Carrier 58CTA Operation manual

58CTA/CTX
P E R F O R M A N C E ™ 8 0 T W O --- S T A G E 4 --- W AY
MULTIPOISE INDUCED---COMBUSTION GAS FURNACE
Input Capacities: 45,000 thru 155,000 Btuh
Series 140
Product Data
Performance
A10249
THE PERFORMANCE 80 GAS FURNACE
The 58CTA/CTX Two-Stage, 4-way Multipoise Gas Furnaces
offer unmatched comfort in their class with ComfortHeatt
technology in an 80% AFUE gas furnace. You get the benefits of a
ComfortHeatttechnology furnace: reduced drafts, reduced sound
levels, longer cycles, less temperature swings between cycles, and
less temperature differences between rooms. Its exclusive,
intelligent microprocessor control adapts to the heating needs of
the home by automatically adjusting high and low heat times to
maximize comfort. The 58CTA/CTX furnaces are approved for use
with natural or propane gas, and the 58CTX is approved for use in
Low NOx Air Quality Management Districts.
STANDARD FEATURES
SComfortHeattTechnology Intelligent microprocessor
control
STwo--stage heating with single-stage thermostat with
patented Adaptive Control Technology
SVery low operating sound through low--stage operation and
QuieTechtsystem
SSmartEvapt--Humidity control when using a
Thermidistattcontrol
SComfort Fantadjustable constant fan speed from the
thermostat
SMicroprocessor based control center
Enhanced diagnostics with LED and reflective sight glass
Stores fault codes during power outages
Adjustable heating air temperature rise
Adjustable cooling airflow
S4-way Multipoise furnace, 13 vent applications
SCompact design -- only 33-1/3 in. (847 mm) tall
SPower HeattIgniter
SDraft Safeguard switch to ensure proper furnace venting
SInsulated blower compartment
SInner door for tighter sealing
SCertified to leak 2 percent or less of its nominal air
conditioning CFM delivered when pressurized to 1--In.
Water Gauge with all present air inlets, air outlets, and
condensate drain port(s) sealed.
SHYBRID HEATrDual Fuel System compatible
SAll models are Chimney Friendly when used with accessory
vent kit
STwinning in Upflow, Downflow and Horizontal
SResidential installations eligible for consumer financing
through the Retail Credit Program

2
MODEL NUMBER NOMENCLATURE
58CTA 045 100 08
58CTA Two-Stage 4-Way Multipoise Nominal Cooling Size
58CTX Low NOx version (Airflow at .5 e.s.p.)
(400 CFM per 12,000 Btuh)
08---800 CFf7
12---1200 CFM
100 14---1400 CFM
110 16---1600 CFM
Input Capacity 120 20---2000 CFM
045---44,000 Btuh 110---110,000 Btuh 130 22---2200 CFM
070---66,000 Btuh 135---132,000 Btuh 140
090---88,000 Btuh 155---154,000 Btuh Series Number
FURNACE COMPONENTS
A02169
HEAT EXCHANGER
A02238
CONTROL BOARD
A02170
INDUCER BLOWER
58CTA/CTX

3
FURNACE COMPONENTS
INDUCER MOTOR
ASSEMBLY
PRESSURE
SWITCHES
FLUE COLLECTOR
BOX
GAS VALVE
HOT SURFACE
IGNITOR
BLOWER DOOR
SAFETY SWITCH
FURNACE CONTROL
BOARD
VENT
ELBOW
MAIN LIMIT SWITCH
(BEHIND GAS VALVE)
BLOCKED VENT
SWITCH
FLAME
SENSOR
GAS MANIFOLD
GAS BURNER
BLOWER AND
MOTOR
MANUAL RESET
LIMIT SWITCHES
CAPACITOR/
POWER CHOKE
A10313
NOTE: The 58CTA/CTX Furnaces are factory shipped for use with natural gas. These furnaces can be field-converted for propane gas with
a factory-authorized and listed accessory conversion kit.
58CTA/CTX

