Brother 884-639 User manual

Be sure to read this document before using the machine.
We recommend that you keep this document nearby for future reference.
Veillez à lire ce document avant d'utiliser la machine.
Nous vous conseillons de conserver ce document à portée de la main pour vous y référer ultérieurement.
Operation Manual
Sewing machine
Product Code: 884-639
Manuel d’instructions
Machine à coudre
Référence du produit: 884-639

1
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using.
When using a sewing machine, basic safety precautions should always be taken,
including the following:
DANGER – To reduce the risk of electric shock:
The sewing machine should never be left unattended while plugged in. Always unplug the sewing machine from the electrical outlet immediately after using and before●
cleaning.
Always unplug before changing the light bulb. Replace bulb with same type rated 120V 15 watts for 120V model or rated 240V 15 watts for 220-240V model.●
WARNING – To reduce the risk of burns, fire, electric shock, or injury:
Do not allow this sewing machine to be used as a toy. Close attention is necessary when the sewing machine is used by or near children.●
Use this sewing machine only for its intended use as described in this manual. Use only accessories recommended by the manufacturer as contained in this manual.●
Never operate this sewing machine if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Return the●
sewing machine to the nearest authorized dealer or service center for examination, repair, electrical or mechanical adjustment.
Never operate the sewing machine with any air openings blocked. Keep ventilation openings of the sewing machine and foot control free from the accumulation of lint,●
dust, and loose cloth.
Never drop or insert any object into any opening.●
Do not use outdoors.●
Do not operate where aerosol (spray) products are being used or where oxygen is being administered.●
To disconnect, turn the main switch to the symbol “O” position which represents off, then remove plug from outlet.●
Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.●
Keep fingers away from all moving parts. Special care is required around the sewing machine needle.●
Always use the proper needle plate. The wrong plate can cause the needle to break.●
Do not use bent needles.●
Do not pull or push fabric while stitching. It may deflect the needle causing it to break.●
Turn off power to the machine by flipping the ON/OFF switch to the symbol “O” before making any adjustments in the needle area, such as threading the needle,●
changing the needle, threading the bobbin or changing the presser foot etc.
Always unplug the sewing machine from the electrical outlet when removing covers, lubricating, or when making any other user servicing adjustments mentioned in●
the instruction manual.
This sewing machine is not intended for use by young children or infirm persons without supervision.●
Young children should be supervised to ensure that they do not play with this sewing machine.●
CAUTION
For U.S.A. only
This appliance has a polarized plug (one blade wider than the other) to reduce the risk of electric shock, this plug is intended to fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not modify the plug in any way.

2
SAVE THESE INSTRUCTIONS
This sewing machine is intended for household use.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
FOR USERS IN THE UK, EIRE, MALTA
AND CYPRUS ONLY
IMPORTANT
In the event of replacing the plug fuse, use a fuse approved by ASTA to BS 1362, i.e. carrying the●mark, rating as marked on plug.
Always replace the fuse cover. Never use plugs with the fuse cover omitted.●
If the available electrical outlet is not suitable for the plug supplied with this equipment, you should contact your authorized dealer to obtain the correct lead.●

3
CONGRATULATIONS ON CHOOSING
A BROTHER SEWING MACHINE
Your machine is one of the finest sewing machines available for home use.
To fully enjoy all the features incorporated into it, we suggest that you study this booklet.
PLEASE READ BEFORE USING YOUR SEWING MACHINE
For safe operation
Be sure to watch the placement of your hands in relation to the needle while sewing. Do not touch moving parts such as the balance wheel, thread take-up or needle●
while the machine is operating.
Remember to turn off the power switch and unplug the cord when:●
Operation is completed●
Replacing or removing the needle or any other parts●
A power failure occurs during use●
Maintaining the machine●
Leaving the machine unattended●
Do not place anything on the foot controller.●
Plug the machine directly into the wall outlet. Do not use extension cords.●
For a longer service life
When storing your sewing machine, avoid direct sunlight and high humidity locations. Do not store the sewing machine beside a space heater, iron, or other hot●
objects.
Use only neutral soaps or detergents to clean the case. Benzene, thinner, and scouring powders can damage the case and machine, and should never be used.●
Do not drop or hit the machine.●
Always consult the operation manual when replacing any accessories, including: the presser feet, needle or other parts to assure correct installation.●
For repair or adjustment
In the event that a malfunction occurs or adjustment is required, first follow the troubleshooting table in the back of the operation manual to inspect and adjust the
machine yourself. If the problem persists, please consult your nearest authorized Brother service center.
To find out the name and phone number for your authorized Brother service center visit www.brother.com and use our convenient dealer locator.

