313AAV/JAV Plus 80x
4--WAY MULTIPOISE
INDUCED--COMBUSTION GAS FURNACE
INPUT CAPACITIES: 45,000 THRU 135,000 Btuh
A08288
THE BRYANT Plus 80x GAS FURNACE
The Plus 80x Deluxe 4--Way Multipoise Gas Furnace offers
outstanding features in an 80% AFUE furnace.
Deluxe features include: an ECM motor which enhances SEER
performance up to 1.5 points*, a third fan relay for discrete
continuous fan speed, the ability to change continuous fan speeds
from the thermostat (Fan on Plust), dehumidify mode, standard
Media Filter Cabinet, fault code storage, and more. The Plus 80x
is very quiet thanks to a new combustion design that eliminates
noise, rather than just muffle or box it in. Applications are easy
with 4--way multipoise design, through--the--furnace downflow
venting, 13 different venting options, and a door designed for easy
service access. An inner blower door is provided for tighter sealing
in sensitive applications. The 313JAV is approved for use in Low
NOx Air Quality Management Districts.
*as compared to the Air Conditioning Heating and Refrigeration
Institute’s standard coil--only ratings when paired with selected
Bryant evaporator coils.
STANDARD FEATURES
SECM blower motor included
SNoise elimination combustion system
SSmartEvaptcan lower the humidity level in the home by
nearly 10%
SFour--position furnace: Upflow, Horizontal Right,
Horizontal Left, Downflow
Thirteen different vent options
SCompact design only 33--1/3 in. (847 mm) tall
SHigh--Efficiency Media Filtration Cabinet included
SWashable filter included
SMicroprocessor based “smart” control center
“Fan on Plus
t “--Continuous Fan speed adjustable from
thermostat
Adjustable heating air temperature rise
Dehumidify mode
LED diagnostics, non--volatile fault code memory, and self--test
feature
On--board fuse for transformer protection
SPatented blocked vent safeguard to ensure proper furnace
venting
SInsulated blower compartment
SHYBRID HEAT®Dual Fuel System compatible
SAll models are chimney friendly when used with accessory
vent kit
SPerfect LighttIgniter
SResidential installations eligible for consumer financing
through the Comfort Credit Program

2
FURNACE COMPONENTS
VENT ELBOW
MAIN LIMIT SWITCH
(BEHIND GAS VALVE)
DRAFT
SAFEGUARD
SWITCH
FLAME SENSOR
GAS MANIFOLD
GAS BURNER
BLOWER DOOR
SAFETY SWITCH
BLOWER AND
MOTOR
CONTROL
RATING PLATE
NOT SHOWN
(LOCATED ON
BLOWER DOOR)
HOT SURFACE
IGNITER
MANUAL RESET
LIMIT SWITCHES
GAS VALVE
FLUE
COLLECTOR
BOX
PRESSURE
SWITCH
INDUCER MOTOR
ASSEMBLY
CAPACITOR/POWER
CHOKE (WHERE USED)
A02259
NOTE: The 313AAV/JAV Furnaces are factory shipped for use with natural gas. These furnaces can be field--converted for propane gas
with a factory--authorized and listed accessory conversion kit.
58DLA/DLX
A02169
A02169 A02170
REWOLBRECUDNIDRAOBLORTNOCREGNAHCXETAEH
A08063
313AAV/JAV

3
BRYANT ACCESSORIES
MECHANICAL
OR ELECTRONIC
AIR CLEANER
Cleans the air of smoke, dirt, and
many pollens commonly found.
Saves decorating and cleaning
expenses by keeping carpets,
furniture, and drapes cleaner.
Electronic air cleaner is shown.
A97432
CONTROLS:
THERMOSTATS
AND ZONING
Available in programmable and
non-programmable models,
Bryant thermostats maintain a
constant, comfortable tempera-
ture level in the home.
For the ultimate in home comfort,
Bryant’s 2, 4, and 8-zone systems
allow temperature control of indi-
vidual “zones” of the home. This is
accomplished through a series of
electronic dampers and
remote room sensors. The
4-zone system is shown.
A01484
MODEL HUMCCLFP
HUMIDIFIER
By adding moisture to winter-dry
air, a Bryant humidifier can often
improve comfort and keep
furniture, rugs, and draperies in
better condition. Moisturizing
household air also helps to retain
normal body heat and provides
comfort at lower temperatures.
