DIGITAL TIME LENS
COMPACT DISC CHANGER TLM-3600
SERVICE MANUAL
CONTENTS
Page
SPECIFICATIONS
1
LASER BEAM INFORMATION 1
LASER BEAM DESCRIPTION AND HANDLING OF MAIN PARTS 2
DiSASSEMBLy···········································································3
CD PLAYER ADJUSTMENTS (MECHANISM)
4
CD PLAYER ADJUSTMENTS (AMP)
6
EXPLODED VIEW (CABINET CHASSIS)
9
PARTS LIST
10
EXPLODED VIEW (MAGAZINE) 14
EXPLODED VIEW (LOADING) .. 15
EXPLODED VIEW (CD MECHANISM) 16
IC BLOCK DIAGRAM
17
VOLTAGE OF IC'S TRANSISTORS 19
BLOCK DIAGRAM 21
SCHEMATIC DIAGRAM
22
WIRING DIAGRAM 24
OPERATION EXPLANATIONS FOR EACH MODE 28
AUTO-CHANGER MECHANISM OPERATION EXPLANATION 32
TROUBLE SHOOTING GUIDE . 34
SPECIFICATIONS _
Frequency Response:
SIN Ratio:
Channels Separation:
Distortion:
Wow and Flutter:
Output:
Sampling Frequency:
5Hz-20kHz
1OOdB nominal
90dB nominal @1kHz
Less than 0.015% @1kHz
below measurable limits
1.8V/1 k ohm
352.8kHz (8Xoversampling)
Specifications are subject to change without notice.
Quantization:
Optical Pick-Up:
Power Supply:
Power Consumption:
Dimensions
Weight:
18 bits
3-beam 790nm laser
120V, 60Hz
15W
4.S7"Hx19"W x13.27"D
11
Ibs.,
14
oz.
A pick-up that emits a laser beam is
used in this compact disc player.
LASER OUTPUT
CAUTION - USE OF CONTROLS OR ADJUSTMENTS OR PERFOR-
MANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED
HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE
The conditions for laser beam emission from the
pick-up are the satisfaction of all two of the follow-
ing points.
PICK UP
r--------...,
I '
IC101
CXA1081M
1.0 mW Max. (CW)
DANGER - Invisible laser radiation when open
and interlock failed or defeated.
AVOID DIRECT EXPOSURE TO BEAM.
a. CONDITIONS FOR lASER BEAM EMISSION FROM THE PICK-UP
(a) A magazine must be installed.
(b) The operation button must have been pressed,
the tray must have been put out from the
magazine, and chucking must have been com-
pleted.
DI5C
SELECT-':"'~=---i-i-r
II
MOTOR
LOADING MOTOR
1--'9.~
,=-'---
CHUCKING SW
15W2-S352)
IC302
TMP~IC820F
Input Output
5 6
2 10
H H
L L
L H
oj.
L H
H L
H L
-1-
LASER BEAM INFORMATION --------------------- _
Operation Explanations
The operation sequencefrom magazineinstallation to laser
beamoutput is explained below.
(1) When a magazineis installed with inserted power plug
and the power switch (5901) set to ON, 5356,357
becomesON, and IC302 detects that a magazinehas
beeninstalled.
(2) When an operation button (pLAY /PAUSE, INTRO·
SCAN, RANDOM PLAYI ispressed,this isdetected by
IC302, MECUP
=
"L", MECDWN
=
"H" is obtained,
and
@
=
"L
n,
@=
"Hn
is reachedfor IC305.
Then the disc selection motor runsand the mechanism
assemblyrises.
(3) Passageof the gear slot is detected by PH1 with
=
"L" during rise of the mechanismassembly,
and asthe position of the first disc isreachedwhen this
has occurred twice, MECUP
=
MECDWN
=
"H" is
obtained,
(1)
=
@
=
"L" is reachedfor IC305, and
the disc selection motor and the mechanismassembly
stop.
(If the disc selection key is pressedbefore step (2), the
mechanismassemblymovesto that position.)
(41
Next, TRYIN
=
"H" and TRYOUT
=
"L" is obtained
for IC302. Then
®
=
"L" and
@
=
"H" isput out
by IC304, the loading motor runs, and the tray is
pulled out from the magazine.
(5) When the tray has been pulled out from a magazine
completely and chucking hasbeencompleted, 5353 be-
comes ON. When this is detected, TRYIN
=
TRYOUT
=
"H" is reached,
(3)
=
@
=
"L" is reachedfor
IC304, and the loading motor and the loading mecha-
nism stop.
(6) Next, LDON
=
"L" is reached by IC302. Then the
APC circuit of IC101 operates,power issuppliedto LD
from Q101, anda laserbeamisemitted.
Protection Operation
(1) After completion of play and before the tray isstored
in the magazine, LDON
=
"H" is reachedby IC302,
and the LD laseroutput is stopped.
(2) After item (6) of the above operation explanation,
IC302 reachesLDON
=
"H" after severalsecondsif it
isdetected that there isno discon the tray.
LASER BEAM DESCRIPTION AND HANDLING OF MAIN PARTS _
PICK-UP HANDLING, REPLACEMENT AND SERVICE
NOTES
• Preparations
The compact-disc player incorporates a great many ICs
and LSls, as well as the pick-up (laser diode).
Because these components are extremely sensitive to
static electricity and therefore can be damaged by a high-
voltage concentration of static electricity, the greatest
care is necessary for their handing. In addition, many high-
precision components, such as the lens, are used in the
pick-up.
flesist.nee (1
Mnl
(1) The compact-disc player and its components must
never be repaired or stored in places where the
temperature or humidity is high, in places where
there is a strong magnetic field, or where there is ex-
cessive dust.
(2) Before making any replacement of acomponent, first
disconnect the power cord's plug from the electrical
outlet.
(3) All equipment, measuring instruments and other
tools must be grounded.
(4) The workbench must be covered by a conductive
sheet and grounded.
(5) In order to prevent AC leakagefrom a soldering iron,
metallic tools must be grounded.
(6) Workers must be grounded.
(7) The laser beam from the
pick-up
must never be per-
mitted to enter the eyes directly, and should not be
allowed to contact the skin.
-2-
LASER BEAM DESCRIPTION AND HANDLING OF MAIN
PARTS, _
(a) Unpacking
In order to prevent damage by static electricity
during shipment, the pick-up is packed in a
special conductive bag. The pick-up should be
left in this bag until immediately prior to use.
Storage in :conductive bag Avoid impact shocks.
(b) Magnetic fields
A powerful magnet is used in the pick-up. Take
care not to bring magnetic materials nearby.
(c) Places that must not be touched
• Pick-up lens
• Pick- up screws
• Printed-circuit board pattern
Your eyes can be injured if the laser beam is allowed to
enter them.
Take the greatest care to absolutely avoid eye contact
with the laser beam
Never switch ON the power to a pick-up if its laser out-
put port (object lens, etc.) is damaged.
Never look directly at the laser beam, and do not allow
the beam to contact your skin.
Cleaning the lens surface
If dust gets on the lens surface
Use an air brush (such as used for cleaning a camera
lens) to blow away the dust.
The lens is held by a support spring.
If the lens surface becomes dirty, use a soft cotton
swab or similar tool dampened with isopropyl alcohol
to clean it, taking care not to apply excessive force and
damage the lens's support spring.
Never attempt to disassemble the lens.
DISASSEMBLy _
FRONT PANEL REMOVAL MECHANISM REMOVAL
-3-
CDPLAYERADJUSTMENTS _
a.
MECHANISM ADJUSTMENT
• Notethat the mechanism of the compact-disc player
is very delicate.
• It is very important that the spindle motor (which
rotates the disc), and the sled motor (which causes
the disc signals to be tracked). as well as the gear
and other components. operate smoothly, without
eccentricity.
• When handlingthe pick-up, take carenot to exert ex-
cessive force, and particular care should be taken
not to touch the lens or the drive circuit's printed-cir-
cuit board pattern.
(a)
Replacement of the spindle motor
• First, prepare the new turntable and new special
washer for replacement.
The removed turntable will be deformed by the heat
of the soldering iron, and cannot be reused.
• Preparedial-type calipers.
(1) The attached bonding material can bedissolved by us-
ing a 60W soldering iron to heat the shaft at the lower
part of the turntable (P11) for about one minute.
