Camco 16 User manual

Refrigerators
Top-mount no-frost
PEPSI PEPSI PEPSI
PEPSI
FullDay's
FullDay's
Supplyof
Supplyof
FullDay's
FullDay's
Supplyof
Supplyof
Part No. 350A4661P001
Cat. No. WR6M426
4/99
Models 16 & 18
Owner’s Manual
Pub. No. 31-47004

CUSTOMER WARRANTY
Your refrigerator is warranted to be free of defects in material and workmanship.
Parts
How Long Warranted Repair or Replace
What is Covered (From Date of Sale) at CamcoÕs Option Labour
Compressor Ten (10) Years Ten (10) Years Five (5) Years
Sealed System (including Five (5) Years Five (5) Years Five (5) Years
evaporator, condenser,
tubing and refrigerant)
All Other Parts One (1) Year One (1) Year One (1) Year
TERMS AND CONDITIONS
1. This warranty applies only for single family domestic use in Canada when the Refrigerator
has been properly installed according to the instructions supplied by Camco and is
connected to an adequate and proper utility service.
Damage due to abuse, accident, commercial use, and alteration or defacing of the serial
plate, cancels all obligations of this warranty.
Service during this warranty period must be performed by an Authorized Camco Service
Agent.
2. Neither Camco or the Dealer is liable for any claims or damages resulting from the failure
of the Refrigerator or from service delays beyond their reasonable control.
3. To obtain warranty service, purchaser must present the original Bill of Sale. Components
repaired or replaced are warranted through the remainder of the original warranty
period only.
4. This warranty is in addition to any statutory warranty.
WHAT IS NOT COVERED:
••Service trips to your home to teach you how to use the product.
• Damage to finish after delivery.
• Improper installation, proper installation includes adequate air circulation to the
refrigeration system, adequate electrical, plumbing and other connecting facilities.
• Replacement of house fuses or resetting of circuit breakers.
• Replacement of light bulbs.
• Damage to product caused by accident, fire, floods or acts of God.
• Loss of food due to spoilage.
• Proper use and care of product as listed in the customer’s manual; proper setting of
controls.
• WARRANTOR IS NOT RESPONSIBLE FOR CONSEQUENTIAL DAMAGES.
IMPORTANT: Keep this warranty and your bill of sale as proof of original purchase and
purchase date.
Camco Service is Available Coast to Coast.
If further help is needed concerning this warranty, contact:
Manager, Consumer Relations
Camco Inc., Consumer Service
1 Factory Lane
Suite 310
Moncton, New Brunswick
E1C 9M3
2

Camco Service
Satisfied with Service?
We want you satisified with our service. If you have reason to be concerned with
the service you received on your appliance, here are two steps you should follow
for service satisfaction.
First: Contact the people who serviced your appliance. Explain your reason for
complaint. In most cases, this will solve the problem.
Finally: If your problem is still not resolved, write, being sure to include all the
details, such as model, serial number, date of purchase as well as your phone
number to:
Manager, Customer Relations
1 Factory Lane
Suite 310
Moncton, New Brunswick
E1C 9M3
Where to Call for Camco Service
Camco service is available coast to coast. Simply phone [phone] to arrange
for service.
EXTENDED SERVICE CONTRACTS
Your new refrigerator is a well designed and engineered product. Before it left
the factory, it went through rigorous tests, just to make sure it was as problem free
as possible. And you have a warranty to protect you against any manufacturing
problems that may occur during the period of your appliance warranty.
Now you can have the same trouble-free and surprise-free service for as long as
you own your appliance. While your warranty is still in effect, you can purchase a
CAMCO SERVICE CONTRACT. For one low fee... usually just pennies a day...
Camco Customer Service will take care of the repairs your appliance needs – both
parts and labour.
You are protected for the life of your contract. Even when costs go up, you pay
nothing more.
Want more information? There’s no obligation. You can obtain information on
Service Contracts any time. Just call 1-800-461-3636.
Manager, Service Contracts
1 Factory Lane
Suite 310
Moncton, New Brunswick
E1C 9M3
3
Operating InstructionsInstallation Instructions Troubleshooting TipsSafety InformationCustomer Service