C04009
A08153
ACCESSORIES
ELECTRONIC AIR CLEANER
(EAC) Model EACB
AIR PURIFIER Models GAPAAXBB1625, GAPAAXBB2025
MECHANICAL AIR CLEANER Models EZXCAB, FILCAB
HUMIDIFIER Model HUM
HEAT RECOVERY
VENTILATOR Model HRV
ENERGY RECOVERY
VENTILATOR Model ERV
UV LIGHTS Model UVL
T H E R M O S T A T ---
N O N --- P R O G R A M M A B L E
F o r u s e w i t h 1 --- s p e e d A i r C o n d i t i o n e r --- d e g . F / C , A u t o C h a n g e o v e r --- T 6 --- N A C , T 2 --- N A C
F o r u s e w i t h 1 --- s p e e d H e a t P u m p --- d e g . F / C , A u t o C h a n g e o v e r --- T 6 --- N H P, T 2 --- N H P *
F o r u s e w i t h 2 --- s p e e d A i r C o n d i t i o n e r --- d e g . F / C , A u t o C h a n g e o v e r --- T 6 --- N R H *
For use with multi ---use / stage configurations --- deg. F/C, Auto Changeover/Temperature and
H u m i d i t y C o n t r o l --- T 6 --- P R H {
T H E R M O S T A T ---
PROGRAMMABLE
F o r u s e w i t h 1 --- s p e e d A i r C o n d i t i o n e r --- d e g . F / C , A u t o C h a n g e o v e r, 7 --- D a y P r o g r a m m a b l e ---
T 6 --- P A C
F o r u s e w i t h 1 --- s p e e d H e a t P u m p --- d e g . F / C , A u t o C h a n g e o v e r, 7 --- D a y P r o g r a m m a b l e ---
T6---PHP*
F o r u s e w i t h 2 --- s p e e d A i r C o n d i t i o n e r --- d e g . F / C , A u t o C h a n g e o v e r, 7 --- D a y P r o g r a m m a b l e ---
T 6 --- P R H *
F o r u s e w i t h 1 --- s p e e d A i r C o n d i t i o n e r --- d e g . F / C , 5 --- 2 D a y P r o g r a m m a b l e --- T 6 --- P A C
F o r u s e w i t h m u l t i --- s t a g e a p p l i c a t i o n s --- d e g . F / C , A u t o C h a n g e o v e r, 7 --- D a y P r o g r a m m a b l e ---
T 2 --- P H P }
F o r m u l t i --- u s e / s t a g e c o n f i g u r a t i o n s --- d e g . F / C , A u t o C h a n g e o v e r , 7 --- D a y P r o g r a m m a b l e /
Temperature and Humidity Control ---T6---PRH{
ZONING CONTROL
Zone Perfect 3---Zone kit --- ZONEBB3ZAC01, ZONEBB3ZHP01
2 --- Z o n e P e r f e c t P l u s k i t / Te m p e r a t u r e a n d H u m i d i t y C o n t r o l --- Z O N E B B 2 K I T 0 1 --- B
4 --- Z o n e P e r f e c t P l u s k i t / Te m p e r a t u r e a n d H u m i d i t y C o n t r o l --- Z O N E B B 4 K I T 0 1 --- B
8 --- Z o n e P e r f e c t P l u s k i t / Te m p e r a t u r e a n d H u m i d i t y C o n t r o l --- Z O N E B B 8 K I T 0 1 --- B
*Model HP and 2S thermostat must be field converted to air conditioner operation.
{ThermidistattControl can be configured for multiple use and staging. It must be configured for each specific application.
}Dual Fuel thermostat is used with furnace and heat pump application.
