Calix T073G HGU ONT User manual

T073G HGU ONT User Guide
November 2013
#220-00602, Rev 11

Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Contents
Chapter 1: Product Description .............................................5
Introduction................................................................................................................5
Services......................................................................................................................5
Features......................................................................................................................6
Specifications ............................................................................................................7
Chapter 2: Safety.....................................................................9
Electrical Safety.........................................................................................................9
Mounting Restrictions.............................................................................................10
Laser Safety .............................................................................................................10
Chapter 3: Installation...........................................................11
Get to Know the ONT ..............................................................................................11
Connecting to the PON Network ............................................................................12
Connecting Power ...................................................................................................13
Connecting to the AC Power Adapter .............................................................13
Connecting to an External UPS ......................................................................14
Connecting Telephone (POTS) Service .................................................................14
Connecting Ethernet Service..................................................................................15
Verifying the Installation.........................................................................................15
Activating the ONT..........................................................................................16
Verifying Services ...........................................................................................17

4
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Chapter 4: Troubleshooting .................................................19
ONT Status LEDs.....................................................................................................19
Troubleshooting Procedures..................................................................................21

Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Chapter 1
Product Description
Introduction
The T073G Optical Network Terminal (ONT) is an ITU-T G.984 compliant device that
receives voice, data, and video traffic in the form of optical signal from the service provider
Passive Optical Network (PON) and transmitted it to the desired format at residential or
business premises.
Upstream traffic is likewise transmitted to the PON network through the fiber optic cable. A
single optical fiber carries both upstream and downstream traffic.
Services
The T073G is equipped with ITU-T G.984 compliant 2.5 Gbps Downstream and 1.25 Gbps
Upstream interfaces, and the following service ports:
Four 10/100/1000 Base-T Gigabit Ethernet ports for high speed internet access and
IPTV/VOD services
Two POTS (VoIP) service ports for voice services
Integrated IEEE 802.11b/g/n wireless (Wi-Fi)
One USB host port

6
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Features
The ONT incorporates the following features:
Single fiber GPON interface with 1244 Mbps upstream and 2488 Mbps downstream data
rates
Advanced data features such as VLAN tag manipulation, classification, and filtering
Traffic classification and QoS capability
SIP-based Analog Telephone Adapter (ATA) function, which provides the different
classification services, and supports caller display, call waiting, call transfer, and call
forwarding
5 REN per line
Multiple voice Codec
Rich set of LED indications for alarming and maintenance
Built-in capability for remote management such as supervision, monitoring, and
maintenance

7
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Specifications
Physical Specifications
Dimensions Height: 47 mm (1.85 inch)
Width: 229 mm (9 inch)
Depth: 174 mm (6.85 inch)
Weight
640 g (1.4 lbs.)
GPON interface
SC/APC angled optical connector
POTS interface
RJ-11 connector
Ethernet interface
RJ-45 connector
Electrical Specifications
Input Power
+12 VDC power input
Power Supply
AC power supply with included power adapter
Power Consumption
< 14.4 W
Environmental Specifications
Temperature
Operating: 0° to +40°C (32° to 104°F)
Humidity
5% to 95% Relative Humidity (RH), non-condensing
Optical Specifications - Transmitter
Minimum Nominal Maximum Notes
Wavelength
1260 nm
1310 nm
1360 nm
Transmit power
0.5 dBm
+5 dBm
Optical Specifications - Digital Receiver
Minimum Nominal Maximum Notes
Wavelength 1480 nm 1490 nm 1500 nm
Sensitivity -28 dBm Minimum received power for
BER<10
-10
Overload -8 dBm Maximum received power for
BER<10
-10

8
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.

Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Chapter 2
Safety
Read and follow all warning notices and instructions marked on the product or included in
its packaging, and observe all safety instructions listed in this guide while handling any ONT.
Electrical Safety
Always use caution when handling live electrical connections.
Do not install electrical equipment in wet or damp conditions.
Ensure that the power source for the system is adequately rated to assure safe operation
and provides current overload protection.
Do not allow anything to rest on the power cable, and do not place this product where
people will stand or walk on the power cable.
To avoid electric shock caused by over-voltage from the PSTN, DO NOT connect the
POTS port on this unit directly to any external PSTN line.
This unit must only be used with the certified power adapter model inside the package,
which complies with the requirement of a limited power source.

10
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Mounting Restrictions
Follow the mounting restrictions below to ensure the ONT works safely:
Do not stack ONTs or stack ONTs on top of other equipment.
Ensure there is a minimum of 100 mm (4") clearance directly above the top cover of the
unit.
Ensure there is a minimum of 50 mm (2") clearance next to the side vent of the unit.
Ensure there are no external heat sources directly above or below the unit.
Laser Safety
Caution! Use of controls or adjustments, or performance of procedures
other than those specified herein may result in hazardous laser radiation
exposure.Invisible laser radiation may be emitted from the ends of un-
terminated fiber cables or connectors. Never look directly into an un-
terminated cable or connector.
Note: This ONT uses a Class 1 laser device.
Danger! Personnel handling fiber optic cables must be trained for laser
safety.
Caution! Do not bend the fiber optic cable to a diameter smaller than 7.5
cm (3 inches). Doing so may damage the fiber or prevent the signal from
passing through properly.