Safety Information
Safety Precautions . . . . . . . . . . .6
How to Connect Electricity . . . . .8
Use of Extension Cords . . . . . . .8
Operating Instructions
Temperature Controls . . . . . . . .17
Features . . . . . . . . . . . . . . . . . . .20
Automatic Icemaker . . . . . . . . .25
Care and Cleaning . . . . . . . . . .26
Installation Instructions
Preparing to
Install the Refrigerator . . . . . . . .9
Reversing the Door Swing . . . .11
Troubleshooting Tips
Normal Operating Sounds . . . .29
Before You
Call For Service . . . . . . . . . . . . .34
Customer Service
Warranty . . . . . . . . . . . . . . . . . . .2
Extended Service
Contracts . . . . . . . . . . . . . . . . . . .3
4
AService Partnership.
Inside you will find many
helpful hints on how to use and
maintain your refrigerator
properly. Just a little preventive
care on your part can save you a
great deal of time and money
over the life of your refrigerator.
Read this Manual
Ask any Camco appliance owner and they
will tell you we stand behind our products
with unmatched quality service. However,
did you know that most questions result
from simple problems that you can easily fix
yourself in just a few minutes? This
Owner’s Manual can tell you how.
You’ll find many answers to
common problems here.
If you review our chart of
Troubleshooting Tips first, you
may not need to call for service
at all.
Review the Section on
Troubleshooting Tips
If you do need service, you can
relax knowing help is only a
phone call away. A list of toll-
free customer service numbers
is included in the back section.
You can call the Camco Answer
Centre at 1-800-361-3400
24 hours a day, 7 days a week.
If You Need Service

Help Us Help You
We’re proud of our quality
products and we are
committed to providing
dependable service. You’ll
see it in this easy-to-use
Owner’s Manual and you’ll
hear it in the friendly
voices of our customer
service department.
Best of all, you’ll
experience these values
each time you use your
refrigerator.
That’s important, because
your new refrigerator will
be part of your family for
many years. And we hope
you will be part of ours for
a long time to come.
We appreciate your
purchase, and hope you
will continue to rely on us
whenever you need quality
appliances for your home.
5
Important!
Staple sales slip or cancelled
check here.
Proof of the original purchase date
is needed to obtain service under
the warranty.
Write the model and serial
numbers here.
#
#
You can find them on a label on the
left side, near the top of the fresh food
compartment.

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
6
Use this appliance only for its intended purpose as
described in this Owner’s Manual.
■Before it is used, this
refrigerator must be
properly installed and
located in accordance with
the Installation Instructions
in this manual.
■Do not allow children to
climb, stand or hang on the
shelves in the refrigerator.
They could damage the
refrigerator and seriously
injure themselves.
■Never touch cold surfaces in
the freezer compartment,
especially when your hands
are damp or wet. Your skin
may stick to these extremely
cold surfaces.
■Keep fingers out of the
"pinch point" areas between
the doors and between the
doors and cabinet. Be
careful closing doors when
children are in the area.
■If your refrigerator model
has an automatic icemaker,
avoid contact with the
moving parts of the ejector
mechanism or with the
heating element that
releases the ice cubes. Do
not place fingers or hands
on the automatic icemaking
mechanism while the
refrigerator is plugged in.
■When moving your
refrigerator away from the
wall, be careful not to roll
over or damage the power
cord.
■Repair or replace
immediately all electric
service cords that are frayed
or damaged. Never use a
cord that shows cracks or
abrasions, either on the
cord or at the plug or
connector end.
■Never unplug your
refrigerator by pulling on
the power cord. Always grip
plug firmly and pull straight
out from the outlet.
■Unplug the refrigerator
before cleaning and making
repairs.
■Before replacing the
burned-out appliance bulb,
power to the refrigerator
should be disconnected at
the fuse box or circuit
breaker in order to avoid
contact with a live wire
filament which can happen
if the old light bulb breaks
when being unscrewed.
Note:Turning the control to
the "OFF" position does not
remove power to the light
circuit.
■Do not operate your
refrigerator in the presence
of explosive fumes. Do not
store or use gasoline or
other flammable vapours
and liquids in the vicinity of
this or any other appliance.
Note: We strongly
recommend that any
servicing be performed by a
qualified individual.
Safety Precautions
When using electrical appliances, basic safety precautions
should be followed, including the following:
WARNING!
Safety Information
Installation Instructions Customer ServiceOperating InstructionsTroubleshooting Tips

