any failure of the Product to operate properly.
Neither Brother nor anyone else involved in the development, production, or delivery of this
Product shall be liable for any indirect, incidental, special, consequential, exemplary, or
punitive damages, including lost profits, arising from the use of or inability to use the product,
even if advised by the end user/purchaser of the possibility of such damages. Since some
Provinces do not allow the above limitation of liability, such limitation, may not apply to you.
This Limited Warranty gives you specific legal rights and you may also have other
rights which vary from Province to Province.
Warranty Service is available at Brother Authorized Service Centres throughout
Canada.
For Technical Assistance or for the name and location of your nearest Authorized
Service Centre call 1-877-Brother.
Internet support: [e-mail] or browse Brother's Web Site www.brother.ca.

vi
Important Information
Federal Communications Commission (FCC) Compliance Notice
(USA only)
This equipment is hearing-aid compatible.
declares, that the products
Product Name: BCL-D10
comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Call the dealer or an experienced radio/TV technician for help.
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
Responsible
Party:
Brother International
Corporation
100 Somerset Corporate
Boulevard
Bridgewater, NJ 08807-0911
USA
TEL: [phone]

vii
The available scientific evidence does not show that any health problems are associated with
using low power wireless devices. There is no proof, however, that these low power wireless
devices are absolutely safe. Low power Wireless devices emit low levels of radio frequency
energy (RF) in the microwave range while being used. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low-level RF that does not produce heating
effects causes no known adverse health effects. Many studies of low-level RF exposures have
not found any biological effects. Some studies have suggested that some biological effects
might occur, but such findings have not been confirmed by additional research. This equipment
has been tested and found to comply with FCC radiation exposure limits set forth for an
uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in
Supplement C to OET65.
IMPORTANT
Changes or modifications not expressly approved by Brother Industries, Ltd. could void the
user’s authority to operate the equipment.
Industry Canada Compliance Statement (Canada only)
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Operation is subject to the following two conditions: (1) This device may not cause interference,
and (2) this device must accept any interference, including interference that may cause undesired
operation.
The available scientific evidence does not show that any health problems are associated with
using low power wireless devices. There is no proof, however, that these low power wireless
devices are absolutely safe. Low power Wireless devices emit low levels of radio frequency
energy (RF) in the microwave range while being used. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low-level RF that does not produce heating effects
causes no known adverse health effects. Many studies of low-level RF exposures have not found
any biological effects. Some studies have suggested that some biological effects might occur, but
such findings have not been confirmed by additional research. This equipment has been tested
and found to comply with IC radiation exposure limits set forth for an uncontrolled equipment and
meets RSS-102 of the IC radio frequency (RF) Exposure rules.
Trademark
The Brother logo is a registered trademark of Brother Industries, Ltd.
Brother is a registered trademark of Brother Industries, Ltd.
© 2007 Brother Industries, Ltd. All rights reserved.
All other brand and product names mentioned in this User’s Guide are registered
trademarks of their respective companies.

viii
Table of Contents
1 General Information
Using the documentation .......................................................................................1
Symbols and conventions used in the documentation ....................................1
Introduction ............................................................................................................1
Optional Cordless Handset....................................................................................2
Carton Components ........................................................................................2
Connecting the power cord to the cradle.........................................................2
Installing the battery ........................................................................................2
Setting your country.........................................................................................3
Registering additional cordless handsets ........................................................3
Deregistering cordless handsets ...........................................................................4
Choosing a location ...............................................................................................5
Important safety instructions..................................................................................5
Control panel overview ..........................................................................................6
LCD display screen .........................................................................................7
2 Telephone
Basic operation ......................................................................................................8
Making a telephone call ...................................................................................8
Answering calls................................................................................................8
Hold .................................................................................................................8
Tone or pulse (For Canada only).....................................................................8
Search .............................................................................................................9
Call History/Redial ...........................................................................................9
Caller ID history ...............................................................................................9
Pause ............................................................................................................10
Storing numbers for easy dialing .........................................................................11
Storing numbers ............................................................................................11
Storing numbers from the Call History...........................................................11
Storing Tel-Index numbers from the Caller ID history ...................................12
Changing numbers ........................................................................................12
Advanced operation.............................................................................................13
Transferring a call at the end of a conversation ............................................13
Intercom calling .............................................................................................14
Three-way calling ..........................................................................................14

