CANARY AUDIO CD-100 User manual

CANARY AUDIO®
Vacuum Tube Compact Disc Player
Handcrafted in California
CD-100
OWNER’S MANUAL
MADE IN USA

!This symbol is intended to alert the user to the presence
of important operating and maintenance (servicing)
instructions in the literature accompanying the unit.
The lightning flash with arrowhead symbol is intended to
alert the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock
to persons.
Dear Customer:
Please allow us to take this opportunity to thank you for purchasing this
CANARY AUDIO product.
We strongly recommend that you carefully study the Safety Instructions before
attempting to operate the unit.
After you have finished reading the instructions, please save this manual for
future reference.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THE UNIT TO RAIN OR MOISTURE.
CAUTION:
TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED AC PLUG
WITH AN EXTERSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS
THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SER-
VICING TO QUALIFIED SERVICE PERSONNEL ONLY.

SAFETY INSTRUCTIONS
Power Source:
•The unit should be connected to an AC power source of the proper rated
voltage.
•Never replace the power supply’s line fuse with the one of incorrect
characteristics.
AC Cord Protection:
•Do not defeat the grounding or polarization feature of the AC cord.
•Make sure that the AC receptacle holds the AC cord plug firmly and securely.
•Keep the AC cord away from heating appliances.
•Never put heavy object on the AC cord.
•If smoke, malodors or noises are emitted from the unit, turn the power off and
disconnect the AC cord.
Keep Away from Water and Moisture:
•This unit should not be used near water.
•Keep the unit away from flower vases, bathtubs, washbowls, kitchen sinks,
laundry tubs, swimming pools, etc. If liquids are spilled into the unit, serious
damage could occur.
Ventilation:
•Slots and openings in the chassis and in the back or bottom are provided for
necessary ventilation.
•Do not place a cloth on top of the unit or block the provided ventilation slots
and openings in any other way.
•Do not place the unit on a bed, sofa, rug or other similar surface which may
block the slots and openings.
•Do not place the unit in a confined space, such as a bookcase or built-in
cabinet, unless proper ventilation is provided.
Non-Use Periods:
•When left unused for a long period of time, the unit should be unplugged from
the AC outlet.

PROPER CARE
Break-in Period:
•As with most audio components, the CD-100 requires a “break-in” period.
During this period the internal components will stabilize and reach their
normal operating parameters. There are no special procedures required for
this break-in period, just listening to your favorite music will accomplish this
task all by itself.
•The time required to break in the CD-100 is approximately 30 to 50 hours.
Upon completion of the break-in period you will hear an improvement in the
overall sound quality of the compact disc player.
Stacking:
•Place the unit in a horizontal position, and do not place anything heavy on it.
•Do not place the unit on any other equipment which may become hot.
No Fingers or Other Foreign Objects:
•Touching internal parts of this unit is dangerous and may cause serious
damage to the unit. Do not attempt to disassemble the unit.
•Do not put any foreign object into the unit through the ventilation slots and
openings.
Cleaning:
•A regular dusting with a soft, non-abrasive cloth will generally keep the finish
of the faceplate and chassis looking like new.
Packing Materials:
•The original packing materials and shipping boxes are custom designed to
prevent shipping damage from occurring.
•We recommend that you retain all of the packing materials and shipping
boxes for future transport of your CD-100. Shipping the CD-100 in anything
other than its original packing boxes or packing materials may result in
damage that is not covered by warranty.
Registration Card:
•To ensure that your CD-100 is registered, please spend a moment now to
complete and return the Registration Card.
•Save a copy of the Registration Card and the bill of sale as proof of purchase
for future reference.

UNPACKING
•After unpacking the CD-100 CD player, inspect it for any shipping damage
and contact us immediately if any is found. Do not plug the power supply into
any outlet if you find any shipping damage.
•Please keep all packing materials for future transport of your player. Shipping
the CD-100 in anything other than its original boxes may result in damage
that is not covered by warranty.
ACCESSORIES
The following parts are included in the package aside from the main unit:
•Owner’s manual
•Warranty card
•AC power cord
•Remote control
•(2) AAA batteries (already installed in the remote control)
The batteries have been installed in the remote control prior shipping. To replace
the batteries in the remote control, open the back cover by loosen the screws.
Remove the old batteries and reinsert new ones in the orientation shown in the
compartment. Replace the back cover of the battery compartment.
INSTALLATION
•Locate the CD-100 player on your shelf or rack.
•Turn off any associated components prior to connecting the CD-100. This
minimizes the chance of momentary electrical surges disturbing your system.
•Connect the analog or digital outputs of the CD-100 to your preamplifier.
•With the power switch in the OFF position, attach the power cord to the
CD-100 and connect it to your outlet.
•Turn on the main power switch. The CD-100 will take about 60 seconds to
initialize before you will hear any sound.
•Turn on the rest of your system.
•Insert a disc and press PLAY.

