Bush WMDF1014B User manual

Instruction manual
Washing Machine
WMDF1014B
WMDF1014W

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
2
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
You’ll soon be enjoying your new washing machine.
It all begins here, with your instructions. Don’t worry,
there’s nothing too technical coming up. Just simple,
step-by-step guidance to get you up and running
quickly. Sound good? Then let’s get started.
Help and Guidance
We’re here to help you get the most from your <washing machine>. Should you require
any guidance, a simple solution can often be found online at:
www.argos-support.co.uk
If you still require further assistance, call one of our experts on 0345 257 7271.

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
3
Contents
Product support
Troubleshooting 32-33
Error Signals 34
Technical Specifications 35
Help and assistance 36
Disposal 37
Guarantee 38
7
Safety information
Safety information 6
Getting to know your washing
machine
Ready? Let’s begin 10
Accessories 12
Installing your washing
machine
Installation requirements 14
Unpacking 14
Connections (electrical, water, gas) 15
Functions
Functions 18
Using your washing machine
First use of <washing machine> 24
Standard and advanced functions/use 25
Care and Maintenance
Cleaning 28
Maintenance actions 28
Technical specifications 29
1
2
3
4
5
6

1
Safety information

Safety information
Important - Please read these instructions fully before
installing or operating your washing machine
Safety information6
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
Before use
• If the supply cord is damaged, it must be replaced
by the manufacturer, their service agent or similarly
qualified persons in order to avoid a hazard.
• The new hose-set supplied with the appliance are to
be used and that old hose-set should not be reused.
• This appliance can be used by children aged 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be done by children without
supervision.
• Children should be supervised to ensure that they do
not play with the appliance.
• Pull out its plug from the power socket before
cleaning or maintenance.
• Make sure that all pockets are emptied.
• Pull out its plug and cut off water supply after the
operation.
• Pets and children may climb into the machine. Check
the machine before every operation.
• Glass door may be very hot during the operation.
Keep children and pets far away from the machine
during the operation.
• Take care that power voltage and frequency shall be
identical to those of washing machine.
• Do not use any socket with rated current less than
that of washing machine. Never pull out the power
plug with wet hands.
• To ensure your safety, the power cord plug must
be inserted into an earthed three-pole socket. Check
carefully and make sure that your socket is properly
and reliably earthed.
• Packing materials may be dangerous to the children.
Please keep all packing materials (plastic bags, foams
etc) far away from the children.
• The installation of this appliance is best carried out by
2 people.
• Dispose of all packaging carefully and responsibly.
• This appliance is for indoor use only. Only install in a
dry indoor environment.
• The appliance MUST be positioned on a firm level
base.
• Do not position the appliance where it is exposed
to direct sunlight or heat sources as this will age the
plastic and rubber components.
• Ensure all 4 packing bolts have been removed.
• Ensure the appliance is connected directly to a
domestic mains water supply.
• Warning: This washing machine MUST only be
connected to a cold water supply.
• Ensure all electrical connections are as stated in this
document.
• Ensure the appliance is plugged into a separate
earthed socket that is easily accessible.
• Ensure the power lead is not trapped under the
appliance.
• Do not connect the appliance to the power supply
until installation is complete.
• This appliance is for domestic/household use only
and is not suitable for commercial use.
• Check that the water hose joints and connections are
secure and there are no leaks. If the hoses leak, do not
use them until the leaks have been stopped.
•Do not forget that the packing material of your
machine may be hazardous for children.

Safety information
Important - Please read these instructions fully before
installing or operating your washing machine
Safety information 7
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
During use
• Do not use a multiple socket or extension cord.
•Do not use if the power lead is damaged. It must be
replaced by the manufacturer, their approved service
agent or similarly qualified person. Customer Helpline:
0345 257 7271.
• Do not insert the plug into the power supply with wet
hands.
• Do not touch or use the appliance when barefoot or
with wet or damp hands.
• Do not open the detergent drawer during a wash
cycle.
• Do not touch the porthole (door) during the washing
cycle - it will get hot.
• Never force the machine door open while the
machine is running.
• Do not open the door if water is visible through the
porthole.
• Do not wash foam rubber or sponge like materials on
a hot wash.
• The machine can reach high temperatures while
running. Do not touch the drain hose or waste water
during draining.
• Keep your pet away from your machine.
• Do not use flammable detergent, sprays or dry
cleaning agents in or near to the appliance.
• Do not remove or insert the plug in the presence of
flammable gas.
• The appliance should not be put on a carpet which
can block the air ventilation on the bottom side.
• Do not place heavy objects or sources of heat or
damp on top of the washing machine.
• Only use detergents which are suitable for automatic
washing machines and follow the detergent
manufacturers recommendations.
• Do not use this appliance if there are any missing or
damaged parts.
• Do not attempt to repair the appliance yourself.
Contact the manufacturer, their approved service agent
or the Customer Helpline: 0345 257 7271.