ix
3 Menu and Features
On-screen programming......................................................................................15
Menu keys ...........................................................................................................15
Memory storage.............................................................................................15
Menu Table..........................................................................................................16
Entering Text .......................................................................................................17
General setup ......................................................................................................18
Ring Volume ..................................................................................................18
Beeper Volume..............................................................................................18
Speaker Volume ............................................................................................18
Handset Volume............................................................................................18
Handset Volume (For Volume Amplify) .........................................................18
Ring Pattern...................................................................................................19
Automatic Daylight Savings Time..................................................................19
LCD Contrast.................................................................................................20
Date and Time ...............................................................................................20
Choosing your language (Canada only) ........................................................20
Voice Enhance ..............................................................................................20
Echo Control..................................................................................................21
4 Troubleshooting and Routine Maintenance
Troubleshooting...................................................................................................22
If you are having difficulty with your cordless handset ..................................22
Error messages ...................................................................................................23
Routine maintenance...........................................................................................24
Charging the battery......................................................................................24
Cleaning ........................................................................................................24
Replacing the battery.....................................................................................25
5 Specifications
General................................................................................................................27
Cordless handset...........................................................................................27
Battery ...........................................................................................................27
Battery cradle ................................................................................................28
AC adapter ....................................................................................................28
Basic Feature.......................................................................................................28
6Index

1
1
Using the
documentation 1
Thank you for buying a Brother machine!
Reading the documentation will help you
make the most of your cordless handset.
Symbols and conventions
used in the documentation 1
The following symbols and conventions are
used throughout the documentation.
Introduction 1
The cordless handset offers several functions
that can be used to enhance the calling
features of your Brother machine.
Redial:
Allows you to choose one of the last 10
numbers dialed for redialing.
Store numbers:
You can store up to 100 names with each
having a number available for Tel-Index.
Transfer:
Transfer calls between the cordless
handset and the machine (base unit). If
you have additional optional cordless
handsets (4 max.) you can also transfer a
call to another cordless handset.
Intercom:
Use the intercom feature to make internal
calls between the cordless handset and
the machine (base unit). If you have
additional optional cordless handsets (4
max.) you can also make an intercom call
to another cordless handset.
Three-way calling:
Three-way calling allows two users to
speak with a third party from the machine
(base unit) and the cordless handset at
the same time.
Caller ID:
If you have the Caller ID subscriber
service from your telephone company the
incoming caller will be identified on the
LCD display of the cordless handset. You
can also store this number as a Tel-Index
number.
General Information 1
Bold Bold typeface identifies specific
keys on the control panel of the
cordless handset or the
machine (base unit).
Italics Italicized typeface emphasizes
an important point or refers you
to a related topic.
Courier
New
Text in the Courier New font
identifies messages on the
LCD of the cordless handset.
Warnings tell you what to do to
prevent possible personal injury.
Cautions specify procedures you
must follow or avoid to prevent
possible damage to the cordless
handset or other objects.
Notes tell you how you should
respond to a situation that may arise
or give tips about how the operation
works with other features.

General Information
2
1
Optional Cordless
Handset 1
Your Brother machine can support 3
additional cordless handsets for a total of 4
cordless handsets. If you have purchased an
optional cordless handset please follow the
steps below to setup and register your
optional cordless handset with the machine
(base unit). For the cordless handset that was
included with your machine please follow the
setup steps in the Quick Setup Guide.
Carton Components 1
Make sure you have all the components
below.
1 AC adapter
2 Cordless Handset
3User’sGuide
4Battery
5 Battery Cover
6Cradle
Connecting the power cord to
the cradle 1
aPlug the connector into the jack (1) and
route the cable through the hook (2) as
shown below.
bPlug the AC adapter into the AC power
outlet.
Installing the battery 1
aInsert the connector (1) of the new
battery (2) in the direction shown below.
1
2
345
1 2
1
2

Chapter 1
3
bPlace the battery in the correct position
as shown below.
cSlide the battery cover back on.
Note
• Be careful that you do not catch the
battery connector cord.
• After replacement, you should set the date
and time.
(See Date and Time on page 20.)
dCharge the battery for 12 hours. (See
Charging the battery on page 24.)
You can continue to set up the handset
during this time.
Setting your country 1
The first time you install the battery, you must
set your country so that the cordless handset
works correctly on local telecommunication
lines.
aPress Menu/OK.
bPress aor bto choose your country.
Press Menu/OK.
cPress 1to confirm.
Registering additional
cordless handsets 1
You can register 3 additional cordless
handsets for a total of 4 cordless handsets to
the machine (base unit). The cordless handset
that was included with your machine is already
registered with the machine (base unit).
Note
Do not operate any other cordless
handsets until registration of the cordless
handset you are registering has
completed.
For non-Color LCD models (base unit) 1
aPress Menu/OK on the cordless
handset.
Note
If you see Enter Register HS Mode
on Base Unit on the LCD of the
cordless handset, go to step c.
bPress aor bto choose Register HS.
Press Menu/OK.
cPress Menu, 0, 6on the control panel of
the machine (base unit).
dPress OK on the control panel of the
machine (base unit).
You will hear one long beep when the
cordless handset is registered correctly.

