Caimore CM520-8AW User manual

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
1
1
Caimore GPS Vehicle 3G/4G WIFI
Router User Manual
Copyright:
All information in this user manual is protected by copyright law. Whereby,
no organization or individual shall copy or reprinted the whole or part of this
user manual by any means without written authorization from Xiamen Caimore
Communication Technology Co.,Ltd.
Trademarks :
Caimore, , & CAIMORE are all registered trademarks of Xiamen
Caimore Communication Technology Co.,Ltd. Other trademarks mentioned in
this manual belong to other organizations related. Xaimen Caimore
Communication Technology Co.,Ltd does not own the right of other trademarks
and logos.
Notice:
Due to product updates or functional upgrading, we may renew the content
of this file, and this file only for reference. All the statements, information,
recommendations, etc. in this file do not compose any form of guarantee and
we Caimore reserves the right of final explanation.

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
2
2
Revision History:
Version
Description
Date
Author
Issue
V1.0
Primarily Released
2008.10.17
linjh
V2.0
Adjusted WEB
configuration whole style
Supported 3G gateway
2009-12-25
Lenev
V2.1
Updated, add new
functions.
2011-11-18
linjh
V3.0
Updated, directions of
the support and snmp
functions for 4G
2013-9-17
lijh

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
3
3
Contents
Chapter 1 Product Introduction.....................................................................................................5
1.1 Product Overview：.......................................................................................................... 5
1.2 Product Appearance and Accessories：.......................................................................6
1.3 Product Features：........................................................................................................... 7
1.4 Software Functions：....................................................................................................... 9
1.5 Specification：................................................................................................................. 10
1.6 Indicator：........................................................................................................................ 15
Chapter 2 Installation.................................................................................................................... 16
2.1 Packing List...................................................................................................................... 16
2.2 Product Introduction........................................................................................................16
2.3 SIM Card Installation...................................................................................................... 19
2.4 Antenna Installation.........................................................................................................19
2.5 RJ45-DB9F Instruction................................................................................................... 20
Chapter 3 Rapid Configuration.................................................................................................... 21
3.1Inset SIM card into gateway SIM card socket（reference 2.3）（refer 2.3）. 21
3.2、Connect antenna（refer 2.4）................................................................................... 21
3.2.1、Connect gateway with PC hardware..................................................................... 21
3.3、PC Network settings（(Set IP address, Gateway, DNS）....................................21
3.4、Setup WAN Parameter................................................................................................ 23
3.5、Setup DNS.....................................................................................................................24
3.6、Device Online Testing..................................................................................................28
Chapter 4 Detailed Parameter Configuration............................................................................28
4.1 Basic Configuration.........................................................................................................29
4.1.1 WAN Configuration.............................................................................................. 29
4.1.2 PPPOE Configuration......................................................................................... 30
4.1.3 LAN Configuration............................................................................................... 31
4.1.4 WIFI Configuration...............................................................................................32
4.1.5 DHCPD Configuration.........................................................................................35
4.1.6Dynamic Domain Name Server (DDNS) Configuration................................. 36
4.1.7Keep Online (make sure to select one kind online maintenance solution).39
4.2 Advance Configuration................................................................................................... 41
4.2.1 IPTABLE Filter...................................................................................................... 41
4.2.1.1 IP Filter Rule Configuration.............................................................................42
4.2.1.2 MAC Filter Configuration..............................................................................45
4.2.2 NAT/DMZ Configuration......................................................................................46
4.2.3Router Configuration............................................................................................ 47
4.3 VPN Configuration...........................................................................................................48
4.3.1 GRE........................................................................................................................48
4.3.2 PPTP...................................................................................................................... 49