7
Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are
still dangerous, even if left "for just a few days". If you
are getting rid of your old refrigerator, please follow
the instructions below to help prevent accidents and
pollution.
Before You Throw Away Your Old Refrigerator
or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may not
easily climb inside.
CFC Disposal
Your old refrigerator has a cooling system that used
CFCs (chlorofluorocarbons). CFCs are believed to
harm the earth's stratospheric ozone layer. Your new
refrigerator uses a new refrigerant that does not
destroy ozone. If you are throwing away your old
refrigerator, make sure the CFC refrigerant is
removed by a qualified servicer for proper disposal. If
you intentionally release this CFC refrigerant you can
be subject to fines and/or imprisonment under
provisions of provincial environmental legislation
respecting ozone depleting substances.
Operating InstructionsInstallation Instructions Troubleshooting TipsSafety InformationCustomer Service
DANGER!
Risk of Child Entrapment

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
8
How to Connect Electricity
Do not, under any circumstances, cut or remove the third
(ground) prong from the power cord. For personal safety,
this appliance must be properly grounded.
The power cord of this appliance is equipped with a 3-prong
(grounding) plug which mates with a standard 3-prong
(grounding) wall outlet to minimize the possibility of electric
shock hazard from this appliance.
Have the wall outlet and circuit checked by a qualified electrician
to make sure the outlet is properly grounded.
Where a standard 2-prong wall outlet is encountered, it is your
personal responsibility and obligation to have it replaced with a
properly grounded 3-prong wall outlet.
The refrigerator should always be plugged into its own individual
electrical outlet (115 V-60 Herts, single phase AC) which has a
voltage rating that matches the rating plate.
This provides the best performance and also prevents
overloading house wiring circuits which could cause a fire hazard
from overheated wires.
Never unplug your refrigerator by pulling on the power cord.
Always grip plug firmly and pull straight out from the outlet.
Repair or replace immediately all power cords that have become
frayed or otherwise damaged. Do not use a cord that shows
cracks or abrasion damage along its length or at either end.
When moving the refrigerator away from the wall, be careful not
to roll over or damage the power cord.
WARNING!
Using Extension Cords
Because of potential safety hazards under certain
conditions, we strongly recommend against the use of an
extension cord.
However, if you must use an extension cord, it is absolutely
necessary that it be a CSA listed, 3-wire grounding type
appliance extension cord having grounding type plug and
outlet and that the electrical rating of the cord be 15 amperes
(minimum) and 120 volts.
SAVE THESE INSTRUCTIONS
Safety Information
Installation Instructions Customer ServiceOperating InstructionsTroubleshooting Tips