CONTENTS
Accessories ................................................................................. 5
Machine Features ........................................................................ 6
BeforeYou Begin (1).................................................................... 7
Power Cord and Foot Controller................................7
Power Switch.............................................................7
Thread Tension Dial...................................................7
Hand Wheel...............................................................7
Stitch Length Regulator.............................................7
Reverse Stitch Lever .................................................7
Presser Foot Lift Lever ..............................................8
Knee Lift ....................................................................8
Presser Foot Pressure Adjustment Dial ....................8
Fabric Extension Table ..............................................8
BeforeYou Begin (2).................................................................... 9
Thread Cutter Button.................................................9
Needle Stop Position Button......................................9
Light Switch...............................................................9
Feed Dog Adjustment Knob ......................................9
Changing Needles and Light Bulb........................................... 10
Changing the Needle...............................................10
Changing the Feed Pin............................................10
Changing Light Bulbs ..............................................10
Threading (1).............................................................................. 11
Bobbin Winding .......................................................11
Bobbin Insertion ......................................................13
Threading (2).............................................................................. 14
Upper Threading......................................................14
Using the Automatic Needle Threader ....................15
Using the Spool Net ................................................15
Stitch Samples and Needle Chart ............................................ 16
Stitch Samples ........................................................16
Thread Tension........................................................16
Changing Presser Feet ............................................................. 17
Changing Presser Feet (Zipper Foot)......................17
Presser Feet............................................................17
Basic Sewing (1)........................................................................ 18
Basic Sewing...........................................................18
Pin Feeding (for hard-to-handle fabrics)..................18
Pin Feeding Mechanism..........................................18
Basic Sewing (2)........................................................................ 19
Rolled Hem Foot .....................................................19
Basic Sewing (3)........................................................................ 20
Zipper Foot..............................................................20
Invisible Zipper Foot ................................................21
1/4” Foot ..................................................................21
Quilting Foot............................................................22
Walking Foot............................................................22
Fabric Separator (for joining lining to fabric) ..........23
Seam Guide ............................................................23
Caring forYour Machine............................................................ 24
Cleaning the Machine..............................................24
Lubrication Points....................................................24
Trouble Shooting ....................................................................... 25

5
Accessories
No. Part Name Part Code
1 Cover XA0917-054
2 Medium Screwdriver XC9541-051
3 Small Screwdriver X55468-051
4 Cleaning Brush X59476-051
5 Knee Lift XA0830-051
6 Needles and Case
(ORGAN HLX5)
1 Size 9, 2 Size 11, 1 Size 14,
1 Size 16, 1 Ballpoint Needle
X80805-151
7 Lining Plate Screw (2) 062670-817
8 Fabric Separator 184720-001
9 Feed Pin 138483-051
10 Feed Pin Changer XC1407-051
11 General Purpose Foot XA1425-001
12 Bobbin (5) SA159 (Americas)
MBN: XA8284-202(Others)
13 Spool Cap XA2111-050
14 Rolled Hem Foot X57138-101
15 Zipper Foot 112797-001
16 Invisible Zipper Foot XC0093-001
17 1/4” Foot XA7258-001
18 Quilting Foot XA7255-301
19 Walking Foot XA7253-001
20 Seam Guide XA7256-001
21 Foot Controller XD0501-151 (EU area)
XC8816-051 (Other areas)
22 Fabric Extension Table XC3117-051
23 Spool Net XA5523-050
24 Pin Feed Foot (on machine) 136021-001
25 Spool Cushion (on machine) XF2071-001
12345
678910
11 12 13 14 15
16 17 18 19 20
21 22 23 24 25
Note (For U.S.A. only)
Foot controller: Model T
This foot controller is used for sewing machine model DZ1500F.