313AAV/JAV

4
BRYANT ACCESSORIES
DESCRIPTION 313AAV/JAV PART NO. 024045 048070 048090 060110 060135
Cartridge Media Filter
FILBBCAR0016 X X
FILBBCAR0020 X X
FILBBCAR0024 X
EXPXXUNV0016 X X
EZ Flex Media Filter with End Caps
EXPXXUNV0020 X X
EXPXXUNV0024 X
EXPXXFIL0016 X X
Replacement EZ Flex Filter Media EXPXXFIL0020 X X
EXPXXFIL0024 X
External Bottom Return KGAFR0401B14 X
KGAFR0501B17 X
Filter Rack KGAFR0601B21 X X
KGAFR0701B24 X
External Side Return Filter Rack KGAFR0801SRE X X X X X
Unframed Filter 3/4---in. (19 mm)
KGAWF1301UFR {S S
KGAWF1401UFR S S
KGAWF1501UFR S
KGAWF1306UFR {X X
KGAWF1406UFR X X
KGAWF1506UFR X
Flue Extension KGAFE0112UPH X X X X X
Combustible Floor Base KGASB0201ALL X X X X X
Downflow Vent Guard KGAVG0101DFG X X X X X
Vent Extension Kit KGAVE0101DNH X X X X X
Chimney Adapter Kit KGACA02014FC X X X X
Chimney Adapter Kit KGACA02015FC X
N a t u r a l --- t o --- P r o p a n e C o n v e r s i o n K i t * KGANP4601ALL X X X X X
P r o p a n e --- t o --- N a t u r a l C o n v e r s i o n K i t * KGAPN3901ALL X X X X X
Label Kit KGALB0101KIT X X X X X
Air Leakage Kit (Qty 10) KGBAC0110DGK X X X X X
Air Leakage Kit (Qty 10) KGBAC0110DGK X X X X X
Gas Orifice Kit (Qty 50)
KGAHA0150N42
See Installation Instructions for model, altitude, and heat value usages.
KGAHA0250N43
(factory supplied)
KGAHA0350N44
KGAHA0450N45
KGAHA0550N46
KGAHA1550N47
KGAHA1650N48
KGAHA0650P54
KGAHA0750P55
KGAHA0850P56
KGAHA5750125
KGAHA5750130
*Factory ---authorized and field---installed. Gas conversion kits are CSA (AGA/CGA) recognized.
{Suitable for Side Return Filter Rack (KGAFR0801SRE)
X --- A c c e s s o r y
S --- S t a n d a r d
313AAV/JAV

5
PHYSICAL DATA
UNIT SIZE 024045 048070 048090 060110 060135
OUTPUT CAPACITY
BTUH
( N o n --- w e a t h e r i z e d I C S )
313JAV Upflow; all 313AAV 36,000 53,000 72,000 90,000 107,000
313JAV Downflow/Horizontal 34,000 51,000 69,000 86,000 102,000
INPUT BTUH 313JAV Upflow; all 313AAV 44,000 66,000 88,000 110,000 132,000
313JAV Downflow/Horizontal 42,000 63,000 84,000 105,000 126,000
AFUE% N o n --- w e a t h e r i z e d I C S 80.0 80.0 80.0 80.0 80.0
SHIPPING WEIGHT LB. (KG) 104 (47) 126 (57) 140 (64) 152 (69) 163 (74)
CERTIFIED TEMP RISE RANGE ˚_F(_C) 30--- 60
( 1 7 --- 3 3 )
25--- 55
( 1 4 --- 3 1 )
35--- 65
( 1 9 --- 3 6 )
30--- 60
( 1 7 --- 3 3 )
40--- 70
( 2 2 --- 3 9 )
CERTIFIED EXT STATIC
PRESSURE (IN. WC)
Heating 0.10 0.12 0.15 0.20 0.20
Cooling 0.50 0.50 0.50 0.50 0.50
AIRFLOW CFM Heating 735 1230 1345 1890 1865
Cooling 1035 1460 1665 2040 2070
LIMIT CONTROL SPST
HEATING BLOWER CONTROL Solid--- State Time Operation
BURNERS (Monoport) 2 3 4 5 6
GAS CONNECTION SIZE 1 / 2 --- i n . N P T
GAS VALVE(Redundant) Manufacturer W h i t e --- R o d g e r s
Minimum Inlet Pressure (in. wc) 4.5 (Natural Gas)
Maximum Inlet Pressure (in. wc) 13.6 (Natural Gas)
IGNITION DEVICE Hot Surface
*Gas input ratings are certified for elevations to 2000 ft. (610 M)*. In USA, For elevations above 2000 ft. (610 M), reduce ratings 4 percent for each 1000 ft. (305
M) above sea level. In Canada, derate the unit 10 percent for elevations 2000 to 4500 ft. (610 --- 1372 M) above sea level. Refer to National Fuel Gas Code
NFPA 54/ANSI Z223.1---2006 Table F.1 (d) or furnace Installation Instructions.