(2) The turntable can then be removed from the shaft by
very carefully applying force upward at the center of
the lower surface of the turntable.
(3) Removethe two screws (PY3)and remove the spindle
motor (P2)
(4) Attach the special washer (PY6) to the spindle motor.
(5) Apply a small amount of a mixture of the
"Three
Bond
2001" and \\2105F" bonding materials to the motor's
shaft.
(6) Install the turntable as shown in the figure.
(7) Secure the turntable by pressing gently.
Be sure to wipe away (by using a piece of cloth, or
similar material) any bonding material coming out of
the hole.
(b) Replacement and lubrication of the pick-up
(1) Before replacement of the pick-up, be sure to carefully
read the section regarding the pick-up when the unit is
moved or transported.
(2) Removethe four screws (PY1) holding the spring plate
(P10), and then take out with the shafts (P9 and P8)
still attached.
(3) If the pick-up is reconditioned or replaced, be sure to
wipe the rails clean and also apply a coating of FLOll
(G-474B) to their entire circumference and entire
length.
(4)
After replacement, install
the
shaft as
before,
and
tighten the four screws (PY1) for the spring plates
(P10).
t t
@
IP11
CF
Pl-
E
E
PY2-'iI
P120
P1
-4-
CDPLAYERADJUSTMENTS _
(BE SURE, AT THIS TIME, NOT TO TOUCH ANY OTHER PART.)
(e) Checking the operation of the CD mechanism
(1) Disconnect the socket (for the sled motor power supp-
ly) from the printed-circuit board.
(2) Apply a voltage of DC 1.7V to the sled motor's ter-
minal.
(3) Measure the current during sled motor operation.
The direction of movement of the pick-up (outer
groove or inner groove) can be changed by changing
the battery polarity.
(4) The current during sled motor operation varies accor-
ding to the positional relationship of the pick-up ac-
tivator gear (P6) and the gear (P12).
If the current is equivalent to or exceeds the value
shown in the table, tighten the screws (PY5) so the in-
stallation position of the gear (P6) moves slightly.
(If the current exceeds 34 mA, s ightly increase the
distance between the screws (PY5) and the gear
(P12).)
b. RESETTING THE PICK-UP TO THE HOME POSITION
(a) The limit switch is switched ON by the projection of
the rack gear secured to the returned pick-up, after
which the sled motor continues to operate (by the cir-
cuit) for approximately 30 milliseconds; there is then
again a reverse operation, and movement to the posi-
tion at which the switch is switched OFF.
P7
F~
P12
~
-~-
P6 PYS
Direction of pick-up Sled motor current
movement
Outer groove 34 mA or less
Inner groove 34 mA or less
Rotation continues for about 30 milliseconds after the
switch is switched OFF,and then the pick-up stops at
home position.
-5-
CDPLAYERADJUSTMENTS _
a.
PREPARATION FOR ADJUSTMENTS
(a) Measuring instruments, tools and filter
1(1) Test disc blo.1 F30L-50146 (Poly Gram) etc.
No.2 YEOS-7 (Sony)
(2) Oscilloscope : S55711 (10 MHz or dual
phenomenon) or, Memoryscope : 05S6521
(Storagescope)
(3)
Automatic distortion analyzer 725 (Shiba
soku)
or
AC voltmeter (-SOdB, input impedance 1MQ or
more)
(4) AF-oscillator (400Hz, 500mV RMS)
(5)
Frequency counter (5 MHz; or more)
(6)
Screwdrivers (non-metalic) for adjustments.
(7) Band pass filter
b. PARTS LOCATION
o
o
C603
C604
TPB FA-~11
TP10 G~
TP9 TA-?: ic 201
o
@SVR203
(PLL
VCO)
IC402
SVR202 ~ SVR201 T.GAIN
F.GAIN
~ @J
SVR102
_/ F.OFFSET
SVR101 ~ @~TP1 RF .
T.BALANCE ~
D
~t~§ f~
K1m
TP4GND
oTP6 ASY
o
0
TPS
EFM
AIC401
V
OTP7
PLCK
~lC~
~lC~5
IN
BAND PASS FILTER
~
o
o
OUT
NOTE: 1. All measurements are referred to TP 4 (GND).
2. Adjust
SVR1 01, SVR102, SVR201 -SVR203, SVR351
and
SVR352
are initial setting position, as shown in the il-
lustration.
3. DTL Button: OFFposition.
-6-
II)
•.....
(/)
a:l
~
(/)
:E
u
«
u
Cl
«
•.....
Cl
N
•.....
It)
~
M
It)
a:
M
>
a:
(/)
>
~
(/)
ra
CD PLAYER ADJUSTMENTS _
c. ADJUSTMENTS
Adjustment Test Measuring Input Output Adjustment Adjustment
Item disc instrument connection connection location value
(a) PLL VCO Frequency TP 7 (PLCK) 4.55 MHz
free-run
......
.
.............. SVR203
adjustment counter TP4 (GND) (± O.05MHz)
(b) Tracking TP 3 (TE) Waveform
balance No.1 Oscilloscope ............... SVR10l symmetrical
adjustment TP 4 (GND) referred to OV.
Voltage during
(c) Focus Oscilloscope TP 2 (FE)· PLAY and
offset Band pass
...............
SVR102 voltage during
adjustment filter TP 4 (GND) STOP
=
same
voltage value
(d) Focus gain Memory scope TP
B
(FA) TP 2 (FE)
adjustment Oscilloscope TP 4 (GND) TP 4 (GND) SVR202 230m Vp-p
Oscillator
(e) Tracking gain Band pass TP 9 (TA) TP 3 (TE) SVR201 230m Vp-p
adjustment filter TP 4 (GND) TP 4 (GND)
(f) MSB No. 2 Oscilloscope
adjustment Track SVR352 (L-ch) -79.5dB
AC Digital ............... LINEOUT
for D/A con- No. 21 voltmeter SVR351 (R-ch) (±0.5dB)
verter -BOdB
(g) Checking the No.1 Oscilloscope TP 1 (RF) ............... " Eye
11
pattern.
...............
eye pattern TP 4 (GND)
(a)
PLL veo
free-run adjustment
(1) Connect a frequency counter to TP7 (PLCK).
(2) Switch ON the unit's power.
(3) Set the player to STOP mode.
(4)
Short TP4 (GND) and TP6 (ASY) electrically.
(5)
Adjust SVR203 (PLL)until the VCO frequency on TP7
is 4.55 MHz (±0.05MHz)
(6) Disconnect TP4 and TP6.
TP7
(+)
FREQUENCY
COUNTER
TP40----o
(-) L-- --'
(b) Tracking balance adjustment.
(1) Connect an oscilloscope to TP3 (TE).
(2) Play the test disc.
(3) Push the FORWARD SEARCH button.
(4) Keep the button pushed and adjust SVR101
(T.
Balance) until the track-jump TE-waves on TP3 are
symmetrical referred to OV. TP3
(TE)
(c) Focus offset adjustment
(1) Connect an oscilloscope via the band-pass filter to
TP2 (FE).
(2) Play the test disc.
(3) Record the DC offset voltage read-out at this time.
(4) PR~SS STOP.
(5)
Adjust SVR102 so that the oscilloscope voltage
TP2
reading
is
the same asthe
value measured at step (3)
above. TP4
lV
..SEARCH
.
.
.
(+ )
10K 0.,1.u
(+ )
IN
0.022
u
*
~
OUT
SCOPE
~
(-)
(-
)
BPF
-7-
CDPLAYERADJUSTMENTS _
(dl Focus gain adjustment
(1)
Connect an oscilloscope via the band-pass filter to
TP2
(FE).
(2)
Play the test disc.
(3)
Connect an AF-oscillator via a 270k ohm resistor to
TP8 (FG).
Frequency
=
400Hz, amplitude
=
500 mV RMS.
(4) Adjust SVR202(F. Gain) until the average 400 Hz FE-
signal amplitude on.TP2, measured through the band-
pass filter, is 230m Vp-p.
(e)
Tracking gain adjustment
(1) Connect an oscilloscope via the band-pass filter to
TP3 (TE).
(2) Play the test disc.
(3) Connect an AF-oscillator via a 1.2M ohm resistor to
TP9 (TG).
Frequency
=
400Hz, amplitude
=
500 rnv RMS.