6
Machine Features
Presser Foot Pressure
Adjustment Dial (Page 8)
Three Holed
Thread Guide (Page 14)
Light Switch
(Page 9)
Thread Trimmer
Sewing Area
Light (Page 10)
Feed Dogs
(Page 9 and 18)
Thread Guide Bar
(Page 11)
Stitch Length
Regulator (Page 7)
Needle Stop Position
Button (Page 9)
Reverse Stitch
Lever (Page 7)
Feed Dog Adjustment
Knob (Page 9)
Knee Lift
(Page 8)
Bobbin Winder
(Page 11)
Hand Wheel
(Page 7)
Power Switch
(Page 7)
Foot Controller Jack
(Page 7)
Power Socket
(Page 7)
Spool Cushion
(Page 11)
Spool Pin
(Page 11)
Presser Foot
Lift Lever (Page 8)
Thread Guide for
Bobbin Winding (Page 11)
Handle
Air Vents
Thread Cutter
Button (Page 9)
Thread Tension Dial
(Page 7 and 16)
Indicator Lamp
Automatic Needle
Threader (Page 15)
Quick Bobbin
Thread Device (Page 13)
Thread Take-up Lever
(Page 14)

7
Before You Begin (1)
Power Cord
Foot Controller
Power Switch
I
O
Hand Wheel
1
2
3
4
5
6
7
Stitch Length Regulator
Reference Mark
Lower number
= shorter stitches
Higher number
= longer stitches
Stitch Length
Reverse Stitch
Lever
Upper Thread Tension
Loosen Tighten
Tension Block
Thread Tension Dial
When tighter thread tension is●
desired, turn the tension dial
to the right. Upper and bobbin
threads will meet on right side of
the fabric.
When looser thread tension is ●
desired, turn tension dial to the
left. Upper and lower threads
will then meet on wrong side of
fabric.
Power Switch
Flip power switch to “I” position●
to turn on.
To switch power off, flip switch to●
“O” position.
Hand Wheel
Position needle using hand●
wheel.
Always turn hand wheel towards✽
you.
CAUTION
Be sure to keep the area under
and around the needle clear.
Stitch Length Regulator
Adjust desired stitch length●
using stitch regulator dial.
Reverse Stitch Lever
Sewing in reverse is possible●
when the reverse stitch lever is
in the lowered position.
Make sure to continuously press✽
the lever to its lowest position
when reverse sewing is desired.
When the feed adjustment dial is ✽
set between 5-7 mm, the reverse
stitch length is always 5 mm.
Power Cord and Foot Controller
WARNING
Please use common household
current.
Plug in cord.●
Plug foot controller into machine.●
When you press the foot controller ●
down lightly, the machine will run
at a low speed. When you press
harder, the machine’s speed will
increase. When you take your foot
off the foot controller, the machine
will stop.
Slower
Faster

8
Presser Foot Lift Lever
Lowering the presser foot●
lift lever lowers the sewing
foot down onto the fabric and
engages the thread tension
function.
When working with heavy✽
fabrics or other fabrics that don’t
slide easily under the foot, raise
the presser foot lever to position
the fabric.
Knee Lift
Using the convenient knee lift●
to lift and lower the presser foot
easily, leaving both your hands
free.
Presser Foot Pressure
Adjustment Dial
Turning the pressure adjustment●
dial raises and lowers the
pressure indicator needle as
the amount of pressure on the
presser foot changes.
See also: “Feed Dog Adjustment
Knob” on page 9.
See “Thread Tension” on page✽
16.
Presser Foot
Lift Lever
Knee Lift
Setting up the knee lift.
Presser Foot Pressure Adjustment Dial
Pressure Indicator
Needle
Push the knee lift bar all the✽
way into the socket.
When knee lift is not in use,✽
it can be stored beneath the
fabric extension table.
Fabric Extension Table
Knee Lift
Fabric Extension Table
Lower the adjustable table feet and slide the fabric extension table on to the ●
machine.
Table legs
1
3
2
Stopper
Hook
3
Guide pin
Hole
2

