Cartft CTFPND-1 V4 User manual

Manual : CTFPND-1 V4
- Start navigation (Page 1)
- Settings (Pages 2-17)
- WindowsCE mode (Pages 18-19)
- Bluetooth (Pages 21-24)
- connecting accessoiry (Pages 25-26)
Navigation
For starting the pre-installed navigation software, please press the „car“-icon.

Settings
For changing GUI language, please follow these steps:

Now choose your desired language and press on „X“ to close and confirm.

Additional settings :
Backlight

Power
Sleep Timer

Sound
Startsound
Choose „customize“ to select own start sound.
Choose path to your sound file (.wav/.mp3) and confirm it.

Time
Choose date and timezone.

Co.adjust = Calibration
Hold the Cross pressed until it moves and repeat until finished.

Additional settings
„Update Logo“ enables you to choose your own boot up logo. Required file format :
24bit/Bmp with 800x480 resolution and filename „LOGO“.

„GPS Path“ enables you to set the path to the navigation software which will be started
when you press the „car“-icon in main menu.

With „USB“ you can change connection mode to PC.
Activesync = Configuration with Windows mobile program

Tools

For connection to your radio, you need to select a frequency which is not used in your
region. Note that PND must be connected to power to enable FM transmitter mode.

Windows CE Modus
With icon „Windows“ you can start the device in WinCE mode.

To end this mode just double click „GPS“ icon.

GPS Test
.
