Cascade Meadows EM131MGG User manual

1
tm
Kitchenware
EM131MGG
1
1
1

PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can
result in harmful exposure to microwave energy. It is important not to
with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or
cleaner residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that
the oven door close properly and that there is no damage to the:
(1) DOOR (bent)
(2) HINGES AND LATCHES (broken or loosened)
(3) DOOR SEALS AND SEALING SURFACE
(d) The oven should not be adjusted or repaired by anyone except properly
qualified service personnel.
1550W
1100W
Specifications
Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
12.4 inch
20.2 12.09 inch (513 416 307mm) 16.38
120V~ 60Hz
EN-2
defeat or tamper
S
EM131MGG
1.1 Cu.ft
31.3Lbs (14.2kg)

IMPORTANT SAFETY INSTRUCTIONS
WARNING
1. Read all instructions before using the
appliance.
2. Read and follow the specific: "PRECAU-
TIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY"
found on page 2.
3. As with most cooking appliances, close
supervision is necessary to reduce the risk
of a fire in the oven cavity.
4.To reduce the risk of fire in the oven
cavity:
i). Do not overcook food. Carefully attend
the appliance when paper, plastic, or
other combustible materials are placed
inside the oven to facilitate cooking.
ii).Remove wire twist-ties and metal
handles from paper or plastic
containers/bags before placing them in
the oven.
iii). If materials inside the oven ignite,
keep the oven door closed. Turn the
oven off, and unplug the appliance.
Disconnect the power cord, shut off
power at the fuse or circuit breaker panel.
iv). Do not use the oven cavity for storage
purposes. Do not leave paper products,
cooking utensils, or food in the cavity
when not in use.
5. This oven must be grounded. Connect
only to properly grounded outlet. See
"GROUNDING INSTRUCTIONS" found
on page 5.
6. Install or locate this oven only in
accordance with the installation
instructions provided.
7. Some products such as whole eggs,
and should not be heated
in the oven.
To reduce the risk of burns, electric shock, fire,injury to
persons or exposure to excessive microwave oven energy
when using your appliance, follow basic safety precautions,
including the following:
8. Use this appliance only for its intended
uses as described in this manual. Do
not use corrosive chemicals or vapors
in this appliance. This oven is specifically
designed to heat cook
or dry food.
It is not designed for
industrial or
laboratory use.
9. As with any appliance, close
supervision is necessary when used
by children.
10. Do not operate this oven if it has a
damaged cord or plug, if it is not
working properly or if it has been
damaged or dropped.
11. This appliance should be serviced only
by qualified service technicians.
Contact the nearest authorized service
facility for examination, repair or
adjustment.
12. Do not cover or block any openings on
the oven.
13. Do not store or use this appliance
outdoors.
14. Do not use this oven near water, for
example, near a kitchen sink, in a wet
basement, near a swimming pool, or
similar locations.
15. Do not immerse cord or plug in water.
16. Keep cord away from heated surfaces.
17. Do not let cord hang over edge of
table or counter.
18. When cleaning interior or exterior
surfaces,
soaps or detergents applied with a
sponge or soft cloth.
sealed containers, or closed glass jars
,
may explode
use only mild, nonabrasive,
EN-3

i) Do not overheat the liquid.
ii) Stir the liquid both before and halfway through heating it.
iii) Do not use straight-sided containers with narrow necks.
iv) After heating, allow the container to stand in the microwave oven for a short time
before removing the container.
v) Use extreme care when inserting a spoon or other utensil into the container.
19. Liquids, such as water, coffee, or tea overheated beyond the boiling point
without appearing to be boiling. Visible bubbling or boiling when the container is
removed from the microwave oven is not always present. THIS COULD RESULT IN
VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS
DISTURBED OR A SPOON, OR OTHER UTENSIL, IS INSERTED INTO THE LIQUID.
This appliance must be grounded. In the event of
an electrical short circuit, grounding reduces the risk
of electric shock by providing an escape wire for the
electric current. This appliance is equipped with a
cord having grounding wire with a grounding plug.
The plug must be plugged into an outlet that is
properly installed and grounded.
Consult a qualified electrician or serviceman if the
grounding instructions are not completely understood
or if doubt exists as to whether the appliance is
properly grounded. If it is necessary to use an
extension cord, use only a 3-wire extension cord that
has a 3-pronged grounding plug, and a 3-slot
receptacle that will accept the plug on the appliance.
GROUNDING INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING
DANGER
Electric Shock Hazard
Touching some of the internal
components can cause serious
personal injury or death. Do not
disassemble this appliance.
Electric Shock Hazard
Improper use of the grounding
can result in electric shock. Do
not plug into an outlet until
appliance is properly installed
and grounded.
(grounding) plug
Three-pronged
The marked rating of the extension cord shall be
equal to or greater than the electrical rating of the
appliance.
may
EN-4