9
Before You Begin (2)
Thread Cutter Button
CAUTION
When the machine stops due to
jammed threads and so forth, do
not step on the foot controller,
turn the power off, and moving
the needle with the hand wheel,
check the situation.
The thread cutter trims upper and ●
bobbin threads at the end of seams.
Needle Stop Position Button
When indicator lamp is lit up, the ●
machine will stop sewing with the
needle lowered through the fabric.
When indicator lamp is off, the●
needle position when sewing
stops, will be random.
If the safety mechanism is activated, ●
for example if the thread becomes
tangled, the red lamp flashes.
Light Switch
Push light switch to turn the light●
over the sewing area on and off.
Feed Dog Adjustment Knob
Height of feed dogs can be●
adjusted to coincide with fabric
weights.
Foot Pressure and Feed Dog Position
Thread Cutter Button
Indicator Lamp
Needle Stop Position Button
Light Switch
Feed Dog Adjustment Knob
Select one of four feed dog positions according to your needs.
Note
If a setting other than is selected, the pin feed mechanism will not
operate.
(Feed Dogs Down)
(Pin Feeding)
Velvet
Lightweight Fabrics
Middleweight Fabrics
Heavyweight Fabrics
Press with the presser lever down.✽

10
Changing Needles and Light Bulb
Changing the Needle
Turn the sewing machine 1
off. Raise needle to highest
position using hand wheel,
and lower presser foot.
Loosen screw with2
screwdriver, and
remove needle.
Hold the needle with the flat 3
side to the right, and insert
the needle as far as it will go.
Make sure needle is securely
set in the needle chamber by
screwing in tightly.
If the needle is not✽
adequately inserted or
the screw is loose, this
may break the needle
or cause a breakdown
and the needle
threader will not work.
Check needles on a✽
flat surface to make
sure they are not bent.
Changing the Feed Pin
Set the feed dogs to “velvet” 1
position. (See page 9.)
Remove needle, presser
2
foot and needle plate.
Lower presser foot and turn
3
hand wheel until feed pin is
in its highest position.
Insert small screwdriver 4
(included) as shown in diagram.
Changing Light Bulbs
Turn off power.1
Remove screw from2
head.
Note
HLX5 needles should be used; however, Schmetz
130/705H may also be used under normal circumstances.
Screwdriver
Flat surface
Lay needle on
a flat surface
(such as the needle
plate or a plate
of glass).
The needle should lay
parallel to a surface.
While holding spring5
with fingertip, lower the
feed pin changer onto
the needle to pick it up.
Attach new feed pin 6
to feed pin changer,
lower and attach while
holding spring with
fingertip.
Remove screwdriver.7
Re-attach needle plate,8
needle and presser
foot.
Remove bulb housing.3
Unscrew bulb and4
remove.
Screw in new bulb.5
Sewing Light:
See page 24.
Re-attach bulb housing6
and tighten screw.
Screwdriver
120V
Light
Bulb
Light
Bulb
230V
CAUTION
Please make sure the power to the machine is turned
off before carrying out the following operations. There
is a chance of injury if the machine accidentally starts
running during this operation.
CAUTION
Please make sure the power to the machine
is turned off before carrying out the following
operations.The glass plate over the light bulb will be
hot immediately after using the machine, therefore
it is advisable to wait until the light bulb has had a
chance to cool down before changing bulbs.

11
b
c
d
a
c
a
b
Spool of Thread
�2
Spool Cushion
Spool Cap
�1
Threading (1)
CAUTION
Do not move bobbin winding clutch while
machine is running.
Bobbin Winding
Raise the thread guide bar all the way.1
Mount a spool of thread on the spool pin.2
✽1 Use spool cap when using parallel-wound thread.
✽2 Use spool cushion when using cross-wound thread.
Pass the thread through the3
triangular hole.
Pass thread through bobbin winding4
thread guide as shown in drawing.
Run thread through top5
thread notch 1, and turning
the bobbin align bottom
thread notch 2 of the bobbin
with guide pin on bobbin
winder shaft.
Press bobbin winding clutch up against6
empty bobbin. If the bobbin stop does not
slide easily between the top and bottom of
the bobbin, check that the bobbin is seated
properly with the guide pin (5) inserted into
the lower notch.
Bobbin
Bobbin Winder
Shaft
Guide Pin
Thread Notch 1
Thread Notch 2
Bobbin Winding Clutch
5- 0: See the following illustrations.