4
CARRIER ACCESSORIES
CONTROLS:
THERMOSTATS
AND ZONING
Available in programmable and
non-programmable models, Carrier
thermostats maintain a constant
temperature level in the home.
For the ultimate in home comfort,
Carrier’s 2, 4, and 8-zone systems
allow temperature control of
individual “zones” of the home.
This is accomplished through a
series of electronic dampers and
remote room sensors. The 4-zone
system is shown.
A97432
MECHANICAL
OR ELECTRONIC
AIR CLEANER
Cleans the air of smoke, dirt, and
many pollens commonly found.
Saves decorating and cleaning
expenses by keeping carpets,
furniture, and drapes cleaner.
Electronic air cleaner is shown.
C04008 A01484
MODEL HUMCCLFP
HUMIDIFIER
By adding moisture to winter-dry
air, a Carrier humidifier can often
improve comfort and keep
furniture, rugs, and draperies in
better condition. Moisturizing
household air also helps to retain
normal body heat and provides
comfort at lower temperatures.
Accessories
ELECTRONIC AIR CLEANER (EAC) Model EACB
MECHANICAL AIR CLEANER Models EZXCAB, FILCAB
HUMIDIFIER Model HUM
HEAT RECOVERY VENTILATOR Model HRV
ENERGY RECOVERY VENTILATOR Model ERV
T H E R M O S T A T ---
NON---PROGRAMMABLE
Fo r u s e w i t h 1 --- s p e e d A i r C o n d i t i o n e r --- d e g . F / C , A u t o C h a n g e o v e r --- T P --- NA C , T C --- N A C
Fo r u s e w i t h 1 --- s p e e d H e a t P u m p --- d e g. F / C , A u t o C h a n g e o v e r --- T P --- NH P, T C --- N HP *
Fo r u s e w i t h 2 --- s p e e d A i r C o n d i t i o n e r --- d e g . F / C , A u t o C h a n g e o v e r --- T P --- NR H *
For use with multi---use / stage configurations --- deg. F/C, Auto Changeover/Temperature and Humidity control
--- T P --- P R H †
T H E R M O S T A T ---
PROGRAMMABLE
Fo r u s e w i t h 1 --- s p e e d A i r C o n d i t i o n e r --- d e g . F / C , A u t o C h a n g e o v e r, 7 --- D a y P r o g r a m m a b l e --- T P --- P A C
Fo r u s e w i t h 1 --- s p e e d H e a t P u m p --- d e g. F / C , A u t o C h a n g e o v e r, 7 --- D a y P r o g r a m m a b l e --- T P --- P H P *
Fo r u s e w i t h 2 --- s p e e d A i r c o n d i t i o n e r --- d e g . F / C , A u t o C h a n g e o v e r, 7 --- D a y P r o g r a m m a b l e --- T P --- P R H *
F o r u s e w i t h 1 --- s p e e d A i r C o n d i t i o n e r --- d e g . F / C , 5 --- 2 D a y P r o g r a m m a b l e --- T P --- P A C
Fo r u s e w i t h m u l t i --- s t a g e a p p li c a t i o n s --- d e g . F /C , A u t o C h a n g e o v e r, 7 --- D a y P r o g r a m m a b le --- T C --- P R H †
Fo r m u l t i --- u s e / s t a g e c o n f i g u ra t i o n s --- d e g . F / C , A u t o C h a n g e o v e r, 7 --- D a y P r o g ra m m a b l e / Te m p e r a t u r e a n d
H u m i d i t y C o n t r o l --- T P --- P R H †
ZONING CONTROL
Comfort™ Series 3-Zone Kit --- ZONECC3ZAC01, ZONECC3ZHP01
2 Performance™ Series ComfortZone™ II Zoning/Temperature and Humidity Control --- ZONECC2KIT01---B
4 Performance™ Series ComfortZone™ II Zoning/Temperature and Humidity Control --- ZONECC4KIT01---B
8 Performance™ Series ComfortZone™ II Zoning/Temperature and Humidity Control --- ZONECC8KIT01---B
* Model HP and 2S thermostat must be field converted to air conditioner operation.
† Thermidistat Control can be configured for multiple use and staging, it must be configured for each specific application.
58CTA/CTX

5
CARRIER ACCESSORIES
58CTA/CTX DESCRIPTION PART NO. 045-
08
045-
12
070-
08
070-
12
070-
16
090-
14
090-
16
090-
20
110-
12
110-
16
110-
22
135-
16
135-
22
155-
20
Media Filter Cabinet
FILCABCC0016 XXXXXX X
FILCABCC0020 XX XXX
FILCABCC0024 X X
Cartridge Media Filter
FILCCCAR0016 XXXXXX X
FILCCCAR0020 XX XXX
FILCCCAR0024 X X
EZ Flex Media Filter with End Caps
EXPXXUNV0016 XXXXXX X
EXPXXUNV0020 XX XXX
EXPXXUNV0024 X X
Replacement EZ Flex Filter Media
EXPXXFIL0016 XXXXXX X
EXPXXFIL0020 XX XXX
EXPXXFIL0024 X X
External Bottom Return Filter Rack
KGAFR0401B14 X X X X
KGAFR0501B17 X X X
KGAFR0601B21 XX XXX
KGAFR0701B24 X X
External Side Return Filter Rack KGAFR0801SRE XXXXXXXXXXXXXX
Unframed Filter 3/4-in. (19 mm)
KGAWF1301UFR† XXXXXX X
KGAWF1401UFR XX XXX
KGAWF1501UFR X X
KGAWF1306UFR† XXXXXX X
KGAWF1406UFR XX XXX
KGAWF1506UFR X X
Flue Extension KGAFE0112UPH XXXXXXXXXXXXXX
Twinning Kit KGATW0601HSI XXXXXXXXXXXXXX
Combustible Floor Base KGASB0201ALL XXXXXXXXXXXXXX
Downflow Vent Guard KGBVG0101DFG XXXXXXXXXXXXXX
Vent Extension Kit KGAVE0101DNH XXXXXXXXXXXXXX
Chimney Adapter Kit
KGACA02014FC XXXXXXXXXXX
KGACA02015FC X X X
Natural-to-Propane Conversion Kit* KGANP4601ALL XXXXXXXXXXXXXX
Propane-to-Natural Conversion Kit KGAPN3901ALL XXXXXXXXXXXXXX
Label Kit KGALB0101KIT XXXXXXXXXXXXXX
Gas Orifice Kit (Qty 50)
KGAHA0150N42
See Installation Instructions for model, altitude, and heat value usages
KGAHA0250N43
(factory supplied)
KGAHA0350N44
KGAHA0450N45
KGAHA0550N46
KGAHA1550N47
KGAHA1650N48
KGAHA0650P54
KGAHA0750P55
KGAHA0850P56
KGAHA5750125
KGAHA5750130
* Factory-authorized and field installed. Fuel conversion kits are CSA (formerly AGA/CGA) recognized.
† Suitable for Side Return Filter Rack
X = Accessory
S=Standard
58CTA/CTX