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
4
4
4.3.3 IPSEC.................................................................................................................... 51
4.3.4 L2TP.......................................................................................................................53
4.4 System Management......................................................................................................53
4.4.1Time Management................................................................................................ 53
4.4.2 User Management............................................................................................... 54
4.4.3 System Status...................................................................................................... 55
4.4.4 Software Upgrade................................................................................................55
4.4.5 System Debug......................................................................................................56
4.5 Internet Access Management.......................................................................................57
4.5.1 Local Push..........................................................................................................57
4.5.2 WIFI Dog Configure...........................................................................................58
4.5.3 Application Filtering...........................................................................................59
4.5.4 Followed Ads......................................................................................................59
4.5.5 Battery Power Feature configure.....................................................................60
4.5.6 GPS Function.....................................................................................................60
4.6 Other Configurations.......................................................................................................62
4.6.1 Activation Mode.................................................................................................... 62
4.6.2 Bandwidth Management.....................................................................................67
4.6.3 connecting device（MAC address binding）................................................. 67
4.6.4 Other Configurations........................................................................................... 68
4.6.5 Timing Restart...................................................................................................... 68
4.6.6 DTU Configuration .............................................................................................. 69
4.6.7 SNMP Configuration............................................................................................72
Chapter 5 FAQ................................................................................................................................73
1、Frequent on/off line......................................................................................................... 73
2、Forgot password ............................................................................................................. 73
3、LAN indicator is off.......................................................................................................... 73
4、Can ’t dial-up to be online.............................................................................................. 73
5、Dial-up to be online, but can’t visit website................................................................. 73
Appendix 1 Login gateway by Telnet......................................................................................... 74
Appendix 2 Login gateway by hypertrm.....................................................................................75
Appendix 3 Obtain debug information from syslogd server....................................................78
Appendix 4 Restore default setting............................................................................................. 79
Appendix 5 Wireless network basic information ..................................................................... 80
Appendix 6 Obtained DNS setting according to gateway....................................................... 80

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
5
5
Chapter 1 Product Introduction
1.1 Product Overview：
CM520-8AX series WIFI router is cellular terminal devices that support
WIFI (802.11 a/b/g/n) and 3G/4G wireless network.
Meanwhile it loads WAN VPN secure tunnel and WIFI LAN authentication
of transmission and other security features of wide area network VPN secure
tunnel and WIFI LAN transmission. It has realized the function of QOS, SNMP
remote management, support QQ, wechat, microblog, a key certification and
variety of authentication access, local media watch, remote multimedia batch
update, reports statistics advertisement push, broadband management, WIFI
backstage management, online behavior management, GPS positioning, GPS
accurate advertisement push. Of course, they also have achieve seamless
connection between LAN and wireless WAN, providing users with a
high-speed, secure, reliable mobile broadband service.
Currently, it has been widely used in vehicle, small and medium-sized
enterprise, home wireless networking, and kinds of public facilities. Such as
city bus, coach, tour bus, shopping malls, exhibition halls, hotels, etc.
This user manual is suitable for the following models:
CM520-8AW(WCDMA Vehicle WIFI Router)
CM520-8AS(TD-SCDMA Vehicle WIFI Router)
CM520-8AE(CDMA2000-EVDO Vehicle WIFI Router)
CM520-8AH(HSPA+ WIFI Vehicle WIFI Router)
CM520-8AF(FDD WIFI Vehicle WIFI Router)
CM520-8AT(TDD WIFI Vehicle WIFI Router)
1.2. WIFI vehicle products Appearance and
Accessory

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
6
6

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
7
7
Power
Optional DC
Ethernet Cable
Optional
adaptor
(Note ：The power accessories for WIFI Vehicle device are using three
vehicle power supply cables---red, yellow and black. The red is positive and
connect the ACC,the black is negative, and the yellow is positive and
connect the battery with the voltage range of 7V-33V.If you want to have
other indoor tests, please use the power adapter and connect to the DC with
vehicle cable.)
1.3 Product features：
Industrial Design
Industrial CPU: Industrial CPU: industrial high-performance
embedded processor, 533MHZ, with 16KB Dcache, high-speed cache
data speed up data access , with 32KB Icache, high-speed instruction
cache, enhanced instruction processing speed.
Industrial wireless module: using industrial wireless module, strong
interference rejection, and stable transmission.
Real-time operating system: using LINUX2.6 operating system
with memory management unit, real-time, upgrades fast, stable system
with improved TCP / IP protocol stack.
Strengthened circuit board: PCB followed the principles of of 3H
and 3W,, meanwhile the circuit boards of all products used high-quality