CAUTION
Personal Injury Hazard
Tightly-closed utensils
could explode. Closed
containers should be opened
and plastic pouches should be
pierced before cooking.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
UTENSILS See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven."
There may be certain non-metallic utensils that are not
safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
Radio Interference
1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in
or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised in
thei use.
3. If a long cord set or extension cord is used:
1) The marked electrical rating of the cord set or extension
cord should be at least
as great as
the electrical rating of the appliance.
2) The extension cord must be a grounding-type 3-wire cord
3) The longer cord should be arranged so that it will not drape over the countertop or tabletop
where it can be pulled on by children or tripped over unintentionally.
1. Operation of the microwave oven may cause interference to your radio, TV
or similar equipment.
2. When there is interference, it may be reduced or eliminated by taking the
following measures:
1) Clean door and sealing surface of the oven
2) Reorient the receiving antenna of radio or television.
3) Relocate the microwave oven with respect to the receiver.
4) Move the microwave oven away from the receiver.
5) Plug the microwave oven into a different outlet so that microwave oven
and receiver are on different branch circuits.
.
EN-5
r

Materials you can use in microwave oven
Utensils Remarks
Follow manufacturer’s instructions.The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing.Transfer food into microwave-safe dish.
May cause arcing.Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
EN-6

A) Control panel
B)Turntable shaft
C)Turntableringassembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C B
ED
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down.The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Turntable Installation
Turntable shaft
EN-7

Installation
A minimum clearance of 3.0 inches
(7.5cm) is required between the oven and
any adjacent walls. One side must be open.
(1) Leave a minimum clearance of 12
inches (30cm) above the oven.
(2) Do not remove the legs from the
bottom of the oven.
(3) Blocking the intake and/or outlet openings
can damage the oven.
(4) Place the oven as far away from
radios and TV as possible.
Operation of microwave oven may
cause interference to your radio or TV
reception.
2. Plug your oven into a standard household
outlet. Be sure the voltage and the
frequency is the same as the voltage
and the frequency on the rating label.
WARNING: Do not install oven over a
range cooktop or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and
the warranty would be void.
3.0 inch(7.5cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Countertop Installation Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
1. Select a level surface that provide
enough open space for the intake
and/or outlet vents.
EN-8

EN-9
Control Panel
(1)Sensor Cook Menu (Sensor Reheat,
Frozen Pizza, Fish, Meat, Fresh Vegetable,
Frozen Vegetable, Potato, Frozen Entree)
(2) Popcorn
(3) Memory function
(4) Time Defrost
(5) Weight Defrost
(6) Number Pad (0-9)
(7) Express Cook (Number Pad 1-3)
(8) Power (10 power levels available)
(9) Cook Time
(10) Stop/CANCEL (Before cooking starts,
press to clear all previous settings;
during cooking, press once to stop
oven; press twice to stop oven and
clear all settings.
(11) START/+30SEC. (Begin cooking
time or add time to cooking)
(12) Clock
(13) Timer
(2)
(3)
(4)
(5)
(6)
(8)
(10)
(12)
(1)
(7)
(9)
(11)
(13)