6
PHYSICAL DATA
UNIT SIZE
045 070 090
08 12 08 12 16 14 16 20
OUTPUT CAPACITY
BTUH*
(Nonweatherized
ICS) †
All 58CTA; 58CTX
Upflow
High 35,000 36,000 54,000 54,000 53,000 71,000 71,000 71,000
Low 23,000 23,000 36,000 36,000 35,000 47,000 47,000 47,000
All 58CTX Downflow/
Horizontal
High 34,000 34,000 51,000 51,000 51,000 68,000 68,000 68,000
Low 23,000 23,000 36,000 36,000 35,000 47,000 47,000 47,000
INPUT BTUH*
All 58CTA; 58CTX
Upflow
High 44,000 44,000 66,000 66,000 66,000 88,000 88,000 88,000
Low 29,000 29,000 43,500 43,500 43,500 58,000 58,000 58,000
All 58CTX Downflow/
Horizontal
HIgh 42,000 42,000 63,000 63,000 63,000 84,000 84,000 84,000
Low 29,000 29,000 43,500 43,500 43,500 58,000 58,000 58,000
AFUE † * Nonweatherized ICS 80.0 80.0 80.0 80.0 80.0 80.0 80.0 80.0
SHIPPING WEIGHT --- LB (KG) 104 (47) 107 (49) 111 (50) 115 (52) 126 (57) 127 (58) 140 (64) 146 (66)
CERTIFIED TEMP RISE RANGE --- ° F (° C)
High 30---60
( 1 7 --- 3 3 )
20---50
( 1 1 --- 2 8 )
40---70
( 2 2 --- 3 9 )
30---60
( 1 7 --- 3 3 )
25---55
( 1 4 --- 3 0 )
40---70
( 2 2 --- 3 9 )
30---60
( 1 7 --- 3 3 )
25---55
( 1 4 --- 3 0 )
Low 20---50
( 1 1 --- 2 8 )
15---45
( 8 --- 2 5 )
30---60
( 1 7 --- 3 3 )
30---60
( 1 7 --- 3 3 )
15---45
( 8 --- 2 5 )
25---55
( 1 4 --- 3 0 )
25---55
( 1 4 --- 3 0 )
15---45
( 8 --- 2 5 )
CERTIFIED EXT
STATIC PRESSURE
Heating 0.10 0.10 0.12 0.12 0.12 0.15 0.15 0.15
Cooling 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
AIRFLOW CFM‡
Heating High/Low 820/725 1030/860 790/685 885/695 1570/1045 1375/1195 1265/1030 1580/1325
Cooling 895 1175 955 1240 1605 1385 1755 2005
LIMIT CONTROL SPST
HEATING BLOWER CONTROL Solid-State Time Operation
BURNERS (Monoport) 2 2 3 3 3 4 4 4
GAS CONNECTION SIZE 1 / 2 --- i n . N P T
GAS VALVE (Redundant) Manufacturer White-Rodgers
Minimum Inlet Pressure (In. W.C.) 4.5 (Natural Gas)
Maximum Inlet Pressure (In. W.C.) 13.6 (Natural Gas)
IGNITION DEVICE Hot Surface
* Gas input ratings are certified for elevations to 2000 ft. (610 M). For elevations above 2000 ft. (610 M), reduce ratings 4 percent for each 1000 ft. (305M)
above sea level. Refer to National Fuel Gas Code NFPA 54/ANSI Z223.1---2009 Table F.4 or furnace Installation Instructions.
† Capacity in accordance with U.S. Government DOE test procedures.
‡ Airflow shown is for bottom only return ---air supply. For air delivery above 1800 CFM, see Air Delivery Table for other options. A filter is required for each
return-air supply.
ICS — Isolated Combustion System
BLOWER PERFORMANCE DATA
UNIT SIZE
045 070 090
08 12 08 12 16 14 16 20
DIRECT-DRIVE MOTOR Hp (PSC) 1/5 1/3 1/5 1/3 1/2 1/3 1/2 3/4
MOTOR FULL LOAD AMPS 2.8 5.1 2.8 5.1 7.4 5.2 7.4 11.0
RPM (Nominal) – Speeds 1075-4 1075-5 1075-4 1075-5 1075-5 1075-4 1075-5 1075-5
BLOWER WHEEL DIAMETER × WIDTHS ---
In. (mm)
10 x 6
(254 x
152)
10 x 6
(254 x
152)
10 x 6
(254 x
152)
10 x 6
(254 x
152)
11 x 8
(279 x
203)
10 x 8
(254 x
203)
10 x 10
(254 x
254)
11 x 11
(279 x
279)
PSC ---Permanent Split Capacitor
58CTA/CTX