Getting to know your washing
machine 2

Getting to know your washing machine
You’ll be up and running in no time
Getting to know your <washing machine>
10
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
Ready? Let’s begin...
Please read these instructions carefully. They contain
important information which will help you get the
best from your washing machine and ensure safe and
correct installation and operation.
If you require any further assistance, our technical
experts are happy to help. For full details, refer to
the product support section at the end of these
instructions.

Getting to know your washing machine
You’ll be up and running in no time
Getting to know your <washing machine> 11
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
1. Detergent drawer
2. Top panel
3. Programme knob
4. Start/Pause button
5. Door
6. Filter
1
2 3 4 8 9
5
7
7 7
7
10
6
7. Packing bolt x 4
8. Power lead
9. Drain hose
10. Water inlet
Front Back

Getting to know your washing machine
You’ll be up and running in no time
Getting to know your <washing machine>
12
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
Model Capacity Spin Speed Energy class
WMDF1014B 10kg 1400rpm A+++
WMDF1014W 10kg 1400rpm A+++
Accessories
This machine includes the below accessories, please
install these parts before operating.
• plastic hole plug x 4
• Inlet hose

Installing your washing
machine 3

Installing your washing machine
Bringing it all together
Installing your <washing machine>
14
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
Unpacking your washing machine
Caution: 2 people are required to unpack the washing
machine, it is recommended that gloves are worn.
a: Carefully remove all packaging materials including
the foam base, dispose of correctly.
Note: When opened, water droplets may be visible in
the drum etc. this is normal as each appliance is factory
tested.
Removing the packing bolts
Important: The packing bolts are designed to support
the internal components during transit, these MUST be
removed before use.
a: Loosen the screws by rotating counter clockwise
with a suitable wrench. (1 & 2)
b: Remove the bolts by pulling them. (3)
c: When the transport bolts have been removed,
insert the plastic transport screw taps found in the
accessories bag into the holes. (4)
Adjusting the feet
a: For your machine to work efficiently with minimum
vibration it should be settled on flat, non-slippery, firm
ground.
b: You can adjust the balance of your machine by
changing the positioning of its feet.
c: First, loosen the plastic adjustment nut. (5)
d: Adjust by rotating the feet upwards or downwards.
(6)
e: After the desired position has been reached, tighten
the plastic adjustment nut again by rotating it upwards.
Note: Never put cartons, wooden blocks or similar
materials under the machine to balance irregularities
in the level of the ground.
X4X4
1 2
X4
3 4
5
6
X4

Installing your washing machine
Bringing it all together
Installing your <washing machine> 15
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
Connections
Water inlet hose connections
Important: This washing machine MUST only be
connected to a cold water supply.
a: Connect the water inlet hose, the angled
connection attaches to the water inlet on the back of
the washing machine. (7)
b: The straight connection attaches to the water supply
valve. (8)
c: Ensure all seals are in place before connecting.
Important: Only tighten the hose connection nut by
hand - do not overtighten.
Drain hose connections
Important: The height of the top of the curve in the
drain hose MUST be between 60 - 100cm from the
floor. (9)
Important: The end of the water drain hose may be
fitted directly to the waste water outlet hole or a special
apparatus mounted on the outlet bracket of the wash-
stand.
Important: Never attempt to extend the water drain
hose by adding extra parts.
Electrical
Any electrical work that is required
to install this washing machine
MUST be carried out by a qualified
electrician.
THIS APPLIANCE MUST BE
EARTHED
Before making any electrical connections, ensure that:
• The power socket is suitable for the maximum power
of the washing machine (fuses in the power circuit
must be 13 amp).
• The supply voltage should be the same as that
indicated in the technical specifications and the
appliance rating plate (located where shown).
• The appliance should be earthed and in compliance
with the applicable law.
• Additional earth cables should not be necessary if the
plug and socket are earthed. If necessary, an additional
earth cable should be attached to the earth terminal on
the back of the washing machine and earthed.
• When installed, the power socket must be within easy
reach.
• The use of adapters, multiple connectors or extension
cables are not recommended.
• The appliance must be connected to a 220-240 volt
50 cycle AC supply by means of a three pin socket,
suitably earthed and protected by a 13 amp fuse.
• Should the fuse need to be replaced, a 13 amp fuse
approved to BS1363/A must be used.
• The plug contains a removable fuse cover that must
be refitted when the fuse is replaced. If the fuse cover
is lost or damaged, the plug must not be used until
a replacement cover has been fitted or the plug is
replaced.
• A damaged plug should be cut off as close to the
plug body as possible, the fuse should be removed and
the plug disposed of safely.
87
9