OPERATION
EN-10
1. POWER LEVEL
10 power levels are available.
LEVEL 10 987654321
POWER 100% 90% 80% 70% 60% 50% 40% 30% 20% 10%
DISPL AY PL10 PL9 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1
2. CLOCK SETTING
(1) Press “CLOCK“, “00:00” will display.
(2) Press the number keys and enter the current time. For example, time is
10:12 now, please press “1,0,1,2” in turn.
(3) Press “CLOCK“ to nish clock setting. “:” will ash and the clock will
illuminate.
(4) If the numbers input are not within the range of 1:00-12:59, the setting will
be invalid until valid numbers are input.
Note: * In the process of clock setting, if the “STOP/CANCEL“ button is
pressed or if there is no operation within 1 minute, the oven will go back
to the former setting automatically. ** If the clock needs to be reset,
please repeat step 1 to step 3.
3. MICROWAVE COOKING
(1) Press “COOK TIME ” once, the screen will display “00:00”.
(2) Press number keys to input the cooking time; the maximum cooking time
is 99 minutes and 99 seconds.
(3) Press “POWER LEVEL“ once, screen will display “PL10”. The default power
(4) Press “START/+30SEC“ to start cooking.
Example: To cook the food with 50% microwave power for 15 minutes.
(a) Press once.”00:00” displays.
(b) Press “1”,”5”,”0”,”0” in order.
(c) Press “POWER LEVEL”once,then press “5” to select 50%
microwave power.
(d) Press “START/+30SEC“ to start cooking.
Note: * In the process of setting, if the “STOP/CANCEL“ button is pressed or
if there is no operation within 5 minutes, the oven will go back to the former
setting automatically. ** You can skip the step of “c” and cook at 100%
microwave power.
4. KITCHEN TIMER
(1) Press “TIMER“ once, the screen will display 00:00.
(2) Press the number keys and enter the timer time. (The maximum cooking
time is 99 minutes and 99 seconds.)
(3) Press “START/+ 30SEC“ to conrm setting.
is 100% power. Now you can press number keys to adjust the power level.
“COOK TIME ”

EN-11
(4) When the timer time arrives, the buzzer will ring 5 times and the screen
display will go back to the time mode.
Note:
5. EXPRESS COOKING
(1) In waiting state, instant cooking at 100% power level with 30 seconds’
cooking time can be started by pressing “START/+ 30SEC“. Each press
on the same button will increase cooking time by 30 seconds. The maximum
cooking time is 99 minutes and 99 seconds.
(2) Start the microwave instantly, at 100% power by pressing number pads
1-3. Press “START/+ 30SEC“ to increase the cooking time; the maximum
cooking time is 99 minutes and 99 seconds.
Note: *During microwave cooking, time defrost and auto menu time can be
added by pressing the “START/+ 30SEC“ button.
6. CANCEL QUICKLY
During setting or running procedure, pressing “STOP/CANCEL“ can stop
current states and turn back to the waiting states instantly.
7. WEIGHT DEFROST
(1) Press “WEIGHT DEFROST“ once, screen will display “0.0”;
(2) Press numerical buttons to input weight to be defrosted. Input the weight
range between 0.3-6.3 lbs. If the weight input is not within 0.3-6.3 lbs, the
input will be invalid.
(3) Press “START/+ 30SEC“ to start defrosting and the cooking time
remaining will be displayed.
8. TIME DEFROST
(1) Press “TIMER DEFROST“ once, screen will display “00:00”.
(2) Press number pads to input defrosting time. The effective time range is
00:01~99:99.
(3) The default is 30% power. And it cannot be changed.
(4) Press “START/+ 30SEC“ to start defrosting. Remaining cooking time
will be displayed.
1. The kitchen time is different from 12-hour system,Kitchen Timer is a timer.
2. Kitchen Timer and cooking (including microwave, defrosting, Auto menu)
are independent, all the cooking functions cannot be set during running Kitchen
Timer, Kitchen Timer cannot be set during running other cooking functions.