(4) Adjust SVR201 (T. Gain) until the average 400 Hz TE-
signal amplitude on TP3, measuredthrough the band-
pass filter, is 230m
Vp-p,
(f) MSB Adjustment for DrA converter
(1)
Connect a automatic distortion analyzer to LINEOUT
socket.
(2) Play the trach No. 21 (-80 dB) of the test disc 2.
(3) Adjust SVR352 (L-CH) or SVR351 (R-CH) until the
AC-voltage on LINEOUT is -79.5dB.
1000kHz
SOOJ.lS
o
1000kHz
SOOJ.lS
x
(g) Checking the eye pattern
The adjustments (a)-(f) complete the adjustments of
the compact-disc player.
Next, check the eye pattern wavetorm.
8
400Hz
500mV RMS
TP8O-
--1.J\ I.(;....+....:)-a
270Kn
TP40----.(')
(-
)
BPF
TP2
..
.
(+)
10K 0.1).1
(+ )
IN
-T
-~
OUT SCOPE
O.022).lT
(-
)
(-)
TP4
TP4
400Hz
500mV
RMS
(+ )
TP9
()--1.J\ I.....:-'-O
1.2Mn
e
(-)
B P F
TP3
. . .
(+ )
10K 0.1).1
(+ )
v-
I
~
IN
0.022)..1T
OUT SCOPE
~
(-
)
(-)
TP4
L ~H
~-(+)
AUTO MATIC
~
LINE
--0
v
DISTORTION
OUT
R-CH
ANALYZER SCOPE
-
(L.P.F.:
GND
(-
)
30KHz
"ON")
TI
t
/"
l\'1\
\
~
OP
ENING EXPANDED
~b
Measuring Test Output connection \\ Eye " pattern
Jnstrument
disc point
• Check to besurethat the" eye" pat-
Oscilloscope
1
TPl ((RF) tern is at the center of the waveform
TP4 (GND) and that the diamond shape is clear-
ly defined.
(+ )
TPI
vn--~~o
SCOPE
TP4
ur"l----O
(-) L- ---'
-8-
I
(0
I
m
><
"tJ
r
o
o
m
o
S
m
=E
n
~
CO
Z
m
-i
120
C")
:t
~
(J)
C/)
en
-
PARTSLIST _
Each precaution in this manual should be followed during servicing. Components identified with the IEC symbol
Lb.
in the parts list and
the schematic diagram designate components in which safety can be of special significance. When replacing a component identified with
Lb.,
use only the replacement parts designated, or parts with the same ratings of resistance. wattage or voltage that are designated in
the parts list in this manual.
Leakage-current or resistance measurements must be made to determine that exposed parts are acceptably insulated from the supply
circuit before returning. the product to the customer. .
PRODUCT SAFETY NOTICE
PACKING
&
ACCESSORIES
CAUTION: Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Ref. Part No. Description
No.
614 216 5690 INNER CARTON
614 216 5706 PAD, TOP
614 216 5713 PAD, BOnOM
614 176 9684 INNER POLYE LAMINA COVER,
550X650MM, SET
614 216 5720 INSTRUCTION MANUAL
&614 022 7598 LEAD CORD, LINE
or & 614 022 9554 LEAD CORD, LINE
or & 614 023 0567 LEAD CORD, LINE
or &614 216 6833 LEAD CORD, LINE
CABINET
&
CHASSIS
Ref. Part No. Description
No.
1 614 216 5430 ASSY, PANEL~ FRONT
2614 216 5416 ASSY, CABINET
3614 216 5744 BACK LID
4 614 203 4200 BOnOM LID ASSY
5 614 216 5478 DECORATION
6 614 216 5461 RING
7 614 216 5621 HANDLE, FRONT
8 614 216 5553 BUnON, SKIP
(+,-)
9 614 217 9284 BUnON, SEARCH
10 614 194 4494 ROTARY KNOB, PHONES LEVEL
11 614 216 5614 BUnON, POWER
12 614 216 5591 BUnON, EJECT
13 614 216 5539 BUnON, PLAY/PAUSE/STOP
14 614 216 5584 BUnON, DISC SELECTION KEYS
15 614 216 5577 BUnON, MEMORY/CLEAR/DISPLAY
16 614 216 5607 BUnON, DTL
17 614 216 5737 COMPARTMENT LID ASSY
18 614 200 1·851 SPRING COIL, COMPARTMENT LID
19 614
200
1455 SIGN WINDOW, LCD
20 614 216 5782 SHEET, LCD
21 614 200 1820 REFLECTOR, LCD
22 614 216 5645 FILTER, LCD
23 614 112 0485 SHEET,30X20XO.1MM
24 614 129
1901
FIXER, POWER CORD
25 614 114 7185 BRACKET, DTL P.C.BOARD
26 411 092 2900 WASHER Z 3X10XIMM,
DTL P.C.BOARD
27 614 129 9136 LUG, MECHANISM LEAD MTG.
28 614
051
9785 LUG, GROUND,
POWER TRANSFORMER MTG.
FIXING PARTS
Ref. Part No. Description
No.
Y01 411
021 6603
SCR S-TPG BIN 3X8MM, CABINET
Y02 412
004
2902
SPECIAL SCREW 3X8MM, BACK LID
Y03 411 021 6405 SCR S-TPG BIN 3X8MM,
DECORATION PANEL
Y04
411 021 6405 SCR S-TPG BIN 3X8MM,
FRONT PANEL. BOnOM
Y05 411 001 2700 SCR S-TPG BIN 4X12MM, HANDLE
V06 411
022 4608
SCR S-TPG FLT 3X8MM,
POWER SWITCH
-10-
Ref. Part No. Description
No.
Y07 411 021 6405 SCR S-TPG BIN 3X8MM,
EJECT BUnON
Y08 411 021 6405 SCR S-TPG BIN 3X8MM,
PLAY/PAUSE/STOP
Y09 411 021 6405 SCR S-TPG BIN 3X8MM,
DTL BUnON
YlO 411 020 9902 SCR S- TPG BRZ
+
FLG 3X8MM,
PHONES
Yll 412 003 1807 SPECIAL SCREW, PHONES
Yl2 411 021 6405 SCR S-TPG BIN 3X8MM,
SWITCH P.C.BOARD
Yl3 411 021 6405 SCR S-TPG BIN 3X8MM,
REFLECTOR
, Yl4 412 004 2902 SPECIAL SCREW 3X8MM, LINE OUT
Yl5 411 021 6405 SCR S-TPG BIN 3X8MM,
MAIN P.C.BOARD
Y16 411 021 5705 SCR S-TPG BIN 3X6MM,
HEAT SINK
Yl7 411 021 5705 SCR S-TPG BIN 3X6MM,
DTL P.C.BOARD, BRACKET
Yl8 412 003 1807 SPECIAL SCREW, MECHANISM
Y19 411 022 4004 SCR S-TPG FLT 3X6MM,
MECHANISM
Y20 411 020 9803 SCR S-TPG BRZ
+
FLG 3X6MM,
POWER TRANSFORMER
Y21 411 001 4407 SCR S-TPG PAN 3X6MM,
LUG MTG., MECHANISM
ELECTRICAL PARTS
Ref. Part No. Description
No.
51 & 614 023 3612 POWER CORD, AC
52 & 614 200 9789 POWER TRANSFORMER (T901)
MAIN P.C.BOARD ASSY
Ref. Part No. Description
No.
71 614 217 7709 P.C BOARD ASSY, MAIN
614 035 5970 SOCKET, PHONES
614 017 6964 TERMINAL BOARD, TEST POINT
614 121 6829 HEAT SINK, IC MTG.
614 217 7938 SOCKET, LINE OUT
T501 614 219 0302 FILTER, LC
T502 614 219 0302 FILTER, LC
L401 614 028 4133 FILTER
L402 614 028 4133 FILTER
X301 614 194 2902 CERAMIC RESONATOR
X701 614 200
0311
CERAMIC RESONATOR
SVRlOl 614 003 3090 SEMI-FIXED RESISTOR, 20K OHM
or 614 204 1918 SEMI-FIXED RESISTOR, 20K OHM
SVRI02 614 003 3120 SEMI-FIXED RESISTOR, lOOK OHM
or 614 204 1956 SEMI-FIXED RESISTOR, lOOK OHM
SVR201 614 003 3090 SEMI-FIXED RESISTOR, 20K OHM
or 614 204 1918 SEMI-FIXED RESISTOR, 20K OHM
SVR202 614 0113 3090 SEMI-FIXED RESISTOR, 20K OHM
or 614 204 1918 SEMI-FIXED RESISTOR, 20K OHM
SVR203 614 003
3052
SEMI-FIXED RESISTOR, 2K OHM
PARTSlIST _
Ref. Part
No.