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
8
8
materials to ensure the board materials stable and reliable.
Industrial components: the machine adopts strictly screened
industrial components.
Industrial Power: Wide voltage power supply design, adaptive range
of power is from DC5V to DC35V, built-in power reverse supply
protection and over-voltage and over-current protection
Electromagnetic protection: built-in 1.5KV magnetic isolation
protection at Ethernet interface
Anti-jamming design: metal shell, shield electromagnetic interference,
the system protection grade IP30; antenna with lightning protection
design; ultra-low and ultra-high temperature system design;
particularly suitable for harsh industrial environments
Stable and reliable
Online maintenance patents: Intelligent anti-dropped, online testing,
online maintenance, automatically reset to ensure that equipment is
always online.
Three-tier system protection: based on the original two protection
functions (software protection +WDT + CPU built-in protection), the
system increased a detection and protection function of VWM (Virtual
Man Watch), if it appears that the network is abnormal or system
receives Strong interference anomaly, the system will auto reset, which
thoroughly solve the problem that it needs maintainer to pull out
electric when the system appears abnormally in the industry, and
ensure that the system is stable and reliable.
UIM / SIM card ESD protection: 1.8V/3V/5V standard putter user card
interface, built-in 15KV ESD protection.
Serial ports ESD protection: serial port RS232, built-in 15KV ESD
protection.
Metal shell: Strong anti-interference ability, meanwhile has shielding
effect and radiation protection, protection grade is IP31.
All wireless modules are certified by the CGD or FCC certification
or CE certification.
High-speed processing CPU: ARM9 industrial-grade high-speed
CPU, can handle a variety of protocol data conversions at higher
speed; solve the difficult problems ,such as, "fake online", "fake death",
"crash" etc
MMU：New type CPU with MMU，to prevent the system unstable when
it appears abnormally.
Large memory: FLASH 128Mbits, SDRAM 1Gbits, a large memory
to cache data sent by customer, meanwhile receiving large packets, no
data lose.
Complete protocol stack: the new system loaded complete TCP / IP
protocol stack, using comprehensive TCP / IP protocol stack; so that
network traffic performance shows outstanding, and the drop-line
probability dramatically reduced.
EMC performance outstanding: Obtained CE Certification ; passed
China detection department test , EMC test and 3000V electrical shock

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
9
9
test, especially suitable for use under harsh industrial environments;
system EMC / EMI performance excellent, system stable and reliable.
Easy to use
Using Factory default configuration parameters, customers only
need to modify some parameters, even no need to change any
parameter, you can quickly use the equipment
Graphical configuration tool: improved graphical configuration tool
that provides rapid deployment capabilities for customers to achieve
rapid deployment; provides mass configuration.
Product manual offers quick configuration instructions, you can
quickly use the equipment
Software checking : Provides SYSLOG log output function, can be
used as equipment work logs and help to analyze the reasons for
exceptions; Provides the serial port debugging log, providing different
levels of debugging output, enabling customers to view a variety of
information, quickly locate the problem.
After eight years of sedimentation, the function of equipment is very
completed and easy to use.
1.4 Software Functions：：
Support WIFI (802.11 b/g/n) and wireless network function,the
system loaded wide area network communication VPN tunnel, WIFI
LAN transmission security authentication and other security features,
to achieve seamless connectivity between wireless LAN and wireless
WAN. Providing users with high-speed, secure, reliable mobile
broadband services.
Provides a standard WAN, supports PPPOE, can directly connect to
ADSL equipment and other leased line
Support backup function for 3G wireless link and broadband link, if
cannot communicate in 3G, it will auto switch to PPPOE broadband
and vice versa.
Support wireless video monitoring and dynamic image transmission
Supports Ethernet data communication and packet forwarding, also
supports serial port TCP / UDP transparent data transmission or serial
configuration
Support VPN tunnel, including PPTP, MPPE, L2TP, GRE and IPSEC
Intelligent anti-dropped, support online testing, online maintenance,
automatic redial, ensure the equipment is always on-line
Support IPTABLES firewall, packet filtering
Support Regular on-line offline functionality, can set the device
on-line and offline in a certain period of time
Support timer switch function
Support dynamic routing and static routing, RIPv1, RIPv2, OSPF,
BGP, NDSP, IRMP, SNSP, IGMP, DVMRP, PIM-SM/DM
Support multiple protocols:TCP/IP，UDP，ICMP，SMTP，HTTP，
POP3，OICQ，TELNET，FTP etc.