EN-12
9. QUICK COOK CONTROL
POPCORN
(1) Press “POPCORN“ repeatedly until the number in OUNCES you need
appears in the display: “3.0”,”3.5”,”1.75” Oz will display in order.
For example, press “POPCORN” once, “3.0” appears.
(2) Press “START/+30SEC.“ to cook, buzzer sounds once. When cooking
nishes, buzzer will sound 5 times, and turn back to former state.
10.SENSOR COOK
(1) In waiting state, put the food in the oven, press the menu key in the
sensor cook.
(2) Press “START/+30SEC.“ to start sensor reheat function with no need to
set time.
(3) The sensor will sound twice when the steaming has emanated. The
surplus time will display, the buzzer will sound 5 beeps when nished.
The oven will turn back to the former state.
Note:
1) When cooking or reheating food, you should do these in order to have
the best effect.
a. The room temperature cannot be over 35 C( ).
b. The weight of food must be more than 110g (4 Oz).
c. The cavity, glass tray and utensils must be kept dry before
putting the food in.
d. Reheating food can be covered with a lid, but the lid must have a
venthole in order to emanate the steam. Sealed utensils must not
be used.
2) During the cooking process, the following must be done.
a. Keep the door closed when the surplus time is not displayed or
the buzzer does not sound twice.
b. When the buzzer sounds twice, the time will count down and
display the surplus time, you can open the door to mix the food
up, turn over or replace the food. And then go on to the next operation.
3) Please let food cool for a while after cooking has nished.
4) During sensor cooking process, if the time is not counting down, please
do not open the oven door or press “STOP/CANCEL“ key. Otherwise, the
sensor will make mistakes.
95 F

EN-13
Menu Weight Initial Temp. Additional Instructions
SC-1
Sensor
Reheat 8~12 Oz
5 degrees
Reheat food is dinner plate. When sensor time
is nished. Cooking time counts down. Now
you can mix it and then continue reheating.
SC-2
Frozen
Pizza 6~12 Oz
(170~340g)
minus 18
degrees
If the weight is over 12 Oz, please set the
additional cooking time manually.
SC-3
Fish
4~16 Oz
(110~450g) 5 degrees
Arrange in a single layer. Cover with lid or vented
plastic wrap. Cover the lm before cooking and leave
a spacing near the edge of the container in order to
let the steam out. When cooking time counts down,
press “STOP/ CANCEL” to pause, open the oven
door to turn overthen continue to cook.
SC-4
Meat
8~24 Oz
(225~680g)
Break apart in glass bowl or colander. Cover
with lid or vented plastic wrap. Juices should
be clear when done, Drain. When cooking time
counts down. Press “STOP/ CANCEL” to pause
and open the oven door to mix and then contin-
ue to cook.
SC-5
Fresh
Vegetable 4~16Oz
(110~450g)
Room
Temp.
All pieces should be the same size. Wash thor-
oughly, add 15ml water per 125g vegetables, and
cover with a lid or vented plastic wrap. When
cooking time counts down. Press to pause and
open the oven door to mix and then continue to
cook.
SC-6
Frozen
Vegetable
6~16Oz
(170~450g)
Wash thoroughly, add 15ml water per 125g vegeta-
bles, and cover with a lid or vented plastic wrap.Do
not salt/butter vegetables until after cooking.
SC-7
Potato
1~4 Units
(6~8Oz
each one) Room
Temp.
Pierce each potato with a fork 6 times around its sur-
face. Place potatoes around the edge of a paper-towel-
lined turntable. Do not cover. If additional time is need-
ed, continue to cook manually. Please let stand for 5
minutes in the oven after nishing to avoid burning.
SC-8
Frozen
entree
8~32 Oz
(225~900g)
Be careful when removing the lm cover after
cooking. Remove facing away from you to avoid
steam burns. If additional time is needed, continue
to cook manually. Cover the lm before cooking
and leave a
space near the edge of the container in order to let
the steam out. When buzzer sounds twice, cooking
time counts down. Press “STOP/ CANCEL” to
pause and open door to mix.
SENSOR COOK CHART
Sensor Reheat Menu
1) In standby state, put the food into the microwave oven. Press “SENSOR
REHEAT“, SC-1 is displayed.
2) Press “START/+30SEC.“ to start sensor reheat function with no need to set
time.
3) The sensor will sound twice when the steaming has emanated. The surplus
time will display, the buzzer will sound 5 beeps when nished and the oven
will turn back to the former state.
(41 F)
(41 F)
(-4 F)
5 degrees
(41 F)
minus 18
degrees
(-4 F)
minus 18
degrees
(-4 F)
“ “