Installing your washing machine
Bringing it all together
Installing your <washing machine>
16
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
Plug replacement (UK & Ireland only)
Should you need to replace the plug; the wires in the
power cable are coloured in the following way:
Blue – Neutral ‘N’
Brown – Live ‘L’
Green & Yellow – Earth ‘E’
The green & yellow wire must be connected to the
terminal in the plug that is marked with the letter E or
by the earth symbol.
The blue wire must be connected to the terminal that
is marked with the letter N.
The brown wire must be connected to the terminal
that is marked with the letter L.
If the power lead is damaged, it must be replaced by a
qualified electrician.

Functions 4

Functions
Simple everyday use
Functions18
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
Programme selection knob
For you to select different washing programme.
Auxiliary functions setting
Press the button repeatedly to set the Delay
time. Temperature, speed and so on.
Start/Pause
Press the button to start
or pause the wash cycle

Functions
Simple everyday use
Functions 19
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
WASHING SEQUENCE
• Plug your machine into the mains power supply.
• Open the water tap.
• Open the washing machine door.
• Load your items of clothing into the drum, ensuring
they are loosely packed.
• Push the door of your machine until you hear the
locking sound to close it.
Selecting programme
Select the programme appropriate for your laundry
from the programme table (Page-22).
EXTRA FUNCTIONS
Before starting the programme you can optionally
select an extra function.
• Press on the button of extra function you would like
to select.
• If an auxiliary function symbol on the electronic
display flashes continuously, the extra function you
have selected will be activated.
• If an extra function symbol on electronic display
blinks, the extra function you have selected will not be
activated.
Reason for non-activation:
• The extra function you want to use in the washing
programme you have selected is not applicable.
• Your machine has passed over the stage, during
which the extra function you would like to select
would be implemented.
• It is not compatible with an extra function you have
selected previously.
1- Temperature selection
You can select the washing water temperature with the
washing water temperature selection button.
Whenever you select a new programme, the maximum
washing water temperature is shown on the washing
water temperature selection.
You can gradually decrease the washing water
temperature between the maximum temperature
and cold washing (--) by pressing washing water
temperature selection button.
If you have missed the washing water temperature you
wanted, you can return to the intended temperature by
continuously pressing the washing water temperature
selection button.
2- Spin Speed Selection
You can set the spin revolution for your laundry via
spin speed button.
When you select a new programme, the maximum
spin revolution speed of the programme you have
selected will be viewed on the display of revolution
speed.
You can gradually reduce the revolution speed
between cancel spinning (--) options through the
maximum spin revolution of the programme selected
by pressing revolution spin speed button.
Temperature
Selection

Functions
Simple everyday use
Functions20
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 257 7271.
pressing on the delay timer button.
If you want to cancel the time delay, you are required
to press the time delay button once. symbol will
no longer flash on electronic display.
To run time delay function, your machine needs to be
operated by pressing on Start/Pause button.
4- Extra Rinse
Select this function by pressing the Extra Rinse button
when the Extra Rinse indicator is displayed.
You may make the programme active by pressing the
extra rinsing auxiliary function button when the LED
light of the symbol turns on.
If you have skipped the spinning revolution you want to
set, you can re-switch to the revolution by keeping the
revolution setting button pressed.
3- Delay timer
Instead of starting the programme immediately you
can set the programme to start automatically after a set
period of time. This time can vary from an hour to 23
hours.
To use the auxiliary function of delay timer:
1- Press delay timer button once.
2- “1 h” will appear on the display. - Symbol will
flash on the electronic display.
3- Repeatedly press the delay timer button until the
desired number of hours delay are shown on the
display.
4- To activate the timer delay press on any auxiliary
function button except the “Start/Pause” button.
If you have skipped the time delay you wanted to
set, you can go back to the time desired by keeping
Extra Rinse
Spin Speed
Delay Timer