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
10
10
Support WIFI WAP encryption ,built in WAP and WAP2.0,and 64 bits
and 128bits wep encryption, support WEP encryption and built in the
hardware security engine ,such as 802.11I 4.0 WEP(64 bits and
128bits) TKIP,AES and CCMP etc.
Mppe supports encryption of MPPE40 and MPPE128 and
encryption mode of stateful, IPSEC supports encryption algorithm of
DES、3DES、AES and AES128.
Support QOS bandwidth management.
Support Dynamic and static route
Support DHCP/DHCPD
Supports NAT port mapping function, such as SNAT, DNAT
Support DDNS(Dynamic Domain Name Server): support ORAY, 88IP,
and DYNDNS domain name service provider
Support DMZ
Support the APN / VPDN network
Convenient WEB configuration, support Remote WEB Management
Support WEB configuration save and restore to achieve the rapid
deployment parameters backup and batch of equipment
Support telnet management, user-friendly console shell interactive
environment
Support multiple terminals sharing router ppp wan
IP Support multiple wireless dial-up mode: automatically assigned,
specify the IP, specify local and remote IP
Support as a PPP server, multiple authentication methods, support
mutual authentication
Easy to use COM and SYSLOG System diagnostics, debugging
Support Serial port local software upgrades
Supports TFTP remote software upgrade
Support real-time clock
Support both LINUX and WINDOWS operating systems
Support local multimedia access, remote batch update
Support shadowing
support for SNMP remote management
support QQ, wechat, microblog, a key certification and variety of
authentication access.
support bandwidth management, down the line speed, total
bandwidth speed, user sharing mode
Support Bus Power Management
1.5 Specification：：
Cellular Parameters
Cellular
Network
Standard and
frequency
bnads
Communication
bandwidth
Transmit
power
Receiver
sensitivity

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
11
11
LTE-TDD/ HSPA+
/UMTS//HSDPA/
HSUPA/WCDMA/
EDGE/GSM
LTE TDD:
2600/2300MHz
UMTS:
2100/900MHz
GSM:
850/900/1800/1900
MHz
RxDiv Band:UMTS
2100/900MHz LTE
TDD 2600/2300MHz
LET TDD:DL 68Mbps/UL
17Mbps
DC_HSPA+:DL
42Mb/s(Category 24)
HSPA+:DL
28Mb/s(Category 18)
HSdPA:DL
14.4Mb/s(Category 8)
HSUPA+:DL
5.76Mb/s(Category 6)
WCDMA CS:UL
64kbps/DL 64kbps
WCDMA
PS:UL384kbps/DL384kb
ps
WCDMA/HSDP
A:24dBm
LET:23 dBm
<-109dBm
LTE-FDD/ HSPA+
/UMTS//HSDPA/
HSUPA/WCDMA/
EDGE/GSM
LTE FDD:
2600/2100/1800/DD
800MHz
UMTS:
2100/900MHz
RxDiv Band: UMTS
2100/900MHz LTE
FDD
LET FDD:DL
100Mbps/UL 50Mbps
DC_HSPA+:DL 42Mb/s
HSPA+:DL 28Mb/s
HSDPA: DL 14.4Mb/s
HSUPA+:DL 5.76Mb/s
WCDMA CS:UL
64kbps/DL 64kbps
WCDMA
PS:UL384kbps/DL384kb
ps
WCDMA/HSDP
A:24dBm
LET:23 dBm
<-109dBm
HSPA+
/UMTS//HSDPA/
HSUPA/WCDMA/
EDGE/GSM
Support
HSPA+/UMTS/HSD
PA/WCDMA
850/900/1900/2100
MHz
Dual-band EGSM
850/900/1800/1900
MHz
Support
GPRS/EDGE
CLASS 12
HAPA+ mode: download
speed 21Mbps,upload
speed 5.76Mpbs
HSDPA/HSUPA mode：
Downlink up to
7.2Mbps,Uplink up to
5.76Mbps
WCDMA mode：
Downlink/Uplink up to
384Kbps
<24dBm
<-109dBm

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
12
12
WCDMA/EDGE/G
PRS/CSD mode
Support
UMTS/HSDPA/WC
DMA
850/900/1900/2100
MHz
Dual-band EGSM
850/900/1800/1900
MHz
Support
GPRS/EDGE
CLASS 12
HSDPA/HSUPA
mode:Downlink up to
7.2Mbps,Uplink up to
5.76Mbps
WCDMA mode：
Downlink/Uplink up to
384Kbps
<24dBm
<-109dBm
TD-SCDMA/HSDP
A/HSUPA/EDGE/
GPRS mode
TD-SCDMA/HSDPA
/HSUPA ：
2010~2025MHz
GSM/GPRS/EDGE：
850/900/1800/1900
MHz
Support 3GPPclass
B
Downlink (Max up to
2.8Mbps) Uplink (Max up
to 384Kbps)
<24dBm
<-109dBm
IS-95 A/B,
CDMA2000
1XrTT,and 1X
EV-DO mode
Support IS-95 A/B,
CDMA2000
1XrTT,and 1X
EV-DO(Revision 0
and A)
single band
800MHz, optional
dual-band
800/1900MHz
single band 450MHz
Downlink ( up to
3.1Mbps ) Uplink ((up to
1.8Mbps )
<23dBm
<-107dBm