9
Preparing to install the refrigerator.
Read these instructions completely and carefully.
Water Supply to the Icemaker (on some models)
You will need to connect your icemaker to a cold water line. A
water supply kit containing copper tubing, shutoff valve, fitting
and instructions is available at extra cost from your dealer.
There should be sufficient tubing for the icemaker from the
cold water supply to allow moving the refrigerator out from the
wall several feet. (You will need approximately 3 coils of 1/4
inch copper tubing that measures at least 25 cm (10") in
diameter.
Install the refrigerator on a floor strong enough to
support it when it is fully loaded.
Do not install refrigerator where temperature will go
below 16°C, 60°F because it will not run often enough to
maintain proper temperatures.
Refrigerator Location
Allow the following minimum clearances for ease of installation
and proper air circulation:
Sides.……2 1/2 cm (1") Top……10 cm (4") Back*……8 cm (3")
*(measure from back surface of cabinet to wall)
If refrigerator is to be installed against a wall on the hinge side,
allow a minimum of 4.5cm (l 3/4") between the wall and the
side of the refrigerator to allow for door and handle clearance.
Clearances
Consider providing a water supply to the refrigerator
location. It will simplify connecting of an optional
automatic icemaker should you wish to install one at a
later date.
When Building a New Home
Operating InstructionsInstallation Instructions Troubleshooting TipsSafety InformationCustomer Service

10
Preparing to install the refrigerator.
Your refrigerator comes with either adjustable rollers or
adjustable legs. Either rollers or legs should be set so the
refrigerator is firmly positioned on the floor and the front is
raised just enough that the doors close easily when opened about
halfway.
To adjust rollers for levelling remove the base grille. Turn the two
front roller adjusting screws counterclockwise to raise the
refrigerator, clockwise to lower it using an adjustable wrench.
Adjustable legs are located at the front corners. Turn the
adjustable leg clockwise to raise the refrigerator and counter
clockwise to lower it.
Levelling Your Refrigerator
Adjustable Roller
Adjustable Leg
Base Grill
Tilt Top Out
Turn Adjusting Screw
Counter Clockwise to Raise
Refrigerator
Turn Adjustment Leg
Clockwise to Raise
Refrigerator
Safety Information
Installation Instructions Customer ServiceOperating InstructionsTroubleshooting Tips

11
Reversing the Door Swing (on models so equipped)
•Read the instructions all
the way through before
starting.
• Handle parts carefully to
avoid scratching paint.
• Set screws down by their
related parts to avoid using
them in the wrong places.
• Provide a non-scratching
work surface for the doors.
When Reversing the Door Swing:
Important
Once you begin, do not
move cabinet until door-
swing reversal is completed.
These instructions are for
changing the hinges from
the right side to the left side.
If you ever want to change
the hinges back to the right
side, follow these same
instructions (merely reverse
all references to left and
right).
Tools Required
• Masking tape
• Phillips Screwdriver
• Robertson #2 Screwdriver
• Putty knife or thin-blade
screwdriver
• 7/32", 5/16", 3/8" sockets
and ratchet (6-point
sockets are recommended)
To Remove the Doors
❶
General
a. Unplug the refrigerator from its
electrical outlet.
b. Empty all door shelves, including
the dairy compartment.
CAUTION: Do not let either door
drop to the floor. To do so could
damage the door stop.
Operating InstructionsInstallation Instructions Troubleshooting TipsSafety InformationCustomer Service
❷
Remove Freezer Door
a. Tape the door shut with masking tape.
b. Remove the hinge cover (on some models). With a
5/16" socket, remove 2 screws that hold the top
hinge to the cabinet.
c. Lift the hinge straight up to free the hinge pin from the socket in the top of the door.
d. Remove tape, tilt the door away from the cabinet and lift it to free its bottom
socket from the hinge pin on the center hinge bracket.
e. Set the door on a non-scratching surface with the outside up.