7
PHYSICAL DATA
UNIT SIZE
110 135 155
12 16 22 16 22 20
OUTPUT CAPACITY
BTUH*
(Nonweatherized
ICS) †
All 58CTA; 58CTX
Upflow
High 89,000 89,000 89,000 107,000 107,000 125,000
Low 59,000 59,000 59,000 70,000 70,000 82,000
All 58CTX Downflow/
Horizontal
High 85,000 85,000 85,000 102,000 102,000 119,000
Low 59,000 59,000 59,000 70,000 70,000 82,000
INPUT BTUH*
All 58CTA; 58CTX
Upflow
High 110,000 110,000 110,000 132,000 132,000 154,000
Low 72,500 72,500 72,500 87,000 87,000 101,500
All 58CTX Downflow/
Horizontal
HIgh 105,000 105,000 105,000 126,000 126,000 147,000
Low 72,500 72,500 72,500 87,000 87,000 101,500
AFUE † * Nonweatherized ICS 80.0 80.0 80.0 80.0 80.0 80.0
SHIPPING WEIGHT --- LB. (KG) 135 (61) 146 (66) 152 (69) 149 (68) 163 (74) 170 (77)
CERTIFIED TEMP RISE RANGE --- ° F (° C)
High 50---80
( 1 7 --- 3 3 )
40---70
( 1 7 --- 3 3 )
30---60
( 1 7 --- 3 3 )
50---80
( 1 7 --- 3 3 )
40---70
( 1 7 --- 3 3 )
45---75
( 1 7 --- 3 3 )
Low 30---60
( 1 7 --- 3 3 )
25---55
( 1 4 --- 3 0 )
20---50
( 1 1 --- 2 8 )
30---60
( 1 7 --- 3 3 )
25---55
( 1 4 --- 3 0 )
30---60
( 1 7 --- 3 3 )
CERTIFIED EXT
STATIC PRESSURE
Heating 0.20 0.20 0.20 0.20 0.20 0.20
Cooling 0.50 0.50 0.80 0.50 0.50 0.50
AIRFLOW CFM‡
Heating High/Low 1335/1180 1290/1045 1555/1295 1525/1320 1865/1640 1790/1565
Cooling 1355 1695 2200 1710 2110 2230
LIMIT CONTROL SPST
HEATING BLOWER CONTROL Solid-State Time Operation
BURNERS (Monoport) 555667
GAS CONNECTION SIZE 1 / 2 --- i n . N P T
GAS VALVE (Redundant) Manufacturer White-Rodgers
Minimum Inlet Pressure (In. W.C.) 4.5 (Natural Gas)
Maximum Inlet Pressure (In. W.C.) 13.6 (Natural Gas)
IGNITION DEVICE Hot Surface
* Gas input ratings are certified for elevations to 2000 ft. (610 M). For elevations above 2000 ft. (610 M), reduce ratings 4 percent for each 1000 ft. (305M)
above sea level. Refer to National Fuel Gas Code NFPA 54/ANSI Z223.1---2009 Table F.4 or furnace Installation Instructions.
† Capacity in accordance with U.S. Government DOE test procedures.
‡ Airflow shown is for bottom only return ---air supply. For air delivery above 1800 CFM, see Air Delivery Table for other options. A filter is required for each
return-air supply.
ICS — Isolated Combustion System
BLOWER PERFORMANCE DATA
UNIT SIZE
110 135 155
12 16 22 16 22 20
DIRECT-DRIVE MOTOR Hp (PSC) 1/3 1/2 3/4 1/2 3/4 3/4
MOTOR FULL LOAD AMPS 5.2 7.4 11.0 7.9 11.1 11.1
RPM (Nominal) – Speeds 1075-4 1075-5 1075-5 1075-4 1075-4 1075-5
BLOWER WHEEL DIAMETER × WIDTHS ---
In. (mm)
10 x 8
(254 X 203)
10 x 10
(254 X 254)
11 x 11
(279 x 279)
10 x 10
(254 x 254)
11 x 11
(279 x 279)
11 x 11
(279 x279)
PSC ---Permanent Split Capacitor
58CTA/CTX

8
A02058
SEE NOTES: 1,2,4,7,8,9
UPFLOW
SEE NOTES: 1,2,3,4,7,8,9
UPFLOW
SEE NOTES: 1,2,4,5,7,8,9
DOWNFLOW
A02059 A02061
SEE NOTES:1,2,3,4,5,7,8,9
DOWNFLOW
SEE NOTES: 1,2,3,4,5,7,8,9
DOWNFLOW
SEE NOTES: 1,2,4,5,6,7,8,9
DOWNFLOW
A02060 A02063 A02062
Venting Notes
1. For common vent, vent connector sizing and vent material: United States, latest edition of the National Fuel Gas
Code (NFGC), ANSI Z223.1/NFPA 54.
2. Immediately increase to 5-in. (127 mm) vent connector outside furnace casing when 5-in. (127 mm) vent connector
required, refer to Note 1.
3. Side outlet vent for upflow and downflow installations must use Type B vent immediately after exiting the furnace,
except when Downflow Vent Guard is used in downflow position.
4. Type B vent where required, refer to Note 1.
5. 4---in. (102 mm) single wall vent must be used inside furnace casing and the Downflow Vent Guard Kit.
6. Accessory Downflow Vent Guard Kit, required in downflow installations with bottom vent configuration.
7. Chimney Adapter Kit required for exterior masonry chimney applications. Refer to Chimney Adapter Kits for sizing
and complete application details.
8. Secure vent connector to furnace elbow with (2) corrosion-resistant sheet metal screws, space approximately 180°
apart.
9. Secure all other single wall vent connector joints with (3) corrosion-resistant screws spaced approximately 120°
apart. Secure Type B vent connectors per vent connector manufacturer’s recommendations.
58CTA/CTX

9
SEE NOTES: 1,2,4,5,7,8,9
HORIZONTAL RIGHT
A02068
SEE NOTES: 1,2,4,5,7,8,9
HORIZONTAL RIGHT
A02070
SEE NOTES: 1,2,4,7,8,9
HORIZONTAL RIGHT A02069
SEE NOTES: 1,2,4,7,8,9
HORIZONTAL LEFT A02064
SEE NOTES: 1,2,4,5,7,8,9
HORIZONTAL LEFT A02065
SEE NOTES: 1,2,4,5,7,8,9
HORIZONTAL LEFT
A02066
SEE NOTES: 1,2,4,5,7,8,9
HORIZONTAL LEFT
A02067
58CTA/CTX