{Capacity in accordance with U.S. Government DOE test procedures.
}Airflow shown is for bottom only return ---air supply. For air delivery above 1800 CFM, see Air Delivery Table for other options. A filter is required foreach
return---air supply. An airflow reduction of up to 7 percent may occur when using a Bryant 4---5/16 in. (110 mm) high efficiency media filter.
ICS --- Isolated Combustion System
BLOWER PERFORMANCE DATA
UNIT SIZE 024045 048070 048090 060110 060135
DIRECT---DRIVE MOTOR Hp (ECM --- 5 Speed) 1/2 3/4 3/4 1 1
MOTOR FULL LOAD AMPS 6.8 8.4 8.4 10.9 10.9
R P M ( N o m i n a l ) --- S P E E D S 1050--- 5 1050--- 5 1050--- 5 1050---5 1050--- 5
BLOWER WHEEL DIAMETER x WIDTHS --- IN (MM) 10 x 6
(254 x 152)
11 x 8
(279 x 203)
10X10
(254 x 254)
11 x 11
(279 x 279)
11 x 11
(279 x 279)
313AAV/JAV

6
SEE NOTES: 1,2,4,7,8,9 SEE NOTES: 1,2,3,4,7,8,9 SEE NOTES: 1,2,4,5,7,8,9
SEE NOTES:1,2,3,4,5,7,8,9 SEE NOTES: 1,2,3,4,7,8,9 SEE NOTES: 1,2,4,5,6,7,8,9
A02063A02060
A02058 A02059 A02061
A02062
UPFLOW UPFLOW DOWNFLOW
DOWNFLOW DOWNFLOW DOWNFLOW
Ven ting Notes
1. For common vent, vent connector sizing and vent material: United States, latest edition of the National Fuel Gas Code (NFGC),
NFPA54/ANSI Z223.1. In Canada, latest edition of the National Standards of Canada, Natural Gas and Propane Installation Code
(NSCNGPIC), CSA B149.1.
2. Immediately increase to 5--in. (127 mm) vent connector outside furnace casing when 5--in. (127 mm) vent connector required, refer to
Note 1.
3. Side outlet vent for upflow and downflow installations must use Type B vent immediately after exiting the furnace, except when
KGAVG0101DFG is used in downflow position.
4. Type B vent where required, refer to Note 1.
5. 4--in. (102 mm) single wall vent must be used inside furnace casing and the KGAVG0101DFG Downflow Vent Guard Kit.
6. Accessory Downflow Vent Guard Kit, KGAVG0101DFG required in downflow installations with bottom vent configuration.
7. Chimney Adapter Kit required for exterior masonry chimney applications. Refer to Chimney Adapter Kit, KGACA02014FC and
KGACA02015FC for sizing and complete application details.
8. Secure vent connector to furnace elbow with (2) corrosion--resistant sheet metal screws, space approximately 180_apart.
9. Secure all other single wall vent connector joints with (3) corrosion--resistant screws spaced approximately 120_apart. Secure Type B
vent connectors per vent connector manufacturer’s recommendations.
313AAV/JAV

7
SEE NOTES: 1,2,4,5,7,8,9 SEE NOTES: 1,2,4,5,7,8,9
SEE NOTES: 1,2,4,7,8,9
SEE NOTES: 1,2,4,7,8,9 SEE NOTES: 1,2,4,5,7,8,9
SEE NOTES: 1,2,4,5,7,8,9 SEE NOTES: 1,2,4,5,7,8,9
HORIZONTAL RIGHT
HORIZONTAL RIGHT
HORIZONTAL RIGHT
HORIZONTAL LEFT HORIZONTAL LEFT
HORIZONTAL LEFT HORIZONTAL LEFT
A02069
A02068 A02070
A02064
A02066
A02065
A02067
313AAV/JAV

8
AIR DELIVERY -- CFM (WITH FILTER)*
UNIT SIZE RETURN---AIR
SUPPLY SPEED EXTERNAL STATIC PRESSURE (in. wc)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
024045 Bottom or
Side(s)
51185 1145 1115 1075 1035 980 905 820 720 580
4920 880 835 800 755 720 680 645 605 540
3735 685 625 585 530 490 435 395 345 295