❷
Transfer Centre Hinge Bracket to the Left
a. Remove the centre hinge bracket and shim by removing the three screws. NOTE:
Keep these screws with the hinge bracket. They are
longer screws and will be used when installing the
hinge on the other side.
b. Remove the three painted screws and take washers
from the centre left side of the cabinet. Screw them
into the holes on the right side, which were
uncovered in Step "a" above.
c. Place the centre hinge bracket and shim over the
holes at the centre left side of the cabinet, insert the
three screws that were removed with the centre
hinge bracket in Step "a" and tighten securely.
Do not install the hinge pin yet.
12
❸
Remove Fresh Food Door
a. Tape the door shut with masking tape.
b. Remove the hinge pin with a 7/32" socket and ratchet.
c. Remove tape and tilt the door away from the cabinet.
Remove and save the washer on the hinge pin.
d. Lift the door straight up to free its bottom socket from
the pin in the bottom hinge bracket.
Plastic
Washer
Hinge Pin
Centre
Hinge
Bracket
Fresh Food Door
To Reverse Hardware on Cabinet
❶
Transfer Bottom Hinge
Bracket to the Left
a. Pull out grille 1" and set down on the
floor to gain access to the hinge bracket
screws.
b. Using a 3/8 Socket, remove the hinge
bracket, screws and plastic washer from
the bottom right side of the cabinet.
c. Remove plug button and screw from the bottom left
side of the cabinet and install at the bottom right.
d. Reinstall the hinge bracket, screws and plastic
washer to the bottom left side of the cabinet.
Plastic Washer
Bottom Right
Reversing the Door Swing
Safety Information
Installation Instructions Customer ServiceOperating InstructionsTroubleshooting Tips
Bottom Left
Plastic
Washer
Centre Right
Centre Left

13
On each door remove the metal
door stop. Use the centre hinge
pin as a guide to align the door
stop on the opposite side, after
reversing the handles.
Left Side Right Side
Door Stops
Washer Washer
Door Stops
Short
Handle
❸
Transfer Top Hinge to the Left
Interchange hinge and shim at top right with 2 plug buttons at top left of
cabinet. Do not tighten screws on hinge side at this time.
❹
Transfer Door Stops
Operating InstructionsInstallation Instructions Troubleshooting TipsSafety InformationCustomer Service
To Reverse Door Handles
Hidden Screw
Short Handle Trim
Long Handle Trim
Style A
❶
Transfer Fresh Food Door Handle to the Right
Dependent on the model, your refrigerator will have either a short or a
long Fresh Food Handle Trim, refer figure 1. The handle is secured by 3
screws, 2 on the top mounting tab and 1 hidden behind the flat trim
located below the grip portion of the handle. The hidden screw is
exposed by sliding the flat trim down approximately 1 inch and then
pulling outwards to remove the trim. The trim will be stiff to slide and
strong tape can be used to assist in gripping the short trim, refer to the
steps below.
To remove handle with short trim…
• Apply an 8 inch long double layer of strong tape to the face of the trim
producing a 4 inch gripping surface, refer figure 2. Slide the trim down
Long
Handle
Fig. 1

14
Reversing the Door Swing
approximately 1 inch and pull out to remove the
trim and expose the handle mounting screw, refer
figure 3. Remove the screw using a
Phillips screwdriver.
• Remove the two screws, which hold
the handle to the top of the door.
• Remove the handle.
Safety Information
Installation Instructions Customer ServiceOperating InstructionsTroubleshooting Tips
To remove handle with long trim…
The handle with long trim is secured in the same manner
as the handle with short trim but has an additional pin
to secure the long trim to the bottom of the door.
Refer figure 4.
• Remove the pin securing the bottom of the long trim
using a Phillips screwdriver.
• Grip the long trim near the bottom and slide down
approximately 1 inch and pull out near the handle to
remove the trim and expose the mounting screw, refer
figure 3. Remove the screw using a Phillips screwdriver.
• Remove the two screws, which hold the handle to the top of the door.
• Remove the handle.
After removing handle…
• Remove screws from right edge of door top and insertthem into handle screw
holes on left side.
• Remove plug button from left top edge of door and insert it
into hole on opposite side, refer figure 5.
• Transfer medallion on door to opposite side.
When reinstalling handle…
• On models with long trims, use one of the painted screws to
clear the inboard locating pin hole on the bottom door
edge by inserting and removing the screw. Refer figure 4.
• Attach the handle to the right side of door with two screws
at the top followed by the single screw in the handle tail.
• Align the trim tabs over the handle tail notches as shown
figure 3. Slide the trim until the trim fits tightly against
the handle. On models with long trims the locating pin
must also be inserted into the locating hole as indicated in
figure 4.
Fig. 2
Fig. 3
Inboard
Hole Locating Pin
Fig. 4
Plug Button
Screws For
Handle Holes
Medallion
Fig. 5
Trim Tab
Tape Handle Tail
Notches
1"