Description
No.
SVR203 614
204
1871 SEMI-FIXED RESISTOR, 2K OHM
CNI0l 614 017 2546 PLUG, 3P, PHOTO COUPLER
CNI02 614 017 2560 PLUG, 5P, DISC SELECTOR MOTOR
CN103 614 017 2584 PLUG, 7P, LOADING MOTOR
CNI04 614 017 2584 PLUG, 7P, SPINDLE/SLED MOTOR
CNI05 614 017 2546 PLUG, 3P, TEST POINT, TP8~TPI0
CNI06 614 017 2591 PLUG, 8P, PICK-UP
CNlO7 614 017 2577 PLUG, 6P, PICK-UP DETECTOR
CNlO8 614 016 3865 PLUG, 4P, TEST POINT, TP1~TP4
CN109 614 201 7616 SOCKET,4P,
FRONT SWITCH P.C.BOARD
CN110 614 201 7685 SOCKET, llP,
FRONT SWITCH P.C.BOARD
CN351 614 017 2096 PLUG, 2P, OF DAC &
DTL P.C.BOARD (CN352)
CN364 614 017 2119 PLUG, 4P, DTL SWITCH
P.C.BOARD (CN363)
CN381 614 020 8917 SOCKET, lOP, DF DAC &
DTL P.C.BOARD (CN353,356,358)
CN602 614 020 6555 SOCKET, 3P, POWER SUPPLY
P.C.BOARD (CN601)
CN604 614 020 6579 SOCKET, 5P, POWER SWITCH
P.C.BOARD (CN603)
RA301 614 004 6625 RESISTOR, 10K OHM X4
RA303 614 004 7523 RESISTOR, 10K OHM X7
IC101 409 108 5502 IC CXA1081 M
IC201 409 185 1602 IC CXA1082BQ
IC302 410 072 2701 IC TMP47C820F-3609
IC304 ~ 409 085 1900 IC LB1645N
IC305 ~ 409 085 1900 IC LB1645N
IC401 409 187 2102 IC CXD1125Q
IC402 409 123 71 0 9 IC LC3517BS-15
or 409 209 0307 IC UM6116K-2
IC503 409 018 4503 IC LA6458DS
or 409 039 77 05 IC NJM4558DD
IC601 ~ 409 026 8500 IC L78M05
IC602 ~ 409 077 5305 IC L79M05
IC603 ~ 409 026 9200 IC L78M10
IC701 410 028 0201 IC TMP42C40P-1367
Q101 405 007 6701 TR 2SB598-F-NP
Q201 405 023 5009 TR 2SD400-E-MP
Q202 405 007 2901 TR 2SB544-E-MP
Q203 405 023 5009 TR 2SD400-E-MP
Q204 405 007 2901 TR 2SB544-E-MP
Q205 405 023 5009 TR 2SD400-E-MP
Q206 405 007 2901 TR 2SB544-E-MP
Q207 405 023 5009 TR 2SD400-E-MP
Q208 405 007 2901 TR 2SB544-E-MP
Q250 405 073 6407 TR 2SK772-E
Q301 405 018 2600 TR 2SC3400
or 405 000 4407 TR DTC124ES
Q401 405 021 0600 TR 2SD1012-G-SPA
Q503 405 021 0600 TR 2SD1012-G-SPA
or 405 033 6805 TR 2SD1468S-S
Q504 405 021 0600 TR 2SDIOI2-G-SPA
or 405 033 6805 TR 2SD1468S-S
Q505 405 021 0600 TR 2SDlO12-G-SPA
or 405 033 6805 TR 2SD1468S-S
Q506 405 021 0600 TR 2SD 1012-G-SPA
or 405 033 6805 TR 2SD1468S-S
Q571 405 036 3108 TR 2SA1503
or 405 082 4609 TR DTA123YS
Q572 405 018 2600 TR 2SC3400
or 405 000 4407 TR DTC124ES
Q573 405 036 3108 TR 2SA1503
or 405 082 4609 TR DTA123YS
0574 405 019 3705 TR 2SC536-G-AUD-SPA
Q575 405 036 3108 TR 2SA1503
or 405
082
4609 TR DTAl23YS
Q576 405
o
1B Z600 TR 25C3400
or
405
000 4407 TR DTC124ES
Q577 405 036 3108 TR 2SA1503
or 405 082 4609 TR DTA123YS
Ref. Part
No.
Description
No.
D305 407 005 4505 DIODE DS442X
or 407 013 7109 DIODE lS2473
D308 407 005 4505 DIODE DS442X
or 407 013 7109 DIODE 152473
D309 407 005 4505 DIODE DS442X
or 407 013 71 09 DIODE lS2473
D310 407 007 9904 DIODE GMAOI
or 407 012 4406 DIODE lSS133
D311 407 007 9904 DIODE GMA01
or 407 012 4406 DIODE lSS133
D312 407 005 4505 DIODE DS442X
or 407 013 7109 DIODE lS2473
D313 407 005 4505 DIODE DS442X
or 407 013 71 0 9 DIODE lS2473
D314 407 005 4505 DIODE DS442X
or 407 013 71 0 9 DIODE lS2473
D321 407 053 5905 ZENER DIODE MTZ4.7C
D322 407 053 5707 ZENER DIODE MTZ4.7A
D561 407 007 9904 DIODE GMA01
or 407 012 4406 DIODE lSS133
D562 407 005 4505 DIODE DS442X
or 407 013 7109 DIODE lS2473
D563 407 007 9904 DIODE GMA01
or 407 012 4406 DIODE lSS133
D564 407 007 9904 DIODE GMA01
or 407 012 4406 DIODE lSS133
D571 407 007 9904 DIODE GMA01
or 407 012 4406 DIODE lSS133
D572 407 007 9904 DIODE GMA01
or 407 012 4406 DIODE lSS133
D576 407 053 6308 ZENER DIODE MTZ5.1 B
0601
&
408 007 9307 DIODE lSR35-200A-HP
or
&
407 005 2006 DIODE DS135D-KBl
D602 ~ 408 007 9307 DIODE lSR35-200A-HP
or ~ 407 005 2006 DIODE DS135D-KB1
D603 ~ 408 007 9307 DIODE lSR35-200A-HP
or ~ 407 005 2006 DIODE DS135D-KB1
D604
&
408 007 9307 DIODE lSR35-200A-HP
or
&
407 005 2006 DIODE DS135D-KB1
CI0l 403 041 9009 ELECT IOU M 16V
C102 403 003 9405 CERAMIC 4700P K 25V
C103 403 012 4101 CERAMIC 15P J50V
C104 403 113 9500 CERAMIC 4P K 50V
C105 403 004 0500 CERAMIC O.047U K 25V
CI06 403 002 7204 CERAMIC 1500P K 25V
C107 403 002 1905 CERAMIC O.OlU K 25V
C108 403 048 6506 ELECT 0.47U M 50V
C109 403 002 1905 CERAMIC O.OlU K 25V
ClIO 403 039 6904 ELECT 100U M 10V
C111 403 040 7709 ELECT 33U M lOV
C112 403 040 7709 ELECT 33U M 10V
C1l3 403 002 0502 CERAMIC 1000P K 25V
C1l4 403 003 9405 CERAMIC 4700P K 25V
C201 403 067 5603 MT-COMPO O.lU J 50V
C202 403 067 6709 MT-COMPO O.22U J 50V
C203 403 050 6808 ELECT 3.3U M 50V
C205 403 002 1905 CERAMIC O.OlU K 25V
C206 403 003 9405 CERAMIC 4700P K 25V
C207 403 041 2307 ELECT 47U M 10V
C208 403 048 6506 ELECT 0.47U M 50V
C209 403 003 1409 CERAMIC 2200P K 25V
C210 403 040 77 0 9 ELECT 33U M 10V
C211 403 049 0305 ELECT 1U M 50V
C212 403 048 6506 ELECT 0.47U M 50V
C213 403 040 1905 ELECT 22U M 10V
C214 403 048 6506 ELECT 0.47U M 50V
C215 403 003 6701 CERAMIC 0.033U K 25V
C216
403
003
6701 CERAMIC O.033U K 25V
C217 403 003 6701 CERAMIC O.033U K 25V
C225
403 059
0705 CERAMIC lOOOP K SOV
C226 403 067 6709 MT-COMPO 0.22U JSOV
C227 403 069 0705 CERAMIC 1000P K 50V
C228 403 067 6709 MT-COMPO O.22U
J
50V
C240 403 003 9405 CERAMIC 4700P K 25V
- 11 -
PARTSLIST _
Ref.