10
AIR DELIVERY—CFM (With Filter)*
UNIT SIZE
RETURN-AIR
SUPPLY SPEED
EXTERNAL STATIC PRESSURE (In. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
045-08
Bottom
or
Side(s)
High
Med-High
Med-Low
Low
1120
930
820
725
1075
890
785
690
1020
850
750
655
960
805
700
605
895
750
650
555
815
680
585
495
720
600
505
405
605
500
400
305
455
345
235
—
340
195
—
—
045-12
Bottom
or
Side(s)
High
Med-High
Medium
Med-Low
Low
1465
1295
1150
1030
860
1400
1260
1120
1008
835
1325
1210
1085
980
810
1250
1155
1040
945
780
1175
1090
985
895
745
1085
1015
920
835
700
980
930
835
765
635
860
830
740
685
555
725
700
620
—
—
—
—
—
—
—
070-08
Bottom
or
Side(s)
High
Med-High
Med-Low
Low
1140
915
795
690
1105
885
770
665
1055
855
740
630
1010
825
700
590
955
785
655
550
885
725
600
475
815
655
510
415
715
530
420
340
545
420
325
245
390
280
—
—
070-12
Bottom
or
Side(s)
High
Med-High
Medium
Med-Low
Low
1440
1180
1015
885
695
1400
1165
1020
885
700
1355
1150
1010
880
700
1300
1125
990
865
690
1240
1085
965
845
670
1170
1030
925
815
640
1090
970
875
770
600
1000
890
800
700
540
890
785
700
605
460
745
645
560
475
345
070-16
Bottom
or
Side(s)
High
Med-High
Medium
Med-Low
Low
1840
1610
1460
1260
1065
1790
1575
1430
1240
1040
1730
1535
1400
1215
1015
1670
1485
1360
1180
985
1605
1435
1315
1145
955
1530
1370
1260
1100
915
1450
1305
1205
1040
875
1370
1230
1130
985
825
1275
1145
1055
915
765
1170
1055
965
835
695
090-14
Bottom
or
Side(s)
High
Med-High
Med-Low
Low
1650
1515
1385
1205
1600
1485
1360
1180
1535
1440
1320
1160
1465
1380
1260
1120
1385
1300
1195
1065
1285
1220
1120
1005
1175
1115
1025
925
1055
990
915
810
895
830
710
630
645
600
565
510
090-16
Bottom
or
Side(s)
High
Med-High
Medium
Med-Low
Low
2060
1710
1470
1260
1030
2000
1695
1475
1265
1025
1930
1665
1450
1245
1020
1835
1585
1390
1225
990
1755
1480
1335
1165
940
1620
1390
1230
1090
890
1490
1245
1120
995
810
1315
1110
1005
880
720
1115
955
855
750
615
910
775
690
600
500
090-20
Bottom
Only
High
Med-High
Medium
Med-Low
Low
2380
2185
1905
1595
1340
2295
2115
1865
1565
1310
2205
2045
1815
1530
1280
2105
1960
1740
1485
1225
2005
1875
1670
1430
1170
1900
1770
1590
1355
1120
1775
1655
1490
1275
1040
1650
1535
1390
1160
955
1510
1400
1245
1055
850
1335
1240
1110
920
750
Both Sides
or 1
Side & Bottom
High
Med-High
Medium
Med-Low
Low
2485
2175
1845
1540
1280
2415
2130
1815
1515
1250
2330
2070
1770
1475
1220
2230
2000
1720
1435
1190
2135
1930
1655
1385
1155
2030
1840
1580
1335
1105
1920
1740
1500
1270
1035
1790
1620
1395
1175
945
1645
1495
1270
1045
845
1485
1345
1090
915
745
1SideOnly
High
Med-High
Medium
Med-Low
Low
2420
2160
1850
1530
1290
2345
2110
1815
1490
1250
2265
2045
1765
1455
1220
2165
1960
1710
1420
1190
2070
1885
1635
1375
1155
1960
1790
1560
1320
1110
1850
1695
1480
1250
1040
17720
1570
1380
1160
950
1570
1445
1250
1055
835
1420
1305
1110
905
740
* A filter is required for each return ---air supply. Airflow performance includes 3/4 ---in. (19 mm) washable filter media such as contained in factory --- a u t h o r iz ed
accessory filter rack. To determine airflow performance without this filter, assume an additional .1 available external static pressure.
— Indicates unstable operating conditions.
58CTA/CTX