EN-14
Note:
1) Food to be avoided in sensor reheating.
a. Bread and other dry food, such as biscuits and cake.
b. Raw or uncooked foods.
c. Beverage and frozen food.
2) The oven cannot cook automatically when the temperature of the oven
cavity is high.
3) The reheat food can be covered with the lid. And the lid must have
venthole to emanate the steam. Sealed utensils must not be used.
4) During sensor cooking process, please do not open the oven door or
press “STOP/CANCEL“ key. Otherwise, the sensor will make mistakes.
5) The sensor reheat has different requests for different food.
Casseroles- Add 3 to 4 tablespoons of water, cover with a lid or vented
plastic wrap. Stir when time appears in the display window.
Canned foods-Empty contents into casserole dish or serving bowl,
cover dish with lid or vented plastic wrap. After reheating, let stand for a
few minutes.
Plate of food- Arrange food on plate; top with butter, gravy, etc. Cover
with lid or vented plastic wrap. After reheating, let stand for a few
minutes.
11.MEMORY FUNCTION
(1) Press “MEMORY” to choose memory 1-3 procedure. The screen will
display 1,2,3.
(2) If the procedure has been set, press “START/+30SEC.“ to begin the
procedure. Only one or two stages can be set
(3) If the procedure has not been set, after nishing the setting, press
“MEMORY” once to save the procedure and turn back to the former
state. If press START/+30SEC , it will start cooking at once and
save the procedure too.
Example: To set the following procedure as the second memory, that is
memory 2. To cook the food with 80% microwave power for 3 minutes and
20 seconds.
The steps are as follow:
a. In waiting states, press “MEMORY” twice, stop pressing until the
screen displays “2”.
b. Press “COOK TIME“ once, then press “3”,”2”,”0” in order.
c. Press “POWER LEVEL“ once, ”PL10” displays, then press “8” and
“PL8” displays.
d. Press “MEMORY“ to save the setting and turn back to the waiting
state; If you press “START/+30SEC.“ the procedure will be saved and
operated as the memory2.
e. If the electricity is not cut off, the procedure will be saved all the time.
If it is, the procedure will need to be reset.
f. When you want to run the saved procedure, in waiting states, press
“ ” twice, screen displays “2”, then press “START/+30SEC.“
to start cooking.
Note:
Auto menu cannot be set in memory function.
“”
MEMORY

EN-15
12.MULTI-STAGE COOKING
At most 2 stages can be set for cooking. In multi-stage cooking, if one stage
is defrosting, then defrosting shall be placed at the rst stage automatically.
Note:
Auto menu cannot work in the multi-stage cooking.
Example: If you want to cook with 80% microwave power for 5 minutes + 60%
microwave power for 10 minutes. The cooking steps are as following:
a. Press “COOK TIME“ once, then press “5”,”0”,”0” to set the cooking
time;
b. Press “POWER LEVEL“ once, then press “8” to select 80% microwave
power.
c. Press “COOK TIME“once, then press “1”,”0”,”0”,”0” to set the cooking.
d. Press time; “POWER LEVEL“ once, then press “6” to select 60%
microwave power.
e. Press power. “START/+30SEC.“ to start cooking.
13.INQUIRING FUNCTION
In the microwave cooking state, press “POWER LEVEL“ to inquire microwave
power level, and the current microwave power will be displayed. After three
seconds, the oven will turn back to the previous state. In multi-stage state, the
inquiring way can be done the same way as above. In the microwave cooking
state, press “CLOCK“ to inquire the current time.
14.LOCK FUNCTION FOR CHILDREN
Lock: In waiting state, press “STOP/CANCEL“ for 3 seconds, there will be
a long “beep” denoting the entering into the child-lock state, and the lock
indicator will light. The screen will display the current time or 0:00.
Unlock: In locked state, press “STOP/CANCEL“ for 3 seconds, there will be a
long “beep” denoting that lock is released.
15.COOKING END REMINDING FUNCTION
When the cooking is over, the buzzer will sound 5 “beeps” to alert user the
cooking is nished.
16.Power Saving Mode
(1) In standby mode, press the STOP/CANCEL button once (less than 3 seconds
(2) In child-locked mode, press the “STOP/CANCEL“ once (for 3 seconds) and
release to enter the Power Saving Mode.
(3) Above operation is the only way to start the Energy Saver mode.
(4) The Power Saving mode works only if the door is closed.
17.OTHER SPECIFICATIONS
(1) In standby state, if the set clock digital tube displays current time, the icon
“:“ will ash; otherwise, it shows “0:00“.
(2) In setting function state, the screen displays corresponding setting.
(3) In working or pause state, the screen displays surplus cooking time.
(4) When the cooking nishes, the screen will display the current time.
Opening the door or pressing “STOP/CANCEL“ can make the oven enter
waiting state.
to avoid starting the child lock function) to enter the Power Saving mode.
“”