12
Stop winding process when9
bobbin is full. Take the foot off foot
controller.
Manually move bobbin winding0
clutch back to original position.
While holding the end of the thread,7
step on the foot controller for a few
seconds. Once enough thread has
wound itself around the bobbin
to hold itself in place, release the
foot controller and trim the excess
thread.
Cut thread and remove bobbin.A
Start winding the bobbin again by8
pressing down on the foot controller.
� Place the thread end so that it does
not protrude from the bobbin.
Bobbin Winding Clutch
Controller
Pedal
Press down
�
Pressing down on the controller
harder increases the winding speed.

13
Quick Bobbin
Thread Device
Lift needle plate and open1
bobbin door.
Put bobbin into the bobbin case.2
Run thread through thread notch and✽
under latch spring, so that a length of
thread is exposed.
Always use the bobbin case that was✽
supplied with this machine. A secondary
bobbin case can be ordered from your
dealer.
Pull the latch lever of the bobbin3
case out and push the bobbin case
into the shuttle race and release the
latch lever.
If the latch lever is not set securely on ✽
the hook, it may fly off during sewing
and cause lower thread breakage.
Rotate the hand wheel one full
rotation towards you to check that the
bobbin case is set securely.
Pass the thread through the quick4
bobbin thread device in the order 1
2, pull in the direction of the arrow
3, then cut the thread.
★ Quick Bobbin Thread Device
This device cuts the bobbin thread end
to an appropriate length after the bobbin
has been replaced and holds it at that
length. Following this process eliminates
the need to manually pull the bobbin
thread through the hole in the needle
plate. Simply close the bobbin case and
continue the upper threading process.
Bobbin Insertion
�Bobbin should be
positioned so it
winds to the left.
Latch Spring
Thread Notch
10 cm (4 inches)
2
1
2
1
Bobbin Door
Needle Plate
1
2
3
Lower slide plate and close5
bobbin door, following numbers
12above in order.
Bobbin Thread Setting Cover
When the fabric extension table is set in place●
Open the bobbin thread setting cover
beforehand, then following the above
directions set the bobbin thread in
place. (You can set the bobbin thread
in place without removing the fabric
extension table.)
CAUTION – Moving parts –
To reduce risk of injury, turn the power to the machine off before servicing. Open covers.

14
Threading (2)
1
2
6
7
8
9
0
A
3
4
5
Long
Groove
Scarf
(depression on
needle shaft)
Thread
Needle Hole
1
7
2
3
5
6
4
7
8
9
0
A
Make sure thread take-up lever ●
( 7 ) is in highest position and
presser foot is up.
When using polyester thread or thread that ✽
tangles or breaks, run the thread through
all three holes of the thread guide.
If the thread is still tangles or breaks, ✽
run the thread through the holes
backwards as shown in diagram.
CAUTION
Please turn off the power to the machine before using the automatic needle threader. Accidentally stepping on the foot controller during this operation could cause bodily injury or damage to the machine.
CAUTION
Turn off the power to the machine before using the
automatic needle threader. Otherwise, it may cause
injuries when you unintentionally press down on the
foot controller.
Upper Threading
Thread tension may not be adjusted✽
adequately unless the thread runs
correctly through the take-up spring.
Thread take-up spring