11
AIR DELIVERY—CFM (With Filter)* continued
UNIT SIZE
RETURN-AIR
SUPPLY SPEED
EXTERNAL STATIC PRESSURE (In. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
110-12
Bottom
or
Side(s)
High
Med-High
Med-Low
Low
1625
1510
1360
1195
1575
1470
1335
1180
1515
1415
1295
1155
1445
1355
1250
1115
1355
1285
1180
1065
1260
1185
1100
980
1165
1070
985
860
990
890
810
740
785
725
670
605
595
530
475
410
110-16
Bottom
or
Side(s)
High
Med-High
Medium
Med-Low
Low
2055
1750
1545
1300
1050
1990
1725
1525
1290
1045
1910
1670
1490
1275
1015
1815
1605
1445
1235
975
1695
1515
1355
1165
935
1575
1400
1260
1085
880
1425
1255
1135
1005
815
1230
1120
1020
895
715
1090
975
880
750
610
910
785
750
620
515
110-22
Bottom
Only
High
Med-High
Medium
Med-Low
Low
2530
2225
1895
1565
1320
2460
2190
1885
1555
1295
2380
2135
1865
1535
1265
2285
2075
1820
1505
1235
2200
1995
1770
1465
1205
2085
1910
1700
1410
1160
1970
1805
1610
1350
1105
1835
1695
1520
1265
1035
1695
1565
1410
1175
950
1545
1430
1290
1050
870
Both Sides
or 1
Side & Bottom
High
Med-High
—
2205
—
2175
2415
2120
2330
2065
2235
1975
2125
1900
1995
1790
1860
1685
1735
1580
1605
1460
1SideOnly
High
Med-High
Medium
Med-Low
Low
2485
2155
1830
1520
1275
2430
2135
1830
1505
1260
2360
2100
1810
1490
1240
2270
2040
1780
1470
1210
2175
1970
1730
1430
1180
2070
1885
1665
1385
1135
1950
1790
1595
1330
1090
1825
1680
1505
1250
1025
1685
1560
1395
1165
930
1535
1420
1275
1055
840
135-16
Bottom
or
Side(s)
High
Med-High
Med-Low
Low
2090
1790
1545
1325
2010
1755
1525
1320
1930
1705
1500
1295
1835
1640
1450
1265
1710
1550
1380
1210
1590
1465
1315
1150
1470
1360
1215
995
1335
1210
1005
865
1025
945
855
745
835
785
670
540
135-22
Bottom
Only
High
Med-High
Med-Low
Low
2485
2195
1880
1640
2400
2150
1850
1635
2310
2090
1820
1615
2215
2000
1780
1585
2110
1920
1715
1530
2000
1825
1635
1465
1880
1720
1540
1370
1725
1565
1415
1255
1535
1405
1290
1150
1355
1255
1160
1040
Both Sides
or 1
Side & Bottom
High
Med-High
Med-Low
Low
—
2180
1880
1640
—
2145
1850
1635
2385
2060
1820
1615
2305
2010
1780
1585
2195
1945
1715
1530
2085
1865
1635
1465
1960
1765
1540
1370
1825
1660
1415
1255
1670
1515
1290
1150
1465
1325
1160
1040
1SideOnly
High
Med-High
Med-Low
Low
2320
2125
1845
1640
2250
2065
1825
1620
2155
1995
1765
1580
2055
1910
1710
1540
1970
1815
1650
1485
1855
1710
1570
1410
1725
1610
1475
1330
1600
1490
1370
1220
1450
1340
1240
1080
1280
1175
1100
960
155-20
Bottom
Only
High
Med-High
Med-Low
Low
2465
2115
1800
1570
2430
2105
1790
1565
2375
2075
1770
1551
2305
2030
1735
1525
2230
1980
1695
1495
2110
1910
1640
1445
2000
1830
1570
1370
1865
1725
1465
1270
1725
1590
1345
1175
1545
1425
1225
1070
Both Sides
or 1
Side & Bottom
High
Med-High
—
2155
—
2135
2375
2095
2285
2040
2200
1975
2105
1895
1995
1790
1870
1685
1730
1550
1570
1400
1SideOnly High
Med-High
—
2140
—
2095
2260
2040
2180
1975
2085
1890
1975
1810
1865
1705
1740
1595
1605
1480
1455
1325
* A filter is required for each return ---air supply. Airflow performance includes 3/4 ---in. (19 mm) washable filter media such as contained in factory --- a u t h o r iz ed
accessory filter rack. To determine airflow performance without this filter, assume an additional .1 available external static pressure.
— Indicates unstable operating conditions.
58CTA/CTX