Troubleshooting
Check your problem by using the chart below and try the solutions for each problem. If the
microwave oven still does not work properly, contact the nearest authorized service center.
TROUBLE
Oven will not start
POSSIBLE CAUSE POSSIBLE REMEDY
a. Electrical cord for oven is
not plugged in.
b. Door is open.
c. Wrong operation is set.
a. Plug into the outlet.
b. Close the door and try
again.
c. Check instructions.
Arcing or sparking
a. Materials to be avoided in
microwave oven were
used.
b. The oven is operated when
empty.
c. Spilled food remains in the
cavity.
a. Use microwave-safe
cookware only.
b. Do not operate with oven
empty.
c. Clean cavity with wet towel.
Unevenly cooked
foods
a. Materials to be avoided in
microwave oven were
used.
b. Food is not defrosted
completely.
c. Cooking time, power level
is not suitble.
d. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Use correct cooking time,
power level.
d. Turn or stir food.
Overcooked foods Cooking time, power level is
not suitable. Use correct cooking time,
power level.
Undercooked foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Oven ventilation ports are
restricted.
d. Cooking time, power level is
not suitable.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Check to see that oven venti-
lation ports are not restricted.
d. Use correct cooking time,
power level.
Improper defrosting
a. Materials to be avoided in
microwave oven were used.
b. Cooking time, power level is
not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Use correct cooking time,
power level.
c. Turn or stir food.
Maintenance
EN-16

EN-17
ONE YEAR LIMITED WARRANTY
This product carries a warranty stating that it will be free from defects in material and
workmanship for a period of one year from the date of purchase. This warranty is valid
for the original retail purchaser from the date of initial retail purchase and is not
transferable. Keep your original sales receipt.
IMPORTANT:
If service is required during the warranty period, properly pack your unit. We
If additional assistance is needed, please contact
recommend using the original carton and packing materials.
customer assistance at:
Some states do not allow this exclusion
quential losses so the foregoing disclaimer may not
rights which may vary from state to state.
SAVE THIS FOR YOUR RECORDS
Made in China
apply to you. This warranty gives you specific legal rights, and you may also have other
expressly disclaims all responsibility for consequential damages orMidea America Corp
incidental losses caused by use of the appliance.
or limitation of incidental or conse
The serial number can be found on the back cabinet. We suggest that you record the
serial number of your unit in the space below for future reference
Model Number:_______________________
Serial Number:________________________
800-842-1289
Midea Am erica Corp
.
5 Sylvan Way,
Parsippany, NJ 07054
1. This warranty does not cover damages resulting from accident, misuse or abuse,
lack of reasonable care, the affixing of any attachments not provided with the
product, loss of parts, or subjecting the appliance to any but the specified
voltage. ( Read directions carefully. )
2. This warranty is void if this product is ever used for other than private household
purposes.
3. This warranty is void if this product is ever used outside of United State . s