2820 765 725 670 630 580 545 490 455 405
1650 595 535 490 430 390 330 280 235 --- ---
048070 Bottom or
Side(s)
51625 1585 1535 1495 1460 1415 1365 1295 1220 1125
41405 1360 1320 1280 1240 1195 1155 1115 1070 1030
31240 1200 1155 1110 1065 1020 975 935 895 850
21190 1140 1095 1050 1000 955 915 870 830 790
11035 985 930 885 835 785 745 695 650 600
048090 Bottom or
Side(s)
51845 1800 1755 1710 1665 1595 1500 1400 1275 1105
41590 1545 1500 1455 1410 1365 1315 1270 1180 1000
31365 1320 1270 1215 1170 1125 1070 1025 955 900
21225 1160 1110 1060 1010 950 895 830 770 710
11100 1030 960 875 805 730 645 570 505 425
060110 Bottom or
Side(s)
52255 2205 2150 2100 2040 1985 1920 1835 1735 1615
41600 1525 1465 1400 1335 1275 1210 1150 1080 1015
31945 1890 1830 1770 1715 1655 1600 1545 1480 1430
21420 1340 1280 1200 1140 1065 1005 925 865 790
11280 1205 1140 1055 990 910 840 760 695 630
060135 Bottom or
Side(s)
52295 2240 2185 2125 2070 2005 1925 1805 1670 1545
41725 1660 1605 1545 1460 1395 1340 1285 1230 1170
31910 1865 1800 1745 1685 1610 1545 1485 1435 1380
21630 1575 1510 1435 1365 1300 1245 1185 1130 1065
11430 1355 1285 1200 1125 1075 1015 945 855 800
*A filter is required for each return ---air inlet. Airflow performance included 3/4---in. (19 mm) washable filter media such as contained in factory ---authorized ac-
cessory filter rack. To determine airflow performance without this filter, assume an additional 0.1 in. wc available external static pressure.
--- --- Indicates unstable operating conditions.
ELECTRICAL DATA
313AAV/
JAV UNIT
SIZE
V O LT S ---
H E R T Z ---
PHASE
OPERATING VOLTAGE
RANGE*MAXIMUM
UNIT AMPS
MAXIMUM WIRE
LENGTH FT (M)}
MAXIMUM FUSE
OR CKT BKR
AMPS{
MINIMUM
WIRE GAGE
Maximum Minimum
024045 1 1 5 --- 6 0 --- 1 127 104 8.1 34 (10) 15 14
048070 1 1 5 --- 6 0 --- 1 127 104 9.5 29 (9) 15 14
048090 1 1 5 --- 6 0 --- 1 127 104 10.3 27 (8) 15 14
060110 1 1 5 --- 6 0 --- 1 127 104 13.1 34 (10) 20 12
060135 1 1 5 --- 6 0 --- 1 127 104 13.1 34 (10) 20 12
* Permissible limits of the voltage range at which the unit operates satisfactorily.
{Time---delay type is recommended.
}Length shown is as measured 1 way along wire path between unit and service panel for maximum 2 percent voltage drop.
313AAV/JAV

9
DIMENSIONS
2-7/16"
1-1/8"
28-7/8"
(733mm)
25-1/4"
22-9/16"
JUNCTION BOX
LOCATION
7/8" DIA
ACCESSORY 1/2" (13 mm) DIA.
THERMOSTAT WIRE ENTRY
3-15/16" (84mm)
LEFT HAND GAS
ENTRY
33-5/16" 24-7/8"
5-1/2"
7/8" (22mm) DIA.
ACCESSORY
11/16"
21-5/8"
BOTTOM INLET 1-11/16"
13/16"
11/16"
4-13/16"
AIRFLOW
19"
OUTLET
13/16"
11/16"
8-9/16"
VENT OUTLET
5 PLACES (TYP)
3-3/4"
1-3/4" DIA.RIGHT HAND
GAS ENTRY
7/8" DIA. K.O. WIRE ENTRY
SIDE INLET
14-7/8"
7/8" DIA. ACCESSORY
1-1/4"
1"
22-1/16"
A
D
F
E
(FLUE COLLAR)
5-15/16"
(135mm)
24"
CASING
1-5/16"
1/2" DIA. K.O.THERMOSTAT
WIRE ENTRY
ALTERNATE
JUNCTION BOX
LOCATIONS (TYP)
26-1/8"
1-1/2"
7-3/4" 9-5/8"
11-1/2"
5-1/2"
(664mm)
(641mm)
(573mm)
(22mm)
(846mm)
(17mm) (549mm)
(
610mm
)
(43mm)
(140mm)
(632mm)
(17mm)
(140mm)
(95mm)
(21mm) (122mm)
(217mm)
(62mm)
(33mm)
(29mm) (483mm)
(13mm)
(44mm)
(22mm)
(22mm)
(38mm)
(560mm)
(25mm)
(32mm)
(378mm)
(17mm)(197mm)
(244mm)
(292mm)
(21mm)