General Information
4
1
Note
• If you hear three short beeps, the cordless
handset did not register. Repeat steps b
and d.
• If you want to install another cordless
handset, repeat steps athrough d.
ePress Stop/Exit on the control panel of
the machine (base unit).
For Color LCD models (base unit) 1
aPress Menu/OK on the cordless
handset.
Note
If you see Enter Register HS Mode
on Base Unit on the LCD of the
cordless handset, go to step c.
bPress aor bto choose Register HS.
Press Menu/OK.
cPress Menu on the control panel of the
machine (base unit).
dPress aor bto choose
Initial Setup.
Press OK.
ePress aor bto choose
Register Handset.
Press OK.
fPress aor bto choose Register.
Press OK.
You will hear one long beep when the
cordless handset is registered correctly.
Note
• If you hear three short beeps, the cordless
handset did not register. Repeat step b
and f.
• If you want to install another cordless
handset, repeat steps athrough f.
gPress Stop/Exit on the control panel of
the machine (base unit).
Deregistering cordless
handsets
If you want to register a handset that has
already been registered, with another
machine (base unit), you should deregister it
first, and then register it with the other
machine (base unit). (See Registering
additional cordless handsets on page 3.) If
you are using more than one cordless
handset, deregistration will remove all
handsets registered with the machine (base
unit).
Note
Do not operate any other cordless
handsets until deregistration of the
cordless handset you are removing has
completed.
For non-Color LCD models (base unit) 1
aPress Menu, 0, 6on the control panel of
the machine (base unit).
bPress Erase.
Then, confirm the Delete by pressing 1.
cPress Stop/Exit.
For Color LCD models (base unit) 1
aPress Menu on the control panel of the
machine (base unit).
bPress aor bto choose
Initial Setup.
Press OK.
cPress aor bto choose
Register Handset.
Press OK.
dPress aor bto choose Terminate.
Press OK.
Then, confirm the Delete by pressing 1.
ePress Stop/Exit.

Chapter 1
5
Choosing a location 1
Choose a location where the temperature
remains between 50°F and 95°F
(10°and 35°C).
DO NOT put the cordless handset and
cradle near heaters, air conditioners,
water or chemicals.
DO NOT expose the cordless handset and
cradle to direct sunlight, excessive heat,
moisture, or dust.
DO NOT use the cordless handset near
electro-medical equipment.
We recommend at least 9.8 ft (3 m)
between the machine (base unit) or
cordless handset and other electronic
devices.
Important safety
instructions 1
WARNING
Use only the AC adapter and the cradle
supplied with this cordless handset.
This product must be installed near an AC
power outlet that is easily accessible.
Use only a genuine Brother rechargeable
battery.
DO NOT dispose of a used battery in a fire.
It may explode.
Corrosive fluid rarely leaks out. If it gets in
your eyes wash them with water at once.
Call a doctor if you are concerned.
DO NOT allow the battery to touch any
conductive materials. It can cause a short
circuit of the battery.
CAUTION
DO NOT take off the white plastic that
covers the battery.
(MFC-885CW)
9.8 ft
(3 m)
9.8 ft
(3 m)

General Information
6
1
Control panel overview1
1 LCD (liquid crystal display)
Displays messages on the screen to help you
set up and use your cordless handset.
2Redial/Pause
Redials any of the last 10 numbers you called.
It also puts a pause in Quick-Dial numbers.
3 Headset jack
You can connect an external headset with
microphone (not included) to the cordless
handset. To access the headset jack fold open
the headset jack cover located on the left side
of the cordless handset. You can connect any
standard headsets that use a 2.5 mm mini style
plug.
4Clear
Press to back up the cursor and delete a letter.
5Talk
Press to make or receive a phone call.
6DialPad
Use these keys to dial a telephone number and
as a keyboard for entering information into the
cordless handset.
(Canada only)
The #key lets you temporarily switch the
dialing mode during a telephone call
from Pulse to Tone.
7 Speaker Phone
Turns the speaker phone on or off.
8 Charging LED
Turns green when the cordless handset is
being charged.
9 Flash/Callwait
Use this key to answer another phone call
when you hear beeps during the conversation.
This feature requires the Call Waiting
subscriber service offered by many local
telephone companies.
(Canada only)
You can make a call from the Caller ID history
in combination with a prefix number by
pressing this key.
1
4
5
6
7
2
10
8
9
3
11
12
13

