CaterKwik CaterCool CK0501 User manual

1
Dear Sir or Madam,
A BIG THANK YOU from all at CaterKwik and congratulations on purchasing your CaterCool bottle cooler.
We aim to bring you the best products at industry leading prices.
We expect that you will receive many years trouble free use from your cooler. However, if you have any questions or
suggestions on how we might improve any aspect of our CaterCool products or service then we would love to hear
from you. Please do not hesitate to call or email.
Yours sincerely from all the team at Caterkwik
01229 480001
[email protected]
BACK BAR
BOTTLE
COOLER
Contents
HOW TO USE………………………………. 2 – 3
SAFETY PRECAUTIONS………………. 4 - 6
CLEANING……………………………………….. 7
IN CASE OF THE FOLLOWING……………. 7
BEFORE REQUESTING SERVICE…………. 8
REQUIRED INFORMATION………………….. 8
INSTRUCTION MANUAL

2
The shelf height can be adjusted.
Arrange the shelves in accordance with the dimension of the items to be placed inside the cooler.
BEFORE USE
HOW TO USE
WAIT 5 MINUTESOR MORE BEFORE RE-STARTING
TEMPERATURE ADJUSTMENT
DRAIN TRAY
EFFICIENT USE
SHELF HEIGHT ADJUSTMENT
1. Remove shipping package, tape, etc. Also leave the doors open for ventilation.
2. The unit is cleaned before shipment. However, clean the compartment interior once after delivery.
3. Please insert the power supply plug into the wall outlet, single-phase to cat voltage.
4. Allow the unit to operate for about 1 hour to cool the compartment before placing items in the cooler.
Restarting the unit immediately after it has been turned off may cause fuses to blow and activate the circuit-breaker,
the compressor may be overloaded, and/or damage may occur.
Thermostat was adjusted using temperature at the factory. To adjust it, turn right for temperature inside the
cooler to go down. To raise the temperature, turn it left. Excessive refrigeration will increase electricity
consumption unnecessarily.
Defrosting is performed automatically and drain water is collected in the drain tray.
Water in the drain tray is evaporated automatically. It is recommended that you clean out your drain tray at
least once a day.
Please follow the below instruction, you could save energy.
To prevent cold air from escaping, open and close the door quickly and keep the door opened for as short a
time as possible.
Please install the unit in the place which is well-ventilated.
DRAIN TRAY
EFFICIENT USE

3
This bottle cooler employs a forced circulation of cold air system. If circulation of cold air is obstructed, the items will
not be adequately refrigerated. Pay attention to the following points:
Do not let items obstruct the cold air inlet and suction outlet.
Place items so that they do not protrude from the shelves. The gap between the shelves and the door is used
for circulation of cold air.
Place items evenly on all shelves.
Please do not display goods on the bottom. Please try to keep them on the shelves.
Operation
Control Panel
The control panel is located below the doors on the front of the appliance.
Turn On
1. Turn the power switch on.
2. Set the temperature to the desired setting (see below).
3. Close the door of bottle cooler.
4. Connect the bottle cooler to a mains power supply.
5. Turn the light switch on [I] or off [O] as required.
Set the Operating Temperature
1. Press the {set} button. The display will flash.
2. Press the {up arrow} or {down arrow} to display the required temperature.
3. Press the {set} button to store the temperature.
Manual Defrost
The bottle Cooler features an automatic defrost. However, should the appliance require an additional defrost period
press and hold the {defrost} button for 6 seconds.
Automatic defrost cycles are every 6 hours and last 20 minutes (factory defaults).
To stop the defrost press and hold the ‘defrost’ button for 6 seconds.
HOW TO USE
PLACING ITEMS IN THE BOTTLE COOLER
SETTING THE TEMPRATURE

4
SAFETY PRECAUTIONS
To ensure proper use, please thoroughly study these SAFETY PRECAUTIONS before operating the unit.
The purpose of the safety precautions in this manual is to ensure safe and correct use of the unit to minimize risks
that could cause serious damage to either the machine or persons operating it. The safety precautions are divided
into warnings and cautions.
Improper handling of the unit could lead to death or serious injuries, these are listed under the ‘WARNING’ tab.
However, the cases listed ‘CAUTION’ heading could also lead to serious injuries. To ensure your safety, adhere
strictly to both types of safety precautions.
After reading the instruction manual, store it in a safe and easily accessed place where you can easily go back to it
if needed.
PRECAUTIONS FOR INSTALLATION
WARNING
Installation should be performed only be the dealer or a qualified expert, attempting to install the unit yourself
could result in water leakage, refrigerant leakage, electrical shock, or a fire.
PRECAUTIONS FOR USE
All repairs, disassembly and modifications should
be performed only by qualified technicians.
Attempting to perform this yourself, could result in
a fire, malfunction or an injury.
Never splash water directly onto the product
or wash with water as a short circuit and
electrical leakage could result.
Never put flammable or volatile
substances into the unit as explosions or
fires could result.
Do not damage, modify, excessively bend, strain,
twist or bundle up the power cord. Also, placing
heavy objects on the power cord or squeezing it
into a tight space could result in damage to the
cord, which may lead to an electrical shock or a
fire.
Use a dedicated wall outlet. Do not use
extensions cords or convenience receptacles as
this could result in overheating, which could lead
to fires or an electrical shock.
Never use flammable spray cans or leave
flammable substances near the unit. Sparks from
electrical switches could result in the flammable
substance catching fire or exploding.