15
To Reverse Door Handles (cont.)
• Remove one screw holding
handle to top of door and
two screws holding handle to
bottom of door.
• Remove handle.
• Remove screws from right
edge of door and insert them
into handle screw holes on
left side.
• Attach handle to right edge
of door with screws at top
and bottom, using holes
closest to edge of door.
Right Side
❷
Transfer Freezer Door Handle to the Right
Left Side
Right Side
Top View
Bottom View
Bottom View
Left Side
Top View
Reverse Door Handles Style ‘B’
❶
Transfer Fresh Food Door
Handle to the Right
a. Remove bottom cap by
pushing it toward bottom of
door and remove screw
underneath.
b. Remove two screws holding
handle to top of door.
c. Remove handle.
d. Attach handle to right side of
door with two screws at top of
door.
e. Screw bottom of handle into
place, and slide bottom cap
onto handle.
Operating InstructionsInstallation Instructions Troubleshooting TipsSafety InformationCustomer Service
Top
Bottom

16
Reversing the Door Swing
Reverse Door Handles (cont.) Style ‘B’
Plug Button
Screws For
Handle Holes
Medallion
After removing the fresh food door handle:
a. Remove screws from right edge of door top and insert
them into handle screw holes on left side.
b. Remove plug button from left edge of door and insert it
into hole on opposite side.
c. Transfer medallion on door to opposite side.
Left Side Right Side
Plastic Washer
Fresh Food Door
Centre
Hinge
Bracket
Hinge Pin
❷
Transfer Freezer Door Handle to the Right
a. Remove one screw holding handle to top of door and two
screws holding handle to bottom of door.
b. Remove handle.
c. Transfer handle screw from right edge of door top and
plug button from left edge of door top to opposite side.
d. Attach handle to right side of door with screws removed
in step (a) above.
Rehang Fresh Food Door
a. Lower bottom socket of fresh food door onto pin
on bottom hinge bracket. Be sure washer is in
place.
b. Tilt door toward cabinet and gently push door
under centre hinge bracket and align with the hole
in the centre hinge bracket.
c. Reinstall hinge pin with a 7/32" socket and ratchet
so it extends through a hole in centre hinge
bracket and into socket on top of fresh food door.
Rehang Freezer Door
a. Lower bottom socket of freezer door onto centre hinge pin. Be sure washer is
in place.
b. Tilt door toward cabinet, lifting the top hinge so the pin fits into the socket on
top of the door.
c. Tighten the top hinge screws after supporting the door on the handle side and
ensuring the gap between the doors is even all across the front.
d. Replace the hinge cover.
Reposition the lower grille
Safety Information
Installation Instructions Customer ServiceOperating InstructionsTroubleshooting Tips

17
Fresh Food Control
The fresh food control maintains the temperatures
throughout the refrigerator.
Moving the fresh food control to
OFF stops cooling
in both areas—fresh food and freezer—but does not
shut off power to the refrigerator.
1
Control Settings
About the controls on the refrigerator.
The temperature controls on your refrigerator have letters and numbers.
Initially set the fresh food control at 5and the freezer control at C.
If you want colder or warmer temperatures, adjust the fresh food
temperature first. When satisfied with that setting, adjust the freezer
temperature.
3
4
5
6
7
E
D
C
B
A
Refrigerator • Réfrigérateur
Intial Setting "5" Réglage de départ
Coldest "9" Plus froid
Freezer • Congélateur
Intial Setting "C" Réglage de départ
Coldest "E" Plus froid
1 2
Operating InstructionsInstallation Instructions Troubleshooting TipsSafety InformationCustomer Service
Operating Instructions