Part
No.
Description
No.
C303 403 041 2307 ELECT 47U M 10V
C307 403 002 3602 CERAMIC
O.W
K 25V .
C308 403 002 1905 CERAMIC 0.01 U K 25V
C309 403 002 3602 CERAMIC O.lU K 25V
C310 403 002 1905 CERAMIC O.OlU K 25V
C311 403 043 9304 ELECT 47U M 16V
C401 403 050 0004 ELECT 2.2U M 50V
C402 403 040 7709 ELECT 33U M lOV
C403 403 002 1905 CERAMIC O.o1U K 25V
C404 403 002 0502 CERAMIC 1000P K 25V
C501 403 039 6904 ELECT 100U M 10V
C502 403 039 6904 ELECT 100U M IOV
C509 403 0.61 1403 POLYESTER 3900P J 50V
C510 403 061 1403 POLYESTER 3900P J 50V
C513 403 041 9009 ELECT IOU M 16V
C514 403 041 9009 ELECT IOU M 16V
C521 403 063 1203 POLYESTER 0.068U J 50V
C522 403 063 1203 POLYESTER 0.068U J 50V
C523 403 047 0109 ELECT 4.7U M 25V
C524 403 047 0109 ELECT 4.7U M 25V
C525 403 069 0705 CERAMIC 1000P K 50V
C526 403 069 0705 CERAMIC 1000P K 50V
C561 403 085 4008 NP-ELECT IOU M 16V
C562 403 050 0004 ELECT 2.2U M 50V
C563 403 050 0004 ELECT 2.2U M 50V
C565 403 042 2702 ELECT 100U M 16V
C601 403 069 8404 CERAMIC 0.01 U Z 50V
C602 403 069 8404 CERAMIC 0.01 U Z 50V
C603 403 043 2503 ELECT 2200U M 16V
C604 403 043 2503 ELECT 2200U M 16V
C605 403039 6904 ELECT 100U M lOV
C606 403 039 6904 ELECT 100U M 10V
C607 403 044 9808 ELECT 100U M 25V
C608 403 042 2702 ELECT 100U M 16V
C691 403 074 2602 CERAMIC 0.047U Z 50V
C701 403 040 7709 ELECT 33U M 10V
C702 403 069 0705 CERAMIC lOOOP K 50V
R101 401 024 7004 CARBON 1K JA 1/6W
RI02 401 024 9701 CARBON 12K JA 1 6W
R103 401 027 8602 CARBON 8.2K JA 1 6W
R104 401 026 4605 CARBON 33K JA 1/6W
RIDS 401 025 8208 CARBON 22K JA 1/6W
R106 401 024 7707 CARBON lOOK JA 1/6W
RI07 401 024 7400 CARBON 10K JA 1/6W
R108 401 026 6401 CARBON 39 JA 1/6W
RI09 401 026 6401 CARBON 39 JA 1/6W
RllO 401 026 3905 CARBON 330 JA 1/6W
Rlll 401 024 7004 CARBON 1K JA 1/6W
R1l2 401 024 7004 CARBON 1K JA 1/6W
R113 401 025 4606 CARBON 18K JA 1/6W
R1l4 401 024 7004 CARBON lK JA 1/6W
R201 401 026 3905 CARBON 330 JA 1/6W
R202 401 025 0004 CARBON 120K JA 1/6W
R203
401 026 0607
CARBON 270 JA 1/6W
R204 401 025 8703 CARBON 220K JA 1/6W
R205 401 027 9005 CARBON 82K JA 1/6W
R206 401 025 8208 CARBON 22K JA 1/6W
R207 401. 024 7707 CARBON lOOK JA 1/6W
R208 401 026 1307 CARBON 27K JA 1/6W
R209 401 024 7707 CARBON lOOK JA 1/6W
R210 401 026 0607 CARBON 270 JA 1/6W
R211 401 027 3201 CARSON 560K JA 1/6W
R212 401 026 8108 CARBON 4.7 JA 1/6W
R213
401 025 4903
CARBON 180K JA 1/6W
flZ14 401 OZO 4~Q~ C '.fUION ~.~K J '.
li6V'{
R215 401 025 8208 CARBON 22K JA 1/6W
R216
401
024 8001 CARBON 1M JA 1/6W
R217 401 024 7707 CARBON lOOK JA
1/6W
R218 401 012 8105 CARBON lOOK JA 1/4W
R:>19 401 024 7400 CARBON 10K JA 1/6W
R220 401 026 0607 CARBON 270 JA 1/6W
R221 401 025
2305
CARBON 150K JA 1/6W
RZ22 401 026 8108 CARBON 4.7 JA 1/6W
-12-
Ref. Part No. Description
No.
R227 401 019 5909 CARBON 4.7 JB 1/4W
R228 401 019 5909 CARBON 4.7 JB 1/4W
R231 401 019 5909 CARBON 4.7 J8 1/4W
R232 401 019 5909 CARBON 4.7 JB
li4W
R233 401 019 5909 CARBON 4.7 JB 1/4W
R234 401 019 5909 CARBON 4.7 JB 1/4W
R242 401 027 3003 CARBON 56K JA 1/6W
R243 401 025 1605 CARBON 1.5K JA 1/6W
R244 401 024 7400 CARBON 10K JA 1/6W
R245 401 024 7400 CARBON 10K JA 1/6W
R251 401 012 7009 CARBON 10K JA 1/4W
R252 401 024 8001 CARBON 1M JA 1/6W
R253 401 024 ·7707 CARBON lOOK JA 1/6W
R254 401 027 5908 CARBON 68K JA 1/6W
R301 401 024 7400 CARBON 10K JA 1/6W
R302 401 024 8001 CARBON 1M JA 1/6W
R303 401 024 7400 CARBON 10K JA 1/6W
R304 401 019 5909 CARBON 4.7 JB 1/4W
R305 401 019 5909 CARBON 4.7 JB 1/4W
R306 401 018 5801 CARBON 330K JA 1/4W
R314 401 024 7400 CARBON 10K JA 1/6W
R315 401 024 7400 CARBON 10K JA 1/6W
R316 401 024 7400 CARBON 10K JA 1/6W
R317 401 024 7400 CARBON 10K JA 1/6W
R401 401 024 7707 CARBON lOOK JA 1/6W
R402 401 024 6700 CARBON 100 JA 1/6W
R403 401 024 9701 CARBON 12K JA 1/6W
R404 401 012 7009 CARBON 10K JA 1/4W
R410 401 026 4605 CARBON 33K JA 1/6W
R4ll 401 024 7707 CARBON lOOK JA 1/6W
R513 401 026 1000 CARBON 2.7K JA 1/6W
R514 401 026 1000 CARBON 2.7K JA 1/6W
R515 401 027 2600 CARBON 5.6K JA 1/6W
R516 401 027 2600 CARBON 5.6K JA 1/6W
R517 401 024 9701 CARBON 12K JA 1/6W
R518 401 024 9701 CARBON 12K JA 1/6W
R519 401 026 4605 CARBON 33K JA 1/6W
R520 401 026 4605 CARBON 33K JA l/6W
R523
401
026 9600 CARBON 470 JA 1/6W
R524 401 026 9600 CARBON 470 JA 1/6W
R525 401 025 6105 CARBON 200 JA 1/6W
R526 401 025 6105 CARBON 200 JA 1/6W
R527 401 024 7707 CARBON lOOK JA 1/6W
R528 401 024 7707 CARBON lOOK JA 1/6W
R531 401 026 9907 CARBON 4.7K JA 1/6W
R532 401 026 9907 CARBON 4.7K JA 1/6W
R533 401 027 0507 CARBON 470K JA 1/6W
R534 401 027 0507 CARBON 470K JA l/6W
R535 401 026 9907 CARBON 4.7K JA 1/6W
R536 401 026 9907 CARBON 4.7K JA 1/6W
R561 401 027 2303 CARBON 560 JA 1/6W
R564 . 401 026 0607 CARBON 270 JA 1/6W
R565 401 024 6700 CARBON 100 JA 1/6W
R566 401 024 7004 CARBON lK JA 1/6W
R568 401 026 4605 CARBON 33K JA 1/6W
R569 401 026 1000 CARBON 2.7K JA 1/6W
R571 401 024 7707 CARBON lOOK JA 1/6W
R572 401 024 7707 CARBON lOOK JA l/6W
R579 401 027 0309 CARBON 47K JA 1/6W
R581 401 024 7004 CARBON 1K JA 1/6W
R701 401 024 7004 CARBON lK JA l/6W
R702 401 024 8001 CARBON 1M JA 1/6W
R711 401 024 7400 CARBON 10K JA 1/6W
R712 401 024 7400 CARBON 10K JA 1/6W
POWER SUPPLY P.C.BOARD ASSY
Ref.