Front Panel and Controls
Pressing this button will open or close the cd drawer.
I
I


Pressing this button successively will back up one track with each press. Pressing
and holding this button will perform a fast backward scan during playback.
Pressing this button successively will advance one track with each press.
Pressing and holding this button will perform a fast forward scan during playback.
Pressing this button will stop playback.
Pressing this button will initiate playback.
Pressing this button once will pause the playback.Asecond press will resume the
playback.
CANARY AUDIO®Handcrafted in California
24BIT 192KHz Vacuum Tube Compact Disc Player
CD - 100  II
O
Pressing this button will turn ON or OFF the cd player. The CD-100 will take about
60 seconds to initialize each time when first turned ON.
O

Remote Control Unit
Pressing this button will open or close the cd
drawer.
I
I

/
Pressing this button successively will back
up one track with each press.
Pressing and holding this button will perform
a fast backward scan during playback.
Pressing this button will initiate playback. In
play mode, this button will toggle between
play and pause.

Pressing this button successively will
advance one track with each press.
Pressing this button once will enter track
repeat mode. A second press will enter disc
repeat mode. A third press will exit repeat
mode.
The CD-100 remote control contains the following
button:
Repeat
Pressing and holding this button will perform
a fast forward scan during playback.
Pressing this button will stop playback.
CANARY
AUDIO®

Repeat
/
 
I I
CD-100
Remote Control
Using the Remote Control Unit:
The infrared remote sensor is located behind the display on the front of the CD
player. Point the remote control unit at the remote sensor when operating it.
The remote control unit will operate from the remote sensor in a direct distance
of approximately 6 meters, but this distance will be shortened if obstacles are
present or if operated at an angle greater than 30 degree in either direction.

SPECIFICATIONS
Model: CD-100
Frequency Response: +/- 1 dB from 20 Hz to 20,000 Hz
Distortion: < 0.005%
Signal-to-Noise Ratio: > 118dB
Dynamic Range: > 116dB
Channel Separation: > 85dB (1KHz)
Sampling Frequency: 44.1KHz
Line Output Voltage: 2.0 Volts
Power Consumption: 30 Watts
Tube Complement: 2-6922
Dimensions: 19” W x 16.5” D x 4.75” H
Weight: 50 lbs.
Note:
Specifications are subject to change without notice. Weight and dimensions are approximate.

LIMITED WARRANTY
Canary Audio warrants to the original purchaser that CD-100 compact disc player
is free of manufacturing defects for a period of three (3) years from the date of
purchase, with the exception of the transport mechanism and laser head.
Transport mechanism and laser head are covered for one (1) year. To receive
this warranty, the original purchaser must complete the enclosed Warranty
Registration Card and mail it to Canary Audio within thirty (30) days from the date
of purchase. Canary Audio will then validate the warranty to the original
purchaser.
This warranty does not cover cosmetic damage or damage due to acts of God,
accident, misuse, abuse or negligence. This warranty does not cover damage
due to improper operation or maintenance, use with incompatible accessory,
connection to improper voltage supply, or attempted repair, modify or upgrade by
anyone other than Canary Audio or a facility authorized by Canary Audio. This
warranty does not cove any damages to the vacuum tubes and does not cover
normal maintenance.
Canary Audio shall not be responsible in any way for consequential or indirect
damages or liabilities resulting from the use and operation of the product covered
herein or resulting from any breach of this warranty or any implied warranty
relating to said product. Under no circumstances does Canary Audio assume
liability or responsibility for injury or damages sustained in the use or operation of
this equipment or for damages to any other equipment connected to it.
During this stated period, Canary Audio will repair or replace any defective
components free of charge. A Return Authorization Number (RA Number) is
required before any product is returned to our factory for any reason. This
number must be visible on the exterior of the shipping container(s).
Units to be repaired by Canary Audio must be sent shipping and insurance
prepaid by the original purchaser in the original packing material. Canary Audio
will accept no responsibility for any damage occurring to the unit that is shipped
in packing material other than the original packing material. A written description
of the defect and a copy of the original bill of sale should be accompanied with
the returned product.
This warranty applies only to the first end-user purchaser of a CD-100 compact
disc player that is purchased and used in the United States of America and is not
valid for subsequent purchasers. All other warranties or conditions either written
or implied are void.
Canary Audio
P.O. Box 6216, Rosemead, CA 91770, USA
Telephone: [phone]
Http://www.canaryaudio.com