Chapter 1
7
10 Menu keys:
Volume keys
dc
You can press these keys to adjust the ring,
speaker or handset volume of the cordless
handset.
a
Lets you look up numbers that are stored in
the cordless handset’s dialing memory.
aor b
Press to scroll through the menus and
options.
11 Menu/OK
Lets you access the Menu to program or store
your settings in the cordless handset.
12 Off
Press to hang up or cancel the current
operation.
13 Hold/Intercom
Lets you place telephone calls on hold. Also,
press this key to speak on the intercom, to
transfer an incoming call to the cordless
handset or to make a three-way call.
LCD display screen 1
The LCD shows the current cordless handset
status.
1 Cordless status
A four level indicator shows the current
cordless handset signal strength.
2 Speaker Phone
Lets you see when you are speaking with the
Speaker Phone.
3 Cordless handset number
Lets you see the cordless handset numbers
that have been registered with the machine
(base unit).
4 Ring volume status
Lets you see when the ring volume is set to off.
5 Battery status
A four level indicator shows the available
battery.
0Max
0Max
12 3 4 5

8
2
2
Basic operation 2
Making a telephone call 2
aPick up the cordless handset.
bEnter a number using the dial pad or
choose a number stored in the dialing
memory.
cPress (Talk).
dSpeak clearly toward the microphone.
ePress (Off) to hang up.
fReplace the cordless handset.
Note
If you want to make a telephone call
without lifting the cordless handset, press
Speaker Phone and enter the number
using the dial pad.
Answering calls 2
aPick up the cordless handset from the
cradle to answer the call. If your
cordless handset is not in the cradle you
must press (Talk) to
answer the call.
bTo end the call, press (Off).
cReplace the cordless handset.
When the machine (base unit) or the cordless
handset rings, instead of lifting the cordless
handset, and pressing (Talk) you
can also press Speaker Phone on the
cordless handset. Speak clearly toward the
cordless handset. To end the call, press
(Off).
If you have a bad connection, your caller
might hear your voice echoed during the call.
If you experience this problem, pick up the
cordless handset and press Speaker Phone
to use the handset.
Note
Even if you answer a fax call, the machine
(base unit) will receive the fax
automatically. (See Easy Receive in the
User’s Guide.)
Hold 2
If you want to put a call on hold, press the
Hold/Intercom key. To release the call from
hold press Hold/Intercom again. You can
also transfer a call to the machine (base unit)
or to another cordless handset if you have an
additional optional cordless handset. (See
Transferring a call at the end of a
conversation on page 13.)
Tone or pulse
(For Canada only) 2
If you have a pulse dialing service, but need
to send tone signals (for example, for
telephone banking), follow the instructions
below. If you have a Touch Tone service, you
will not need this feature to send tone signals.
aPick up the cordless handset.
bPress (Talk).
Telephone 2

Chapter 2
9
cPress #on the control panel of your
cordless handset. Any digits dialed after
this will send tone signals.
When you hang up, the cordless
handset will return to the pulse dialing
service.
dPress (Off).
Search 2
You can search for names you have stored in
the Tel-Index memories.
aPick up the cordless handset.
bPress aand do one of the following:
Press aor bto choose the name
you want to call.
Use the dial pad to enter the first
letter of the name, press Menu/OK,
and then press aor bto choose the
name you want to call.
Call History/Redial 2
The last 10 numbers you called will be stored
in the call history. You can choose one of
these numbers to make a call, add it to
Tel-Index, or delete it from the history.
aPick up the cordless handset.
bPress Redial/Pause.
You can also choose Call History
by pressing Menu/OK.
cPress aor bto choose a number and
do one of the following:
To make a call, press
(Talk).
To store or delete the number, press
Menu/OK and go to step d.
dDo one of the following:
If you want to store the number,
press aor bto choose
Set Tel-Index.
Press Menu/OK.
(See Storing numbers from the Call
History on page 11.)
If you want to delete the number,
press aor bto choose Delete.
Press Menu/OK.
Then, confirm the Delete by
pressing 1.
If you want to delete all the stored
numbers, press aor bto choose
All Delete.
Press Menu/OK.
Then, confirm the Delete by
pressing 1.
Caller ID history 2
This feature requires the Caller ID subscriber
service offered by many local telephone
companies. (See Caller ID in the machine’s
User’s Guide.)
The last 30 numbers you received will be
stored in the Caller ID history. You can
choose one of these numbers to make a call,
add it to Tel-Index, or delete it from the
history.
aPick up the cordless handset.
bPress Menu/OK.
cPress aor bto choose
Caller ID hist..
Press Menu/OK.
dPress aor bto choose a number and
do one of the following:
To make a call, press
(Talk).
To store or delete the number, press
Menu/OK and go to step e.