12
DIMENSIONS
A
A
B
[736.9]
[736.9]
29
29
Ø7/8
Ø7/8
[22.2]
[22.2]
ACCESSORY
ACCESSORY
5 15/16
5 15/16
[150.7]
[150.7]
28.39
28.39
[721.2]
[721.2]
Ø7/8
Ø7/8
[22.2]
[22.2]
ACCESSORY
ACCESSORY
14 7/8
14 7/8
[337.3]
[337.3]
(BOTH SIDES)
(BOTH SIDES)
Ø7/8
Ø7/8
[22.2]
[22.2]
ACCESSORY
ACCESSORY
Ø7/8
Ø7/8
[22.2]
[22.2]
ACCESSORY
ACCESSORY
Ø1 3/4
Ø1 3/4
[44.5]
[44.5]
GAS ENTRY
GAS ENTRY
Ø1/2
Ø1/2
[12.7]
[12.7]
THERMOSTAT WIRE ENTRY
THERMOSTAT WIRE ENTRY
22 1/16
22 1/16
[560]
[560]
SIDE INLET
SIDE INLET
(BOTH SIDES)
(BOTH SIDES)
11 7/16
11 7/16
[290.7]
[290.7]
9 11/16
9 11/16
[245.4]
[245.4]
[197.8]
[197.8]
7 13/16
7 13/16
Ø7/8
Ø7/8
[22.2]
[22.2]
J.BOX PROVISION
J.BOX PROVISION
Ø7/8
Ø7/8
[22.2]
[22.2]
JUNCTION BOX
JUNCTION BOX
LOCATION
LOCATION
Ø1 3/4
Ø1 3/4
[44.5]
[44.5]
GAS ENTRY
GAS ENTRY
1 15/16
1 15/16
[49.2]
[49.2]
1
[25.4]
[25.4]
1 1/4
1 1/4
[31.8]
[31.8]
29 9/16
29 9/16
[750.7]
[750.7]
1 15/16
1 15/16
[49.2]
[49.2]
5 5/8
5 5/8
[143.3]
[143.3]
5 7/16
5 7/16
[138.5]
[138.5]
6 13/16
6 13/16
[172.3]
[172.3]
Ø1/2
Ø1/2
[12.7]
[12.7]
THERMOSTAT WIRE ENTRY
THERMOSTAT WIRE ENTRY
19
19
[481.7]
[481.7]
OUTLET
OUTLET
D
21.6
21.6
[549.5]
[549.5]
BOTTOM INLET
BOTTOM INLET
C
33 1/4
33 1/4
[843.9]
[843.9]
9 9/16
9 9/16
[243.3]
[243.3]
3/4
3/4
[19.1]
[19.1]
5 7/8
5 7/8
[148.5]
[148.5]
3 7/16
3 7/16
[86.8]
[86.8]
9 7/8
9 7/8
[250.7]
[250.7]
27 3/4
27 3/4
[704.7]
[704.7]
2 5/16
2 5/16
[59]
[59]
FRONT OF CASING
FRONT OF CASING
TOP OF CASING
TOP OF CASING
4 13/16
4 13/16
[122.2]
[122.2]
27 3/4
27 3/4
[704.7]
[704.7]
5 7/8
5 7/8
[148.5]
[148.5]
8 5/8
8 5/8
[219]
[219]
5 1/2
5 1/2
[140.3]
[140.3]
8 7/16
8 7/16
[213.5]
[213.5]
FRONT OF CASING
FRONT OF CASING
TOP OF CASING
TOP OF CASING
6.1
6.1
[155.7]
[155.7]
2 1/16
2 1/16
[51.6]
[51.6]
5.1
5.1
[130.5]
[130.5]
1.7
1.7
[43.5]
[43.5]
Ø7/8
Ø7/8
[22.2]
[22.2]
ACCESSORY (2)
ACCESSORY (2)
AIR FLOW
AIR FLOW
AIR FLOW
AIR FLOW
BOTTOM RETURN
BOTTOM RETURN
WIDTH
WIDTH
AIR FLOW
AIR FLOW
KNOCK OUTS FOR
KNOCK OUTS FOR
VENTING(5
VENTING(5
PLACES)
PLACES)
A10270
NOTES:
1. Two additional 7/8 ---in. (22 mm) diameter holes are located in the top plate.
2. Minimum return---air openings at furnace, based on metal duct. If flex duct is used, see flex duct manufacturer’s recommendations for equivalent diameters.
a. For 800 CFM---16---in. (406 mm) round or 14 1/2 x 12---in. (368 x 305 mm) rectangle.
b. For 1200 CFM---20---in. (508 mm) round or 14 1/2 x 19 1/2---in. (368 x 495 mm) rectangle.
c. For 1600 CFM---22---in. (559 mm) round or 14 1/2 x 22 1/16---in. (368 x 560mm) rectangle.
d. For airflow requirements above 1800 CFM, see Air Delivery table in Product Data literature for specific use of single side inlets. The use of both sideinlets,
a combination of 1 side and the bottom, or the bottom only will ensure adequate return air openings for airflow requirements above 1800 CFM.
FURNACE
SIZE
A
CABINET
WIDTH
IN (mm)
B
OUTLET
WIDTH
IN (mm)
C
TOP AND
BOTTOM FLUE
COLLAR
IN (mm)
D
BOTTOM
INLET WIDTH
IN (mm)
VENT
CONNECTION
SIZE
IN (mm)
SHIP WT
LB (KG)
ACCESSORY
MEDIA
CABINET SIZE
IN (mm)
045---08 14---3/16 (360) 12---9/16 (319) 9---5/16 (237) 12--- 11/16 (322) 4 (102) 104 (47) 16 (406)
045---12 14---3/16 (360) 12---9/16 (319) 9---5/16 (237) 12--- 11/16 (322) 4 (102) 107 (49) 16 (406)
070---08 14---3/16 (360) 12---9/16 (319) 9---5/16 (237) 12--- 11/16 (322) 4 (102) 111 (50) 16 (406)
070---12 14---3/16 (360) 12---9/16 (319) 9---5/16 (237) 12--- 11/16 (322) 4 (102) 115 (52) 16 (406)
070---16 17---1/2 (445) 15--- 7/8 (403) 11--- 9/16 (294) 16--- 1/8 (410) 4 (102) 126 (57) 16 (406)
090---14 17---1/2 (445) 15--- 7/8 (403) 11--- 9/16 (294) 16--- 1/8 (410) 4 (102) 127 (58) 16 (406)
090---16 21 (533) 19---3/8 (492) 13---5/16 (338) 19--- 1/2 (495) 4 (102) 140 (64) 20 (508)
090---20 21 (533) 19---3/8 (492) 13---5/16 (338) 19--- 1/2 (495) 4 (102) 146 (66) 20 (508)
110---12 17---1/2 (445) 15--- 7/8 (403) 11--- 9/16 (294) 16--- 1/8 (410) 4 (102) 135 (61) 16 (406)
110---16 21 (533) 19---3/8 (492) 13---5/16 (338) 19--- 1/2 (495) 4 (102) 146 (66) 20 (508)
110---22 21 (533) 19---3/8 (492) 13---5/16 (338) 19--- 1/2 (495) 4 (102) 152 (69) 20 (508)
135---16 21 (533) 19---3/8 (492) 13---5/16 (338) 19--- 1/2 (495) 4 (102)* 149 (68) 20 (508)
135---22 24---1/2 (622) 22--- 7/8 (581) 15--- 1/16 (383) 23 (584) 4 (102))* 163 (74) 24 (610)
155---20 24---1/2 (622) 22--- 7/8 (581) 15--- 1/16 (383) 23 (584) 4 (102)* 170 (77) 24 (610)
*135 and 155 size furnaces require a 5 or 6 ---in. (127 or 152 mm) vent. Use a vent adapter between furnace and vent stack. See Installation Instructions for
complete installation requirements.
58CTA/CTX

13
A10269
D
E
S
I
G
N
C
E
R
T
I
F
I
E
D
Always Ask For
Use of the AHRI Certified TM Mark indicates a
manufacturer’s participation in the program. For
verification of certification for individual products,
go to www.ahridirectory.org.
58CTA/CTX