I
Part
No.
Description
No.
n
614 217 7716 P.C BOARD ASSY, POWER SUPPLY
614 051 9785 LUG (REI'.NO.28)
CN601 614 020 6555 SOCKET. 3P, MAIN P.C.BOARD
(CN602)
PARTSlIST _
Ref.
Part
No. Description
No.
C651 403 074 2602 CERAMIC 0.047U Z SOV
POWER SWITCH P.C.BOARD ASSY
Ref.
Part
No.
I
Description
No.
73 614 217 7723 P.C BOARD ASSY, POWER SWITCH
5901 614 019 0656 PUSH SWITCH, POWER
CN603 614 020 6579 SOCKET, SP, MAIN P.C.BOARD
(CN604)
C901 403 069 8404 CERAMIC
o.oiu
Z 50V
C902 403 069 8404 CERAMIC 0.01 U Z 50V
LCD P.C.BOARD ASSY
Ref.
Part
No. Description
No.
74 614 217 7747 P.C BOARD ASSY, LCD
614 198 3486 LCD
614 046 0032 LAMP (REF.NO.S3)
PHONES P.C.BOARD ASSY
Ref.
Part
No. Description
No.
75 614 217 7204 ASSY, PCB, PHONES
614 020 2281 SOCKET, PHONES
VR801 614 217 77 54 VARIABLE RESISTOR,
PHONES LEVEL ADJ.
614
o
51 9808 PLUG, GROUND
IC801 409 039 71 0 I IC NJM4556D
C801 403 043 9304 ELECT 47U M 16V
C802 403 043 9304 ELECT 47U M 16V
R801 401 025 1902 CARBON 15K JA 1/6W
R802 401 025 1902 CARBON 15K JA 1/6W
R803 401 026 7002 CARBON 3.9K JA 1/6W
R804 401 026 7002 CARBON 3.9K JA 1/6W
R80S 401 021 0701 CARBON 56 JA 1/4W
R806 401 021 0701 CARBON 56 JA 1 4W
R807 401 012 3001 CARBON 10 JB 1 4W
R808 401 012 3001 CARBON 10 JB l/4W
FRONT SWITCH P.C.BOARD ASSY
Ref.
Part
No. Description
No.
76 614 217 7211 ASSY, PCB, FRONT SWITCH
5301 614 018 9049 SWITCH, EJECT
S311 614 018 9049 SWITCH, DISC SELECTION KEY 1
S312 614 018 9049 SWITCH, DISC SELECTION KEY 2
S313 614 018 9049 SWITCH, DISC SELECTION KEY 3
S314 614 018 9049 SWITCH, DISC SELECTION KEY 4
S315 614 018 9049 SWITCH, DISC SELECTION KEY 5
S316 614 018 9049 SWITCH, DISC SELECTION KEY 6
5317 614 018-9049 SWITCH, DISC SELECTION KEY 7
S318 614 018 9049 SWITCH, DISC SELECTION KEY 8
S319 614 018 9049 SWITCH, DISC SELECTION KEY 9
S320 6 14 018 9049 SWITCH, DISC SELECTION KEY 10
5321 614 018 9049 SWITCH, RANDAM
5322 614 018 9049 SWITCH, MEMORY
5323 614 018 9049 SWITCH, INTRO SCAN
S324 614 018 9049 SWITCH, REPEAT
S325 614 018 9049 SWITCH, CLEAR
S326
614
0111 90-49 SWITCH, DISPLAY
5327
&14 018 9049
SWITCH, BACK SKIP
5328 614 018 9049 SWITCH, FF SKIP
S331 614 018 9049 SWITCH, STOP
5332
614 018 9049 SWITCH, PLAY/PAUSE
5333 614 018 9049 SWITCH, BACK SEARCH
5334
614 018 9049 SWITCH, FF SEARCH
614
051 9785
PLUG, GROUND
Ref.
Part
No.
Description
No.
S702 614 024 2829 SPECIAL SWITCH,
REMOTE SENSOR, GP1U1IS
or 614 208 1198 OPTO CONNECTOR,
REMOTE SENSOR
CN109 614 035 4935 SOCKET, 4P, MAIN P.C.BOARD
CNIIO·1 614 035 4942 SOCKET, 5P, MAIN P.C.BOARD
(CN110)
CNllO·2 614 035 4959 SOCKET, 6P, MAIN P.C.BOARD
(CNllO)
0301 407 007 9904 DIODE GMA01
or 407 012 4406 DIODE 15S133
0302 407 007 9904 DIODE GMA01
or 407 012 4406 DIODE 15S133
0303 407 007 9904 DIODE GMAOI
or 407 012 4406 DIODE 1SS133
0304 407 007 9904 DIODE GMAOI
or 407 012 4406 DIODE 1SS133
C331 403 074 2602 CERAMIC 0.047U Z 50V
OF DAC
&
DTL P C BOARD ASSY
..
Ref.
Part
No. Description
No.
77 614 217 7228 ASSY, PCB, OF DAC & DTL
614 221 0819 ASSY, CONNECTOR-S,
SHIELD, CN352 MTG.
L3S1 614 028 6748 FILTER
X351
614 210 5986 RESONATOR (C391 =9PF)
or 614 212 1030 RESONATOR (C391=27PF)
SVR351 614 204 1956 SEMI-FIXED RESISTOR, lOOK OHM
SVR352 614 204 1956 SEMI-FIXED RESISTOR, lOOK OHM
CN352 614 020 1215 SOCKET, 2P, MAIN P.C.BOARD
(CN351)
CN353 614 020 6562 SOCKET, 4P, MAIN P.C.BOARD
(CN381)
CN354 614 020 6555 SOCKET, 3P, MAIN P.C.BOARO
CN356 614 020 6555 SOCKET, 3P, MAIN P.C.BOARD
(CN381)
CN358 614 020 8849 SOCKET, 3P, MAIN P.C.BOARO
(CN381)
CN359 614 201 7647 SOCKET,7P,
DTL SWITCH P.C.BOARD (CN360)
IC351 409 202 4500 IC PCM61P
or 409 210 0402 IC AD1860N
IC352 409 202 4500 IC PCM61P
or 409 210 0402 IC AD1860N
IC353 409 195 4204 IC PD0050
IC371 409 018 4503 IC LA6458DS
or 409 039 7705 IC NJM4558DD
IC381 409 018 4503 IC LA6458DS
or 409 039 77 05 IC NJM4558DD
C351 403 081 5900 POL YPRO 330P J 100V
C352 403 081 5900 POLYPRO 330P J 100V
C353 403 069 8404 CERAMIC O.OIU Z 50V
C354 403 069 8404 CERAMIC O.OIU Z 50V
C371 403 041 9009 ELECT IOU M 16V
C372 403 058 3205 POL YESTER 0.015U K 50V
C373 403 041 9009 ELECT IOU M 16V
C381 403 041 9009 ELECT IOU M 16V
C382 403 058 3205 POL YESTER 0.015U K 50V
C383 403 041 9009 ELECT IOU M 16V
C39l 403 020 2809 CERAMIC 27P K 50V (X351
ONLY PARTS NO.614 2121030)
or 403 034 3106 CERAMIC 9P D 50V (X351
ONLY PARTS 1'10.614210 5986)
C392 403 020 2809 CERAMIC 27P K SOV
(X351
ONL y PARTS 1'10.614212 1030)
or
403 034 3106 CERAMIC 9P D 50'J (X351
ONLY PARTS NO.614 210 5986)
C393 403 039 6904 ELECT 100U M lOV
C394 403 039 6904 ELECT 100U M 10V
C396 403 041 2307 ELECT 47U M JOV
C397 403 041 2307 ELECT 47U M IOV
C398 403 074 2602 CERAMIC 0.047U Z 50V
-13 -
PARTSLlST _
I
Ref.