A04037
1. Two additional 7/8--in. (22 mm) dia. knockouts are located in the top plate.
2. Minimum return--air openings at furnace, based on metal duct. If flex duct is used, see flex duct manufacturer’s recommendations for equivalent diameters.
3. Minimum return--air opening at furnace.
a. For 800 CFM--16--in. (406 mm) round or 14--1/2 x 12--in. (368 x 305 mm) rectangle.
b. For 1200 CFM--20--in. (508 mm) round or 14--1/2 x 19--1/3 in. (368 x 491 mm)rectangle.
c. For 1600 CFM--22--in. (559 mm) round or 14--1/2 x 22--1/16--in. (368 x 560 mm) rectangle.
d. For airflow requirements above 1800 CFM, see Air Delivery table in Product Data literature for specific use of single side inlets. The use of both side inlets, a
combination of 1 side and the bottom, or the bottom of single side inlets. The use of both side inlets, a combination of one side and the bottom, or the bottom only
will ensure adequate return air openings for airflow requirements above 1800 CFM.
313AAV/JAV
UNIT SIZE
A
CABINET
WIDTH
IN (MM)
D
SUPPLY WIDTH
IN (MM)
E
BOTTOM
RETURN WIDTH
IN (MM)
F
TOP VENT
OUTLET
IN (MM)
VENT
CONNECTION
SIZE
(see Notes 1 & 2)
MEDIA CABINET
SIZE
IN (MM)
024045 14--- 3/16 (360) 12--- 9/16 (319) 12--- 11/16 (322) 9--- 5/16 (237) 416 (406)
048070 17---1/2 (445) 15--- 7/8 (403) 16--- 1/8 (410) 11--- 9/16 (294) 416 (406)
048090 21 (533) 19--- 3/8 (492) 19--- 1/2 (495) 13--- 5/16 (338) 420 (508)
060110 21 (533) 19--- 3/8 (492) 19--- 1/2 (495) 13--- 5/16 (338) 420 (508)
060135 24---1/2 (622) 22--- 7/8 (581) 23 (584) 15---1/16 (383) 4(Note1) 24 (610)
1. 135 size furnaces require 5---in. (127 mm) vents. Use a 4---5 in. (102---127 mm) vent adaptor between furnace and vent stack.
2. See installation instructions for complete installation requirements.
313AAV/JAV

10
A08471
MEETS DOE RESIDENTIAL CONSERVATION
SERVICES PROGRAM STANDARDS.
Before purchasing this appliance, read important
energy cost and efficiency information available
from your retailer.
REGISTERED QUALITY SYSTEM
C
a
r
r
i
e
r
C
o
r
p
o
r
a
t
i
o
n
R
E
G
I
S
T
E
R
E
D
F
I
R
M
I
S
O
9
0
0
1
#
A
2
8
8
3
¨
EFFICIENCY
RATING
CERTIFIED
CERTIFIED
D
E
S
I
G
N
C
E
R
T
I
F
I
E
D
®
REGISTERED
ISO 9001:2000
A
Media/
Filter Cabinet ABC
16"/ 17"/ 161/4"/ 15"/
20"/ 21"/ 201/4"/ 19"/
24"/ 25"/ 241/4"/ 23"/
23
5
/
8 "
23
3
/
8
"
Furnace Side
23
3
/
4 "
Centerline Screw Slots
25
5
/
8 "
Duct Side
24
1
/
2
"
With Flanges Bent Out
23
1
/
8 "
Opening
5
3
/
4 "
COpening
with Flanges Bent In
B
(600mm)
(600mm)
(603mm)(146mm)
(651mm)
(651mm)
(587mm)
(406mm)
(508mm)
(610mm)
(432mm)
(533mm)
(635mm)
(413mm)
(514mm)
(616mm)
(381mm)
(483mm)
(584mm)
A00444
313AAV/JAV