14
TYPICAL WIRING SCHEMATIC
A95236
ELECTRICAL DATA
58CTA/CTX
UNIT SIZE
VOLTS HERTZ
PHASE
OPERATING VOLTAGE RANGE
MAXIMUM
UNIT AMPS
MAXIMUM
WIRE
LENGTH --
FT (M)‡
MAXIMUM
FUSE OR CKT
BKR AMPS†
MINIMUM
WIRE GAGE
Maximum* Minimum*
045-08 115-60-1 127 104 5.3 49 (14.9) 15 14
045-12 115-60-1 127 104 7.1 38 (11.5) 15 14
070-08 115-60-1 127 104 5.2 51 (15.5) 15 14
070-12 115-60-1 127 104 7.3 37 (11.2) 15 14
070-16 115-60-1 127 104 10.1 27 (8.2) 15 14
090-14 115-60-1 127 104 8.2 34 (10.3) 15 14
090-16 115-60-1 127 104 9.9 28 (8.5) 15 14
090-20 115-60-1 127 104 12.9 34 (10.3) 20 12
110-12 115-60-1 127 104 8.2 34 (10.3) 15 14
110-16 115-60-1 127 104 10.1 28 (8.5) 15 14
110-22 115-60-1 127 104 13.7 32 (9.7) 20 12
135-16 115-60-1 127 104 10.2 27 (8.2) 15 14
135-22 115-60-1 127 104 14.5 30 (9.1) 20 12
155-20 115-60-1 127 104 15.0 29 (8.8) 20 12
* Permissible limits of the voltage range at which unit operates satisfactorily.
† Time---delay type is recommended.
‡ Length shown is as measured 1 way along wire path between unit and service panel for maximum 2 percent voltage drop.
58CTA/CTX

15
TYPICAL INSTALLATION
CONDENSING
UNIT
GAS-FIRED
WATER HEATER
ELECTRONIC
AIR CLEANER
AIRFLOW
HUMIDIFIER
A10211
58CTA/CTX

16
GUIDE SPECIFICATIONS
Gas Furnace
58CTA/CTX
General
SYSTEM DESCRIPTION
Furnish a _________________ fixed capacity gas-fired
furnace for use with natural gas or propane (factory
authorized conversion kit required for propane); furnish
cold air return plenum.
QUALITY ASSURANCE
Unit will be designed, tested and constructed to the
current ANSI Z 21.47/CSA 2.3 design standard for
gas--fired central furnaces.
Unit will be 3rd party certified by CSA to the current
ANSI Z 21.47/CSA 2.3 design standard for gas--fired
central furnaces.
Unit will carry the CSA Blue StarRlabel.
Unit efficiency testing will be performed per the current
DOE test procedure as listed in the Federal Register.
Unit will be certified for capacity and efficiency and
listed in the latest AHRI Consumer’s Directory of
Certified Efficiency Ratings.
Unit shall carry the current Federal Trade Commission
Energy Guide efficiency label.
DELIVERY, STORAGE AND HANDLING
Unit shall be shipped as single package only and is
stored and handled per unit manufacturer’s
recommendations.
WARRANTY (for inclusion by specifying engineer)
U.S. only. Warranty certificate available upon request.
Products
EQUIPMENT
Components shall include: slow-opening two stage gas
valve to reduce ignition noise, regulate gas flow, with
electric switch gas shut-off; flame proving sensor, hot
surface igniter, pressure switch assembly, flame rollout
switch, blower and inducer assembly, 40va transformer;
low-voltage (heating) (heating/cooling) thermostat.
Blower Wheel and Blower Motor
Galvanized blower wheel shall be centrifugal type,
statically and dynamically balanced. Blower motor of PSC
type shall be permanently lubricated with sealed bearings,
of _______hp, and shall be multiple-speed direct drive.
Blower motor shall be soft mounted to the blower scroll to
reduce vibration transmission.
Filters
Furnace may have reusable--type filters. Filter shall be
_______ (x) _______in. (mm). An accessory high
efficiency Media Filter is available as an option.
_______________ Media Filter.
Casing
Casing shall be of .030 in. (.76 mm) thickness
minimum, pre-painted galvanized steel.
Two Speed Inducer Motor
Two Speed Inducer motor shall be soft mounted to
reduce vibration transmission.
Draft Safeguard Switch
Draft Safeguard Switch (blocked vent safeguard) shall
be factory installed to reduce the possibility of vent gas
infiltration due to a blocked or restricted vent pipe.
Heat Exchangers
Heat exchangers shall be a 4-Pass 20 gage aluminized
steel of fold--and--crimp sectional design when applied
operating under negative pressure.
Controls
Control shall include a micro--processor based
integrated electronic control board with at least 11 service
troubleshooting codes displayed via diagnostic flashing
enhanced LED light on the control, a self--test feature that
checks all major functions of the furnace within one
minute, and a replaceable automotive-type circuit
protection fuse. Multiple operational settings available
including, separate blower speeds for low heat, high heat,
low cooling, high cooling and continuous fan. Continuous
fan speed may be adjusted from the thermostat. Cooling
airflow will be selectable between 350 or 400 CFM per ton
of air conditioning. Features will also include temporary
reduced airflow in the cooling mode for improved
dehumidification when a control or Thermidistattis
selected as the thermostat.
OPERATING CHARACTERISTICS
Heating Capacity shall be ________ Btuh input;
________ Btuh output capacity.
Fuel Gas Efficiency shall be 80% AFUE.
Air delivery shall be ___________ CFM minimum at
0.50 in. W.C. external static pressure.
Dimensions shall be: depth __________ in. (mm);
width _________ in. (mm); height_________in. (mm).
(casing only). Height shall be_________in. (mm). with
A/C coil and _____________in. (mm) overall with
plenum.
ELECTRICAL REQUIREMENTS
Electrical supply shall be 115 volts, 60 Hz,
single--phase (nominal). Minimum wire size shall
be_________AWG; maximum fuse size or circuit breaker
shall be __________Amps.
SPECIAL FEATURES
Refer to section of the product data sheet identifying
accessories and descriptions for specific features and
available enhancements.
Copyright 2010 Carrier Corp. D7310 W. Morris St. DIndianapolis, IN 46231 Printed in U.S.A. Edition Date: 09/10
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
Catalog No: 58CT---7PD
Replaces: 58CT---6PD
58CTA/CTX