I
Part
No.
Description
No.
C399 403 074 2602 CERAMIC O.047U Z 50V
R351
401 027 0507 CARBON 470K JA 1 6W
R352 401 025 8703 CARBON 220K JA l/6W
R353 401 024 8001 CARBON 1M JA 1/6W
R354 401 027 3201 CARBON 56 OK JA 1 6W
R361 401 027 0507 CARBON 470K JA 1 6W
R362 401 025 8703 CARBON 220K JA 1 6W
R363 401 024 8001 CARBON 1M JA 1/6W
R364 401 027 3201 CARBON 560K JA 1 6W
R371 401 024 7707 CARBON lOOK JA 1/6W
R372 401 027 1603 CARBON 5.1K JA l/6W
R373 401 025 3302 CARBON 16K JA 1I6W
R374 401 026 4605 CARBON 33K JA 1/6W
R375 401 027 1603 CARBON 5.1 K JA 1/6W
R376 401 026 9600 CARBON 470 JA l/6W
R377 401 024 77 07 CARBON lOOK JA 1/6W
R381 401 024 7707 CARBON lOOK JA 1/6W
R382 401 027 1603 CARBON 5.1K JA 1/6W
R383 401 025 3302 CARBON 16K JA 1I6W
R384 401 026 4605 CARBON 33K JA 1/6W
R385 401 027 1603 CARBON 5.lK JA l/6W
R386 401 026 9600 CARBON 470 JA 1/6W
R387 401 024 77 07 CARBON lOOK JA 1 6W
R390 401 026 1307 CARBON 27K JA 1/6W
R393 401 026 3905 CARBON 330 JA 1/6W
DTL SWITCH P.C.BOARD ASSY
Ref.
Part
No. Description
No.
78 614 2 17 7235 ASSY, PCB, DTL SWITCH
6 14 221 0826 ASSY, CONNECTOR-S,
SHIELD, CN361 MTG.
SW351 614 217 7945 SWITCH, PUSH, DTL
CN360 614 035 4966 SOCKET, 7P, DF DAC &
DTL P.C.BOARD (CN359)
CN363 614 020 1239 SOCKET, 4P, MAIN P.CBOARD
(CN364)
R39l 401 026 9600 CARBON 470 JA 1 6W
R392 401 026 9600 CARBON 470 JA 1/6W
DTL LED P.C.BOARD ASSY
Ref.
Part
No. Description
No.
79 614 217 7242 ASSY, PCB, DTL LED
0351 407 027 4804 LED SLP-151B-B
REMOTE CONTROL (RB-TLM-3600/CV)
Ref.
Part
No. Description
No.
6 14 221 7771 REMOTE CONTROL ASSY, UNIT
614 193 7267 INNER POLY COVER,
180X200MM, REMOTE CONTROL
EXPLODED VIEW (MAGAZINE)
&
PARTS LIST ----:- _
--
10-CD MAGAZINE (TLM.lO)
A10
Ref.
Part
No. Description
No.
614 217 9352 INNER CARTON, 10-CD MAGAZINE
614 217 9390 TRAY ASSY, 10-CD MAGAZINE
614 202 1170 LABEL, INDEX, lO-CD MAGAZINE
614 176 7758 INNER POLYE LAMINA COVER,
200X250MM, IO-CD MAGAZINE
614 205 9395 NOTICE, PRE-CAUTION,
10-CD MAGAZINE
CABINET
CHASSIS (TlM.I0)
Ref.
Part
No. Description
No.
Al 614 217 9628 BonOM LID ASSY, MAGAZINE
A2L 614 202 7509 TRA Y ASSY, CD TRAY,
LEFT, lO-CD MAGAZINE
A2R ,614 202 7516 TRA Y ASSY. CD TRAY,
RIGHT, 10-CD MAGAZINE
A4 614 205 7438 SPRING PLATE, TRAY LOCK
A5 614 217 9611 TOP LID ASSY
A6 614 203 2923 SIDE PANEL RIGHT
A7 614 203 2930 SIDE PANEL LEFT
AID 411 100 0201 SCR S- TPG BIN 2X8MM,
TOP LID ASSY
A12 411 104 7008 SCR S-TPG BIN 2X5MM,
SPRING PLATE
3 INCH TRAY INSERTS (TlM·3) (OPTION)
Al0
Ref.
Part
No. Description
No.
614 202 7530 TRAY ASSY, 3 INCH MAGAZINE,
LEFT (A2L)
614 202 7547 TRAY ASSY, 3 INCH MAGAZINE,
RIGHT (A2R)
614 221 1915 HOLDER
614
221 2493
POLY COVER, 150X160MM
614 221 2554 INSTRUCTION SHEET
-14-
Ml~
MY2
M30
MY5
-15-
PARTS LIST (LOADING)
EXPLODED VIEW (CD MECHANISM) -------------
LOADING MECHANISM (PM.OAOCH2)
Ref. Part No. Description
No.
M1 614
140
13 93 LEVER, CHUCK
M2 614 211 6654 SPRING PLATE, CHUCK
M3 614 135 9342 PULLEY. CHUCK
M4 614 108
2875
BRACKET, TRAY GUIDE
M5
614 108 2110 BRACKET, TRAY GUIDE, LOWER
M6 614 194 6214 LEVER ASSY, SLIDE
M7 614 194 6207 LEVER ASSY, EJECT
M8 614 198 1017 LEVER, HOLD
M9 614 15.1 7117 SPRING COIL, LEVER RETURN
MI0 614 108 2868 BRACKET, MAGAZINE GUIDE
Mil 614 140 1423 LEVER, MAGAZINE LOCK
M12 614 151 7124 SPRING COIL,
MAGAZINE LOCK LEVER
M13 614 018 9223 SWITCH, MAGAZINE, S355-357
614 018 9223 SWITCH,
MECHANISM INITIALIZATION
POSITION DETECT, S351
M14 614 139 1045 SLIDE, SELECTOR, LEFT
M15 614 127 8650 PIPE, SLIDE GUIDE
.'
M16 614 1.94 6184 BRACKET ASSY, MAGAZINE TOP
M17 614 194 6085 COMMUTATE MOTOR ASSY,
DISC SELECTOR
M18 614 134 8926 GEAR, RELAY
M19 614 134 8957 GEAR, SLIDE
M20 614 115 6705 CHASSIS, MAIN
M21 614 139 1052 SLIDE, SELECTOR, RIGHT
M22 614 194 6085 COMMUTATE MOTOR ASSY,
LOADING
M23 614 151 8244 SPRING PLATE, CHASSIS
M24 614 194
6368
P,C BOARD ASSY, SENSOR
614 002 4562 PHOTO INTERRUPTER
401 026 9600 CARBON 470 JA 1/6W, R351
M25 614 194 6191 CHASSIS ASSY,
LOADING MECHANISM
M26 614 202 2689 GEAR, RELAY
M27 614 134 8964 GEAR, TRAY LOADING
M28 614 140 0129 LEVER, TRAY LOCK
M29 614 203 5993 SPRING WIRE, LEVER
M30 614 151 7315 SPRING COIL, LEVER
M32 614 200 3633 PIPE, SLIDE GUIDE
M33 614 129 4636 FIXER, LEAD
M3S 614 134 8933 GEAR,CAM
M36 514 024 1778 SWITCH, CHUCKING
COPLETION DETECT, S353
M37 614 024 1600 SWITCH, TRAY STORAGE
COMPLECTION DETECT, S352
M38 614 145 9363 SHAFT, MAGAZINE ROLLER
M39 614 209 2774 SPRING, TENSION,
LOADING MECHANISM
M40 614 129 9136 LUG. LEAD
614 194 3541 SOCKET, 3P, PHOTO COUPLER
(CNlOl)
614 194
3558
SOCKET. 'SP, MAGAZINE SWITCH/
DISC SELECT MOTOR (CNI02)
614 201 4523 SOCKET, 7P, CAM SWITCH,
LOADING MOTOR (CNI03)
614 125 6443 CUSHION, 15X25X3MM,
MOTOR LEAD MTG.
