C3 Custom Coolers ROVER Operating and maintenance instructions

1.
See Owner’s Manual and assembly videos on
www.c3customcoolers.com/p/ownersmanual
2.
• Install batteries in remote
• Switch cooler power to OFF position
• Hold down Pairing Button until LEDs flicker, continue holding
• Turn cooler ON (the motor will buzz when paired)
• Release Pairing Button
3.
1.
2.
3.
Before first use, you MUST
If you experience any issues, please
complete the steps below prior to
contacting customer service
complete the steps below!
Pairing Button
See inside of this Quick Start Guide
Rough shipping & handling may loosen electronics connections
• Switch cooler power to OFF position
• Remove four screws attaching large, plastic access panel
• Ensure all wire connectors are tightly connected
• Replace access panel
See Owner’s Manual: www.c3customcoolers.com/p/ownersmanual
Do not return product to store. Contact customer support
for assistance at 1-844-723-4909 or [email protected].
Assemble Wheels
Pair Remote to Cooler
Charge Battery 10-12 hrs
Complete quick start steps
Check connections
Refer to troubleshooting guide
Remote Control Cooler
Applies to Models: ROVER, TRUCK, ZAMBONI
Styles and Colors May Vary
Designed, Molded and Assembled in the USA
Reference full owner’s manual at
WWW.C3COOLER.COM/P/OWNERSMANUAL
MAXIMUM LOAD CAPACITY 60 LBS
DO NOT SIT ON COOLER
Quick
Start Guide
FULL
MANUAL
ONLINE

Attaching Wheels
Tools required: Phillips head screwdriver, wrench or needle nose pliers
Assembly time: 10 minutes
Assembly
Step 7
Line up notches on hubcaps with
notches on wheels.
Gently press hubcaps to snap
into place.
Step 5
Place cooler body upside down
on a non-abrasive, clean surface.
Remove rubber band from
rear gear box assembly.
place, slide rear axle through
gear boxes.
remove rubber
band
Step 6
Place a wheel on left rear axle,
then a washer.
wheel faces out as shown and
Insert (1) cotter pin through the
axle to secure wheels.
Using needle nose pliers, bend
back longer end of cotter pin to
secure.
Repeat for right rear axle.
insert pin &
bend back
Step 1
Insert front axle assembly as shown
.
Insert (1) cotter pin in both bottom
ends of front axle assembly.
Using needle nose pliers, bend back
longer end of cotter pin to secure.
Parts
Step 2
Insert steering rod into gear
box.
Using a Phillips head
screwdriver and wrench,
secure steering rod in place
with bolt and lock nut.
Step 4
Line up notches on hubcaps
with notches on wheels.
Gently press hubcaps to
snap into place.
Step 8
Pair cooler remote.
Refer to back page.
Step 9
Charge battery for 12 hours.
(6) Cotter
pins
(4)
Wheels
(4)
Hubcaps
(1) Front axle assembly
(1) Front
steering rod
(1) Rear axle rod
(6)
Washers
(1)
Lock nut
(1) Bolt
Step 3
Place a washer on left
front axle, then wheel, then
another washer.
wheel faces out as shown.
Insert (1) cotter pin through
axle to secure wheels.
Using needle nose pliers,
bend back longer end of
cotter pin to secure.
Repeat for right front axle.
insert pin &
bend back