5
SAFETY PRECAUTIONS
The cooler is intended for storage and display
of beer and beverages for sale. Do not use for
other purposes than the intended as this could
adversely affect items placed in the unit.
Never attempt to insert fingers, sticks, etc. into the
cold air suction outlet. A circulation fan is rotating
at high speed inside the outlet. Injury, electrical
shock and improper operation could result.
For indoor use only. Using the unit in a location
exposed to rain could result in electrical
leakage and electrical shock.
Never place heavy objects or items containing
water on top of the unit. Objects could fall down
and cause injury and spilled water could
deteriorate the insulation of electrical components.
Install the unit in a location where the floor is
sturdy enough to support the load of the unit, if
the floor is not sturdy enough or instillation is
incorrectly performed, the unit could tip over
and falling shelves and products could cause
personal injury.
If you find gas leakage, please don’t touch the
cooler, close all gas valves and open the door
for ventilation. Gas leakage could cause an
explosion or start a fire.
Store the unit in a location where it is not
exposed to rain. Using a unit that has been
exposed to rain could result in electrical
leakage and electrical shock.
Place the unit away from hot air sources, the
cooling performance is reduced if the unit is
place near heat sources such as stoves, or if it
exposed to direct sunlight.
Leave disassembly and disposal of the unit to
qualified experts.
Should the unit need temporary storage, make
sure not to store the unit in a location where
children play and take precautions so that the
door cannot be completely closed. This will
minimize the risk that a child becomes trapped
inside the compartment.

6
SAFETY PRECAUTIONS
Please make sure there is more than 10cm between the
wall and the cooler. If there is no space, the cooling
capacity can drop.
If installation in a damp location is
unavoidable, also install an electrical leakage
circuit breaker. If there is no electrical leakage
breaker, this may result in electric shock.
Never hang from the door or climb onto the
unit. The unit could tip over and fall and cause
the glass to smash or injure someone.
Disconnect the power cord plug from the wall
outlet before moving the unit and make sure
that the power cord is not damaged during
transport. A damaged power cord could result
in electrical shock and/or a fire.
Grasp the handle when closing the door.
Holding at other positions could result in you
trapping your fingers.
Do not apply excessive force to the glass
surfaces as the glass could break/smash and
cause injury to person/persons.
When disconnecting the power cord plug from
the wall outlet, hold at the plug main body,
close to the outlet. Pulling on the cord could
cause the wire to break, possibly resulting in
overheating and a fire.
Make sure that the unit does not tip over or fall
when it is moved. A falling unit could cause
serious injury.
Do not throw items onto the shelves and do not
place items totalling more than 30Kg on each
shelf. The shelf could fall, causing injury or break
the shelf itself.
Be sure to attach and secure shelves correctly.
An improperly attacked shelf could fall down
and cause injury or break the shelf.

7
AFTER CLEANING
POWER FAILURE
WHEN NOT USED FOR A LONG PERIOD
TRANSPORTATION
TEMPORARY STORAGE
Clean the cooler regularly to keep it clean at all times.
Never use polishing powder, soap powder, benzene, oil or hot water as these will damage the painting and
plastic components.
To ensure the safety, perform the following checks after cleaning the appliance.
Is the power cord firmly inserted into a dedicated wall outlet? Confirm that the plug is not abnormally hot.
Check the power cord for cracks and damage. Should the slightest irregularity be observed, contact the
dealer from whom you purchased this unit or our customer service team on 01229 480001.
Keep opening and closing the door to a minimum.
Avoid placing new items in the cooler as this will raise the temperature inside the compartment.
Remove all items from the compartment and disconnect the power cord plug from the wall outlet.
Clean the compartment interior and wipe away all water.
To prevent mould formation and bad smell, leave the door open to dry the compartment completely.
Disconnect the power cord plug from the wall outlet.
When moving the cooler, make sure that the feet do not damage the power cord.
Do not let the feet hit against floor steps, thresholds, etc.
Affix a piece of wood, etc. between the door and the main unit to prevent complete closing of the door.
Make sure not to store the unused cooler at a location where children play. Should a child enter the compartment
and the door is closed, the child may not be able to open the door from the inside.
WARNING: Do not splash water directly onto the cooler and do not wash the appliance with water.
Short –circuit and electrical shock could result.
IN CASE OF THE FOLLOWING

8
In the case that you need assistance, please contact our service team on
01229 480001, or E-mail your problem to [email protected].uk
1. Nature of malfunction (as accurately as possible).
2. Product number/serial number (inscribed on the badge).
3. Your name, address & contact details.
4. Year and date of purchase.
BEFORE REQUESTING SERVICE
REQUIRED INFORMATION
Is the power supply interrupted?
Is the power cord plug disconnected from the wall outlet?
Are the shop’s power fuses blown and/or the circuit breaker activated?
Is the temperature setting appropriate?
Are items obstructing the cold air inlet and suction outlet?
Are stored items packed too tight?
Is the door open or is it opened and closed frequently?
Is the condenser clogged?
Are all the feet in firm contact with the floor?
Is the rear panel of the cooler contacting the wall or other objects?
Is anything in contact with the cooler? E.g. boxes, mops, brushes etc.
You may find that on hot and humid days there may be times where a lot of
condensation will condense on the exterior and door of the cooler, this is
completely normal, clean away the condensation with a cloth.