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
13
13
WIFI parameters:
Item
Content
WIFI module
WIFI module chip-embedded, high integration, good stability
WIFI standard
Support 802.11 b/g/n standard, speed，
Support 6M/9M/12M/18M/24M/36/48/54Mbps,up to 108M
Encryption
Supports WAP encryption, built-in WAP and WAP 2.0, Built-in 64-bit
and 128-bit WEP encryption, Support WEP encryption, built-in
802.11I 4.0 WEP (128-bit and 64-bit) TKIP, AES and CCMP and
other hardware security engine
AP mode
Support AP mode
Transmission distance
Outdoor non-stop, outdoor coverage up to 150 meters
GPS Parameters
ITEM
CONTENT
GPS Module
Use industrial GPS wireless module
Receiver type
Receive GPS,48 channels, Frequency L1 ,chip speed 1575.42MHZ,C/A
code,chip speed 1.023MHZ.
Positioning accuracy
Positioning:2.5m CEP SBAS:2.0m CEP
Speed accuracy
Speed accuracy < 0.01m/s（high speed）<0.01° (heading)，（ 50 % @
30 m/s ）
Capture time
Cold start: 35S,Auxiliar start <3S；Hot start：1S
Output information
NMEA,UBX BIN：GGA GSA GSV RMC VTG GLL
navigation data update rate
1Hz
sensitivity
Track:-163dBm;Navigation:-160dBm;Acquisition：-147dBm
Operating limit
Speed：500m/s Height：50000m
Hardware System：
Item
Content
CPU
industrial high-performance embedded processor, 320MHZ
MMU
CPU with MMU memory management unit, can prevent memory
overflow
FLASH
128Mbits
SDRAM
1GMbits
Dual TF Card
2*128G TF card

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
14
14
Operating System：
Item
Content
Operating system
Using LINUX2.6 operating system with memory management unit and real-time
feature, upgrades is very fast and system is stable；
Interface Type：
Item
Content
WAN port
One 10/100M self-adaption WAN port, built-in isolation, support Auto
MDI/MDIX; support PPPOE.
Ethernet port
Four 10/100 Base-T Ethernet port(LAN1-LAN4),support Auto MDI/MDIX;
built-in 1.5KV magnetic isolation protection
Serial Port
1 RS485 interface 1 or RS232 serial port (support RS422/TTL)
Data bit: 7,8 bit
Stop bits: 1, 2-bit
Parity: no parity, odd parity, even parity, SPACE and MARK parity
Baud rate: 300bps - 115200bps
Flow Control: None flow control
USB interface
one USB interface, USB2.0, HOST interface, speed at 12Mbps
I/O interface
Support 3 channel I/O interface, can apply to vehicle detection and
control; this function is optional and customized.
Indicator LED
Power indicator
SYS indicator
WIFI-2.4G indicator；
WIFI-5G indicator；
4G/3G online indicator
Antenna Interface
Standard SMA female interface, 50 ohm; optional 3M/5M/10M/15M
antenna extension cable, meet the different needs of customers
WIFI antenna
Parity: no parity, odd parity, even parity, SPACE and MARK parity
UIM interface
1.8V/3V/5V standard putter user card interface, built-in 15KV ESD
protection
Power Interface
Standard 3-pin power jack
RESET button
Reset button to restore factory settings
Power supply：

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
15
15
Item
Content
Supply voltage
Wide voltage design, DC 6V to the DC32V power supply directly to the
device; and built-in power supply has the over-voltage protection and reverse
current protection
Standard power
DC9V/1.5A
Communication Current
Average communication current : 390mA @ +9 VDC;
Communicating instantaneous peak current: 1.0A @ +9 VDC
Standby current
Standby average current: <56mA @ +9 VDC
Physical features：
Item
Content
Housing
Metal housing, anti-radiation, anti-interference; lightning protection
design;protection rating IP30; particularly suit for harsh industrial control
environments.
Product dimensions
167 * 104 * 26mm（not including the antenna and the fixed parts）
Packing Size
350*215*88mm
Weight
Other Parameters:
Item
Content
Operating Temperature
-25ºC ~+65ºC
Extended operating temperature
-35 ºC~+75ºC
Storage Temperature
-40~+85ºC
Relative Humidity
95%(No condensation)

