BAS-102V 1/2
2000.7
BAS-102V
Automatic Serging Machine
Specifications -001 -010 -011
Machine head Ultra high speed single needle overlock sewing machine with vertical air type chain cutter
Sewing speed High speed :1,600 - 7,500 rpm
Low speed : 600 - 6,400 rpm
Max. stitch length 1.2 - 5.0 mm
Stitch width 3, 4, 5 mm
Height of presser foot 5 mm
Differential ratio 0.7 - 1.3 mm
No. of needles 1(DC ×27 #11)
No. of threads 3
Pitch 1.6 mm
Feed dog Standard 2 row
Teflon table -¡ ¡
Stacker ¡-¡
Cloth-edge control Pulse motor
Cloth-edge sensor Photosensor
Air pressure 0.49 Mpa 100 l / min
Motor DC motor
Power supply 3-Phase 220 V, 380 V, 415 V 1kVA
Machine dimensions 1,950 (W) ×720 (D) ×900 (H) mm (With stacker and accessory table)
Weight 130 kg
*Optional table (1,000 (W) ×(L) 600 ×(H) 900 mm) can be prepared.

BAS-102V 2/22000.7
Option parts [Models BAS-102V]
Part name Part code Q’ty
< (For 5 mm) Standard parts >
Needle plate S30483-001 1
< (For 4 mm) Option parts >
Needle plate S30482-001 1