15
Before sewing, pull the thread loop to the 6
right and then pull the thread tail towards
the back of the machine following the
opening in the presser foot.
The automatic needle-threader cannot be ●
used with the thread-needle combinations
illustrated in the chart shown above.
Transparent nylon thread can be used
regardless of the chart, providing the
needle used is a #14 or #16.
Rotate hand wheel towards you1
until needle is in the highest
position, and lower presser foot.
Take thread in your left hand, and2
gently pull it forward.
Lower automatic needle threader.3
Pull thread along the right side of the pin. ✽
Do not force the needle threader lower ✽
than the eye of the needle. Be sure that
the needle is in the highest position.
Turn the needle threader lever all the 4
way in the direction of 1and when
the hook extends from the needle
hole, pull the thread in the direction
of 2to catch it on the hook.
While holding the thread gently, return 5
the needle threader lever to the right. As
you do this the hook that has caught the
thread will move as well, pulling a loop
of thread through the eye of the needle.
Using the Automatic Needle Threader
Pin
Thread
1
2
Hook
Automatic
Needle
Threader
Pull the thread to ✽
the left and check
that it is caught
on the hook.
Needle (HLX5) Thread
#9 #20 #30 #50 #60
#11 #20 #30
#14 #20 #30
#16 #20
Using the Spool Net
a
b
c
d
If using transparent nylon
thread, metallic thread, or
other strong thread, place
the included spool net over
the spool before using.
If the spool net is too long,
fold it once to match it to the
spool size before placing it
over the spool.
Spool net1
Thread spool2
Spool pin3
Spool cap4

16
Stitch Samples and Needle Chart
Stitch Samples
Set stitch length regulator to1
desired stitch length.
Make sure approximately 15 cm2
of upper thread is pulled out and
laying behind presser foot. While
needle is in raised position,
insert a test strip from the
garment fabric under the foot.
Lower presser foot.3
Turn the hand wheel forward to4
lower the needle through the
fabric, then step gently on the
foot controller to begin.
Turn the hand wheel towards you 5
to raise the needle and thread
take-up lever to their highest
positions.
Lift presser foot, remove fabric6
and then manually cut the
thread with the cutter on the left
side of the head of the machine
or with a pair of scissors.
When using thread cutter:✽
5
Press the thread cutter button
while the presser foot lever in the
down position
.
6
Lift foot and remove fabric.
Thread Tension
Bobbin thread should feed smoothly. Adjust bobbin ✽
thread to match that of upper thread. (If bobbin
thread is too tight it may cause fabric to bunch up.)
to increase
bobbin
tension
to reduce
needle
thread
tension
to increase
needle
thread
tension
Fabric
Upper
Thread
Lower
Thread
to reduce
bobbin
tension
Correct thread tension
Incorrect thread tension can lead
to such undesirable results as
messy stitches, puckered seams
and thread breakage.
Upper
Thread
Lower
Thread
Right side of Fabric
Upper
Thread
Lower
Thread
Right side of Fabric
Wrong side of fabric
Bobbin tension . . . Proper
When it is week
Bobbin tension . . . Proper
When it is strong
Wrong side of fabric
Adjust the upper thread to match the bobbin thread.
Selecting the proper needle for use with the fabric and thread you are working with ●
The following chart applies to many different fabric, thread and needle combinations. ✽
HLX5 needles are recommended; however, Schmetz 130/705H needles may✽
also be used under normal sewing conditions.
Adjust the pressure adjustment dial and the feed dog adjustment knob✽
according to the chart on the sewing machine.
When sewing on knit fabrics such as jersey or tricot, use a ballpoint needle✽
or a needle designed for use with knit fabrics.
Fabric - Thread - Needles
Cloth Thread Needle (HLX5)
Specialty
fabrics
Velvet Silk, Polyester #30 – #50 #11 – #14
Quilt Polyester #20 – #50 #11 – #16
Synthetic Suede Polyester #20 – #50
Knit Polyester #20 – #50
Coating Polyester #50 #11 – #14
Light
weight
fabrics
Lawn Cotton #80 #9
Tricot Polyester #60
Silk Georgette Silk #50
Wool Georgette Silk, Polyester #50 #11
Middle
weight
fabrics
Gingham Cotton #60 – #80 #11 – #14
Lightweight Jersey Polyester #60 #11
Gabardine, Flannel Silk #50
Heavy
weight
fabrics
Denim Cotton #20 – #50 #14 – #18
Jersey Polyester #20 – #50 #11 – #16
Tweed Silk #20 – #50
HLX5
Schmetz
130/705H
#9 #65
#11 #75
#14 #90
#16 #100
#18 #110