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
16
16
1.6Indicator：
Indicator：
Chapter 2 Installation
2.1 Packing List
Thanks for using our communication products. When you open the product
box, please check inside the items consistent with the packing list. Factory
standard configuration in the box is as follows ：：
Gateway Host
1 Unit
RJ45-DB9 Serial Line
1PC
DC 9V Power Adapter
1 Unit
Network Cable
1PC
3G Antenna
1PC
WIFI Antenna
1PC
CD of User Manual
1PC
2.2 Product Introduction
Product Appearance：
Indicator
State
Description
Power
On
Power is Normal
Off
Power off
WAN
Off
WAN unconnected
On
WAN connected
Flash
Data transmitting and receiving
WIFI
Off
Disable WIFI
On
Enable WIFI
Flash
Data transmitting and receiving
COMM
Flash
Data transmitting and receiving
Off
No Data transmitting and receiving
Online
On
On line
Off
Off line

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
17
17
Picture 2-2-1
Front of Device：
图2-2-2
1Power Indicator ②WIFI Indicator ③COMM Communication
Indicator(not use now) ④ALARM Indicator(not use now) ⑤Online
Indicator(3G/4G/WAN Indicator)
Back of Device：
图2-2-3
1Restore to Default Setting Button ②Power Port ③
USB(NOT USE NOW)
④Port for test or debug ⑤Ethernet Port ⑥
WAN Port

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
18
18
2.3 SIM Card Installation
SIM cards store information of user ’s ID, telephone directory, network
settings, and additional services etc. Gateway supports 1.8V/3V/5V SIM card,
SIM card interface socket uses a drawer-type SIM card connector, and users
can easily install SIM card without open the chassis.
Installation method：：
Without electrifying device, please use a needle object to press on the out
button of SIM card outlet, SIM card sheath will flick out at once. Cover SIM
card with SIM card sheath. But you must pay attention to put the side which
has metal point of SIM card outside, and insert card sheath back to SIM card
outlet. See below of the picture:
Picture 2-3-1
Warning: forbid to pull out or insert SIM card with electricity.
2.4 Antenna Installation
Please turn SMA male connector clockwisely to be tight. Read below
picture:
Left is 3G antenna，Right is WIFI antenna.

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
19
19
Picture 2-4-1
2.5 RJ45-DB9F Instruction
This Gateway supports RS232 asynchronous communication serial
interface and adopts RJ45. Serial interface mainly used to configure control or
configure to be DTU function.
Com/line: RS232 asynchronous communication serial interface
RJ45-DB9F Conversion line signal connection as below mentioned: The
signal definition of DB9F Serial communication interface shows as below
mentioned:：
RJ45
DB9F
1
8
2
6
3
2
4
1
5
5
6
3
7
4
8
7
The signal definition of DB9F Serial communication interface shows

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
------------------------------------------------------------------------------
----------------------------------------
Tel:[phone] web:www.caimore.com/emain.asp
20
20
as below mentioned:
PIN
RS232 Signal
Name
Description
Direction relative
to
DTU
1
DCD
carrier wave
signal check
Output
2
RXD
receive data
Output
3
TXD
send data
Input
4
DTR
data
terminal ready
Input
5
GND
Power
reference
ground
6
DSR
data
device ready
Output
7
RTS
Request to
send
Input
8
CTS
Data device get
ready to receive
data
Output
Chapter 3 Rapid Configuration
We release this setting instruction in order to realize below mentioned two
points. First, When customer receives our device, they can check fast whether
the device is good or not, whether it can work normally or not. Second, Most
customer can use device fast by only changing setting parameters of this
setting instruction (other parameters are default setting). Take Window XP as
an example, let us explain our wireless industrial fast setting process.
Fast setting usually need to configure WAN parameter and LAN
parameter and keep other parameters as leaving-factory default setting. If
need to change other parameters, please read < chapter 4 Detailed
Parameters Configuration >