18
Use the milk test for the fresh food compartment. Place a
container of milk on the top shelf and check it a day later. If the
milk is too warm or too cold, adjust the temperature controls.
Use the ice cream test for the freezer compartment. Place a
container of ice cream in the center of the freezer and check it
after a day. If it's too hard or too soft, adjust the temperature
controls.
After changing the controls, allow 24 hours for the refrigerator to reach the
temperature you have set.
How To Test Temperatures
The type of packaging used and the storage temperatures will
affect how long food will keep in the refrigerator.
New food storage guidelines are constantly being developed.
Please refer to chart on page 32.
Food Storage
Safety Information
Installation Instructions Customer ServiceOperating InstructionsTroubleshooting Tips
Damper
Side View
(Coldest
Setting)
E
C
A
(Warmest
Setting)
Freezer Control
The freezer control moves a damper to change the amount of cold
air that moves from the freezer to the fresh food compartment.
2

19
Many refrigerators use special electric heaters. This refrigerator needs
none. That's why there is no "energy-saver" switch...there's no need for it.
Warm liquid from the refrigerator's condenser is automatically
circulated around the front edge of the freezer compartment to help
keep moisture from forming on the outside of the refrigerator during
humid weather. This is why the front edges of the refrigerator cabinet
may feel slightly warm to the touch.
No Defrosting
It is not necessary to defrost the freezer or fresh food compartments.
Although your refrigerator is designed and equipped to defrost itself
automatically, some frost on packages is normal.
Automatic Energy Saver System
• Location of your refrigerator is important. Try not to locate it next to
your range, a heating vent or where the sun will shine directly on it.
• Don't open doors more often than necessary.
• Close the doors as soon as possible, particularly in hot, humid weather.
• Be sure the doors are closed tightly. Before leaving the house or retiring
for the night, check to be sure the doors haven't been left ajar
inadvertently.
• Store only those foods requiring refrigeration in your refrigerator.
• Allow warm or hot foods to cool before placing them in your
refrigerator.
• Wipe all moisture from bottles and cartons before putting them in the
refrigerator.
• Keep all foods covered to reduce moisture build-up inside the
refrigerator.
• Don't waste ice cubes by letting many melt while using only a few.
• If you turn the control to coldest position for quick chilling or freezing,
be sure to turn it back to normal setting.
• Don't overcrowd your refrigerator. Overcrowding can require extra
electrical energy to keep everything cool.
• Your refrigerator must have sufficient clearances from surrounding
cabinets to ensure proper air circulation.
• Keep condenser clean.
Energy-Saving Tips
Operating InstructionsInstallation Instructions Troubleshooting TipsSafety InformationCustomer Service

20
All about refrigerator shelves, storage drawers
& dishes
Not all features are on all models.
Lift up
and out
❷
❶
Tilt up
Shelves
In the fresh food compartment are adjustable shelves
to suit your needs. To remove shelves, tilt shelf up at
front (1), then lift it up and out of tracks on rear wall
of refrigerator (2).
To replace shelves, select desired shelf height. Raise
shelf front slightly, engage top lugs in tracks at rear of
cabinet. Then lower front of shelf until it locks into
position. Wire, tempered glass and spill proof shelves
are adjustable in the same manner.
Adjustable Door Bins
Adjustable Storage Bins on the Doors (on some
models) - Adjustable storage bins on fresh food
compartment doors can easily be carried from the
refrigerator to the work area. To remove, simply lift
the front edge of the storage bin and gently slide the
bin forward on molded supports until it comes
completely out of the door.
❶
Engage
top lug
❷
Lower
to lock
into place
Fruit and Vegetable Drawers
These storage drawers at the bottom of the fresh food
compartment are designed to provide HIGH
humidity levels required by most vegetables and
LOWER humidity levels required for most fruits.
Make sure drawers are tightly closed when not in use.
Excess water that may accumulate in the bottom of
the drawers should be emptied and the drawers
wiped dry.
To Remove
To Replace
Safety Information
Installation Instructions Customer ServiceOperating InstructionsTroubleshooting Tips