FIXING PARTS (MECHANISM B)
.-.
Ref. Part No. Description
No.
MY 411 003 880~ SCR PAN + SW 2..6X6MM,
LOADING MOTOR
MY2 411 020 9902 SCR S-TPG BRZ+FLG 3X8MM,
SLIDE
MY4 411 087 4704 WASHER V 2X6XO.4MM, BRACKET
Mve 411 022 7807 SCR S- TPG PAN 2X6 MM, BRACKET
MY6 411 020 9902 SCR S- TPG BRZ +FLG 3X8MM,
GEAR
- 16-
Ref. Part No. Description
No.
MY? 411 020 9100 SCR S-TPG BRZ+FLG 3X12MM,
LEVER
MYB 411 021 6405 SCR S-TPG BIN 3X8MM, BRACKET
MY9 411 021 5705 SCR S-TPG BIN 3X6MM.
SLIDE GUIDE
MYlO 411 104 4205 SCR TPG PAN pes L7X8MM,
SWITCH
or
411 030 2801 SCR TPG PAN PCS L7X8MM,
SWITCH
MYlI 411 099 0503 SCR TPG PAN PCS 1,7X6MM,
SWITCH
MYl2 411 087 6005 WASHER V 2.6X7.5XO,SMM,
BASE MECHANISM FLOATING
MY13 411 119 8908 SCR S-TPG PAN 2X14MM,
BASE MECHANISM
MYl4 411 022 8408 SCR S-TPG PAN 2X8MM, SWITCH
MYl5 411 044 7205 SCR PAN+SW 2X4MM,
SENSOR P.C.BOARD
MYl6 411 119 8908 SCR S-TPG PAN 2XI4MM,
BRACKET
MYl7 411 002 5908 SCR PAN 2.6X4MM, MOTOR
MYl8 412 014 6501 SPECIAL WASHER. SHAFT
MYl9 412 022 6500 SPECIAL WASHER, LEVER
MY20 .411 015 7906 RING E L5MM
MY21 412 027 1906 SPECIAL WASHER, GEAR
MY22 411
020
9902 SCR S- TPG BRZ HLG 3X8MM,
LEVER
MY23 412 005 2307 SPECIAL SCREW, SLIDE
MY25 614 205 1559 RUBBER CUSHION,
MECHANISM FLOATING
MY26 411 001 4407 SCR S-TPG PAN 3X6MM, LUG
PARTS LIST (CD MECHANISM)
&
IC BLOCK DIAGRAM _
CD MECHANISM (PM-DADCH2B)
Ref.
,
No.
Part
No. Description
P614 222
3208
CHASSIS ASSY WITH
SPINDLE MOTOR & TURN TABLE
(REF.NO.P I,P2,P 11,PY3&PY6)
PI
614 067 2756
CHASSIS ASSY, BASE MECHANISM
P2 614 945 2) 05 COMMUTATE MOTOR. SPINDLE
P3 614 045 2136 COMMUTATE MOTOR ASSY, SLED
P4 614 199 0712 PICK-UP
P5 614 018 9223 SWITCH, LIMIT, S354
P6 614 134 8902 GEAR. PICKUP SLED
P7 614 134 8919 GEAR. PICKUP SLED
P8 614 145 9653 SHAFT, PICKUP SLED, LONG
P9 614 145 9622 SHAFT, PICKUP SLED, SHORT
PI0 614
207
2653 SPRING PLATE, SHAFT
P11 614
073
7073 TURN TABLE
P12 614 134 8872 GEAR. PICKUP SLED
P13 614 134 8889 GEAR, RELAY
P15 614 201 4516 SOCKET, 7P, MAIN P.C.BOARD,
CNI04
P16 614 151 7223 SPRING COIL, PICKUP SLED GEAR
P17 614 129 4636 FIXER. LEAD MTG.
P18 614 130 0535 LUG,GROUND·
P19 614 222 1280 SHEET, 10X4XO.12MM,
CHASSIS MTG.
P20 614
222
1273 SHEET, 8X4XO.25MM,
CHASSIS MTG.
HZGMCGR6020++ MC-GREASE, MOL YKOTE, X5-6020,
PICKUP SLED
IC304, 305 LB1645N
(TAPE MECHANISM MOTOR DRIVER)
•....
HQrrnaJ(R •••••••••. )AotO'y
~w{No-YPIOI)~cry
""'"
I~ L~ Cif'c:uil
1-----{i]6
1HZ
I
IC353 PD0050 (DIGITAL FILTER)
LRCK
C>-------------,
DATA
BCLK
I~
--J
Ref.
Part
No.
I
Description
No.
HZGFLGR474B++ F-GREASE, FLOIL, G-474B.
GEAR SHAFT
HZCTBND2001++ THREE-BOND, TB2001,
TU,RN TABLE
(TB2105 MIXED IN AI: 1 RATIO)
HZCTBND210S++ THREE-BOND, TB210S,
TURN TABLE
(TB2001 MIXED IN AI: 1 RATIO)
FIXING PARTS (MECHANISM E)
Ref.
Part
No.
Description
No.
PYl 411
028
2806 SCR S- TPG PAN 2X3MM.
SPRING PLATE
PY2 412 013 0609 SPECIAL WASHER,
1.6X3.2XO.25MM. GEAR
PY3 411 044 7007 SCR PAN+SW 2X3MM,
SLED MOTOR
411 044 7007 SCR PAN + SW 2X3MM,
SPINDLE MOTOR
PY4 411 099 OS03 SCR TPG PAN PCS l.7X6MM,
LIMIT SWITCH
PY5 411 044 7502 SCR PAN+SW 2X5MM,
PICK-UP SLED GEAR
PY6 412 032 0208 SPECIAL WASHER,
1.9X5XO.3MM, SPINDLE MOTOR
IC351, 352 PCM61 P or AD 1860N
(D/A CONVERTER)
18-BIT
OAe
MSB AOJ
vs
TRIM
lOUT 1- ...•..•-( lOUT
AGNO
SJ
Rf
XIN
IC371, 381, 503
LA6458DS or NJM4558 DD
(DUAL OPERATIONAL AMP.)
I-~-+-¢
XOUT
CKOur
MODE'
I----~ MODO
I----~ MOoE3
I----¢
SHOUT
1----(1 WOUT
L_-1---i
SOUT
von
BOUT
WOUT
MODE3
RD OUT
1---+0 LDO,UT
"-_--I
SHOUT
vss e
9 MOOE 2
TOP VIEW
vss voo
-17-
ROOUT
IC BLOCK DIAGRAM _
IC401 CXD1125Q
(DIGITAL SIGNAL PROCESSOR)
~
" 0
u m
(;)
~
SOCK
su >o
OlCRCF
i
:::t
I- (()
C§ d ~ ~
III
3~~a
o -
-c
-c
co co
"III
ur
-c
u '"
u
-e: -c
tx a:
IC402 LC3517BS-15 (STATIC RAM)
A10
MEMORY
A2
CELL
A1
Af'lAV
AD
JI,PUT DATA BUFFER
....,~ ••••••<.br---CO?l
4444:444
Ii:
I~
eo
£? -. - ..•. ~
18
IC601 L78M05 (5V REGULATED POWER SUPPLY)
IC603 L7SM10 (10V REGULATED POWER SUPPLY)
IC602 L79M05 (-5V REGULATED POWER SUPPLY)
LCS01 NJM4556 (DUAL OPERATIONAL AMP.)
DOTX
OUTPUT
A
INPUT
-A
OUTPUT
B
INPUT
+A INPUT
-8
INPUT
+8
TERMINAL NAME TERMINAL DESCRIPTION
-
,
R NP T
1
,
1AU. NPUT
I
UTPUT
P ENABLE
NP
T
N
uTP"T FNA' F ''''PIIT
V" +~V
POWER $OUR
E
C;ND C;FlOLf<D
_13
i
I~
Other Carver CD Player manuals