17
Changing Presser Feet
(Zipper Foot)
Raise presser foot, and raise1
needle to highest position.
Loosen and remove screw using2
screwdriver.
Changing Presser Feet
Presser Feet
Attach zipper foot and tighten3
screw.
Use the same method to attach✽
the other feet that come with
your machine.
See page 22 for directions on✽
attaching the “Walking Foot”.
Use the position knob on back of✽
the zipper foot to adjust position
of foot in relation to needle.
Only the zipper foot has a✽
position knob.You can begin
sewing with all other presser feet
immediately after attaching.
Use only feet supplied with your machine. Each foot is ✽
specially designed for this machine and has clearance
for the pin at the rear of each foot. Use of other presser
feet may damage or break the pin feed mechanism.
CAUTION
Make sure the power to the machine is off before changing presser feet.
Walking Foot●
For sewing or
quilting on fabrics
which stick or tend
to slip Useful for
sewing multiple
layers as in quilting.
1/4” Foot●
For quilt and
patchwork piecing
with 1/4” or 1/8”
seam allowance.
Zipper Foot●
Use to attach fasteners
other than concealed
fasteners. The zipper
foot can also be used
to secure piping in
place as you sew. Use
the side of the foot
closest to the needle to
rest against the edge of
the piping as you sew.
General purpose Foot ●
This foot is used for
most sewing. (Can
also be used for
sewing thick fabrics or
seams.)
When sewing thick
✽
seams, lightly guide
the fabric with your
hand on the downward
side of the seam.
Can also be used with
✽
pin feeding.
Pin Feed Foot●
For perfect
stitching on
otherwise difficult
fabrics like velvet,
leather and suede.
Rolled Hem Foot●
Use on the edge
of fabric, such as
on hems of dress
shirts, to fold the
edge of the fabric
in three while
sewing.
Invisible Zipper Foot ●
Use to attach
concealed fasteners.
Quilting Foot●
Spring action
foot for darning,
quilting or
free-motion
embroidery.

18
Basic Sewing (1)
Basic Sewing
Lift foot, pull about 15 cm1
of upper and bobbin thread
under and behind foot, and
position fabric under foot.
Lower presser foot lever to2
lower foot.
Turn the hand wheel toward3
you to lower the needle
through the fabric, then step
gently on the foot controller
to begin.
Raise needle to highest position. 4
Lift foot, remove fabric and cut thread. 5
When using thread trimmer:✽
4
Push thread trimmer button (this will
cause the upper and bobbin threads
to be cut automatically and the
needle to stop in a raised position).
5 Lift presser foot and remove fabric.
Make sure needle is pierced1
all the way through fabric.
Lift presser foot, and turn2
fabric using needle as an
axis.
Lower presser foot and3
continue sewing.
At the beginning and end✽
of a seam, press down the
reverse stitch lever and
backstitch about 1 cm.
Before
sewing.
Begin
sewing.
Finish
sewing.
� When changing sewing directions.
Backstitches
1 cm
1 cm
Pin Feeding (for hard-to-handle fabrics)
The fabrics shown ✽
above can be joined
evenly by activating the
pin feed mechanism.
Pin Feeding Mechanism
The feed pin passes up through all layers of fabric moving with the feed dog’s
motion to feed all layers of the fabric evenly.
For safety, the feed pin is automatically lowered when presser foot is raised.✽
Fabric:
Velvet
Quilt
Synthetic
Suede
Knit
Coating
Others
Move feed 1
adjustment knob to
pin feeding position.
Adjust pressure adjustment 2
dial until indicator needle is
in the right position in the
matching color coded area.
Gently pull thread until3
feed pin catches fabric
and sew.
Feed Pin
Feed Pin
Fabric
Feed Dog
Indicator Needle
CAUTION
While the presser foot lever is lowered, the feed pin appears up through the feed dog. Keep your fingers away from the feed pin.
